A Formal Semantics on Net Delay in Verilog-HDL

A Formal Semantics on Net Delay in Verilog-HDLHisashi Sasaki. Toshiba Corp., Semiconductor Company.STE Building 1000-1, Kasama-cho, Sakae-ku, Yokohama 247-8585, Japan,hisashi3.sasaki@toshiba.co.jpAbstractThis paper presents a formal semantics for the wire data structure and behavior such as continuous assignment and inertial delay in Verilog-HDL. Its language-interoperability also clarifies the background why VHDL experts so frequently fall in the misinterpretation on the cancellation of scheduled events regarding on the wire concept in Verilog-HDL.1. IntroductionThere are many works on formal semantics for VHDL. Their primary purpose is to provide the theoretical framework to promote the understanding of the semantics. These works have been not recognized as practical tools yet. Recently a successful application of formal approach to define the analog and mixed-signal extension are known to validate the semantic consistency of the proposed standard even during its development process, and resulted in successful contribution to standardization activity [3,4,5]. Now the formal specification is becoming widely accepted in EDA community and strongly recognized as a new tool in defining languages, for example, SLDL regards it as a prerequisite technical item to be considered.On the other hand, a few works are known for Verilog-HDL. The Berge’s book [1] gives the first comprehensive discussion to compare VHDL and Verilog-HDL. However, it is descriptive explanation not based on a formal method. Gordon’s appeal [6] is the first declaration that formal method is necessary for Verilog-HDL too. At that time, formal semantics is not explicitly established, and their work is still in progress at present. Most of today’s discussions [11,12] still remains based on non-formal method. Borrione’s work [7] is the first successful paper by formal approach. But their discussion is limited to synchronous design and their aim is to provide the synthesis semantics, not simulation one. Sasaki [8], Lasseter [10,14] and Li [13] independently developed formal simulation semantics by Abstract State Machine (ASM), operational semantics and Interval Temporal Logic (ITL) respectively. Lasseter’s and Li's works focused only on Verilog-HDL. Sasaki’s work provided the common foundation for VHDL and Verilog-HDL which admits the discussion on interoperability issues between the both. In this paper, we will enhance our semantic analysis for Verilog-HDL by adding the formal formulation on net delay mechanism.This paper deeply enhances the discussion proposed by Stewart [9]. Our discussion not only provides the direct description of semantic behavior, but also reveals the background why VHDL experts fall in the misinterpretation mentioned in his paper.2. Preliminary backgroundIn the previous Sasaki’s work [8], the following item are focused to establish the clarification of delicate differences between the two languages.(1) delay mechanism: There are not only the distinctiontransport delay and inertial delay but also the delicate differences between the concept of transport delay in VHDL and modified transport delay and pure transport delay in Verilog-HDL.(2) waveform: Only single element is admissible inVerilog-HDL, but multiple-element is admissible in VHDL. The successive assignments of Verilog-HDL can generate the multiple waveform (equivalent counterpart supported by VHDL) effectively. (3) thread of control: It controls the flow of control tosuspend the user-defined process in VHDL and always block in Verilog-HDL, and triggers the simulation kernels. The blocking property of Verilog-HDL assignment is expressed by the semantic rule, in which the suspended flag is set to true to show the suspension, the timeout data is set by computing from the delay specification, and the activation flag of driver is set true if requested. On the other hand, non-blocking does not include such settings.(4) overwrite property of signal driver: Verilog-HDLdoes not remove the events scheduled by the previous assignment. VHDL removes all the events scheduled by the previous assignment.In order to assure to establish the common foundation for the both languages, we intentionally ignored the delicate differences in the two simulation cycles.(1) The stratification mechanism of Verilog-HDL isignored. The separated treatment of non-blocking assignments and blocking assignment is replaced by the formulation using the thread of control.(2) non-deterministic behavior of Verilog-HDLconcurrent process. LRM explicitly requests the order preservation that the event must be scheduled in the simulation queue in accordance with the syntactic order when there are multiple assignments for the same target in the same always block (the same concurrent process).(3) resolution: Verilog-HDL has two type of signals:wire and register. Wires should be resolved by the signal resolution mechanism such as wired-or or wired-and. But registers should modify the driver by adding the new event. Therefor, the reuse of resolution mechanism for VHDL is applicable for wires, not for registers.