诺瓦科技LED透明屏接收卡A4参数参考说明书英文版
诺瓦科技LED显示屏接收卡MRV365规格书英文版
SpecificationsReceiving Card MRV365Product images provided in this file are for reference only , and the actual products shall prevail.Rev2.1.1NS110100111XI 'AN NOVA S TAR T E C H C O .,L T D.OverviewNova M3 MRV365 is the advance model of Nova receiving card. It is compatible with all functions of MRV320, and increasing the MOM (Memory on Module) interface.Features1) Single card outputs 16-group of RGBR 'data;2) Single card outputs 20-group of RGB data;3) Single card outputs 64-group of serial data; 4) Single card supports resolution of 256x226； 5) 1 relay control; 6) MOM can store calibration coefficients and the LED module information; 7) Configuration file readback; 8) Temperature monitoring; 9) Ethernet cable communication status detection; 10) Power supply voltage detection;11) Pixel-by-pixel brightness and chromaticity calibration;12) Brightness and chromaticity calibration coefficients for each LED; 13) Pre-store picture setting; 14) Able to connect monitoring card.XI 'A N N O VA S T A R T E C H C O .,L T D.Output interface definitionUnder all the three different working modes of it, two 50P interfaces can output different data, and only one common program and software are required. No customized program is needed. Interfaces are defined as follows:1) 16-group data modeSupporting 16-group of RGBR 'parallel data, defined as follows:Virtual R signal in the last data group of each 50pin hub is decodingsignal E at 1/32 scan mode.X I 'AN NOVA S TAR T E C HCO .,L T D.2) 20-group parallel data modeSupporting 20 sets of parallel data, defined as follows:XI 'A N N O VA S T A R T E C HCO3) 64-group serial data modeSupporting 64 sets of serial data, defined as follows:Under serial mode, there are 64 data cables totally. Each cable can drive one LED bar independently.XI 'A N N O V A S T A R T EIn case of horizontal LED bar, the default is, Data1 drives the first row from the top, and Data64 drives the 64th row. (front view).In case of vertical LED bar, the default is, Data1 drives the first column of from the left, and Data64 drives the 64th column. (front view).Thickness of the board is about 1.6mm. Overall thickness (board thickness ＋thickness of the components on front and backside) is about 30mm.RELAY:Unit: mmXI 'AN NOVA S TAR T E C HCO .,L T D.Note: Product images provided in this file are for reference only, and the actualproducts shall prevail.J4（MOM interface ）defintion ：J9 definition （Indicator Light Socket ）J10 definition （Indicator Socket ）：S T A R T E C HD.AppendixSerial data decoding circuit：X I'A NN OV AS TA RT EC HC O.,L TD.。
诺瓦科技LED显示屏接收卡MRV210-7规格书英文版
SpecificationsReceiving Card MRV210-7Product images provided in this file are for reference only , and the actual products shall prevail.Rev1.0.1NS110100261XI 'AN NOVA S TAR T E C H C O .,L T D.FeaturesMRV210 is the receiving card with 24-group data mode of Nova. It has the following features:1) Single card outputs 16-group of RGBR 'data; 2) Single card outputs 24-group of RGB data; 3) Single card outputs 20-group of RGB data; 4) Single card outputs 64-group of serial data; 5) Single card supported resolution 256x226; 6) Configuration file read back; 7) Temperature monitoring;8) Ethernet cable communication status detection; 9) Power supply voltage detection;10) Pixel-by-pixel brightness and chromaticity calibration andbrightness and chromaticity calibration coefficients for each LED; 11) Comply with EU RoHs standard; 12) Comply with EU CE-EMC standard.XI 'A N N OV A S T A R T E C HCO .,L T D.Output Interface DefinitionUnder all the four different working modes of it, four 26P interfaces can output different data. Interfaces are defined as follows: 1) 16-group data mode （With virtual output ）Supporting 16-group of RGBR 'parallel data, defined as follows:It support 1/32 scan mode in 16-group data mode, and R4B ，R8B ，R12B ，R16B are decoding signal E.Pin 9 is decoding signal Ctrl below 1/16 scan mode(contain 1/16 scan). Pin 8 is decodingXI 'AN NOVA S TAR T E C HCO .,L T D.X I'A NN OV AS TA R2) 20-group data modeSupporting 20 sets of parallel data, defined as follows:Pin9 is Ctrl signal in 1/16 scan and below, and Pin 8 is decoding Ctrl signal in 1/8 scan andS T A R T E C HCO .,L T D.3) 24-group data modeSupporting 24 sets of parallel data, Serial data decoding is required for scan mode above 1/4 scan (Serial data decoding circuit in the appendix), defined as follows:XI 'AN NOVA S TAR T E C HCO .,L T D.4)64-group serial data modeX ISupporting 64 sets of serial data, defined as follows:Under serial mode, there are 64 data cables totally. Each cable can drive one LED bar independently.In case of horizontal LED bar, the default is, Data1 drives the first row from the top, and Data64 drives the 64th row.In case of vertical LED bar, the default is, Data1 drives the first column of from the left, and Data64 drives the 64th column.S TAR T E C HCO .,L T D.DimensionsBoard thickness is not greater than 2mm, and the total thickness (board thickness + thickness of both front panel and back panel) is not greater than 18mm.Unit: mm.XI 'A N N O V A S T A R T E C H C O .,LAppearanceNote: Product images provided in this file are for reference only, and the actual products shall prevail.J9 definition （Indicator light Socket ）SpecificationsT A R L T D.AppendixSerial data decoding circuit：X I'A NN OV AS TA RT EC HC O.,L TD.www.novastar.tech Page 10。
