北京德威特电力系统自动化有限公司硬件系列资料DVP – 9021使用说明书北京德威特电力系统自动化有限公司重要提示感谢您使用北京德威特电力系统自动化有限公司的产品。
为了安全、正确、高效地使用本装置，请您务必注意以下重要提示：1) 请仔细阅读本说明书，并按照说明书的规定调整、测试和操作。
如有随机资料，请以随机资料为准。
2) 为防止装置损坏，严禁带电插拔装置各插件、触摸印制电路板上的芯片和器件。
3) 请使用合格的测试仪器和设备对装置进行试验和检测。
4) 装置如出现异常或需维修，请及时与本公司服务热线联系，（010）80482861。
2006.07第一次印刷注：本公司保留对此说明书修改的权利。
如果产品与说明书有不符之处，请您及时与我公司联系，我们将为您提供相应的服务。
北京德威特电力系统自动化有限公司I目录1.装置概述 (1)2.技术数据 (3)3.装置结构说明 (5)3.1结构视图 (5)3.2接线端子图及端子接线说明 (7)4.运行系统说明 (11)4.1基本功能 (11)5.参数设置 (12)6.通讯部分 (13)6.110M/100M以太网通讯 (13)6.2RS485或RS232通讯 (13)7.运行人员注意事项及要求 (15)8.检修及维护 (16)II北京德威特电力系统自动化有限公司1.装置概述为解决无人职守型变电站微机保护装置与调度系统通讯方面的不足，我公司开发了DVP-9021微机型智能通讯管理系统。
该系统主要实现收集不同厂家的多种类型监控保护装置的数据信息并将其转发到调度系统，提高了我公司产品与其他厂家产品相互集成以及与调度系统通讯的能力。
在配电系统自动化中，DVP-9021时用于实现配电系统的通信处理和设备管理功能的管理单元。
其具有良好的人机界面，能够将多种装置和设备通过现场总线技术（CAN总线），以太网通信技术（10/100Mb接口），串口通信技术（RS232&RS485）有机的连接起来，并且在测控网上实现信息交换和共享利用，同时还能实现现场层面的人机对话。
◆微处理器（CPU）主板已整合高性能VIA Eden Onboard CPU 667MHZ低功耗中央处理器。
◆芯片组（Chipset）主板使用高性能VT8606（Twister-T）+VT82C686B芯片组，支持133M前端总线，支持PATA-100IDE。
◆系统存储器（System Memory）本CPU卡采用144pin SODIMM SDRAM内存，最大支持512MB。
◆IDE功能一个具有总线主控制器能力独立PATA100IDE通道，可以支持2个IDE设备。
◆USB功能本CPU卡具有1个USB1.1接口◆网络功能（LAN）本CPU卡集成2个10/100M全双工以太网接口，一个型号为Realtek RTL8100C，一个型号为Realtek RTL8139C。
◆AGP图形功能主板在芯片组VIA VT8606中内建了S3 Savage图形控制器，可以进行并行数据处理和精确像素插入的3D超管线构架，全2D硬件加速，以及动画加速能力。
◆I/O功能北京德威特电力系统自动化有限公司 1键盘和鼠标接口：1个键盘+鼠标PS/2接口2个RS232串口1个VGA接口1个并口◆扩展通讯卡功能主芯片采用带有128字节FIFO缓冲的高性能OXFORD 16PCI954串口芯片（内置PCI控制器）支持速率最大可达921.6Kbps数据控流：自动RS-485数据流控制隔离保护：2500Vdc浪涌保护、2500Vdc隔离保护◆系统支持目前支持的系统有：、WXP embeded、Windows XP等◆高度可靠性产品采用高密封设计，防水防尘抗振动设计适合安装于开关柜等环境条件较为恶劣的现场运行；产品具有优异的抗干扰性能，顺利通过IEC 60255-22-4 标准规定的IV 级4kV ；快速瞬变干扰试验通过IEC 60255-22-2 标准规定的IV 级；空间放电15kV 接触放电，8kV 静电放电试验；组屏或安装于开关柜时不需其它抗干扰模件。
◆人性化设计6.4寸真彩色液晶显示屏、图形界面、操作方便。
操作中交互性强，具有多种提示信息和反馈信息；显示内容按照相关性、就近性原则进行组织；人机交互采用触控鼠标，具有快速灵活方便的特点。
2北京德威特电力系统自动化有限公司2.技术数据●功耗及电源装置电源：低功耗状态 < 15W最大负荷时 < 30W●通讯接口主板卡：两路10M/100M自适应高速以太网接口，一路RS232；扩展通讯卡：四路RS232/485，一路CAN PART2.0总线接口。
●通讯规约IEC60870-5-103●绝缘性能符合IEC255-5标准【1】绝缘电阻试验装置的电源输入回路、出口、信号输出回路、开关量输入回路对地（机壳）用开路电压为2500V的测试仪器测定其绝缘电阻不小于1000MΩ。
符合DL478-2001标准【2】介质试验装置的电源输入回路、出口、信号输出回路、开关量输入回路与地之间及各回路之间施加50Hz的交流试验电压2000V(有效值)历时1min试验，装置各实验部位无绝缘击穿或闪络现象。
符合DL478-2001标准【3】冲击电压试验装置的电源输入回路、出口、信号输出回路、开关量输入回路与地之间及各回路之间施加峰值为5kV的标准雷电波短时冲击电压，装置本身性能不改变。
