路虎揽胜发动机故障码
路虎故障代码中英文对照
路虎故障代码中英文对照————————————————————————————————作者: ————————————————————————————————日期：ﻩ路虎故障代码中英文对照1、CHECK SＰAＲE TＹRＥPRESSURＥ(备胎胎压降到警告状态检查备胎胎压)ﻫ２、COOLINＧＳYSTEM ＦAＵLT MOＮIＴＯRＧAUGE（防冻液液位低停车检查防冻液液位)液液位)3、CRUＩSE CANＣEＬLED(驾驶员关闭巡航定速功能不需要）4、CRUISE NOTＡVＡILABＬE（系统故障)５、CRUＩSE CＯNTROL NOT PERMIＴTED(系统故障或车辆操作的参数超出正常巡航操作值）6、CRＵＩSEGAP（自适应巡航系统距离设定、时间间隔调整,调速需要的距离)7、DRＩVEＲOVＥＲRIDＥ(在巡航定速时,驾驶员踩下油门踏板不需要任何操作.当油门松开时信息将会消失，巡航将会恢复)８、ＤOORＭＩＲＲＯRDIＰＳTORED（记忆系统确认已存储驾驶员信息不需要）9、DRIＶERINTＥRＶENE(紧急警告,需要驾驶员踩刹车如果需要,请踩刹车）10、DＲIVEＲOVER SPEED SＥT CLＥＡR(旅行电脑信息不需要任何操作)11、DRIVER’SDOＯROPEN（驾驶员侧门打开或没关严关闭驾驶员侧门）12、ＤSC SＷITＣHＥD OＦF(系统不可用）1３、ENＧIＮE SYＳTEＭFAULＴ(发动机管理系统存有一系列故障可能降低发动机性能避免高速行驶，并联系授权经销商）１4、ENGINＥＳYＳTEM SERVICE REQＵIＲED（保养时间已到达，车辆需要保养尽快保养）15、FＷD ALERT ON(ＯR ＯFF)(前向警告系统功能打开(或关闭)1６、FWＤＡLERＴ?—?(前向警告系统灵敏度调节调节需要的灵敏度，四种设定)17、ＦＡSＴEN SEＡＴBELＴS(请您系好安全带）18、FRＯNT ＬEＦT TＹRE RＥS SＵRE NOT MＯNＩTORED(你可能在该位置安装了一个备胎,或者胎压检测传感器失灵,因为你可能安装了一个未授权的附件,影响了胎压检测系统工作，又或者你安装的车轮上没有传感器.把车速降到80ＫＭ/小时,并尽快更换一个完整充气轮胎,或者尽快联系授权维修经销商）１9、ＦRONT LＥFＴTYRE PＲESSUＲE TOO ＨIＧＨ（行驶中的右前轮胎胎压过高调整到正常胎压)２0、FRＯNT ＬEFT TYRE PRESＳURE ＶEＲYLOＷ（行驶中的右前轮胎胎压过低调整到正常胎压）２１、FUEL USAGE UNITS（燃油使用的单位）22、ＧRASS GRAＶＥL SＮＯＷ(如果将旋钮保持在此位置,你将启动全地形系统的该特殊程序不需要任何操作。
2022年捷豹路虎发现运动混动版发动机故障灯常亮
332023/11·汽车维修与保养文/浙江 蔡永福2022年捷豹路虎发现运动混动版故障现象一辆2022年生产的捷豹路虎发现运动插电混动版，搭载AJ20型1.5T 三缸发动机，VIN码为L2CHA2B79NG15***，行驶里程为1 123km，该车发动机故障灯常亮。
故障诊断与排除接车后，首先验证故障现象。
启动车辆，发现仪表台上的发动机故障灯常亮(图1)。
上路试车，未见其他异常。
询问车主得知，由于暂未安装家用充电桩，第一次在外公共的充电桩充电后启动车辆时，就发现仪表台上的发动机故障灯常亮。
而且，车主确认在充电之前，仪表台上的发动机报警灯未点亮。
另外，车主还反映，车载娱乐系统显示屏出现过一次黑屏的情况，但重新启动后又自动恢复正常了。
图1 故障车仪表台上的发动机故障灯检查车辆，未发现该车有任何加装或改装；查询维修记录，该车之前未进行过任何维修； 查询技术网站，未发现任何与故障车型相关的技术公告和服务活动。
使用诊断电脑PF对故障车进行全车扫描，发现系统内存有多个故障码(图2)：U006487-车辆通信总线E消息缺失；U008087-车辆通信总线F消息缺失；B130002-音频输出A一般信号故障；B156119-座椅高度调节电机驱动[B1561]电路电流高于限值；U004681-车辆通信总线C接收到无效串行数据。
在上述这些故障码中，没有一个故障码与发动机故障灯点亮是相关的，因此笔者推测可能是该车使用了非授权的充电桩而导致发动机故障灯点亮。
使用诊断电脑清除所有故障码后重新进行全车扫描，系统内未再发现无任何故障码，且仪表台上的发动机故障灯也不再点亮。
交车时，建议车主不要使用非捷豹路虎授权的充电桩进行充电，同时在用车时留心观察，发现任何异常时，请及时返厂检修。
一周后，该车再次进店，车主反映仪表台上的发动机故障灯再次点亮，并且这次车辆没有进行过任何充电，故障灯也是在车辆启动时点亮的。
再次使用诊断电脑PF进行全车扫描，得到的故障码与上次基本相同，依旧存有故障码 U0064-87和U0080-87，但仍然未发现与发动机故障灯点亮有关的故障码。
2018年捷豹路虎揽胜行驶中耸车且多个报警灯点亮
文/浙江 蔡永福2018年捷豹路虎揽胜故障现象一辆2018年生产的捷豹路虎揽胜，搭载SCV6Petrol型3.0L发动机，VIN码为SALGA3BV6JA39****，行驶里程为77 036km，据车主反映，在行驶过程中该车变速器突然出现明显冲击，随即仪表台上出现“HDC不可用”“稳定控制不可用”“自适应动态不可用”等故障提示信息，但车辆仍可正常行驶。
出现这种情况后，车主马上靠边停车，并熄灭发动机，之后再按点火开关尝试启动时发现发动机无法启动，但挡把上的P挡指示灯正常点亮，仪表台上仍然显示着上述故障提示信息。
锁车大约10min后车主再次尝试启动，发动机顺利启动，且车辆恢复正常。
此时，车主不敢再次熄灭发动机，担心无法再次启动，并直接将故障车开到店内进行检修。
故障诊断与排除接车时，发动机处于正常运转状态，查看仪表台，发现“HDC不可用”“稳定控制不可用”“自适应动态不可用”等故障提示信息一直在显示，同时多个报警灯点亮(图1)，但未见其他明显异常。
另外，换挡杆上的指示灯显示正常，重新挂挡，车辆依旧行驶正常。
熄火后重新点火，发动机启动正常，未出现车主担心的熄火后无法启动的情况。
查看车辆，未发现任何加装或改装，查阅技术网站，未发现相关的技术公告和服务活动。
询问车主得知，该车同样的故障大约一周出现一次，故障出现时马上熄火就会出现发动机无法再次启动的情况。
连接诊断电脑PF，发现故障车内存有大量故障码，其中，与故障现象相关的故障码(图2)有：U029187-与换挡模块B的通信中断，消息缺失；U010187-与变速器控制模块的通信丢失，消息缺失；U004687-车辆通信总线C消息缺失；U004681-车辆通信总线C接收到无效串行数据；U004682-车辆通信总线C活动/顺序计数器不正确，未更新；U008088-车辆通信总线F总线断开；U008082-车辆通信总线F活动/顺序计数器不正确，未更新；U010100-与变速器控制模块的通信丢失，没有任何子类型信息；U040382-接收到来自分动箱控制模块的无效数据，活动/顺序计数器不正确，未更新；U010287-与分动箱控制模块的通信丢失，消息缺失。
路虎 故障码