诺瓦科技透明LED屏接收卡XC200详细参数规格书英语版
Receiving Card XC200Rev1.1.2 NS110100195GeneralXC200 is a high density receiving card in Nova M3 series. Comparedwith traditional receiving card, XC200 is more flexible in usage. A singleXC200 card can load pixel of 512*384, supporting such utility functionsas memory on module, intelligent module management, LED displayhuman-computer interaction and built-in voltage temperaturedetection. Specific circuit and program design of XC200 can effectivelyreduce electromagnetic radiation of the system, helping users to maketheir products pass EMC certification easily.Features1)Single card supports the maximum output of 32-group RGB data.2)Single card supports resolution of 512*384.3)Supporting any scan types with Supporting any scan types within1-1/32 scan; supporting 595 and other serial decoding scan.4)Supporting all mainstream LED driving chips, such as regular chipand PWM chip.5)Supporting high gray scale and high refresh rate.6)Supporting pixel-by pixel calibration of brightness and chroma.7)Supporting the special shape: loading much easier with randomalignment, random pixel test, special-shaped module,special-shaped cabinet and special-shaped LED display.8) Supporting seamless switch of various hot backups, including loopbackup, dual card backup, dual power supply backup, etc. 9) Supporting the connection of LCD module to realize thehuman-computer interaction.Note:RFUxx refers to reserved signal; The blue part in JH2 refers to the MOM interface (left idle if not used).10)Supporting one channel of voltage and temperature detection. 11)Supporting intelligent module, with the functions of storing and managing calibration coefficient, module information and module parameters, as well as the row line detection and LED pixel-by-pixel error detection without the need of monitoring card.12)The special EMC design effectively reduces the electromagnetic radiation.Output interface definition1) 32- g roup parallel data modeSupporting 32-group of RGB parallel data, defined as follows:serial data modeSupport 64 sets of serial data, defined as follows:DimensionsAppearanceNote1: P ositioning hole is connected to GND.Note2: P ictures used in this manual areB version of the board card. The functions of different versions are basically the same. There are only a few small differences in their appearance.J1 （ N etwork Port ） d efinition:。
诺瓦科技全彩LED接收卡MRV481-1规格书英文版
Receiving CardMRV481-1SpecificationsCop 2018 Xi’an NovaStar Tech Co., Ltd. All Rights Reserved.No part of this document may be copied, reproduced, extracted or transmitted in any form or by any means without the prior written consent of Xi’an NovaStar Tech Co., Ltd.Trademarkis a trademark of Xi’an N ovaStar Tech Co., Ltd.StatementYou are welcome to use the product of Xi’an NovaStar Tech Co., Ltd. (hereinafter referred to as NovaStar). This document is intended to help you understand and use the product. For accuracy and reliability, NovaStar may m ake improvements and/or changes to this document at any time and without notice. Any problem in use or any good suggestion, please contact us through ways provided in the document. We will do our utmost to solve the problems and adopt the suggestions after e valuation as soon as possible.Specifications Change HistoryChange HistorySpecifications ContentsChange History (ii)1Safety (1)2Overview (2)3F eatures (3)44 Hardware Structure.......................................................................................................................4.1Appearance (4)4.2Dimensions (5)4.3Definition of Data Interface (6)5Specifications (8)1 Safety1 S afetyThis chapter illustrates safety of the MRV481-1 receiving card to ensure the product’sstorage, transport, installation and use safety. Safety instructions are applicable to allpersonnel who contact or use the product. First of all, pay attention to following points.●Read through the instructions.●Retain all instructions.●Comply with all instructions.Storage and Transport Safety●Pay attention to dust and water prevention.●Avoid long-term direct sunlight.●Do not place the product at a position near fire and heat.●Do not place the product in an area containing explosive materials.