（MAX1471接收器）
专业班级： 电子071
课 程： 通信原理课程设计
学 号： 20074470147
学生姓名： 蒋佳成
指导老师： 陈 和
摘要
目前，射频技术在各个领域都有着广泛的应用，各种基
于射频的设备都在向小体积、低功耗、抗干扰、高纠错的方
向发展，使用分离元件构成的射频设备已不能满足需要。因
此，使用FSK/ASK调制的集成射频收发芯片便应运而生。
基于FSK／ASK的超外差收发机在远程无线进入、汽车胎压
检测、无线传感器等方面都有很广泛的应用。本设计以
PIC16F189单片机和MAX1479、MAX1471为核心器件，设
计一款为无线遥控门锁使用的FSK/ASK超外差射频收发机；
介绍PIC16F819芯片和MAX1479、MAX1471芯片的性能，
详细讨论收发机的硬件和软件系统设计并予以实现。
关键字：
FSK 、 ASK 、 PIC16F819 、
MAX1479、MAX1471 、 超外差收发机
一、 元器件的选择：
(1) 控制器的选择（PICl6F819）
在本系统设计中，需要涉及到以下几个方面：处理器
性能、所支持的开发工具、处理器的成本和功耗．综合以上
几个方面考虑，微控制器选择Microchip公司的一款高性价
比的8位微控制器PICl6F819。PICl6FSl9采用20脚贴片
封装，在线方式进行程序调试和烧写；可采用内部晶振，工
作频率可选31 kHz~8 MHz；工作电压从2~5.5V；正常
工作时使用2V电压供电、使用内部晶振频率为32kHz、电
流为7μA；睡眠状态时使用2V电压供电、电流为0．7μA。
（2）收发器器件的选择（MAXl479和MAXl471）
随着无线技术的发展，无线收发芯片的集成度和性能都
得到大幅度提高，芯片性能也各有特色。生产此类芯片的厂
商主要有Nordic、TI和Maxim等。选择无线收发芯片时，
应考虑以下几点因素：功耗、发射功率、接收灵敏度、传输
速率和芯片成本等。Maxim公司的MAXl479和MAXl471
分别是超外差射频发射机和接收机，都采用+2．1~+3．3V
的单电源供电，可以选择FSK／ASK调制方式，低工作电流，
小贴片封装。
二、系统硬件的构成：
2.1
发射部分
发射部分由微控制器PICl6F819和射频发射芯片
MAXl479组成，其系统构成原理图如图1所示。
图1
微控制器PICl6F819通过PA口的8个引脚控制MAXl479的
发射工作。MAXl479的主要引脚功能如表l所列。
表1 表3
其中，Mode引脚用于选择发射芯片是FSK模式或ASK
模式。Enable引脚为高电平，则MAXl179进入发射状态。DIN
引脚输入串行数据。
Clk0和Clk1共同决定Clkout引脚的输出频率，该频率可以作
为微控制器的时钟频率输入。Clk0和Clkl的状态组合如表2所
列。
Dev0、Devl、Dev2共同决定FSK调制时的背离频率的大小，
其组合状态表如表3所列。
发射的载波频率由MAXl479所用的晶振决定，晶振同发射
载波频率间的关系是：
如果选择的发射载波频率为315MHz，则所使用品振为
9.8437MHz；如发射载波频率为433MHz，则所使用品振为
13.56MHz。
MAXl479使用的天线要符合50Ω阻抗匹配，天线可以采用
l／4波长的鞭状天线，也可以使用PCB布线作为天线。
2.2
接收部分
接收部分由射频接收芯片MAXl47l和微控制器构成，接收
方一般和其他系统连接在一起，故不需要刻意根据低功耗选择微
控制器，而是根据数据处理的需要自行选择。构成框图如图2
所示。
MAXl47l需要外接一个lO.7MHz的低通滤波器，晶振的频率同
接收载波的频率的关系为：
如果接收载波的频率为315MHz，则晶振的频率为9.509MHz；
接收载波的频率为433.92MHz，则晶振的频率为
13.2256MHz。
MAXl47l的主要引脚如表4所列。
图2
其中，IFIN+MIXOUT、AGND连接10.7MHz的低通滤波
器，用于ASK数据的解调。ADATA引脚为高，表示到来的是
ASK解调数据；FDATA为高，表示到来的是FSK解调数据。
微控制器连接SCLK、CS、DIO引脚对MAXl472内部的寄存
器进行读写。
MAXl471同样要求50Ω阻抗匹配的天线，可以使用PCB
布线作为天线。
三、系统软件设计：
3.1
发射部分
发射部分的编程主要是对PIC16F819的操作。程序由
PlCl6F8l9初始化、MAXl479初始化和数据发射三部分组成。
对PICl6F819的初始化包括设置内部晶振的工作频率和
PA口的状态。对MAXl479的初始化包括设置工作模式、晶振
输出频率选择和FSK背离频率的选择。数据发射部分包括：设
置数据帧格式、发送位“0”或“l”子程序、发送一个字节数据子程
序和循环发送多个字节数据子程序。程序流程图如图3所示。
图3
3.2
接收部分
接收部分程序主要是微控制器通过SCLK、CS、DIO等引
脚对MAX147l内部寄存器进行读写的过程。
对MAXl471内部寄存器进行写操作的时序图如图4所示。
CS引脚为低，MAXl47l进入工作状态，SCLK引脚产生串行输
入时钟，DIO向MAXl47l串行输出命令。命令的格式为；4位
命令码、4位地址、8位数据。命令码共有3个：0x01代表写、
0x02代表读、0x03代表复位。
图4
对MAXl47l内部寄存器进行读操作的时序图如图5所示。
CS引脚为低，MAX147l进入工作状态，SCLK引脚产生串行输
出时钟，DI0从MAXl471串行输出数据。当ADATA为高，输
出ASK解调数据；当FDATA为高，输出FSK解调数据。输出
数据遵循同样的数据格式。
MAX147l内部常用寄存器和地址的对照表如表5所列。
表5
图5
以接收315MHz的FSK数据为例说明接收数据的编程
步骤：
①写0x3000对芯片进行复位。
②写0x10f0使能所有的RF和基带部分。
③写0x135f设置晶振寄存器，芯片工作于315 MHz频率。
④写0x1120置配置寄存器的FSKCALLSB位，使能FSK
校准。
⑤写0x1121开始FSK校准。
⑥读0x2900读状态寄存器位0和位1的状态，以确定FSK
校准已完成。
⑦读FSK调试后的数据，由微控制器进行处理。
四、小结：
通过这次通信原理的课程设计，我初步掌握FSK/ASK
超外差射频收发机的原理。以及认识到它在无线射频领域的重要
性。在设计过程中遇到很多不懂的地方，通过上网查阅资料以及
在同学、老师的帮助下，设计得以按时完成。以及通信原理在当
今社会的发展前景，虽然在前面的学习中自己没有学好，但我有
信心有激情去学习这门课程，掌握一门技能。
