测量工具中英文对照表

heodolite 经纬仪

Water Level 水位仪

Level Ruler 水平尺Casing gradienter

Coating thickness

Measurer 涂层测厚仪

Ultrasonic thickness

measurer 超声波测厚仪

Ultrasonic crack

detector 超声波裂纹测试仪

Digital thermometer 数字温度计

radiation thermometer 辐射温度计

Gradient Reader 坡度读数器

Volometer 万用表MegaOhmmeter 兆欧表

Earthing resistance

Reader 接地电阻读数表Plug gauge 圆柱塞规Magnifying glass 放大镜Plummet 铅锤Profile projector 投影仪

Pin Gauge 针规(不知道和plug gauge 的区别在哪里,知道的请指正)

Gauge block 块规

Bore gauge 百分表

A vernier caliper 游标卡尺

Coordinate Measureing Machine(CMM) 三尺元

Pressure gague寸压力计

电度厚度测试仪(Electroplating THK.Tester)

转(扭)力仪(Twisting Meter)

螺纹规(Thread Gauge)

块规(Block Gauge)

环规(Ring Gauge)

力矩计(Torque Meter)

塞规(Plug gage)

高度仪(Altitude gauge)

塞尺/间隙规(Clearance gauge)

千分卡尺(Micrometer Calipers )

“过” -- “不过” 验规(通-止规) [go-no-go gauge]

游标卡尺(Vernier Caliper)

电子卡尺(Digital caliper)

深度千分尺(Depth Micrometer)

销(针)规(Pin Gauge)

投影仪(Projector )

数字高度测量仪(Digital Height Gauge)

表面处理测试仪(Surface Finish Tester)

内/外径千分尺(Inside/outer Micrometer)

洛(威)氏硬度仪[(HRC/HV) Hardness Tester)]

温度计(Thermometer)

孔规(Bore Gauge)

电子称(Electric/digital Balance)

三坐标测试仪 (CMM)

万用表(Multimeter)

1.刀口型直尺:knife straigjht edge

2.刀口尺: knife straigjht edge

3.三棱尺three edges straigjht edge

4.四棱尺four edges straigjht edge

5.条式和框式水平仪

bar form and square levels

6.合像水平仪 imaging level meter

7铸铁平板 cast iron surface plate 8.岩石平板 granite surface plate

9.铸铁平尺cast iron straigjht edge

10.钢平尺和岩石平尺

steel and granite straigjht edge

11.圆度仪 roundness measuring instrument

12.电子水平仪electronic level meter

13.表面粗糙度比较样块铸造表面roughness comparison specimens cast surface

14.表面粗糙度比较样块磨、车、铣、插及刨加工表面

roughness comparison

specimens-ground,turned,bored,mi lled,shape and planed

15.表面粗糙度比较样块电火花加工

表面

roughness comparison specimens spark-erostion machining surfaces

16.表面粗糙度比较样块抛光加工表

面

roughness comparison specimens pollshed surfaces

17.接触式仪器的标称特性

18.轮廓profiles

19.轨迹轮廓 traced profile

20.基准轮廓 reference profile

21.总轮廓 total profile

22.原始轮廓 primary profile

23.残余轮廓residual profile

24.触针式仪器stylus instrument

25.感应位移数字存储触针式量仪displacement sensitive,digitally storing stylus instrument

26.触针式仪器的部件stylus instrument components

27.测量环measurement loop

28.导向基准renfence guide

29.驱动器drive unit

30.测头(传感器)probe(pick-up)

31.拾取单元tracing element

32.针尖stylus tip

33.转换器transducer

34.放大器amplifier

35.模/数转换器analog-to-digital converter

36.数据输入data input

37.数据输出data output

38.轮廓滤波和评定profile

filtering and evaluation

39.轮廓记录器profile recorder

40.仪器的计量特性metrological characteristics of the instrument

41.静测力的变化change of static measuring force 42.静态测力 static measuring force

43.动态测量力 dynamic measuring force

44.滞后hysteresis

45.测头的测量范围 transmission function for the sine waves

46.仪器的测量范围measuring range of the instrument

47.模数转换器的量化步距quantization step of the ADC

48.仪器分辨力 instrument resolution

49.量程分辨力比

range-to-resolution ratio

50.测头线性偏差probe linearity deviation

51.短波传输界限short-wave transmission limitation

52.轮廓垂直成分传输 vertical profile component transmission

53表面粗糙度比较样块抛丸、喷砂加工表面

roughness comparison specimens shot blasted and blasted surfaces

54产品结构几何量计术规范（GPS）geometrical product

specifications(GPS)

55表面结构 surface texture
