电子海图题库(第三次修订版)

单选题（目前72个，未完待续）1.how do you get information on an ENC object(buoy-beacon-berth etc)on the FURUNO ECDIS?A.I right click on the use chart function in the route planning tool.B.I click on the chart info in the instant access batC.I enter click on the object.D.I right click on the object估计答案：D正确答案：2.where can you find a list of the manual updates that have been applied to the FURUNO ECDIS?A.in the chart legendB.In the manual update windowC.In the chart catalogueD.In the chart display menu估计答案：B正确答案：3.how can you see if a chart object i cteated using manual updates?A.the manual update will be larger than any other chart objectsB.It is always shown in redC.It will have a special orange markerD.There is no way i can see if a chart object is created using manual updates估计答案：C正确答案：4.How do you add navigation chart objects to the FURUNO ECDIS when you are require to do so by notices to mariners?A.i can not add any chart objects to the ECDIS unless they are included in the weekly updateB.I use the manual update functionC.I use the user chart functionD.I use the chart edit function估计答案：我估计选B 老大选D正确答案：5.how can you verity which route is being monitored?A.by clicking on the “route”and then on “route info”in the quickaccess sidebar in Plan modeB.The mame of the route will be displayed in the status barC.By clicking on “route”and then on “route info” in the quick access sidebar in Navi modeD.I can not get information on the route which is being monitored 估计答案：C正确答案：C6.where do you switch between multicolor and two color setting for the chart?A.in chart legendB.In symbol displayC.In basic settingD.In chart display估计答案：C 网上选C正确答案：C7.what should you remember to set up first when planning a route?A.the setting for the voyage logB.The alarm level in the operation submenuC.The safety contour in the route planing toolD.The radar overlay估计答案：C正确答案：C8.Which ECDIS setting is adjusted in ship and route parameters?A.chart alignment 排列图B.Safety contourC.Maximum rate of turn(MAX.R.O.T)D.Safety depth估计答案：C正确答案：C9.When do you use a manual update?A.always when i have to update my chartsB.When i receive information which must be displayed on my ECDIS and this is not yet included in the official weekly updatesC.I should never use manual updatesD.When i have to update the software of the ECDIS估计答案：B正确答案：10.How do you hide(not delete) a manual update objetc?A.i select clear from the manual update menuB.I select undo last from the manual update menuC.I deselect that general type of chart object in the chart display dialogueD.I deselect the option from the symbol display dialogue估计答案：A正确答案：11.Can you create a manual update from an AIS safety message shown on the ECDIS?A.yes-by manually creating the objectB.Yes-by letting the ECDIS creat the object antomaticallyC.Yes-either by creating it manually or letting the ECDIS create it automaticallyD.No估计答案：A正确答案：12.which recording function is available in the FURUNO ECDIS?A.gyro logB.Engine logC.Ship’s logD.Details log估计答案：D正确答案：D13.How do you update your vector charts on the FURUNO ECDIS using the ENC update CD?A.i use the autoload functionB.I cteate a manual update from the information on the CDC.I creat a user chartD.I import the information using the chart details function in the chart catalogue估计答案：A正确答案：14.can you edit the user chart when the ECDIS is in Navi mode?A.YesB.Only if the user chart is not linked to a route planC.Yes if the user chart contains no tidal informationD.No估计答案：D正确答案：15.Can you edit a route without removing it from the route monitoring function?A.NoB.Yes,but i must copy it to another ECDIS where it can be edited without interfering with the monitoring function of the FURUNO ECDISC.Yes,if i create a copy of the route plan in ANTS format on a USB and edit the file on a normal offrice PCD.Yes,if i select copy from monitor in the route plan menu and edit the copy.when copying is completed i select-exchange with monitor in the plan menu估计答案：D正确答案：16.Which operation can you perform on the FURUNO ECDIS?A.i can record my position manually on the ENCSB.I can set the ECDIS to automatically shoosing a safety contour based on my setting of ship’s maximum draftC.I can set ship’s maximum height to enable chart alerts from areas in charts where there is not sufficient air draftD.I can send a copy of my route plan