软管内径确定方法(PARKER)
软管及总成的表示方法
软管及总成的表示方法一、DN值及DASH/SIZE值概念DN值是德国DIN标准所规定的软管标定尺寸，即软管的公称内径尺寸（毫米）。
例如DN值为10的软管即表示该软管的公称内径尺寸为10毫米。
DASH值也叫SIZE值，为美国SAE标准所规定的软管标定尺寸。
它是软管或接头规格尺寸（英寸）的缩写，实际上是省略了分母16的分子数。
例如一个DASH值为04的规格尺寸，软管或接头的实际公称尺寸是4/16或表示为1/4英寸。
DN值与DASH/SIZE值的对照关系如下：二、高压软管的表示方法：汉萨.福莱柯斯公司高压软管的表示方法为HD加上三位数字表示。
其中第一位数字代表软管钢丝加强层层数，第二、第三位数字代表DN值。
常州公司使用的高压软管目前只有三种形式，一种是DIN20022标准的2SN软管，中间有二层编织钢丝加强、工作介质为矿物油、工作温度为-40度－100度。
表示方法为HD200。
第二种是DIN20023标准的4SP软管，中间有四层缠绕钢丝加强、工作介质为矿物油。
工作温度为-40度－100度。
表示方法为HD400。
第三种是DIN20023标准的4SH软管，中间有四层高强度缠绕钢丝加强、工作介质为矿物油。
工作温度为-40度－100度。
表示方法为HD500。
需要说明的是HD500中的5并不代表钢丝加强层为五层。
例如：HD 206 其中HD＝高压软管2＝二层高张力钢丝编织层06＝DN值为6毫米例如：HD 420 其中HD＝高压软管4＝四层高强钢丝缠绕增强层20＝DN值为20毫米例如：HD 532 其中HD＝高压软管5＝四层高强缠绕钢丝增强层32＝DN值为32毫米三，扣压式套筒的表示方法：我公司使用的扣压式套筒共有二种形式。
一种是PHN套筒，扣压时不需剥去胶管外胶层。
另一种是PHD套筒，扣压时需剥去胶管外胶层。
汉萨.褔莱柯斯公司扣压式套筒的表示方法为PHN或PHD加上三位数字表示。
例如：PHN 206 其中PHN200＝不剥皮扣压式套筒适用胶管：HD100 ,HD200 ,KP2006＝DN值为6毫米例如：PHD 113 其中PHD100＝剥皮扣压式套筒适用胶管：HD100,KP100,KP200,KP200S,HD100T等13＝DN值为13毫米例如：PHD 420 其中PHD200＝剥皮扣压式套筒适用胶管：HD200,HD200S,HD200T,KP400,HD400等20＝DN值为20毫米三、接头的表示方法1、接头的表示方法汉萨.褔莱柯斯公司压力接头的表示方法由PN加一组数字及一组字母组成。
液压软管基本知识2
HPDE-GB_M06_Nr.20_27/07/98
FluidConnectors
派克订货信息
FluidConnectors
尺寸转换示例
DN(公称尺寸）-〉Size(划线规格) 例: 381 - 12.7 (size 08) 尺寸基准 = 16/16 = 1“ = 25.4mm
HPDE-GB_M06_Nr.30_27/07/98
1 CA 48 15-8
1 CA 48 15-8 1 CA 48 15-8
> 接头系列
HPDE-GB_M06_Nr.110_27/07/98
> 硬管连接尺寸 > 胶管内径 (划线规格)
FluidConnectors
订货信息
3. 胶管总成
例: F301SN CA CF 15 15 08 1000 ...F301SN CA CF 15 15 08 1000 ...- > F301SN CA CF 15 15 08 1000 ...- > F301SN CA CF 15 15 08 1000 ...- > F301SN CA CF 15 15 08 1000 ...- > F301SN CA CF 15 15 08 1000 ...- > F301SN CA CF 15 15 08 1000 ...- > F301SN CA CF 15 15 08 1000 ...- > F301SN CA CF 15 15 08 1000 ...- > F301SN CA CF 15 15 08 1000 ...- > F301SN CA CF 15 15 08 1000 ...- >
48
-15
硬管外径 (连接尺寸)
parker软管说明2
Parker软管使用说明尊敬的客户朋友：针对广大用户对CNG软管的使用方法、使用寿命、更换周期、更换条件等的迫切需求，我公司根据软管生产商的原英文使用说明翻译成中文使用说明，以便广大用户理解，有此说明书，就能更好的明确软管的使用方法和更换依据。
CNG软管CNG软管应用于天然气输送和加气机系统等。
最高使用温度为180F。
CNG软管不能运用于没有足够通风的局限空间。
注意：首先必须组装起来检漏，检漏遵从GAG规则。