符合IEC60255-22-1标准等级3●抗干扰【1】共模干扰符合IEC60255-22-1标准等级3 2.5KV/1MHz/2S 【2】差模干扰符合IEC255-22-1标准等级3 1.0KV/1MHz/2S 【3】静电电场干扰符合IEC60255-22-2标准等级4接触放电 8kV空气放电 15kV【4】辐射电磁场干扰符合IEC60255-22-3标准等级3北京德威特电力系统自动化有限公司 3至试验设备天线距离>0.5m ，在所有侧面试验场强，频率波段80-1000MHz，10V/m【5】电快速瞬变暂态或脉冲干扰符合IEC60255-22-4标准等级4 幅值： 4kV 频率：2.5kHz 持续时间：1min【6】浪涌抗扰动干扰符合IEC60255-22-5标准等级3 线-地±2kV 线-线±1kV 【7】射频传导干扰符合IEC60255-22-6标准等级3 频率范围150kHz～80MHz【8】工频抗扰度干扰符合IEC60255-22-7标准等级A 差模 150V 共模300V 检验频率50Hz●电源中断影响 IEC60255-11标准电源允需中断时间不超过0.3S●耐湿热性能恒定湿热试验。
装置应能承受GB／T2423．9规定的恒定湿热试验：相对温度为+40℃±2℃，相对湿度为(93±3)％，试验持续时间为48h。
在试验结束前2h内，测量各导电回路对外露非带电导体部位及外壳之间、电气上无联系的各回路之间的绝缘电阻，其绝缘电阻值不应小于1.5MΩ；介质强度不低于标准环境下介质强度试验电压值的75％。
●环境温度工作温度范围 DL478-2001 -0--+55C︒储存及运输温度 DL478-2001 -25--+60C︒相对湿度 10% — 95%无冷凝●防护等级 IP52●重量 6Kg●外型尺寸 170 x 200 x 245 (宽x高x深)4北京德威特电力系统自动化有限公司3.装置结构说明3.1结构视图装置的外形尺寸见图1，使用状态见图2图1. 装置外形尺寸及安装尺寸示意图（单位：mm）北京德威特电力系统自动化有限公司 5北京德威特电力系统自动化有限公司6图2装置使用状态参考图说明：装置面板右侧是键盘的PS/2接口，左侧是开关液晶屏背光的控制按钮，当长时间不监视液晶屏时，应关闭液晶屏背光以延长液晶屏的使用寿命。
北京德威特电力系统自动化有限公司73.2接线端子图及端子接线说明北京德威特电力系统自动化有限公司8主机板2个RS232串口定义 以下图型为从后盖板顶层向下看RS232 口定义北京德威特电力系统自动化有限公司9通讯板4个RS232串口定义 以下图型为从后盖板顶层向下看网络接口PS/2键盘接口前门侧方有PS/2键盘接口10北京德威特电力系统自动化有限公司4.运行系统说明DVP-9021微机型智能通讯管理系统简洁易用，为通讯设置提供了方便的设置界面。
DVP-9021微机型智能通讯管理系统使用CAN总线与我公司各系列保护装置通信；通过串口和以太网与其他厂家的不同装置进行通讯。
系统内嵌部颁CDT、IEC60870-103、MODEBUS等多种规约处理模块以及常见的直流屏、电度表接口模块。
使我公司的产品能够方便的与其他厂家的产品进行互相集成。
同时，DVP-9021微机型智能通讯管理系统能够对规约处理模块进行灵活扩展，更新升级规约库。
4.1基本功能●实现与现场的各种智能设备通讯连接和数据处理。
●直观显示现场的测量信息和状态信息，记录设备的动作累计数据。
●实时显示当前各模块，通讯，打印机等工作状态，出错自动报警。
●实现对电力设备的远程测控。
●监视现场各种智能设备的通讯状态及报文传输状态。
●可动态显示及修改各保护装置内保护定值，可在线投退保护装置内各保护功能。
●可查询和保存最近一年的告警信息。
●对于各类检测电量的修改及功能操作，系统配有多种授权密码，整个系统操作控制方便可靠。
●向其它系统转发数据。
北京德威特电力系统自动化有限公司115.参数设置通讯管理机的参数设置一般由厂家负责设置调试。
参数设置部分包含采集系统设置和转发系统设置。
采集参数设置一般为采集参数设置，特殊时候还包括如某些直流屏、电度表或微机保护监控装置的采集接口编制。
转发系统设置一般为转发参数设置，有时还有一些特殊应用也需要编制转发接口模块。
12北京德威特电力系统自动化有限公司6.通讯部分6.1 10M/100M以太网通讯装置可以通过以太网接口与主机连接组成综合自动化系统；装置带有双10M/100M以太网接口（NET_A,NET_B）。
两个接口可选配，装置IP设置按照主管部门分配的IP地址设置。
以太网通讯线采用五类线或超五类线，按照EIA／TIA 568B标准制作。
如下图：以太网组网要求：网络拓扑形式采用星型连接通信线远离高压电线，尽量不要与电源线并行。
如通讯距离过长，可采用级联方式或者改用光纤通道。
如通信信号干扰过大，需采用光纤通道。
6.2 RS485或RS232通讯装置可以通过RS485接口采集各保护监控单元、直流屏和电度表的信息，并可与主机通过转发规约连接组成综合自动化系统，或将信息送向调度自动化系统；当使用多台设备时，需要用RS485网络联网，总线使用屏蔽线双绞线，按照北京德威特电力系统自动化有限公司13RS485接线方法，将设备接入总线。
