日立USP存储架构和管理(原厂资料)

Module Objectives
Upon completion of this module, the learner will be able to:
– Identify and describe key business and operational features of the Hitachi TagmaStore™ Universal Storage Platform and Network Storage Controller – Identify and describe the Universal Storage Platform and Network Storage Controller architecture – Describe Universal Storage Platform and Network Storage Controller architecture’s use of: FED/BED Cache and Shared Memory – Describe Universal Storage Platform and Network Storage Controller Parity Groups and Emulation. – Describe Universal Storage Platform and Network Storage Controller LDEV’s and LUN mapping
Thunder AMS1000 TagmaStore AMS500 TagmaStore AMS200
TagmaStore WMS100
Scalability
© 2005 Hitachi Data Systems Principles of Operation
4
Introduction
The Hardware Implementation Requirement
DKA (BED) Option
0 Fibre Port Number Fibre Port 00 Fibre Loop 01 62 63
1
DKA (CL1) 2 3 4 5 6 00 01 62 63 00 01 62 63
The DKA controls data transfer between the hard disk and the cache memory
Hitachi TagmaStore® Universal Storage Platform and Network Storage Controller Architecture and Administration
HDS Academy
Principles of Operation
© 2005 Hitachi Data Systems
E L S P
F M P AA
G P U AB
P N V AC
Principles of Operation
16
RAID-6: Striping with Dual Parity Drives
RAID 6
6D + 2P RAID 6+ Configuration
SAN
Internal Storage
DKU DKC DKU
Front-end FC connection
9900 9900V 9500V
External Storage
© 2005 Hitachi Data Systems Principles of Operation
3
Introduction
© 2005 Hitachi Data Systems
Principles of Operation
6
Universal Star Network - Data Paths
Connect to Host CPU
Logic Box
CHA
CHA
CSW CSW CSW CACHE
Data Path Cache Data Path (CHSN) Shared Data Path (SHSN)
CSW CSW CSW CSW
CSW CSW CSW SM
DKA
FSW PCBS
DKA
HDDs
HDD Box
Data Path Back end Fiber Path
© 2005 Hitachi Data Systems
Principles of Operation
7
Clusters
Dual Clusters
7
00 DKA Pair DKA (CL2) 01 62 63
0
1 2 3 4 5 00 01 62 63 00 01 62 63
6
7 00 01 62 63
00
01
62
63
© 2005 Hitachi Data Systems
Principles of Operation
10
Network Storage Controller Back-End
The hardware is split into two separate clusters. Each has separate power and separate logic. Features consist of two logic cards one installed into each cluster
4D + 4D RAID 1+ Configuration
A
E’ I M
A’
E I’ M’
B
F’ J N
B’
F J’ N’
C
G’ K O
C’
G K’ O’
D
H L P
D’
H’ L’ P’
Principles of Operation
© 2005 Hitachi Data Systems
15
Universal Storage Platform RAID5
© 2005 Hitachi Data Systems Principles of Operation
8
Universal Storage Platform Back-End
Back-End
© 2005 Hitachi Data Systems
Principles of Operation
9
Universal Storage Platform Back-End
Universal Storage Platform: 48 HDD Network Storage Controller: 60 HDD
© 2005 Hitachi Data Systems
Universal Storage Platform: 1,152 HDD Network Storage Controller: 240 HDD
Hitachi TagmaStore Family Position
– All models compatible for tiered storage
Universal Storage Platform USP Network Storage Controller NSC55
Performance
PBC PBC PBC
PBC
Port Failure
HDD Failure
PBC: Port Bypass circuit
© 2005 Hitachi Data Systems
Principles of Operation
13
RAID
Supported RAID levels
– Universal Storage Platform RAID 1(2D+2D)/(4D+4D) RAID 5(3D+1P)/(7D+1P) RAID 6(6D+2P) – Network Storage Controller RAID 1(2D+2D) RAID 5(3D+1P) RAID 6(6D+2P)
Disks
© 2005 Hitachi Data Systems Principles of Operation
5
Introduction
The Data Storage Subsystem
– – – – – – Channel Adapters (CHA/FED) Cache Memory Control (Shared) Memory Cache Switch Disk Adapters (DKA/BED) Hard Disk Drives (HDDs)
Host Server with one or more HBAs Universal Storage Platform/Network Storage Controller
• The subsystem is required to present disk space, as LUNs to many servers • The hardware must provide data resilience and be fault tolerant • It also needs to be fast
© 2005 Hitachi Data Systems
Principles of Operation
14
Universal Storage Platform RAID1
RAID 1
2D + 2D RAID 1+ Configuration
A E’ G I A’ E G’ I’ B F’ H J B’ F H’ J’