to an AIS target as a safety message估计答案：C正确答案：17.which informatin can you find in VECTOR CHART LEGEND?A.T&P noticeC.WarningD.Safety contour setting估计答案：B正确答案：B18.Where do you select the color Palette(颜色暗淡模式)used to display the charts?A.in chart legendB.In chart displayC.In quick accessor barD.In chart catalogue估计答案：C 网上选C正确答案：C19.Which information can you find in the Raster Chart Legend?A.horizontal datumB.Safety depther permit numberD.License number估计答案：A正确答案：A20.Which information can you find in the Raster Chart Legend?A.shallow waterB.Chart nameC.Chart viewing dateD.Depth contour估计答案：B正确答案：B21.Which information can you find in the Vector Chart Legend?A.notice to marinerB.Presentation library edition numberC.Chart edition & update dateD.Safety contour setting估计答案：C正确答案：C22.How can you tell if your FURUNO ECDIS is displaying an ENC?A.there is an”ENC data available”indication in the own ship functions boxB.there is an”RNC data ”indication in the own ship functions boxC.The FURUNO ECDIS will give an audible alarm if i am not viewing an ENCD.There is no special indication in the own ship functions box估计答案：A 网上选D正确答案：23.How do you manually record Own Ship's current position in the Logs?A.by opening the voyage log and entering the current positionB.By right clicking on own ship icon on the use interfaceC.By press the record button on the control unitD.By using the record position event function of the event log估计答案：D正确答案：24.What is a Manual Update?A.A manual update is an update applied using the manual function in load & update chartsB.A manual update is an update to the charts created by the operator from information received from pilot-a navtex message-a VHF broadcast etc.C.A manual update is an update to the charts by an official representative of the chart producerD.A manual update is a chart created using the digitizer function of FURUNO ECDIS估计答案：B正确答案：25.What should you do if you have to leave your planned route during a voyage?A.switch off the FURUNO ECDIS and concentrate on the radarB.Disable the routing monitoring on the RURUNO ECDISC.Change the display of the FURUNO ECDIS to all IMO all otherD.Configue and enable the check area function to assis me in scaning the ENCS for danger to navigation and hazardous objects估计答案：D正确答案：26.Which operation can you perform(进行)on the FURUNOECDIS?A.I can record target ship’s position in the voyage log automaticallyB.I can record a position fix manually bu using just one distance and one bearingC.I can playback my past voyage track on the chartsD.I can send my route plan and user chart and notes to FURUNO GPS for displaying the GPS估计答案：C正确答案：27.Where can you change the settings for the Safety Contour used for monitoring?A.nowhere-because i must never change the setting for the safety contourB.In the setting menu and i can only change the setting if i have the service passwordC.In chart alertD.In the route planing tool估计答案：C正确答案：28.Which color scheme is used for a Manual update on the Furuno ECDIS?A.blue ENC symbolsB.standard ENC symbolsC.orange ENC symbolsD.red ENC symbols估计答案：C正确答案：29.Which setting can be changed in Sensors?A.log stabilization modeB.Safety contour settingC.Safety depth settingD.Kalmen filter setting估计答案：A正确答案：A30.Where do you change the Ship Outlines(轮廓)?A.in the quick access barB.In chart displayC.In symbol displayD.In the status bar估计答案：C正确答案：C31.Can you set the overall maximum speed for a route plan?A.yes in the ship and route parameters of menuB.In chart displayC.Yes in optimization parametersD.Yes in the route planing tool估计答案：A正确答案：A32.Which information can you find in the Vector Chart Legend?A.magtinec variationB.Base CD numberC.Permit expiration dateD.Safety contour setting估计答案：A正确答案：33.Where do you change the Velocity Vectors style?A.in the quick access barB.In chart displayC.In symbol displayD.In the status bar估计答案：C正确答案：C34.Where can you find information concerning the charts stored on the HDD(硬盘驱动器)?A.on the internetB.The chief officer will knowC.In the chart catalogueD.In the chart display menu估计答案：C 或D(可能性比较大) 网上选C正确答案：35.How do you document(记录) your previous voyage on the FURUNO ECDIS?A.I use my paper logbook as documentationB.I use my paper logbook and my VDR or SVDR as documentationC.I use the tracking function in the symbol displayD.I show a playback of my past voyage