具有明火处或者具有打火装置处，不能够使用。
检漏液体必须回清洗掉，软管上不得残留检漏液。
需更换条件包括：1. 有渗漏物；2. 软管上有膨胀气泡或者软点3. 过度磨损4. 破裂或者折损5. 纠结或拧捏6. 将软管置于超过180F(82.2C)或者低于-40F(-40C)7. 软管错位或者变形CNG软管符合ANSI/ISA NGV 4.2-1999 CSA 1.52-M99条款。
“CNG软管应用于天然气输送和加气机系统上”CNG软管主要参数如下：注意：特别注意软管应确保不被强行弯曲、缠绕或扭转。
应确保周围环境对软管与设备连接的有效保护应对软管进行每月至少一次的检查按照步骤，首先对软管外观进行检查，看有无破损，然后对软管进行耐压测试，看软管是否泄漏。
最后对软管进行导静电测试。
对软管没有可靠的保护装置，则不能使用软管。
✧不适当的选择或错误的使用该产品可能会导致人员伤亡和财产损失。
错误的使用包括触电以及由于高压泄露引起的表皮脱落、软管破裂、连接处松动或碾砸而引起的危险；✧在选择或使用这个产品之前，阅读和遵循这个标签以及公告4400-B.1的安全指导。
拨打电话330-296-2871或1-800-CPARKER索要安全指导书。
✧不要使软管在超过它的工作压力下工作：3CNG-3600psi 4CNG-4000psi 5CNG-5000psi.✧高速流动的液体流经软管可能会造成静电的增加。
在装配时，若软管不能通过电阻测试都必须立即更换。
Parker软管培训资料
软管尺寸规格－选择合理的流速
划线 －4 －5 －6 －8 －10 －12 －16 －20 －24 －32 规格
英制 1/4 5/16 3/8 1/2 5/8 3/4 1 尺寸
1-1/4 1-1/2 2
公制 6.4 7.9 9.5 12.7 15.9 19 尺寸
25.4 31.8 38.1 50.8
精品文档
温度－同时在高压和高温下工作的软管会 大大缩短使用寿命！
同时考虑介质温度和环境温度 同时考虑最高温度和最低温度 －40/+100C°- 381,481,371,731 －40/+125C°301,421,771/77C,781/78C
560, 590 －40/+150C°- 421H, 436 －55/+100C°- 301LT, 53LT, 55LT -50/ +230C° - 919 (2MPa)
精品文档
软管
软管接头
精品文档
软管总成
精品文档
软管的基本结构-钢丝编织软管
增强层
钢丝编织的夹角 －中位角－ 54°44“
外层
内层
精品文档
软管的基本结构－钢丝缠绕软管
钢丝缠绕的夹角 －中位角－ 54°44“
精品文档
软管的类别(按基本材料区分)
橡胶 软管（派克 HPD 产品 )
热塑 软管（派克PARFLEX 和
公制 6
8
10 12 15 20 25 32 40 50
公称
规格
英制 3/16 1/4 5/16 13/32 1/2 5/8 7/8 1-1/8 1-3/8 1-
当量
13/16
规格
划线规格－4＝4/16=1/4 (英制)
水管管径计算
水管管径计算水管管径是一个重要的参数，它直接影响着水流的速度、压力和流量。
无论是家庭用水还是工业生产，选择合适的水管管径都是至关重要的。
下面我将以人类的视角为您介绍水管管径的计算方法和相关知识。
我们需要了解什么是水管管径。
水管管径指的是水管的内径，通常以毫米（mm）为单位进行表示。
常见的水管管径有20mm、25mm、32mm、40mm等。
不同的应用场景和需求会选择不同的管径。
那么，如何确定合适的水管管径呢？通常情况下，我们会根据需要输送的水量来选择合适的管径。
一般来说，水管的内径越大，水流的速度就越慢，但可以输送更大的水量。
相反，内径越小，水流的速度就越快，但输送的水量较小。
在选择水管管径时，我们需要考虑以下几个因素：首先是输送水量的要求，即需要输送多少水量。
其次是水流的速度要求，比如对于家庭用水，我们希望水流稳定，不会出现断流或者漫流的情况。
再次是水管的材质和长度，不同材质和长度的水管对水流的阻力也不同。
针对不同的需求，我们可以参考一些经验公式来初步确定水管管径。
比如，对于家庭用水，一般可以按照每分钟3-5升的需求来选择管径。
对于工业生产，需要根据具体情况和工艺要求来确定。
还有一些专业的水力学计算方法可以用来精确计算水管管径，但这需要一定的专业知识和工具支持。
如果遇到复杂的情况或者有特殊需求，建议咨询专业的水管工程师或者相关机构。
选择合适的水管管径是确保正常供水和排水的重要因素。
在选择时我们需要考虑水量、水流速度、水管材质和长度等因素，并可以参考经验公式或者专业计算方法来确定。
最终目标是为用户提供稳定、高效的供水和排水系统。
Parker 工业水泥管产品简介与拉出图说明书
