米特(meteor)绕线机的英文说明书
麦格米特 MV600J注塑机专用伺服驱动器用户手册V1

由于没有按要求操作,可能造成中等程度伤害或轻伤,或造成损坏财物的场合。
·请安装在金属等不可燃物体上,否则有发生火灾的危险。 ·不要把可燃物放在附近,否则有发生火灾的危险。 ·不要安装在含有爆炸性气体的环境里,否则有引发爆炸的危险。 ·必须由具有专业资格的人进行配线作业,否则有触电的危险。 ·确认输入电源处于完全断开的情况下,才能进行配线作业,否则有触电的危险。 ·必须将驱动器的接地端子可靠接地,否则有触电危险。 ·上电前必须将盖板盖好,否则有触电和爆炸的危险。 ·存贮时间超过 2 年以上的驱动器,上电时应先用调压器逐渐升压,否则有触电和爆炸的危险。 ·通电情况下,不要用手触摸端子,否则有触电的危险。 ·不要用潮湿的手操作驱动器,否则有触电的危险。 ·应在断开电源 10 分钟后进行维护操作,此时充电指示灯彻底熄灭或确认正负母线电压在 36V 以下,否则有
目录
MV600J 注塑机专用伺服驱动器 ..................................................................................................... 1 第一章 MV600J 伺服驱动器介绍 ................................................................................................... 6
触电的危险。 ·必须专业人员才能更换零件,严禁将线头或将金属物遗留在机器内,否则有发生火灾的危险。
·更换控制板后,必须正确设置参数,然后才能运行,否则有损坏财物的危险。 ·主回路接线用电缆鼻子的裸露部分,一定要用绝缘胶带包扎好,否则有触电危险。
自动绕线机

CM-IB0736C全自动绕线机操作说明书CONTENTS内容1目的 (2)2全自动绕线机的结构或组成 (2)3启动和操作全自动绕线机 (4)4生产结束 (7)5环境,健康和安全 (7)6责任 (7)Revision 版本版本NO: 修改记录Remark 负责人Name 日期Date00 Create a New Document Xi LIU 2011.10.10 Prepared: Xi LIU Checked:Jiasong ZHAO Approved: Yong HUI1目的该手册是解释全自动绕线机的基本操作 2 全自动绕线机的结构或组成其主要结构如下:1. 引线支架2. 侧带安装轴3. 排线夹具安装轴4. 骨架安装轴5. 胶带安装轴6. 启/停开关7. 绕线机控制器8. 运行开关9.复位开关124 36 758 9夹紧螺丝的松紧程度,以铜线张紧且能通过为宜穿线时选择对应线径的线槽(多线并饶时需估算其直径,选择对应的线槽)绕线机控制面板排线方法和注意事项.3 启动和操作全自动绕线机操作步骤Responsible责任人3.1 穿线:铜线从引线支架的穿线孔拉过来,经过滑轮、防护海绵、传线作业员孔、传线槽,最后到骨架。
3.2 安装侧带:以侧带在安装槽中能轻松转动且能固定侧带的水平位置即可。
作业员3.3安装胶带:胶带夹具是可转动的,胶带应固定在夹具中。
作业员3.4根据骨架和产品的参数,在绕线机控制器上设置和输入:1)首先计算出绕线所需要的步骤总数(包括侧带、绕线、胶带,其中两侧都有侧带时为两步)2)以CM-LLJG-001第一个绕组为例(2mm侧带,20mm宽的胶带,绕线区域为16mm),第一步为左侧的侧带,第二步为右侧的侧带,第三部为50圈绕线,第四步为一圈胶带,第五步为50圈绕线,第六步为2圈胶带:设置方法:(1)设置起绕点:——————工程师/作业员————此时显示界面上的灯亮,歩序处显示“1”(开始设置第一个步骤的起绕点)。
