wfet2000s电能量数据采集终端使用说明书v1311产品简介wfet2000s是长沙威胜信息技术有限公司在多年专业ertu研发应用的基础上精心研制而成的一款高性能电能量数据采集终端其硬件平台采用高端32位嵌入式risccpuarm9内核软件平台采用实时嵌入式linux操作系统结合现代主流通信技术使终端具有采集精度高可靠性好存储容量大开放性好操作简单运行稳定维护方便等特点
◆模块化设计思想
1〉终端硬件模块化：数据通信部件模块化。数据通信模块可以在不更换终端主体的情况下方便更换，支持热插拔功能。
2〉终端软件模块化：终端应用软件采用模块化编程方式，各个应用模块独立运行，不相互影响，可以监控每个模块的运行状况，当该模块运行发生异常，可以自动恢复，从而保证了终端软件运行的可靠性。终端应用软件对拨号MODEM/专线MODEM/GSM模块自动识别，自动适应。
在安装本终端前，请先仔细阅读本使用说明书。
图1-1 WFET-2000S电能量数据采集终端外形
图1-2系统拓扑结构图
1.2
如图1-3，终端主要由交/直流双电源切换及保护电路、高性能开关电源、主处理器模块、大容量Flash存储器、大画面液晶显示器、键盘、数据通信模块及保护电路组成。通过RS-485接口采集电表数据，经主处理器分析、处理后保存在电子盘中，并通过PSTN、GSM网络、载波、微波、光纤、网络等远传通道上传给主站。
第2路：AC150V～AC285V（单相）或DC150V～DC375V。
◆电磁兼容性能
抑制高频干扰、静电放电、快速瞬变干扰、雷击浪涌等指标都达到4级标准。
◆环境条件
1〉ห้องสมุดไป่ตู้作环境
正常工作温度：-25℃～+60℃，极限工作温度：-30℃～+65℃；相对湿度：10%～100%；大气压：66～106kPa。
图1-3工作原理示意图
1.3
1.3.1
◆数据采集
通过抄表RS-485接口可定时采集电表上的各项数据并存储，也可以人工随机查询并显示。
◆参数设置
可以当地或远程设置表计档案和终端运行参数。
◆数据存储
终端配置有大容量Flash存储器（标准配置32MB）可将20块电表、时间间隔15分钟的所有数据（电量、需量、瞬时量、失压纪录、报警、电压合格率等）保存30天以上，且在断电情况下数据保存时间≥10年。
2〉存储环境
存储温度：-35℃~70℃，相对湿度≤50%。
◆整机功耗
正常工作时，整机功耗≤5W。
◆MTBF
MTBF≥100000小时。
◆终端结构
壁挂式结构，尺寸为：长×宽×高，270mm×183mm×90mm；密封式设计，ABS防水防紫外线阻燃材料，达到IP54防护标准。
2
2.1
终端为壁挂式安装，可直接安装在配电表屏上，外型尺寸为270×183×90mm（长×宽×高），如图2-1所示。
1〉接线颜色区分
当只有一路RS-485接线时，该方法最简单易行。
◆多种先进技术的有效融合
1〉采用稳定可靠的嵌入式10BaseT（10Mbps）以太网、拨号话音MODEM、专线MODEM和先进的GSM无线通信技术。
2〉采用大容量FLASH数据存储器（FLASH存储器标准配置32MB，可选配64MB或128MB），从而可以保证终端存储很长时间的历史数据。
3〉采用高精度日历时钟，时钟误差≤1s/d，断电后可连续运行10年。
尊敬的用户：
衷心感谢您选择长沙威胜信息技术有限公司的产品。
我们一直致力于科技创新，以信息技术为社会创造价值，努力以先进的技术、可靠的产品、一流的服务，更高、更快、更优地满足客户对信息应用产品的需求。
本使用说明书主要向您介绍我公司生产的WFET-2000S电能量数据采集终端的安装、接线与调试等内容。在应用中如果您有任何问题和要求，或需要相关的技术支持，可以通过下面的方式与我们联系，我们将及时给予回应。
◆安全功能
具备密码设置和权限管理，防止非法操作。
1.3.2
◆平台化设计理念
1〉采用高性能32位嵌入式RISC CPU（ARM9内核）—S3C2410（处理速度为203MIPS，即每秒可运行203,000,000条指令）硬件平台。
2〉采用稳定可靠的实时嵌入式LINUX操作系统软件平台。
平台化设计是终端实现各种复杂功能的基础，并具有优异的扩展性和伸缩性，能够长期满足客户潜在需求，有效保护客户投资。
终端抄表RS-485接口A端（即：RS-485标准的“＋”极）与电表RS-485接口A（A +）端相连；终端抄表RS-485接口B端（即：RS-485标准的“－”极）与电表RS-485接口B（A－）端相连。RS-485通信线的屏蔽层按施工要求必须单端接地。
注意A（A+）与B（A-）端的区分，可采用以下几种方法来区别：
1〉标准配置
1路10BaseT网卡（10Mbps），RJ45接口；
1路RS-485（9600bps，此为出厂默认配置，但也可配置为抄表口）；
1路拨号V.92MODEM（56kbps）。
2〉增选配置
1路专线MODEM（1200bps）；
1路GSM无线MODEM（此时不能再配拨号和专线MODEM）。
◆电表通信接口
4〉将终端上电，开始参数设置和调试工作。
注意：
为了防止非法开启终端，终端出厂前已打有2个铅封，一个是终端上部的合盖铅封，另一个是终端右侧的面盖铅封，没有本公司正式授权，任何人不许拆开这两个铅封。另外，终端端盖上还有两个安装铅封的孔位，终端接线并调试完毕后，电力局（公司）可以将端盖上这两个铅封打上以保护其合法权利。
图2-1终端外型尺寸示意图
1〉在电表屏上选择易于操作的位置，对照终端上挂钩中间位置用Φ7mm钻头钻一个孔。
2〉将终端垂直悬挂在挂钩螺钉上，并拧紧固定螺钉。注意保证挂钩与挂钩螺钉、挂钩螺钉与保护地接触良好。为了使终端免受雷击的损坏，终端的防雷保护地端子必须通过随终端所配的接地线可靠地接保护地。终端配1路话音MODEM或1路话音MODEM +1路专线MODEM时，接线示意图见图2-2所示；终端配两路话音MODEM时，接线示意图见图2-3所示。另外，在雷电高发地区，终端通信模块必须再外接防雷设备进行进一步加强保护，如选配本公司的电话防雷器和专线防雷器，接线方式可参考相应的防雷器。
WFET-2000S终端遵循电力行业《DL/T 743-2001电能量远方终端》和《DL/T 698-1999低压电力用户集中抄表系统技术条件》等标准。本公司终端拥有国家计量器具生产许可证，在电磁兼容性能和远程连接的安全认证等方面采取了多种防护措施，可以有效抗击各种干扰，确保终端运行可靠，数据准确安全，可以满足电量计量计费的严格要求，是建立电力市场各类计量计费系统理想的配套产品。