路虎故障码路虎（LANDROVER）自定义故障码P0101 Mass Air Flow Sensor Signal Error FaultP0102 Mass Air Flow Sensor Low Out of Range FaultP0103 Mass Air Flow Sensor High Out of Range FaultP0111 Air Temperature Sensor Signal Error FaultP0112 Air Temperature Sensor Low Out of Range FaultP0113 Air Temperature Sensor High Out of Range FaultP0116 Engine Coolant Temperature Sensor Falling Temp FaultP0117 Engine Coolant Temperature Sensor Low Out of Range Fault P0118 Engine Coolant Temperature Sensor High Out of Range Fault P0121 Throttle Position Sensor Output Signal Error FaultP0122 Throttle Position Sensor Low Out of Range FaultP0123 Throttle Position Sensor High Out of Range FaultP0125 Engine Coolant Temp Sensor Warm Up FaultP0130 Oxygen Sensor Cycle Fault *Code s* A UP0131 Oxygen Sensor Low Volt age *Codes* A UP0132 Oxygen Sensor High Voltage *Codes* A UP0133 Oxygen Sensor Slow Response *Codes* A UP0136 Oxygen Sensor Cycle Fault *Codes* A DP0137 Oxygen Sensor Low Voltage *Codes* A DP0138 Oxygen Sensor High Voltage *Codes* A DP0139 Oxygen Sensor Slow Response *Codes* A DP0150 Oxygen Sensor Cycle Fault *Codes* B UP0151 Oxygen Sensor Low Voltage *Codes* B UP0152 Oxygen Sensor High Voltage *Codes* B UP0153 Oxygen Sensor Slow Response *Codes* B UP0156 Oxygen Sensor Cycle Fault *Codes* B DP0157 Oxygen Sensor Low Voltage *Codes* B DP0158 Oxygen Sensor High Voltage *Codes* B DP0159 Oxygen Sensor Slow Response *Codes* B DP0171 Oxygen Sensor System Too Lean Fault Bank AP0172 Oxygen Sensor System Too Rich Fault Bank AP0174 Oxygen Sensor System Too Lean Fault Bank BP0175 Oxygen Sensor System Too Rich Fault Bank BP0181 Fuel Temperature Sensor Signal Error FaultP0182 Fuel Temperature Sensor Low Out of Range FaultP0183 Fuel Temperature Sensor High Out of Range FaultP0201 Injector 1 Circuit FaultP0202 Injector 2 Circuit FaultP0203 Injector 3 Circuit FaultP0204 Injector 4 Circuit FaultP0205 Injector 5 Circuit FaultP0206 Injector 6 Circuit FaultP0207 Injector 7 Circuit FaultP0208 Injector 8 Circuit FaultP0300 Misfire On Multiple CylinderP0301 Misfire Cylinder 1P03O2 Misfire Cylinder 2P03O3 Misfire Cylinder 3P0304 Misfire Cylinder 4P0305 Misfire Cylinder 5P0306 Misfire Cylinder 6P0307 Misfire Cylinder 7P0308 Misfire Cylinder 8P0326 Continuous Knock Fault Bank AP0327 Bac kground Noise Low Fault Bank AP0328 Background Noise High Fault Bank AP0331 Continuous Knock Fault Bank BP0332 Background Noise Low Fault Bank BP0333 Background Noise High Fault Bank BP0335 Crankshaft Position Sensor Signal Error FaultP0336 Crankshaft Position Sensor Out of Range FaultP0340 Camshaft Position Sensor Signal Error FaultP0420 Catalyst Efficiency Low Fault Bank AP0430 Catalyst Efficiency Low Fault Bank BP0441 Evap Purge Valve Incorrect Flow FaultP0442 Evap System Small Leak Detected FaultP0443 Evap Purge Valve Open or Short Circuit FaultP0451 Fuel Tank Pressure Sensor Signal Error FaultP0452 Fuel Tank Pressure Sensor Low out of Range Fault P0453 Fuel Tank Pressure Sensor High Out of Range Fault P0461 Fuel Tank Level Measurement Not Valid FaultP0500 Vehicle Speed Sensor Signal Error FaultP0506 Idle Speed Control Engine Speed Low FaultP0507 Idle Speed Control Engine Speed High FaultP0560 Battery Voltage Below Minimum FaultP0562 Measurement Circuit OK Battery Voltage Low Fault P0563 Battery Voltage Above Maximum FaultP0605 ECM Self Test