APDS-9960 中文资料
图 8.详细接近图
接近结果受三个基本因素的影响：红外 LED 发射，红外接收和环境因素，包括目标距离和 表面反射率。 IR 接收信号路径从四个[定向手势]光电二极管的 IR 检测开始，并以 PDATA 寄存器中的 8 位 接近结果结束。来自光电二极管的信号被组合，放大和偏移调整以优化性能。相同的四个光 电二极管用于手势操作以及邻近操作。二极管配对形成两个信号路径：UP / RIGHT 和 DOWN / LEFT。不管配对，任何一个光电二极管都可以被掩蔽，以排除其对接近结果的贡献。屏蔽 成对的二极管之一有效地将信号减少一半，并使满量程结果从 255 减少到 127.为了校正全量 程的这种减小，可以设置接近增益补偿位 PCMP，返回 F.S.到 255.使用 PGAIN 控制位，增益 可以从 1x 调整到 8x。通过调整 POFFSET_UR 和 POFSET_DL 寄存器来实现偏移校正或串扰 补偿。器件的模拟电路将偏移值作为减法运算到信号累加中;因此，正偏移值具有降低结果的 效果。 在光学上，IR 发射显示为脉冲串。脉冲数由 PPULSE 位设置，每个脉冲的周期可以使用 PPLEN 位进行调节。使用 LDRIVE 控制位可以选择 IR 发射的强度;对应四个，出厂校准，电流等级。 如果需要更高的强度（例如较长的检测距离或深色玻璃下方的器件放置），则 LEDBOOST 位 可用于将电流升高至额外的 300％。 集成 IR LED 的 LED 占空比和随后的功耗可以使用表 2 所示的下表和等式计算。如果接近事 件按照 AWAIT 和 WLONG 设置的等待时间分隔，那么总的 LED 关闭时间必须增加等待时间。
Omron QM Series 光电传感器说明书
Photoelectric Sensors tSEN-69
1-800-633-0405
For the latest prices, please check .
QM Series Photoelectric Sensors
$44.50
NPN
2m [6.5 ft] cable
Diagram 1
$44.50 $44.50
0–1m [0 – 3.28 ft]
Visible Red
NPN
630nm
PNP
4-pin M8 quick-disconnect 2m [6.5 ft] cable
Diagram 1 Diagram 2
Note: Purchase reflectors separately.
Emission Type
Visible Red 630nm
Infrared 850nm
Logic NPN NPN PNP PNP NPN NPN PNP PNP NPN NPN PNP PNP
Connection 2m [6.5 ft] cable 4-pin M8 quick-disconnect 2m [6.5 ft] cable 4-pin M8 quick-disconnect 2m [6.5 ft] cable 4-pin M8 quick-disconnect 2m [6.5 ft] cable 4-pin M8 quick-disconnect 2m [6.5 ft] cable 4-pin M8 quick-disconnect 2m [6.5 ft] cable 4-pin M8 quick-disconnect
1-800-633-0405
For the latest prices, please check .
TDR961智能测控单元说明书V120
V1.2 1202-2008
目
1. 2. 3. 4. 5............................................................................................................................... 1 简介 ......................................................................................................................................................... 2 特点 ......................................................................................................................................................... 2 应用 ......................................................................................................................................................... 2 工作原理 ................................................................................................................................................. 3 TDR961 智能测控单元结构说明 .......................................................................................................... 4 5.1. 5.2. 5.3. 5.4. 5.5. 5.6. 5.7. 5.8. 6. 7. DP820 模件 ..................................................................................................................................... 4 AI801 模件...................................................................................................................................... 6 AI803 模件...................................................................................................................................... 7 AI810 模件...................................................................................................................................... 8 DI801 模件...................................................................................................................................... 8 DO802 模件 .................................................................................................................................. 10 IO801 模件.................................................................................................................................... 10 EV820 模件................................................................................................................................... 12
- 1、下载文档前请自行甄别文档内容的完整性，平台不提供额外的编辑、内容补充、找答案等附加服务。
- 2、"仅部分预览"的文档,不可在线预览部分如存在完整性等问题,可反馈申请退款(可完整预览的文档不适用该条件!)。
- 3、如文档侵犯您的权益，请联系客服反馈,我们会尽快为您处理(人工客服工作时间：9:00-18:30)。
On9668 Ambient Light Switch Sensor
On Elelctronics Co.,Ltd. Copyright v3.2 Web:www.On- ele.org
1
开关型可见光照度传感器On9668
On9668是一个光控阀值可调的光电集成传感器。典型入射波长为λp=520nm，内置双敏感元接收器，
可见光范围内高度敏感，光开关阀值通过外置电阻线性可调，直接输出高、低电平，外围电路极为简单。
特别适合各类玩具、灯具、仪器仪表、工业设备等诸多领域的节能控制、自动感光开关电路。
■ 电气特性
z 暗电流小，低照度响应，灵敏度高；
z 光控阀值通过外置电阻线性可调,直接输出高、低电平，外围电路简单；
z 内置双敏感元，自动衰减近红外，光谱响应接近人眼函数曲线；
z 内置微信号CMOS放大器、高精度电压源和修正电路，输出电流可达30mA；
z 工作电压范围宽，温度稳定性好；
z 可选光学纳米材料封装，可见光透过，紫外线截止、近红外相对衰减，增强光学滤波效果；
z 符合欧盟RoHS指令,无铅、无镉；
Fig.1 开关型可见光照度传感器原理图
On9668 Ambient Light Switch Sensor
On Elelctronics Co.,Ltd. Copyright v3.2 Web:www.On- ele.org
2
■ 典型应用
节能控制：室外广告机、感应照明器具、玩具；
仪器仪表：仪器仪表及工业控制；
环保替代：替代传统光敏电阻、光敏二极管、光敏三极管；
■ 额定参数
参数名称 符号
额定值 单位
输入电压
Vdd
2.4-15
V
功率损耗
P
150 mW
工作温度范围
Topr.
