欧切斯公司定义的Push DIM 功能和DALI 不能同时使用。 Push DIM是可调光LED驱动器一种功能。
1ቤተ መጻሕፍቲ ባይዱ
Push DIM定义
Push DIM是欧切斯(EUCHIPS)公司定义一种新型的符合DALI调光模式的 主控模式，又名为Touch DIM，也是一种极其简易的DALI主机模式，通 过按键时间长短来达到控制灯具亮暗。所以这种Touch DIM功能开关也 是一种数字模式DALI主控器，当然需要相对应的灯具支持Touch DIM功 能。 Push DIM主要功能：
1. 短按Push DIM 开关 (<0.5秒) 进行灯的亮暗控制。 2. 长按Push DIM 开关 (>0.5秒) 进行灯具的亮度调节，调光的亮暗方向随着 每次按压开关变化。 3. 双击Push DIM 开关 (<0.3秒)，连接的所有灯具将达到最亮状态。 4. 当灯具处于关闭状态，长按Touch DIM开关可以开启灯具并按照变化方向 进行亮度的调节。 5. 亮度调节范围为1%-100%。 6. 具有断电记忆功能，重新上电将恢复到上一次断电的状态。