FaultP1130 Oxygen Sensor Fuel Trim at Limit *Codes* A UP1131 Oxygen Sensor Engine Lean *Codes* A UP1132 Oxygen Sensor Engine Rich *Codes* A UP1137 Oxygen Sensor Engine Lean *Codes* A DP1138 Oxygen Sensor Engine Rich *Codes* A DP1150 Oxygen Sensor Fuel Trim at Limit *Codes* B UP1151 Oxygen Sensor Engine Lean *Codes* B UP1152 Oxygen Sensor Engine Rich *Codes* B UP1157 Oxygen Sensor Engine Lean *Codes* B DP1158 Oxygen Sensor Engine Rich *Codes* B DP1171 Oxygen Sensor System Too Lean Fault Banks A & BP1172 Oxygen Sensor System Too Rich Fault Banks A & BP1176 Maximum Positive FMFR Correction FaultP1177 Maximum Negative FMFR Correction FaultP1178 Maximum Positive AMFR Correction FaultP1179 Maximum Negative AMFR Correction FaultP1185 Oxygen Sensor Heater Circuit Open UpstreamP1186 Oxygen Sensor Heater Circuit Short UpstreamP1187 Oxygen Sensor Heater Circuit Short UpstreamP1188 Oxygen Sensor Heater High Resistance UpstreamP1189 Oxygen Sensor Heater Type 1 Low Resistance UpstreamP1190 Oxygen Sensor Heater Type 2 Low Resistance UpstreamP1191 Oxygen Sensor Heater Circuit Open DownstreamP1192 Oxygen Sensor Heater Circuit Short DownstreamP1193 Oxygen Sensor Heater Circuit Open DownstreamP1194 Oxygen Sensor Heater High Resistance DownstreamP1195 Oxygen Sensor Heater Type 1 Low Resistance Downstream P1196 Oxygen Sensor Heater Type 2 Low Resistance Downstream P1199 Fuel Level Sensor Circuit FaultP1201 Injector 1 Open Circuit or Ground Short FaultP1202 Injector 2 Open Circuit or Ground Short FaultP1203 Injector 3 Open Circuit or Ground Short FaultP1204 Injector 4 Open Circuit or Ground Short FaultP1205 Injector 5 Open Circuit or Ground Short FaultP1206 Injector 6 Open Circuit or Ground Short FaultP1207 Injector 7 Open Circuit or Ground Short FaultP1208 Injector 8 Open Circuit or Ground Short FaultP1313 Misfire Catalyst Damage Fault Bank AP1314 Misfire Catalyst Damage Fault Bank BP1315 Misfire Persistent FaultP1316 Misfire Excessive Emissions FaultP1317 ABS Rough Road Line Low FaultP1318 ABS Rough Road Line High FaultP1361 No Ignition Coil Activation Fault Coil 1P1362 No Ignition Coil Activation Fault Coil 2P1363 No Ignition Coil Activation Fault Coil 3P1364 No Ignition Coil Activation Fault Coil 4P1371 Early Ignition Coil Activation Fault Coil 1P1372 Early Ignition Coil Activation Fault Coil 2P1373 Early Ignition Coil Activation Fault Coil 3P1374 Early Ignition Coil Activation Fault Coil 4P1440 Evap System Purge Valve Stuck Open FaultP1441 Evap System Purge Valve Flow 1 FaultP1442 Evap System Purge Valve Blocked FaultP1447 Evap System Purge Valve Open or Short Circuit Fault P1448 Evap System Purge Valve Flow 2 FaultP1508 Idle Speed Control Open Circuit FaultP15O9 Idle Speed Control Short Circuit FaultP1514 Neutral Drive Load FaultP1516 Neutral Drive Gear Change FaultP1517 Neutral Drive Cranking FaultP1607 Malfunction Indicator Lamp Short Circuit FaultP1608 Malfunction Indicator Lamp Open Circuit FaultP1620 Reprogramming Code Learn FaultP1621 Serial Data Link Dead FaultP1622 Repeated Wrong ECM Security Code FaultP1623 ECM Security Code FaultP1701 Transfer Box Line FaultP1703 Transfer Box Line Open Circuit FaultP1708 Transfer Box Line Short Circuit FaultP1775 Gearbox FaultP1776 Gearbox Ignition Retard Request Timeout FaultP1777 Gearbox Ignition Retard Request Line Fault。