●Do not place the product in a strong electromagnetic environment.●Place the product at a stable position to prevent damage or personal injurycaused by dropping.●Save the packing box and materials which will come in handy if you ever have tostore and ship the product. For maximum protection during storage and shipping,repack the product as it was originally packed at the factory.Installation and Use Safety●Only trained professionals may install the product.●Plugging and unplugging operations are prohibited when the power is on.●Ensure safe grounding of the product.●Always wear a wrist band and insulating gloves.●Do not place the product in an area having frequent or strong shake.●Perform dust removing regularly.●Contact NovaStar for maintenance at any time, rather than have the productdisassembled and maintained by non-professionals without authorization.●Replace faulty parts only with the spare parts supplied by NovaStar.2 Overview2Overview3 FeaturesThe MRV481-1 is a new receiving card developed by NovaStar. A single MRV481-1 loads up to 256×360 pixels.The MRV481-1 supports pixel level brightness and chroma calibration, which effectively removes color difference, greatly improves display consistency of LED images, and presents finer displays to users. 3Features ●Outputs 24 groups of RGB parallel data per receiving card.●Supports 1/32 scan.●Supports pixel level brightness and chroma calibration.●Supports setting of images pre-stored in the receiving card.●Supports detection of temperature, voltage, Ethernet cable communicationstatus and video source signals status.●Supports management of module flash which stores calibration coefficients andmodule information.●Supports readback of configuration files .34Hardware Structure4.1 AppearancePictures shown in this document are for illustration purpose only. Actual product maydiffer.Definition of J4 (module flash management interface):JH1JH2 1C1 A1 2 C3 A3 2 3B1 OE1 4 3 B3 OE3 4 5LAT1 DCLK1 6 5 LAT3 DCLK3 6 7D1 E1 8 7 D3 E3 8 Dimensions4.2 The board thickness is not greater than 2.0 mm, and the total thickness (boardthickness + thickness of components on front and rear panels) is not greater than17.5 mm.The unit of dimension chart is “mm ”. The location holes are connected to signal grounds (GND).125 G5 B5 26 25 G17 B1727 R6 G6 28 27 R18 G18 29 B6 VCC 30 29 B18 VCC 31 C2 A2 32 31 C4 A433 B2 OE2 34 33 B4 OE4 35 LAT2 DCLK2 36 35 LAT4 DCLK4LTD.37 D2 E2 38 37 D4 E4Receiving Card MRV481-1Specifications 75Specifications。
诺瓦科技LED显示屏接收卡DF30规格书英文版
DF30Receiving CardSpecificationsProduct Version:V1.0.0Document Number: NS110100556XI 'AN N OVA S T AR T EC HCO .,L T D.Copyright ©2018 Xi’an NovaStar Tech Co., Ltd. All Ri ghts Reserved.No part of this document may be copied, reproduced, extracted or transmitted in any form or by any means without the prior written consent of Xi’an NovaStar Tech Co., Ltd.Trademarkis a trademark of Xi’an NovaStar Tech Co., Ltd.StatementYou are welcome to use the product of Xi’an NovaStar Tech Co., Ltd. (hereinafter referred to as NovaStar). This document is intended to help you understand and use the product. For accuracy and reliability, NovaStar may make improvements and/or changes to this document at any time and without notice. Any problem in use or any good suggestion, please contact us through ways provided in the document. We will do our utmost to solve the problems and adopt the suggestions after evaluation as soon as possible.X I'A NN OV AS TA RT EC HC O.,LT D.Specifications Change HistoryChange HistoryX I'A NN OV AS TA RT EC HC O.,LTSpecifications 1 Overview1 OverviewThe DF30 is a receiving card developed by NovaStar. It features small size and largeloading capacity, loading 256×256 pixels per card.The DF30 supports pixel level brightness and chroma calibration by working withNovaLCT and NovaCLB. It can effectively remove color difference and greatlyimprove LED display image consistency, presenting smoother images to users. Inaddition, it also supports quick seam correction, which makes LED images moreuniform and thus tremendously improves visual experiences.The hardware designs of the DF30 have concerned the user deployment, operatingand maintenance scenarios, enabling easier deployment, more stable operating andmore efficient maintenance.Advanced hardware designs:●The small-size hardware design is applicable to scenarios of small cabinet spaceand small pixel pitch.●The two rows of 2.0-pitch female headers are shockproof, therefore highly stableand reliable.X I'A NN OV AS TA RT EC HC O.,LT D.Specifications2 Features2Features● Loads 256×256 pixels.● Supports parallel output of up to 32-group RGB data. ● Supports serial output of up to 64-group data. ● Supports up to 1/32 scan.