track on the charts估计答案：D正确答案：36.Which operation can you perform during a voyage or after completion of a voyage?A.i can use the record function to record special events in the voyage logB.I can create and save a screen shot(截屏) for future referenceC.I can view and print a copy of details logD.I can connect the ECDIS to the internat and upload all documentation to an external storage估计答案：A正确答案:37.Which information can you find in the Raster Chart Legend?A.magnetic variationB.Safety contour settingC.Quality of dataD.T&P notice估计答案：A正确答案: A38.How can you reset the odometer?A.I can reset the odometer from the voyage tab of the menuB.I can reset the odometer from the sensor setting dialogueC.I can reset the odometer from the symbol display dialogueD.I can reset the odometer from the quick access sidebar估计答案：A正确答案: A39.Can you plan a route while you monitor another route?A.NoB.Yes but only if i have two ECDISC.Yes the routing planing function is independent(不相关联的) from the route monitoring functionD.Yes but i must select the safety contour for both route plan估计答案：C正确答案: C40.Where do you find information on the software version of the FURUNO ECDIS?A.in the voyage logB.In the system dialogue of the menuC.In the about dialogueD.In the S52 presentation library(图书馆)估计答案：C正确答案: C41.How are loaded ENCs converted into SENCs when updating?A.the FURUNO ECDIS will normally convert(转变) the ENCs to SENCs automaticallyB.I must use the conversion tool（转变工具）from the menuC.I can not convert the ENCs to SENCsD.I load the new permit file using the file named ENC.PMT and then i use S52 presentation library from the system menu in the chart menu to convert the ENCs to SENCs估计答案：D正确答案:42.How do you add navigational chart objects to the FURUNO ECDIS when you are required to do so by information received via VHF broadcast?A.I can not add any chart objects to the ECDIS unless they areincluded in the weekly update CDB.I use the manual update functionC.I use the user chart functionD.I use the chart edit function估计答案：B(类似于第4题)正确答案:43.How do you switch from Vector chart to Raster chart on the FURUNO ECDIS?A.i select rather chart in the main menuB.I selet RNC in the chart legendC.I lelect raster chart from the drop down list in the status barD.I selet RNC in the chart catalogue估计答案：C正确答案: C44.Which operation can you perform after completion of a voyage?A.i can add additional records of manual positions to the voyage log adding further details to the past voyageB.I can cteate a user chart from the monitored route plan and save it to a USB memory deviceC.I can create a backup copy of the voyage plan on a USB memory deviceD.I can view and print a copy of the chart usage log(chart alert)估计答案：D正确答案: D45.What is the maximum limit of the Check Area?A.NO limitB.240min+20nm+5km+999mC.120min+10nm+3km+500mD.999min+999nm+999km+999m估计答案：B正确答案: B46.Which ECDIS setting is activated in Ship and Route Parameters?A.Gyro errorB.Safety contourC.Notes alarm timeD.Ship’s minimum speed估计答案：A正确答案: A47.Where do you offset own ship chart position on the FURUNO ECDIS?A.in symbol displayB.In chart displayC.In chart menuD.In own ship functions box估计答案：D正确答案: D48.Where do you set system priority of multiple GPS connected to the FURUNO ECDIS?A.In the sensor dialogueB.In basic setting.C.In ship and route parametersD.In nav tools估计答案：A正确答案: A49.Where do you change the Targets color?A.in the quick access barB.In chart displayC.In symbol dispalyD.In the status bar估计答案：C正确答案: C50.Where do you control the settings and visibility of the chart layers?A.in chart legendB.In symbol displayC.In chart displayD.In basic setting估计答案：C 网上选C正确答案:51.which manual update objects can be hidden from view by operatior selecrion?A.only the manual updates special area (from the chart display dialogue)B.All manual updates objects (from the chart display dialogue)C.Only the manual updates buoys (from the chart display dialogue)D.Only the manual updates sonding (from the chart display dialogue)估计答案：B正确答案:52.how do you switch the kalman filter on or off?A.the kalman filter is always switched on when a route is put into monitor mode and switched off when theres is no route being monitoredB.The kalman filter is always on so i never have to switch it on or offC.The kalman filter is swiched on or off in the sensor menu on theposition tabD.The