路虎故障代码中英文对照
路虎故障代码中英文对照1、CHECK SPARE TYRE PRESSURE(备胎胎压降到警告状态检查备胎胎压)2、COOLING SYSTEM FAULT MONITOR GAUGE(防冻液液位低停车检查防冻液液位)液液位)3、CRUISE CANCELLED(驾驶员关闭巡航定速功能不需要)4、CRUISE NOTAVAILABLE(系统故障）5、CRUISE CONTROL NOT PERMITTED（系统故障或车辆操作的参数超出正常巡航操作值）6、CRUISEGAP（自适应巡航系统距离设定、时间间隔调整，调速需要的距离）7、DRIVER OVERRIDE（在巡航定速时,驾驶员踩下油门踏板不需要任何操作.当油门松开时信息将会消失,巡航将会恢复）8、DOORMIRRORDIPSTORED（记忆系统确认已存储驾驶员信息不需要）9、DRIVERINTERVENE（紧急警告,需要驾驶员踩刹车如果需要,请踩刹车）10、DRIVER OVER SPEED SET CLEAR（旅行电脑信息不需要任何操作）11、DRIVER’SDOOROPEN（驾驶员侧门打开或没关严关闭驾驶员侧门）12、DSC SWITCHED OFF（系统不可用）13、ENGINE SYSTEM FAULT（发动机管理系统存有一系列故障可能降低发动机性能避免高速行驶,并联系授权经销商）14、ENGINE SYSTEM SERVICE REQUIRED（保养时间已到达,车辆需要保养尽快保养）15、FWD ALERT ON(OR OFF)（前向警告系统功能打开(或关闭)16、FWDALERT?—?（前向警告系统灵敏度调节调节需要的灵敏度，四种设定）17、FASTEN SEATBELTS（请您系好安全带）18、FRONT LEFT TYRE RES SURE NOT MONITORED（你可能在该位置安装了一个备胎,或者胎压检测传感器失灵,因为你可能安装了一个未授权的附件,影响了胎压检测系统工作,又或者你安装的车轮上没有传感器.把车速降到80KM/小时,并尽快更换一个完整充气轮胎,或者尽快联系授权维修经销商）19、FRONT LEFT TYRE PRESSURE TOO HIGH（行驶中的右前轮胎胎压过高调整到正常胎压）20、FRONT LEFT TYRE PRESSURE VERYLOW（行驶中的右前轮胎胎压过低调整到正常胎压）21、FUEL USAGE UNITS（燃油使用的单位）22、GRASS GRAVEL SNOW（如果将旋钮保持在此位置,你将启动全地形系统的该特殊程序不需要任何操作。
路虎故障代码中英文对照
路虎故障代码中英文对照1、CHECK SPARE TYRE PRESSURE(备胎胎压降到警告状态检查备胎胎压)2、COOLING SYSTEM FAULT MONITOR GAUGE(防冻液液位低停车检查防冻液液位)液液位)3、CRUISE CAN CELLED(驾驶员关闭巡航定速功能不需要)4、CRUISE NOTAVAILABLE(系统故障）5、CRUISE CONTROL NOT PERMITTED（系统故障或车辆操作的参数超出正常巡航操作值）6、CRUISEGAP（自适应巡航系统距离设定、时间间隔调整，调速需要的距离）7、DRIVER OVERRIDE（在巡航定速时,驾驶员踩下油门踏板不需要任何操作.当油门松开时信息将会消失,巡航将会恢复）8、DOORMIRRORDIPSTORED（记忆系统确认已存储驾驶员信息不需要）9、DRIVERINTERVENE（紧急警告,需要驾驶员踩刹车如果需要,请踩刹车）10、DRIVER OVER SPEED SET CLEAR（旅行电脑信息不需要任何操作）11、DRIVER’SDOOROPEN（驾驶员侧门打开或没关严关闭驾驶员侧门）12、DSC SWIT CHED OFF（系统不可用）13、ENGINE SYSTEM FAULT（发动机管理系统存有一系列故障可能降低发动机性能避免高速行驶,并联系授权经销商）14、ENGINE SYSTEM SERVICE REQUIRED（保养时间已到达,车辆需要保养尽快保养）15、FWD ALERT ON(OR OFF)（前向警告系统功能打开(或关闭)16、FWD ALERT?—?（前向警告系统灵敏度调节调节需要的灵敏度，四种设定）17、FASTEN SEATBELTS（请您系好安全带）18、FRONT LEFT TYRE RES SURE NOT MONITORED（你可能在该位置安装了一个备胎,或者胎压检测传感器失灵,因为你可能安装了一个未授权的附件,影响了胎压检测系统工作,又或者你安装的车轮上没有传感器.把车速降到80KM/小时,并尽快更换一个完整充气轮胎,或者尽快联系授权维修经销商）19、FRONT LEFT TYRE PRESSURE TOO HIGH（行驶中的右前轮胎胎压过高调整到正常胎压）20、FRONT LEFT TYRE PRESSURE VERYLOW（行驶中的右前轮胎胎压过低调整到正常胎压）21、FUEL USAGE UNITS（燃油使用的单位）22、GRASS GRAVEL SNOW（如果将旋钮保持在此位置,你将启动全地形系统的该特殊程序不需要任何操作。
路虎揽胜发动机故障码
路虎揽胜V8发动机故障码ENGINE MANAGEMENT SYSTEM –V8Engine Management P CodesP Code No. Component/Signal Fault Description0010 LH bank CMP sensor Signal malfunction0011 LH bank CMP sensor Timing over-advanced or system performance 0012 LH bank CMP sensor Timing over-retarded0020 RH bank CMP sensor Signal malfunction0021 RH bank CMP sensor Timing over-advanced or system performance 0022 RH bank CMP sensor Timing over-retarded0030 LH bank front HO2S heater circuit Circuit intermittent0031 LH bank front HO2S heater circuit Short circuit to ground0032 LH bank front HO2S heater circuit Short circuit to battery0036 LH bank rear HO2S heater circuit Circuit intermittent0037 LH bank rear HO2S heater circuit Short circuit to ground0038 LH bank rear HO2S heater circuit Short circuit to battery0050 RH bank front HO2S heater circuit Circuit intermittent0051 