● Supports 3D function with loading capacity up to 256×256 pixels (PWM IC). ● Supports one click to apply the calibration data saved in module Flash. ● Supports management of information saved in module Flash. ● Supports pixel level brightness and chroma calibration.● Supports monitoring the voltage and temperature of itself without using other peripherals.● Supports monitoring the Ethernet cable communication status. ● Supports dual-power backup detection. ● Supports loop backup.● Supports dual-program backup.● Supports backup and readback of configuration parameters. ● Supports 5-pin LCD in the cabinet. ● Supports bit error rate detection.●Supports the mode of no sending card connected.XI 'AN N OVA S T AR T EC HCO .,L T D.3Hardware Structure3.1 AppearanceProduct images provided in this file are for reference only , and the actual productsshall prevail.3.2 IndicatorXI 'AN N OVA S T AR T EC HCO .,L T D.3.3 DimensionsBoard thickness is not greater than 2.0 mm, and the total thickness (board thickness+ thickness of both front panel and rear panel) is not greater than 8.5 mm.Unit: mmX I'A NN OV AS TA RT EC HC O.,L3.4 Definition of Data Interface3.4.1 32-Group Parallel DataJH1OVA S T AR T EC HCO .,L T D.3.4.2 64-Group Serial DataJH1 XI 'AN N OVA S T AR T EC H3.4.3 Extended Functions DesignX I'A NN OV AS TA RT EC HC O.,LT D.Specifications 4 Specifications4 SpecificationsX I'A ND.。
诺瓦科技LED显示屏全彩接收卡A4参数说明书
3.1 提升显示效 果 .............................................................................................................................................. 4
请勿擅自维修产品，您可以随时联系诺瓦科技。 请使用诺瓦科技的同款产品进行备件更换。
1 安全说明
2
接收卡 A4 规格书
2 概述
2 概述
A4 是诺瓦推出的小尺寸全功能高端接收卡，单卡带载 256×256（PWM IC）像素。 A4 支持逐点亮色度校正，配合 NovaLCT 和 NovaCLB，对每个灯点的亮度和色度进行 校正，有效消除色差，显著提升 LED 画面显示的一致性，给用户带来更细腻的画面。 同时，支持显示屏画面以 90°的倍数进行旋转，画面变化更加丰富，提升用户的视觉 体验。 A4 的硬件设计和软件设计充分考虑用户部署、运行和维护时的场景，使部署更容易， 运行更稳定、维护更高效。 先进的硬件设计： 采用小尺寸的硬件设计，适用于小的箱体空间和小间距应用场景。 采用 DDR3 接口，接触性良好，且具有良好的兼容性。 实用的软件设计：
ii
接收卡 A4 规格书
目录
目录
更新记录 .............................................................................................................................. ii
诺瓦科技LED透明屏接收卡MRV560详细参数说明书英语版
Product images provided in this file are for reference only , and the actual products shall prevail.Rev1.1.2 NS110100117SpecificationsReceiving Card MRV560OverviewMRV560 is the EMC version of MRV360 with its effective reduction ofthe electromagnetic radiation of the whole system.Features1)Single card outputs 16-group of RGBR 'data;2)Single card outputs 20-group of RGB data;3)Single card outputs 64-group of serial data;4)MOM can store calibration coefficient and LED moduleinformation;5)Single card supports resolution of 256x226;6)Configuration file readback;7)Temperature monitoring；8)Ethernet cable communication status detection;9)Power supply voltage detection;10)Pixel-by-pixel brightness and chromaticity calibration.11)Brightness and chromaticity calibration coefficients for each LED;12)Pre-store picture setting;13)Able to connect monitoring card to achieve comprehensivemonitoring;14)Comply with RoHS standard;15)Comply with EU CE-EMC Class B standard.Output Interface DefinitionUnder all the three different working modes of it, two 50P interfacescan output different data, and only one common program andsoftware are required. No customized program is needed. Interfacesare defined as follows:Virtual R signal in the last data group of each 50pin hub is decodingg n a l9 G8 R8 10 9 G16 R16 10 11 RR7 U7 12 11 RR15 U15 12 13 G7 R7 14 13 G15 R15 14 15 RR6 U6 16 15 RR14 U14 16 17 G6 R6 18 17 G14 R14 18 19 RR5 U5 20 19 RR13 U13 20at od e .2) 20- g roup parallel data modeSupport 20 sets of parallel data, defined as follows: TECHUnder serial mode, there are 64 data cables totally. Each cable can drive one LED bar independently.In case of horizontal LED bar, the default is that Data1 drives the first row from the top, and Data64 drives the 64th row. (front view). In case of vertical LED bar, the default is that Data1 drives the first column of from the left, and Data64 drives the 64th column. (front view).3)Support 64 sets of serial data, defined as follows:DimensionsThickness of the board is about 1.7mm. The overall thickness (boardthickness＋thickness of the components on front and back side) isabout 19mm.Unit: mm.J10 definition（Indicator Socket）：SpecificationsSpecific Model ListTo meet the needs of different customers, Nova has provided morespecific models of the products, including standard products in stock.Other models need to be customized.AppendixSerial data decoding circuit：。
诺瓦科技LED显示屏接收卡TR100规格书英文版