kalman filter is switched on when steering is switched to autopilot估计答案：D正确答案:53.when the software of the FURUNO ECDIS is being updated-it is important that?A.the software is updated by a FURUNO service engineer（古野检修师）B.the software is updated by the captain（船长）C.the software is updated by the ship’s electrical engineer（老电）D.the software is updated by an IMO resentative（IMO 组织）估计答案：A(说明书中指出只能是人而不是单位组织，排除法) 正确答案:54.which operation can you perform with the FURUNO ECDIS?A.i can send my route plan and user chart to any RADAR for display on the RADARB.i can send my route plan and user chart to any AIS for display on the AISC.i can send my route plan and user chart to a ny GPS for display on the GPSD.i can send my route plan and user chart to a FURUNO RADARfor dispaly on the RADAR估计答案：D正确答案:55.Can you monitor a route even though it indicates an active alert when you have completed the route plan check?A.yes-the only thing preventing me from monitoring would be an impossible turn message in the WPT tabB.Yes-if i enter the service safety passwordC.NOD.IT depends on the type of alert generated(safety contour-restricted area-caution area etc)估计答案：C 或D(可能性较大)正确答案:56.how do you save your route to the HARD DISC DRIVE when is has been edited?A.i don’t.the route is automatically saved to the hard disc drive whenever changes are appliedB.I click on save or save as in the route planing toolC.I select save in the backup and restore dialogueD.I click new in the route planning tool估计答案：B正确答案:57.can you copy your manual updates from one FURUNO ECDIS to another?A.NoB.Yes-by using the backup and restore dialogue to transfer the manual updates to a USBC.Yes-by sending the manual updates via an emailD.No-but i can transfer them to another manufacturer’s type of ECDIS估计答案：A正确答案:58.Which recording function is available in the FURUNO ECDIS?A.danger target logB.Engine logC.Speed logD.GPS log估计答案：A正确答案:59.Where do you change the visibility of your Circles?A.in chart legendB.In symbol displayC.In chart displayD.In chart catalogue估计答案：B正确答案: B60.How do you start the route planning tool?A.i press plan on the control unitB.I click on the route icon in the status barC.I select route plan from the menu dialogueD.I click on route in the quick access bar估计答案：D正确答案:61.where can you updated the RNCs on the FURUNO ECDIS?A.in the update function of the menuB.In the chart manager(individual update)C.In the update function of the chart catalogueD.In the update function of the chart legend估计答案：B正确答案:62.how do you modify an existing manual updates object?A.I use the ENC tab of the chart maintenance functionB.I use the mariner tab of the symbol display functionC.I cannot modify a manual update-only delete itD.I use the list tab of manual update tool function估计答案：D正确答案:63.can you open the route planning tool when the ECDIS is in chart mode?A.yes if i open the menu dialogue firstB.Yes if i right click on the chart and select eventC.Yes if i select plan in the chart catalogueD.No估计答案：我选C(解释：chart mode 包括：PLAN{for the voyage planing mode,click the planing button followed by the route button to select a route or user chart button to selcet a user chart} 和NA VI)老大选D正确答案:64.how do you start the route planning tool?A.i press plan on the control unitB.I click on the route icon in the status barC.I select route plan from the menu dialogueD.I click on route in the quick access bar估计答案：我选D 老大选C正确答案:65.how do you record own ship’s position on the ECDIS charts when you have a range/bearing observation from your RADAR?A.i can not record own ship’s position manually on the FURUNO ECDISB.I record LOP in the record function of the event logC.I press the[TRL]&[ACQ/AC] button on the control unitD.I select[record][event log]and[user event]from the instant access bar and insert the observation in the record user event window估计答案：我选B(解释：LOP(line of position)a plotted line on which a vsl is located,determined by observation or measurement of the range or bearing to an aid to navigation or other charted element)老大选D正确答案:66.When the software of the FURUNO ECDIS is being updated-it is important that?A.the multiple GPS connected to the ECDIS are updated with the new software versionB.That it is done when the ECDIS in not being used for navigation(in port etc)C.The HUBs(解释：HUB是一个多端口的转发器，当以HUB为中心设备时，网络中某条线路产生了故障，并不影响其它线路的工作。