RH bank front HO2S heater circuit Short circuit to ground0052 RH bank front HO2S heater circuit Short circuit to battery0056 RH bank rear HO2S heater circuit Circuit intermittent0057 RH bank rear HO2S heater circuit Short circuit to ground0058 RH bank rear HO2S heater circuit Short circuit to battery0102 MAF sensor signal Short circuit to ground0103 MAF sensor signal Short circuit to battery0106 ECM internal ambient pressure sensor Performance problem0107 ECM internal ambient pressure Short circuit to ground0108 ECM internal ambient pressure Open circuit or short circuit to battery0112 IAT sensor Short circuit to ground0113 IAT sensor Open circuit or short circuit to battery0114 Ambient temperature input Fault data received0116 ECT sensor Signal implausible0117 ECT sensor Short circuit to ground0118 ECT sensor Open circuit or short circuit to battery0120 APP sensor switch A Implausible0121 APP sensor switch A Range/ Performance problem0122 APP sensor switch A Open circuit or short circuit to ground0123 APP sensor switch A Short circuit to battery0125 ECT sensor Insufficient coolant temperature for closed loop control0128 Thermostat monitoring sensor Low coolant temperature –thermostat stuck open 0130 LH bank front HO2S signal Circuit malfunction0131 LH bank front HO2S signal Short circuit to ground0132 LH bank front HO2S signal Short circuit to battery0133 LH bank front HO2S signal Slow response0134 LH bank front HO2S signal No activity0135 LH bank front HO2S heater circuit Circuit malfunction0136 LH bank rear HO2S signal Circuit malfunction0137 LH bank rear HO2S signal Short circuit to ground0138 LH bank rear HO2S signal Short circuit to battery0139 LH bank rear HO2S signal Slow response0140 LH bank rear HO2S signal No activity0141 LH bank rear HO2S heater circuit Circuit malfunction0150 RH bank front HO2S signal Circuit malfunction0151 RH bank front HO2S signal Short circuit to ground0152 RH bank front HO2S signal Short circuit to battery0153 RH bank front HO2S signal Slow response0154 RH bank front HO2S signal No activity0155 RH bank front HO2S heater circuit Circuit malfunction0156 RH bank rear HO2S signal Circuit malfunction0157 RH bank rear HO2S signal Short circuit to ground0158 RH bank rear HO2S signal Short circuit to battery0159 RH bank rear HO2S signal Slow response0160 RH bank rear HO2S signal No activity0161 RH bank rear HO2S heater circuit Malfunction0171 LH bank lambda control Fuelling too lean0172 LH bank lambda control Fuelling too rich0174 RH bank lambda control Fuelling too lean0175 RH bank lambda control Fuelling too rich0201 Fuel injector 1 Open circuit0202 Fuel injector 2 Open circuit0203 Fuel injector 3 Open circuit0204 Fuel injector 4 Open circuit0205 Fuel injector 5 Open circuit0206 Fuel injector 6 Open circuit0207 Fuel injector 7 Open circuit0208 Fuel injector 8 Open circuit0221 APP sensor switch B Range/ Performance problem0222 APP sensor switch B Open circuit or short circuit to ground 0223 APP sensor switch B Short circuit to battery0231 Fuel pump motor drive Short circuit to ground0232 Fuel pump motor drive Short circuit to battery0233 Fuel pump motor drive Circuit fault0261 Fuel injector 1 Short circuit