TR100Receiving CardSpecificationsVersion:V1.0.0Document Number: NS110100329XI 'AN NOVA S T AR T E C H CO .,LT D.Change HistoryX I'A NN OV AS TA RT EC HC O.,L TD.Table of Contents1 General (1)2 Features (2)2.1 Improvement in Display Effect (2)2.2 Improvement in Maintainability (2)2.3 Improvement in Hardware Reliability (3)2.4 Improvement in Software Reliability (4)3 Output interface definition (5)3.1 32-group parallel RGB data (5)3.2 Reference Design for Expandable Interfaces (8)4 Interface (9)5 Dimensions (10)6 Specifications (11)X I'A NN OV AS TA RT EC HC O.,L TD.1 General The TR100 is a new generation of receiving card developed by NovaStar. A singleTR100 loads up to 384x384 pixels.The TR100 supports 1.0/2.3 (SAA) coaxial connectors, ensuring more reliable system connection and data transmission. Benefiting from the SerDes technology, the TR100 also features lower latency. What's more, the TR100 supports 18Bit+ grayscale output. It can effectively avoid grayscale loss caused by brightness reduction on LED display and make the display smoother.X I'A NN OV AS TA RT EC HC O.,L TD.2Features2.1 Improvement in Display Effect2.2 Improvement in Maintainability XI 'A2.3 Improvement in Hardware ReliabilityXI 'T2.4 Improvement in Software ReliabilityX I'A NN OV AS TA RT EC HC3Output interface definition3.1 32-group parallel RGB dataJH1XI 'AN NOVA S T AR T E C H CO .,LT D.Note 1. Voltage ranging from 3.8V to 5.5V is recommended for input power (VCC). Note 2. RGB data groups must be used in group.Note 3. Operating indicator that meets low level is valid.Note 4. OE_RED, OE_GREEN and OE_BLUE are display enabled pins. In case thatOE_RGB are not controlled separately, OE_RED signal is applied. WhenPWM chip is used, GCLK signal is enabled.Note 5. RFU1﹘18 are the reserved extended function interfaces. Please refer to “3.2Reference Design for Expandable Interfaces”.3.2 Reference Design for Expandable InterfacesDescription:RFU8 and RFU10 are signal multiplexing expandable interfaces for which theinterfaces of either Recommended Smart Module Interface or RecommendedModule Flash Interface can be enabled in one operation。
诺瓦科技LED显示屏接收卡XC200规格书英文版
Product Specifications Receiving Card XC200Rev1.1.2NS110100195XI 'AN N OVA S T AR T E C H CO .,LT D.GeneralXC200 is a high density receiving card in Nova M3 series. Compared with traditional receiving card, XC200 is more flexible in usage.A single XC200 card can load pixel of 512*384, supporting such utility functions as memory on module, intelligent module management, LED display human-computer interaction and built-in voltage temperature detection. Specific circuit and program design of XC200 can effectivelyreduce electromagnetic radiation of the system, helping users to make their products pass EMC certification easily.Features 1) Single card supports the maximum output of 32-group RGB data. 2) Single card supports resolution of 512*384.3) Supporting any scan types with Supporting any scan types within1-1/32 scan; supporting 595 and other serial decoding scan. 4) Supporting all mainstream LED driving chips, such as regular chipand PWM chip.5) Supporting high gray scale and high refresh rate.6) Supporting pixel-by pixel calibration of brightness and chroma. 7) Supporting the special shape: loading much easier with randomalignment,randompixeltest,special-shapedmodule,special-shaped cabinet and special-shaped LED display.8) Supporting seamless switch of various hot backups, including loopXI 'A N N O VA S T A R T E C H CO .,LT D.backup, dual card backup, dual power supply backup, etc.9) Supporting the connection of LCD module to realize thehuman-computer interaction.10) Supporting one channel of voltage and temperature detection. 11) Supporting intelligent module, with the functions of storing andmanaging calibration coefficient, module information and module parameters, as well as the row line detection and LED pixel-by-pixel error detection without the need of monitoring card.12) The special EMC design effectively reduces the electromagneticradiation.Output interface definition 1) 32-group parallel data modeSupporting 32-group of RGB parallel data, defined as follows:Note:RFUxx refers to reserved signal; The blue part in JH2 refers to the MOM interface (left idle if not used).XI 'A N N O VA S T A R T E C H CO .,LT D.JH1JH21 GND 5V2 1 GND 5V 23 GND 5V4 3 GND 5V 45 TEST_KEY STA_LED6 5 R17 G17 6 7 FPGA_InOut3 FPGA_InOut2 8 7 B17 R18 8 9 FPGA_InOut1 Com_In2 10 9 G18 B18 10 11 Com_In1 Com_Out2 12 11 R19 G19 12 13 Com_Out1 GND 14 13 B19 R20 14 15 OE_BLUE OE_GREEN 16 15 G20 B20 16 17 OE_RED CTRL 18 17 R21 G21 18 19 E D 20 19 B21 R22 20 21 C B 22 21 G22 B22 22 23 A LAT 24 23 R23 G23 24 25 DCLK GND 26 25 B23 R24 26 27 B16 G16 28 27 G24 B24 28 29 R16 B15 30 29 GND GND 30 31 G15 R15 32 31 R25 G25 32 33 B14 G14 34 33 B25 R26 34 35 R14 B13 36 35 G26 B26 36 37 G13 R13 38 37 R27 G27 38 39 B12 G12 40 39 B27 R28 40 41 R12 B11 42 41 G28 B28 42 43 G11 R11 44 43 R29 G29 44 45 B10 G10 46 45 B29 R30 46 47 R10 B9 48 47 G30 B30 48 49 G9 R9 50 49 R31 G31 50 51 GND GND 52 51 B31 R32 52 53 B8 G8 54 53 G32 B32 54 55 R8 B7 56 55 GND SPI_CLK 56 57 G7 R7 58 57 SPI_CS SPI_MOSI 58 59 B6 G6 60 59 SPI_MISO