(4) In the LRM for Verilog-HDL, there is no concept ofsignal driver. However, the introduction of the concept is not harmful but useful. The flat (uniform) treatment of all events for signals could be organized as the driver just like as the concept VHDL has adopted.By ignoring the above differences of the two simulation cycles, we can reuse both the semantic functions and the simulation cycle as the common foundations, which are already developed by ASM [2].3. The problem: misunderstanding on net delayThe task to get accurate understanding on net delay is not easy from reading LRM in Verilog-HDL. For example, syntax does not always reflect the semantic classification of objects: the two delay3 options have different meanings in the following BNF rule (FIG.1): all other wire refers net delay data found in net declaration rather globally. When we generates a driver, we refers a delay data found in continuous assignment. Its reference is confined in that driver locally.Although this fact could be read carefully from the chapter 6.1.3 LRM (FIG.2), the accurate understanding for the propagation of signal change seems not so easy.This descriptive explanation may cause the wrong interpretation about net delay. Let illustrate such semantic fault by using the following stimulus and net delay description [9] (FIG.3, FIG.4).A wrong interpretation (FIG.5, FIG.6): At the current time Tc=30, the waveform r2=0 (called w1) is scheduled at Tc+30+10 = 70. Next, at the current time Tc=30+25=55, the waveform r1=0 (called w2) is scheduled at Tc+20+10 = 85. At the same time, the effect by r1 is directly propagated to w, the waveform w2should overwrite the waveform w1. Therefore, the value of w is ‘0’ at the time 85, and is keeping its old value ‘1’until that time 85. That causes the cancellation of the event of r2 (the waveform w1).This wrong interpretation suggests that we may believe that cancellation of all previous events by the new assignment removes the events more excessively than one must expect. The correct interpretation (FIG.7, FIG.8) is based on the resolution mechanism on wires. The waveform r2=0 is scheduled at the time 30+30=60, and the waveform r1=0 is schedule at the time 55+20=75.Next the waveform is resolved, and then the result is delayed by 10 cycles (net delay). Finally, w = ‘x’ at the time 60+10=70, w=”0” at the time 75+10=85.This paper will extend my previous work [8] by augmenting the treatment for net delay mechanism for continuous assignment. The Stewart’s discussion [9] is the first proposal pointing out the insufficiency of the definition on the net delay. His solution was the introduction of the new function “combine2” (for example, see FIG.9) to explicitly describe the signal resolution.The Stewart’s function “combine2” explains thesemantics via the syntactic rewriting of Verilog-HDL source code, and therefore it is indirect semantics. If we want to know what is the differences between the two descriptions (compare FIG.4 with FIG.10 and FIG.11) including the warning or error interpretation, the immediate answer is not found by the combine2. Anyway, it is disadvantage that he could not mention the semantics for a continuous assignment.4. Formal semantics for net delayOn the other hand, our approach will directly specify the semantic behavior by the ASM description. It is our advantage, for example, to explicitly reveal the relationship between the data specified by net delay declaration and events scheduling for signal driver. As the simulation model is common to the both languages, note that the concept of net delay is defined too in VHDL simultaneously (however, syntax is not proposed yet.). The target semantics is implemented by the equivalent always block in FIG.12.This definition is similar to the definition for the concurrent signal assignment in VHDL, which reflects the nature of iterative (continuous) evaluation: whenever a signal changes, a new event is scheduled. In fact, this definition is not mentioned in the LRM. However, we will intentionally introduce such an artificial definition via the sequential counterpart for continuous assignment, which is called “sequential continuous assignment”. Its semantic rule is given as FIG.13.The semantic functions and semantic objects are summarized as follows. These are almost originally formulated by [2], and a few of them are enhanced by [8].- driver(P, S): the driver of signal S in process P. It is the sequence of <value, time> - a pair to represent the scheduled events.- active(d) : the flag to show whether the drive d is active or not. The simulation kernel to activate the computation process to set the driving value, the effective value and the current value refers it.- SingleWaveform: the waveform to be newly appended to a driver. Its value part is computed from the evaluation of the expression Expr. Note that the renaming of this semantic object from "Waveform" (VHDL) to "SingleWaveform" (Verilog-HDL). This suggests that only single element is admissible as waveform in Verilog-HDL.- d |> T : the relative future part of the driver d with respect to the time T. This is an enhanced semantic function in order to insert a SingleWaveform to driver.- Time’ : the absolute time value summated from the specified assignment delay Time, the net delay netDelay(S) and the current simulation time Tc.- tail (d) : the tail part of the driver d as a list.- d |< T : the relative past part of the driver d with respect to the time T.- first (d) : the first part of the driver d as a list.