to ground0262 Fuel injector 1 Short circuit to battery0264 Fuel injector 2 Short circuit to ground0265 Fuel injector 2 Short circuit to battery0267 Fuel injector 3 Short circuit to ground0268 Fuel injector 3 Short circuit to battery0270 Fuel injector 4 Short circuit to ground0271 Fuel injector 4 Short circuit to battery0273 Fuel injector 5 Short circuit to ground0274 Fuel injector 5 Short circuit to battery0276 Fuel injector 6 Short circuit to ground0277 Fuel injector 6 Short circuit to battery0279 Fuel injector 7 Short circuit to ground0280 Fuel injector 7 Short circuit to battery0282 Fuel injector 8 Short circuit to ground0283 Fuel injector 8 Short circuit to battery0300 Misfire detection Random/Multiple cylinder misfire0301 Misfire detection Cylinder 1 misfire0302 Misfire detection Cylinder 2 misfire0303 Misfire detection Cylinder 3 misfire0304 Misfire detection Cylinder 4 misfire0305 Misfire detection Cylinder 5 misfire0306 Misfire detection Cylinder 6 misfire0307 Misfire detection Cylinder 7 misfire0308 Misfire detection Cylinder 8 misfire0324 Knock sensors Control system error0327 LH bank knock sensor 1 Short circuit to ground0328 LH bank knock sensor 1 Short circuit to battery0332 RH bank knock sensor 3 Short circuit to ground0333 RH bank knock sensor 3 Short circuit to battery0335 CKP sensor Signal implausible0340 LH bank CMP sensor Signal implausible0342 LH bank CMP sensor Short circuit to ground0343 LH bank CMP sensor Short circuit to battery0345 RH bank CMP sensor Signal implausible0347 RH bank CMP sensor Short circuit to ground0348 RH bank CMP sensor Short circuit to battery0370 Reference mark detection Timing reference high resolution signal A0411 SAI vacuum solenoid valve Incorrect flow detected0412 SAI vacuum solenoid valve drive Circuit malfunction0413 SAI vacuum solenoid valve drive Open circuit0414 SAI vacuum solenoid valve drive Short circuit0418 SAI air injection pump relay Open circuit0420 LH bank catalytic converter Efficiency below threshold –light off too long 0430 RH bank catalytic converter Efficiency below threshold –light off too long 0442 EV AP system Minor leak (1.0 mm or less)0443 Purge valve drive Circuit malfunction0444 Purge valve drive Open circuit0445 Purge valve drive Short circuit to battery or ground0455 EV AP system Major leak (more than 1.0 mm)0456 EV AP system Minor leak (0.5 mm or less)0461 Fuel tank level signal Range/Performance problem0462 Fuel tank level signal Short circuit to ground0463 Fuel tank level signal Short circuit to battery0464 Fuel tank level signal Circuit intermittent0491 SAI system Malfunction on LH bank0492 SAI system Malfunction on RH bank0500 Vehicle speed signal Signal implausible0501 Rough road detection vehicle speed signal Intermittent, erratic or high0503 Rough road detection vehicle speed signalRange/Performance0512 Comfort start Request circuit malfunction0530 A/C refrigerant pressure sensor Signal fault0532 A/C refrigerant pressure sensor Short circuit to ground0533 A/C refrigerant pressure sensor Short circuit to battery0561 Battery voltage monitor System voltage unstable0562 Battery voltage monitor System voltage low0563 Battery voltage monitor System voltage