CODE0 60 61 R6 B5 62 61 CODE1 CODE2 62 63 G5R564 63 CODE3CODE4 64 65 B4 G4 66 65 H164_CLK H164_CSD 66 67 R4B3 68 67 GND RFU1 68 69 G3 R3 70 69 RFU2 RFU3 70 71 B2 G2 72 71 RFU4 RFU5 72 73 R2 B1 74 73 RFU6 RFU7 74 75 G1 R1 76 75 RFU8 RFU9 76 77 5V GND 78 77 5V GND 78 795VGND80795VGND80XI 'AN NOVA S T AR T E C H CO .,LT D.2) 64-group serial data modeSupport 64 sets of serial data, defined as follows:Signals in blue are MOM control interface and green is LCD control interface.JH1JH21 GND 5V2 1 GND 5V 23 GND 5V4 3 GND5V 4 5 EXT_KEYSTA_LED- 6 5 DATA32 DATA33 6 7 RFU7RFU6 8 7 DATA34 DATA35 8 9RFU5 TEST_INPUT_KEY 10 9 DATA36 DATA37 10 11RFU3 RFU2 12 11 DATA38 DATA39 12 13 RFU1GND 14 13 DATA40 DATA41 14 15 OE_BLUE OE_GREEN16 15 DATA42 DATA43 16 17 OE_REDCTRL 18 17 DATA44 DATA45 18 19 E D 20 19 DATA46 DATA47 20 21 C B 22 21 DATA48 DATA49 22 23 ALAT 24 23 DATA50 DATA51 24 25 DCLK GND 26 25 DATA52 DATA53 26 27 NC NC 28 27 DATA54 DATA55 28 29 NC NC 30 29 GND GND 30 31 NC NC 32 31 DATA56 DATA57 32 33 NC NC 34 33 DATA58 DATA59 34 35 NC NC 36 35 DATA60 DATA61 36 37 NC NC 38 37 DATA62 DATA63 38 39 NC NC 40 39 NC NC 40 41NCNC4241NCNC42XI 'AN NOVA S T AR T E C H CO .,LT D.43 DATA31 DATA30 44 43 NC NC 44 45 DATA29 DATA28 46 45 NC NC 46 47 DATA27 DATA26 48 47 NC NC 48 49 DATA25 DATA24 50 49 NC NC 50 51 GND GND 52 51 NC NC 52 53 DATA23 DATA22 54 53 NC NC 54 55 DATA21 DATA20 56 55 NC SPI_CLK 56 57 DATA19 DATA18 58 57 SPI_CS SPI_MOSI 58 59 DATA17 DATA16 60 59 SPI_MISO CODE0 60 61 DATA15 DATA14 62 61 CODE1 CODE2 62 63 DATA13 DATA12 64 63 CODE3 CODE464 65 DATA11 DATA10 66 65 H164_CLK H164_CSD66 67 DATA9 DATA8 68 67 GND EXT_LCD_BL68 69 DATA7 DATA6 70 69 EXT_LCD_BL1EXT_LCD_SC L/DB0 70 71 DATA5 DATA4 72 71 EXT_LCD_SCL/DB1 EXT_LCD_CD/RS 72 73 DATA3 DATA2 74 73 EXT_LCD_CS#/RW RFU8 74 75 DATA1 DATA0 76 75 RFU9RFU10 76 77 5V GND 78 77 5V GND 78 795VGND80795VGND 80DimensionsUnit: mmXI 'A N N O V A S T AR T E C H CO .,LT D.AppearanceNote1: Positioning hole is connected to GND.Note2: Pictures used in this manual are B version of the board card. The functionsof different versions are basically the same. There are only a few small differencesin their appearance.J1（Network Port）definition:X I'A NN OV AS TA RT EC HC O.,L TD.Port1_TRD0- 1 2 Port1_TRD0+Port1_TRD1- 3 4 Port1_TRD1+Port1_TRD2- 5 6 Port1_TRD2+Port1_TRD3- 7 8 Port1_TRD3+GND 9 10 GNDGND 11 12 GNDPort2_TRD0- 13 14 Port2_TRD0+Port2_TRD1- 15 16 Port2_TRD1+Port2_TRD2- 17 18 Port2_TRD2+Port2_TRD3- 19 20 Port2_TRD3+Working conditionsStorage and transport temperature-40℃~100℃Temperature of working environment-25℃~85℃Input voltage DC 3.3V~6VRated current0.5ARated dissipation 2.5WNet weight 42.2gX I'A NN OV AS TA RT EC HC O.,L TD.。
诺瓦科技LED透明屏接收卡A10s技术文档说明书英文版
Copyright © 2018 Xi ’an NovaStar Tech Co., Ltd. All Rights Reserved.No part of this document may be copied, reproduced, extracted or transmitted in any form or by any means without the prior written consent of Xi ’an NovaStar Tech Co., Ltd.Trademarkwww.novastar.tech i Change HistoryChange Historyis a trademark of Xi ’an NovaStar Tech Co., Ltd.StatementYou are welc ome to use the product of Xi ’an NovaStar Tech Co., Ltd. (hereinafter referred to asNovaStar). This document is intended to help you understand and use the product. For accuracy andreliability, NovaStar may make improvements and/or changes to this document at any time and without notice. Any problem in use or any good suggestion, please contact us through ways provided in the document. We will do our utmost to solve the problems and adopt the suggestions after evaluation as soon as possible.Product DescriptionTable of ContentsTable of Contents 1 Safety ...............................................................................................................................1Storage and TransportSafety (1)Installation and UseSafety (1)2 Overview ..........................................................................................................................23Characteristics (4)Improvement in DisplayEffect (4)Improvement inMaintainability (5)Improvement in HardwareReliability (6)Improvement in SoftwareReliability (6)4 Hardware Structure (8)Appearance .......................................................................................................................................... (8)Dimensions .......................................................................................................................................... (8)Indicator ............................................................................................................................................... (9)Definition of the Data Interface(Top) ........................................................................................................ 