- ^ : the concatenation operator to append waveforms. To implement a "transport delay" mechanism, it is sufficient (the reject function is not necessary.) - reject : the function to implement “inertial delay”mechanism by removing the small-width pulses such as glitch. The combination of waveform append, trimming of waveform by first, and the relative past part of the driver with this function reject will produce the final rejected waveform.The net delay data is stored in the variable netDelay(S) whose value is set by the instance of net declaration and the data is possible to be shared globally by referring S in any other continuous assignment. This shows the explicit relation between the net declaration and the event scheduling in continuous assignment. To represent the event insertion, the two functions d | > T (future part) and d |< T (past part) are used. If the specified delay time is zero, then the drive is set “active” immediately. This is implemented by using the active flag active(driver(Process, S)). The simulation kernel provides the resolution mechanism with respect to the drivers.We can develop a further semantic discussion. For instance, FIG.14 describes the semantic rule for VHDL transport delay. Using this rule, we can recognize precisely semantic difference between Verilog-HDL and VHDL. (1) It cancels the future part of waveform by replacing all the previous waveform by newly generated “Waveform” specified in that assignment. On the other hand, FIG.13 keeps the future part of the driver by appending it directly. (2) Here the transport delay mechanism is implemented as the concatenation of the value of driver at the time (Tc+Time1) and “Waveform”. FIG.13 uses the function "reject" which shows the inertial delay mechanism. (3) Additionally, we can also easily identify the differences from the two transport delay mechanisms of Verilog-HDL by [8]. The pure transport delay for continuos assignment copies the driver itself, not appending the waveform. The modified transportdelay for assignments (blocking/non-blocking) keeps the future parts. (4) There is no netDelay(S) part in the rule for registers. This shows the difference between nets and registers in Verilog-HDL. Thus, the precise semantic comparisons have achieved.Finally, we should discuss the background why the misinterpretation mentioned by Stewart [9] was taken. (1) In Verilog-HDL, the cancellation of event should not be occurred for registers. On the contrary, in VHDL, an event may be cancelled by the future events scheduled by other signal assignment. At first study, we cannot determine which mechanism is chosen for wires. (2) As there is no concept for “sequential continuous assignment” in the LRM, the propagation of event is not well formulated. By these fact (1) and (2), the interaction between the propagation mechanism and the resolution mechanism is not well formulated by the descriptive explanation in the LRM.In the meta-position of language understanding, by the above discussion, we have showed why such a misinterpretation is popular. A Verilog-HDL expert, who only has learned Verilog-HDL, cannot think about the cancellation of scheduled event. On the other hand, a VHDL expert, who only has learned VHDL, implicitly assumes the cancellation. When a VHDL expert tries to learn Verilog-HDL, as both languages seem to be very similar, the difference is not recognized. A Verilog-HDL expert may not give the immediate correction for VHDL expert's misinterpretation because the cancellation is out of reach of his think. Such a recognition gap was bridged by the interoperable property of our semantic model. 5. SummaryAs a conclusion, a formal semantic analysis for Verilog-HDL and VHDL is enhanced on net delay mechanism in order to give the common simulation model especially focusing on signal scheduling mechanism. Based on this model, we have also clarified the background why the semantic misinterpretation is so popular for VHDL experts. Our semantics is expected to become a coherent first step for a future semantic interoperability analysis on multi-semantic-domain such as Verilog-AMS and VHDL-AMS.References> @ J-M. Berge et al, chapter 9, Verilog and VHDL, in VHDL Designer’s Reference, pp.231-317, Kluwer Academic Publishers, 1992.[2] E gon Boerger et al., A Formal Definition of anAbstract VHDL’93 Simulator by EA-Machines, in Formal Semantics for VHDL, pp.107-139, Carlos D.Kloos, et al. (Editors) “Formal Semantics for VHDL”Kluwer Academic Publishers, 1995./gasm/hardware.htm#vhdl [3] H isashi Sasaki, et al., Semantic Validation of VHDL-AMS by Abstract State Machine, pp.61-68, IEEE/VIUF BMAS97. October 1997.http://katayama-www.cs.titech.ac.jp/~sasaki/vhdl_ams/[4] T akeshi Sasaki, et al., Semantic Analysis of VHDL-AMS by Attribute Grammar, FDL98. September 1998.[5] T om Kazmierski, A formal description of VHDL-AMS analogue systems, DATE98, pp. 916-920. [6] M ike Gordon, The Semantic Challenge of Verilog-HDL, LICS’95, 1995./users/mjcg/[7] D ominique Borrione, et al., An approach to Verilog-VHDL interoperability for synchronous designs, CHARME’97. October 1997. http://www-tima-vds.imag.fr/Publications/Charme97.ps[8] H isashi Sasaki, A Formal Semantics for Verilog-VHDL Simulation Interoperability by Abstract State Machine, DATE99, pp. 353-357.[9] D aryl Stewart, Combining Verilog Signals in Nets,May 13, 1997. /users/ [10] J ohn Fiskio-Lasseter, A Formal Description ofBehavioral Verilog Based on Axiomatic Semantics.Tech. Rep. TR-98-04, Univ. of Oregon. 1998./~johnfl/thesis/[11] J ohn Willis et al., Verilog: Dialect of VHDL?, VIUFSpring 1996.[12] D .J. Smith, VHDL & Verilog Compared &Contrasted – Plus Modeled Example Written in VHDL, Verilog and C. DAC 1996.[13] X iaoshan Li, Formal Semantics of Verilog HDL,FDL99, August 1999. (to appear)[14] J ohn Fiskio-Lasseter, Amr Sabry. Putting OperationalTechniques to the Test: A syntactic Theory for Behavioral Verilog./~sabry/papers/index.html。