-20 to +75 ℃
存储温度
Tstg.
-40 to +120 ℃
焊接温度
Tsol.
260 ℃
■ 光电参数
参数名称 符号测试条件 最小值 典型值 最大值 单位
典型入射波长 λp - - 520 - nm
静态电流 ID Ev=0Lux, 0.3 0.4 0.6 mA
U
ADJ
≤1.2V
20 30
U
ADJ
≥1.6V
0
输出电流 I
L
1.2V＜UADJ＜1.6V
---
保持原
来状态
---
mA
Tr - - 2 - μS
响应时间
Tf - - 2 - μS
测试条件：环境温度25ºC±3，外置电阻R=1KΩ@100 LUX ,电源电压Vdd=5V。
On9668 Ambient Light Switch Sensor
On Elelctronics Co.,Ltd. Copyright v3.2 Web:www.On- ele.org
3
■ 输出逻辑
FIG.2 逻辑时序图
■ 光谱曲线
人眼函数、普通硅光器件、照度传感器光谱曲线对照
0
10
20
30
40
50
60
70
80
90
100
400450500580600650700750800850900950100010501100
波长
%
普通硅光器件光谱
光照传感器光谱
人眼函数
Fig.3 人眼函数、硅光器件、照度传感器光谱曲线对照
On9668 Ambient Light Switch Sensor
On Elelctronics Co.,Ltd. Copyright v3.2 Web:www.On- ele.org
4
Fig.4 波分多段环氧树脂（纳米胶）和普通环氧树脂光谱对比图
备注：由于入射界面到芯片位置的深度不同，采用的封装材料不同，以及光源的误差，得到的数据会有
所不同。
■ 典型测试应用电路
Fig.5 使用ON-9668传感器的光控典型电路。
通过调整Vadj使照度低于一定值LED/继电器/灯具开启。当光线从亮态到暗态或者从暗态到亮态过
渡时，内部有一照度回差约10%，即1.2V＜VADJ＜1.6V 输出端保持原来状态，不会造成频繁开关现象。
On9668 Ambient Light Switch Sensor
On Elelctronics Co.,Ltd. Copyright v3.2 Web:www.On- ele.org
5
Fig.6 使用ON-9668传感器的光控继电器典型电路。
■ 外形尺寸
Fig.7 普通Φ5mm 平头直插型外形封装尺寸 单位：mm
On9668 Ambient Light Switch Sensor
On Elelctronics Co.,Ltd. Copyright v3.2 Web:www.On- ele.org
6
Fig.8 SMD3528外形封装尺寸 单位：mm
■ 封装材料
部件名称 主要材料 颜色 特 性 环保
晶元 硅 --- --- RoHS
封装材料 环氧树脂 无色 近红外光影响光电流 RoHS
封装材料 纳米环氧树脂 淡蓝色 紫外截止、近红外相对衰减。 RoHS
■ 注意事项
不要在超出产品规格范围的情况下使用本传感器；
本说明书中提到的应用电路仅仅作为使用范例，请注意根据外围设施来设计电路并调整参数设置；
本传感器内有CMOS IC，应避免静电击穿；
应保证焊接温度在最大额定范围内，在焊接过程中或刚刚焊接完毕时避免有外力作用于引脚，不可
反复焊接；
本产品符合欧共体RoHS指令；
产品表面的损伤和污染均会影响光电流，注意防潮；
普通Φ5mm包装每包1000只，SMD3528封装每盘2000只；
On9668 Ambient Light Switch Sensor
On Elelctronics Co.,Ltd. Copyright v3.2 Web:www.On- ele.org
7
■ 法律声明
本产品已取得中华人民共和国国家知识产权局授予的专利权,专利号ZL200520060170.5。任何单位
和个人没有明确的书面许可，不得以任何形式包括对芯片样品、封装产品进行复制、仿制、修改、出售。
出于市场需求原因，所有相关厂商必须通过正当渠道及书面合约获准使用。任何侵权行为必须承担由此
引起的法律后果和赔偿专利权人的经济损失。