104.4.1 32-GroupParallel Data Interface (10)64-Group Serial DataInterface (14)Reference Design for ExpandableInterfaces (17)Product Description5 Software Structure ........................................................................................................186 Typical Networking (19)7 Specifications (20)A Abbreviation (21)B Terms (22)www.novastar.tech iii1 Safety1 SafetyThis chapter illustrates the safety of the A10s receiving card to ensure products’storage, transport, packing and application safety. Safety description is applicable toall personnel that contact or use the products. Pay attention to following points:●Read throughout the description.●Save the whole description.●Be complied with the whole description.1.1 Storage and Transport Safety●Pay attention to dust and water prevention.●Avoid long-term direct sunlight.●Do not place the products at the position near fire and heat.●Do not place the products in an area containing explosive materials.Product Description●●Place the products at a stable position to prevent damage or personal injurycaused by dropping.●Save the packing box and materials which will come in handy if you ever have toship your products. For maximum protection, repack your product as it wasoriginally packed at the factory.1.2 Installation and Use Safety●Only trained professionals may install the products.●Do not insert and unplug (power cord plug) when the power is on.●Ensure the safe grounding of the device.●Always wear an anti-static wrist band and insulating gloves.●Do not place the products in an area having more or strong shake.●Perform dust removing regularly.●Do not maintain the products without authorization but contact NovaStar as soonas possible.●Replace spare parts only with the same parts supplied by NovaStar.www.novastar.tech 12 Overview2 OverviewA10s is a high-end receiving card developed by NovaStar, featuring small size andlarge loading capacity with the single card loading capacity up to 512×384 (PWM IC)pixel.A10s can work with the independent controller MCTRL R5, making display rotate atany angel. A10s can also work with the independent controller MCTRL4K featuringlarge loading capacity and support HDR10 compliant video input, realizing largerdynamic brightness range and larger color space, and making the image smoother.Product DescriptionA10s supports pixel level brightness and chroma calibration, which removes colordifference effectively and improves display consistency of LED images. In addition, italso supports image rotation in 90° increments, creating richer images and improvingvisual experiences.Software and hardware designs of the A10s concern the user deployment as well asoperating and maintenance scenarios, enabling easier deployment, more stableoperating and more efficient maintenance.Advanced hardware design:●Small size and thinner thickness save space for increasingly narrower cabinetspace and smaller spacing between lamps.●Use high-density connector which is resistant to dust and vibration and featureshigh stability and high reliability.●Assembly network transformer features simple design and improved magneticcompatibility, helping user’s products to successfully pass the EMCauthentication.Useful software design:●Support for HDR10●Support for LVDS transmission (customized function)●Support for low latency (customized function)●Support for smart module (customized function)●Support for auto module calibration●Support for Mapping function●Support for 18Bit+ grayscale output●Support for ClearView●Support for image rotation in 90° increments●Support for pre-stored image setting of the receiving cardwww.novastar.tech 2Product Descriptionwww.novastar.tech 3Table of Contents● Support for lamp panel Flash management● Support for monitoring of temperature, power supply voltage● Support for monitoring of Ethernet cable communication status (customized function)●Support for 5pin LCD module3Characteristics 3.1Improvement in Display EffectProduct Description 3 Characteristics www.novastar.tech 4www.novastar.tech 5Product Description 3 Characteristicsa te r t h a n2.0mm , a nd the total thickness (board thickness + thickness of both front panel and back panel) is not greater than 9.5mm.Unit of the dimension chart is “mm ”. Ground connection is enabled for location hole (GND). normal operation of the display while the main device fails. ● Ethernet port redundant backup:HUB ’s Ethernet port improves thereliability for the serial connection of the receiving card through main and standby redundant mechanism. Among the main and standby serial connection lines, if one fails, the otherwill begin to work to ensure thenormal operation of the display.Characteristics DescriptionSupporting firmware read back Information saved in the receiving card could be read back on the NovaLCT. Product images provided in this file are for reference only shall prevail. Models of the