high0571 Brake lights switch Cruise control/brake switch circuit A0604 ECM self test RAM error0605 ECM self test ROM error0606 ECM self test Processor fault0615 Comfort start relay drive Open circuit0616 Comfort start relay drive Short circuit to ground0617 Comfort start relay drive Short circuit to battery0634 ECU internal temperature ECU temperature high0650 MIL output drive Open circuit, or short circuit to ground or battery0660 Manifold valve output drive Control circuit malfunction0661 Manifold valve output drive Open circuit or short circuit to ground0662 Manifold valve output drive Short circuit to battery0691 Engine cooling fan control Short circuit to ground0692 Engine cooling fan control Short circuit to battery0693 Engine cooling fan control Circuit intermittent0704 A/C compressor clutch switch Input circuit malfunction1000 DMTL pump motor drive Intermittent or short circuit to ground or battery 1102 Throttle position to mass air flowplausibility not active Air mass too small 1103 Throttle position to mass air flowplausibility not active Air mass too large 1117 Thermostat monitoring sensor Short circuit to ground1118 Thermostat monitoring sensor Open circuit or short circuit to battery 1120 APP sensor Implausible signals1121 APP sensor 1 Range/ Performance problem1122 APP sensor 1 Short circuit to ground1123 APP sensor 1 Short circuit to battery1129 HO2S Swapped sensors (LH to RH)1161 LH bank lambda control Adaption per ignition too small1162 LH bank lambda control Adaption per ignition too large1163 RH bank lambda control Adaption per ignition too small1164 RH bank lambda control Adaption per ignition too large1170 LH bank front HO2S signal Fuel trim malfunction1171 LH bank lambda control Adaption over time too large1172 LH bank lambda control Adaption over time too small1173 RH bank front HO2S signal Fuel trim malfunction1174 RH bank lambda control Adaption over time too large1175 RH bank lambda control Adaption over time too small1221 APP sensor 2 Range/ Performance problem1222 APP sensor 2 Short circuit to ground1223 APP sensor 2 Short circuit to battery1300 Misfire detection Catalyst damaging misfire1301 Misfire detection Multiple cylinder misfire1327 LH bank knock sensor 2 Short circuit to ground1328 LH bank knock sensor 2 Short circuit to battery1332 RH bank knock sensor 4 Short circuit to ground1333 RH bank knock sensor 4 Short circuit to battery1413 SAI air injection pump relay Short circuit to ground1414 SAI air injection pump relay Short circuit to battery1450 DMTL pump motor Reference current above limit1451 DMTL pump motor Reference current below limit1452 DMTL pump motor Reference current unstable1453 DMTL pump motor Changeover valve stuck1454 DMTL changeover valve drive Short circuit to battery1455 DMTL changeover valve drive Short circuit to ground1456 DMTL changeover valve drive Open circuit1481 DMTL heater output drive Signal intermittent1482 DMTL heater output drive Open circuit or short circuit to ground1483 DMTL heater output drive Short circuit to battery1488 DMTL pump motor drive Open circuit1489 DMTL pump motor drive Short circuit to ground1490 DMTL pump motor drive Short circuit to battery1522 