high-density receptacle and plug used by A10s are shown in table Figure 4-1. Figure 4-1 Model of high-density connector Type Brand Material Code Receptacle Amphenol F CI 10140609 PLUGAmphenol F CI10140607 XI'AN NOVASTAR TECH CO., receiving cardXI'ANNOVASTARTECHCO.,Product Description 4 Hardware Structure4.3 IndicatorCO.,LTD.Product Description 4 Hardware Structure4.4 Definition of the Data Interface (Top)4.4.1 32-Group Parallel Data InterfaceProduct Description 4 Hardware StructureBacklightsignal 2 ofLCD EXT_LCD_BL113 14 NC LCD control button EXT_KEY 15 16 NCRefe r to Note 5. / RFU1 17 18 NC / RFU2 19 20 NC GND 21 22 NC NC 23 24NCGND 25 26 GNDRefe r to Note 2. / G17 27 28 R17 / / R18 29 30 B17 / / B18 31 32 G18 / / G19 33 34 R19 / / R20 35 36 B19 / / B20 37 38 G20 / GND 39 40 GND Refe r to Note 2. / G21 41 42 R21 / Refer to Note 2./ R22 43 44 B21 / / B22 45 46 G22 / / G2347 48 R23 / R24 49 50 B23 / / B24 51 52 G24/GND 53 54Refer to Note 2. / G25 55 56 R25 / Refer toNote 2. / R26 57 58 B25 / / B26 59 60 / / G27 61 62R27 / / R28 63B27 / /B2866 G28 /GND 67 68 GNDData signal of LCD EXT_LCD_SDA 9 10 NC Backlight signal 1 ofLCDEXT_LCD_BL0 1112NCAR64G26 TECGND H/CO.,Refer to Note 2 .LTD.XI'ANNOVASTARTECHCO.,LTD.Product Description 4 Hardware StructureportDCLK_2Product Description 4 Hardware StructureProduct Description 4 Hardware StructureProduct Description 4 Hardware Structure 4.4.2 64-Group Serial Data InterfaceProduct Description 4 Hardware StructureProduct Description 4 Hardware StructureProduct Description 4 Hardware StructureProduct Description 4 Hardware StructureLTD.Note 7. Operating indicator that meets low level is valid.Note 8. OE_RED, OE_GREEN and OE_BLUE are display enabled pins. In casethatOE_RGB are not controlled separately, OE_RED is applied. While PWM chip is used, GCLK signal is enabled.Note 9. RFU1﹘18 are the reserved extended function interfaces. Please refer to“4.4.3 Reference Design for Expandable Interfaces ”.Product Description 4 Hardware StructureProduct Description 4 Hardware StructureRFU8 and RFU10 are signal multiplexing expandable interfaces for which theinterfaces of either Recommended Smart Module Interface or RecommendedModule Flash Interface can be selected at a time.Product Description5 Software Structure6 Typical Networking0.5A Rated power consumption 2.5WOperating temperature -20°C –70°C Storage temperature -25°C –125°C Operating humidity80.0mm×45.0mm×9.1mm 22.3g●Pass the EMC Class B authentication.●Pass the RoHS authentication.5Software StructurProgram download method:Visit w ww.novastar.tec h a nd choose D ownload > F irmware . On the F irmware section, choose the desired program package to download.XI'ANNOVASTARTECHCO., LTD Authentication1 0 % R H ～90 % R H TECHCO.,6Typical NetworkinA10s is applied to LED display synchronous system which is generally composethe LED display, HUB board, receiving card, video controller and controller peripThe receiving card is connected to the display over a HUB board.Synchronous system requires connecting a c omputer to display the computer ’sXI'ANNOVASTARTECHLTDProduct Description7SpecificationsLTD.7 Specifications XI'ANProduct DescriptionXI'ANNOVASTARTECHCO.,LTD.A AbbreviationB Terms BTerms18Bit+Specify the grayscale of LED displays. Enabling 18 bit mode on NovaLCT couldimprove LED display grayscale by 4 times, and therefore avoid grayscale losscaused by brightness reduction and make images finer.ClearViewDisplay screen effects. Enable ClearView on NovaLCT to adjust the texture, size and contrast in different area based on human visual system to make image more realistic.Calibration coefficientCalibration system generates a group of values for each LED lamp, includinginformation about brightness and chroma. After display calibration, thecalibration values of each lamp are just the calibration coefficient. Smart moduleThe smart module is composed of Flash and MCU.Flash could store calibration coefficients and lamp panel information. MCU could communicate with the receiving card to realize monitoring over temperature, voltage and wiring communication status, as well as LED error detection. The smart module could make monitoring unit smaller, requiring no independent monitoring card and saving cabinet space.MappingAAbbreviatioEEMCElectro m a gnetic CompatibilityF FPGA Field - P rogrammable Gate Array L LED Light E mitting DiodeM MCU Micro c o ntroller Unit RRCFG Receiving Card Configuration XI'ANNOVASTARTECH CO.,LTDProduct DescriptionAfter the Mapping function is enabled on NovaLCT, the target cabinet will displaythe cabinet number and Ethernet port information, and the user could get thereceiving card’s location and wiring route.Error detectionPerform status detection for each LED lamp. If the LED lamp fails, the user couldnotify in a timely manner upon monitoring system.。