Plausibility MSR intervention No activity1523 LH bank VCC control solenoid valve Short circuit to ground1524 LH bank VCC control solenoid valve Short circuit to battery1525 LH bank VCC control solenoid valve Open circuit1526 RH bank VCC control solenoid valve Open circuit1527 RH bank VCC control solenoid valve Short circuit to ground1528 RH bank VCC control solenoid valve Short circuit to battery1614 Electric thermostat heater drive Open circuit1615 Electric thermostat heater drive Short circuit to ground1616 Electric thermostat heater drive Short circuit to battery1619 5V reference voltage Internal reference voltage error1620 Comfort start input Engine crank signal error (request whileengine running)1621 Serial link with immobilisation ECU Timed out1623 Serial link with immobilisation ECU Exchange code in EEPROM failure1624 Serial link with immobilisation ECU EEPROM read/write failure1626 ECM, throttle monitoring/ self test Engine torque monitoring problem1630 ECM, throttle monitoring/ self test Throttle position control deviation1631 Throttle drive Motor power stage fault1632 ECM, throttle monitoring/ self test 'Limp home' position not adapted1633 ECM, throttle monitoring/ self test Throttle position control band stuck short1634 ECM, throttle monitoring/ self test Throttle position control band stuck long1635 ECM, throttle monitoring/ self test Control gain adaption error1638 ECM, throttle monitoring/ self test Throttle control range not learned1639 ECM, throttle monitoring/ self test Throttle motor spring test failed1645 CAN bus link with ABS ECU Timed out1646 CAN bus link with EA T ECU Timed out1647 CAN bus link with instrument pack Timed out1651 CAN bus link with transfer box ECU Timed out1659 ECM self test Torque monitor error1660 ECM self test Limp home monitor error1666 Serial link with immobilisation ECU Message parity bit fault (wrong code)1672 Serial link with immobilisation ECU Exchange code implausible1673 Serial link with immobilisation ECU No start code programmed1674 Serial link with immobilisation ECU Message fault1693 Serial link with immobilisation ECU False manipulation of start code by tester interface 1694 Serial link with immobilisation ECU Start code corrupted1700 Transfer box ECU Implausible signal1709 CAN bus link with transfer box ECU Message information error。
捷豹路虎故障3则
空调状态不佳的维修指引
涉及车辆：2016年款路虎发现运动版及路虎揽胜极光车型。
通 报 内 容 ：上 述 部 分车 型 在 使 用 过 程中出 现 无 法 制 冷 的 故 障。维修人员试车发现，在空调压缩机（A /C）打开情况下，通风 口仍吹送热风。经过检查分析，故障是由于在更换空调接头保护 盖时，空调压缩机（A /C）进气口或出风口的O形密封圈损坏。当 出现此类问题时，按照如下方式进行检查及维修。
针对路虎第四代发现（L319）、路虎揽胜运动版(L320)及 路虎揽胜(L322)车型采用如下维修方法。
（1）本程序要求加载DVD145.08和校准文件240或更高版本。 （2）打开点火开关（发动机未运转）。 （3）将故障诊断仪连接至车辆并开始新的诊断会话。
（4）按照提示读取车辆识别码，并启动数据收集序列。 （5）在会话类型中选择“诊断”。 （6）如果此时没有超链接弹出，可通过以下方式找到应用 程序。 ①选择“选定的症状”会话类型。 ②依照步骤选择动力传动系统——发动机系统——无法起 动，或电气——仪表——信息中心——信息显示屏——动力传动 系统。 （7）选择“继续”，随后选择“建议”。 （8）从“建议”选项中，选择“运行”已执行“防盗-未找到智 能钥匙”选项。
（6）拆下并弃用2个A /C压缩 机 进气管O形密封圈（图2）。 （7）安装2个全新的进气口密封圈，零件号为LR054870。 （8）安装压缩机进气口，在安装前必须拆下封口盖并且安装 扭矩为25 N·m（图3）. （9）拆下A /C压 缩 机出口管路，在拆除前 确 保 所有开口密 封 完好，并使用新堵盖（图4） （10）拆除并弃用所有压缩机出口管路O形密封圈（图5）。 （11）安装2个 全新压缩机出口管路O形密封圈。零件号为 LR054871。 （12）安装压缩机出口管路，安装扭矩为25 N·m。在安装前 必须拆下封口盖（图6）。 （13）安装发动机下挡板。 （14）降下车 辆，随 后重新加注（A /C）系统至 正确的规格。
