CX4-120 Storage System Technical Specifications and Operating Limits

CX4-120Storage SystemTechnical Specifications andOperating LimitsJune24,2008This document lists the technical specifications,operating limits,andshipping and storage requirements for your storage system.The storage system consists of a storage processor enclosure(SPE),one or moredisk-array enclosures(DAEs),and a standby power supply(SPS).For descriptions of these components,refer to the CX4-120Storage System Hardware and Operational Overview.Some documents refer to the DAE as the DAE3P.Major topics are:SPE and DAE technical specifications (2)SPS technical specifications (8)SPE,DAE,and SPS operating limits (9)1SPE and DAE technical specificationsTechnical specifications include storage-system power requirements,size,drive,interface,and environment information.Power requirementsThe input current,power(VA),and dissipation per enclosure listedin this document are based on measurements of fully configuredenclosures under worst-case operating e the operatingmaximum values to plan the configuration of your storage system.These values represent either:the values for a single power supply line cord,orthe sum of the values shared by the line cords of the combinedpower supplies in the same enclosure,with the division between theline cords and supplies at the current sharing ratio(approximately50%each).A failure of one of the combined power supplies per enclosure resultsin the remaining power supply supporting the full load.You must usea rackmount cabinet or rack with appropriate power distribution,andhave main branch AC distribution that can handle these values foreach SPE and DAE in the cabinet.2Technical Specifications and Operating LimitsTable1CX4-120AC power specificationsRequirement DescriptionDevice electrical rating100to240V AC,50–60Hz,4.9–2.0A,single phaseAC line voltage tolerance Voltage±10%,frequency±3HzAC line current(operating maximum) 3.4A max at100V AC,1.7A max at200V ACPower consumption(operating maximum)340VA(260W)maxPower factor.98min at full load,low voltageHeat dissipation(operating maximum)9.36x105J/hr,(890Btu/hr)maxIn-rush current30A max for½line cycle,per line cord at240V AC15A max for½line cycle,per line cord at120V ACStartup surge current22A rms max for50ms,at any line voltageAC protection7.8A fuse on each power supply,both phasesAC receptacle IEC320-C14appliance coupler,per power zoneRide-through time30ms minCurrent sharing±15%of full load,between power suppliesTechnical Specifications and Operating Limits3Table2DAE AC power specificationsParameter ValueAC line voltage100to240V AC±10%,single phase47to63HzAC line current 3.8A at100V AC,1.9A at200V ACInternal power380VA(365W)max(fully configured–see note)consumptionPower factor0.98min at full load,low voltageHeat dissipation 1.31x106J/hr(1,250BTU/hr)maxIn-rush current50A max for1/2line cycle,per power supply at240V AC25A max for1/2line cycle,per power supply at120V ACStartup surge current15A pk(10.6A rms)max for100ms,at any line voltageAC protection10A fuse in each power supply,both phasesAC receptacle type IEC320-C14appliance coupler,per power supplyRide-through time30ms minCurrent sharing60%max,40%min,between power suppliesNote:Ratings assume a fully configured DAE3P that includes2power supplies,2LCCs,and15disk drives.4Technical Specifications and Operating LimitsDimensions and weightTable3CX4-120hardware dimensions and weightComponent Dimensions Vertical size Weight(see notes)2NEMA units23.81kg(52.5lb)SPE Height:8.90cm(3.50in)Width:44.50cm(17.50in)Depth:62.60cm(24.25in)3NEMA units30.8kg(68lb)with15disksDAE Height:13.34cm(5.25in)Width:45.0cm(17.72in)Depth:35.56cm(14.00in)1NEMA units21.3kg(47lb)Each SPS Height:4.02cm(1.58in)Width:42.1cm(16.5in)Depth:60.33cm(23.75in)Notes:Weights do not include mounting rails.Allow2.3-4.5kg(5-10lbs)for a rail set.Platform-specific power ratings are in theTechnical Specifications document for the product on the product’s support website,and include DC power ratings where appropriate.A fully configured DAE includes15disk drives.DAE drive typeThe DAE uses8.75cm(3.5in)by2.54cm(1.0in)disk drives.FibreChannel drives are12-volt,and support the Fibre Channel interface.SATA drives are12-and5-volt and support the SATA3Gb interface;apaddle card on the drive converts the assembly to12-volt Fibre Channeloperation.The EMC Storage Systems CX4Series Disk and FLARE OEMatrix on the EMC Powerlink website()lists the supported drives.SP optical cabling to Fibre Channel switch or serverOptical cables connect the small form-factor pluggable(SFP)moduleson the storage processors(SPs)to the external Fibre Channelenvironment.Technical Specifications and Operating Limits5Cable type Operating speed Length50µm1.0625Gb2m(6.6ft)min to500m(1,650ft)max2.125Gb2m(6.6ft)min to300m(985ft)max4Gb2m(6.6ft)min to150m(495ft)max1.0625Gb2m(6.6ft)min to300m(985ft)max62.5µm2.125Gb2m(6.6ft)min to150m(492ft)max4Gb2m(6.6ft)min to70m(231ft)maxNotes:All cables are multi-mode,dual LC with a bend radius of3cm(1.2in)min.The maximum length for either the62.5µm or50µm cable(noted inthe table above)includes two connections or splices between sourceand destination.CAUTIONEMC does not recommend mixing62.5μand50μm optical cables inthe same link.In certain situations you can add a50μm adapter cableto the end of an already installed62.5μm cable plant.Contact yourservice representative for details.6Technical Specifications and Operating LimitsSP-to-DAE and DAE-to-DAE copper cablingThe expansion port interface to the DAE is copper cabling.Thefollowing copper cables are available:Cable type LengthSFP-to-HSSDC2for SP-to-DAE2meters(6.6feet)5meters(16.5feet)HSSDC2-to-HSSDC2for DAE-to-DAE2meters(6.6feet)5meters(16.5feet)8meters(26.4feet)The cable connector is either a shielded SFP(small form-factorpluggable)module direct attach or an HSSDC2(high speed serial dataconnector),as detailed below:SP connector—Shielded,150Ωdifferential,shield-bonded to SFPplug connector shell(360°),SFF-8470150specification for SFPtransceiver.DAE connector—Shielded,150Ωdifferential,shield-bonded toplug connector shell(360°)FC-PI-2standard,revision13or laterfor HSSDC2.SP-to-SPS interface cablingThe SP-to-SPS interface meets the following specifications:Parameter Value or descriptionInterface Serial RS-232Baud rate9600baud,8bitParity NoneConnection Shielded mini DB-9to RJ-45Technical Specifications and Operating Limits7SPS technical specificationsThis section lists the technical specifications for the1U or2U standbypower supply.Table41U SPS power specificationsParameter ValueAC line voltage100to240V AC±10%,single-phase,47to63HzAC line current,internal and pass-through 0.10A max at100V AC,internal power consumption(Up to10A max at100V AC, pass-through to AC outlets)0.05A max at200V AC,internal power consumption(Up to6A max at200V AC, pass-through to AC outlets)Internal power consumption70VA(40W)pk in hi-charge mode,10VA(6W)in float charge mode Power factor N/A for pass-through load,internal10VA load is0.60power factor Heat dissipation21.6x103J/hr,(20Btu/hr)steady stateIn-rush current9A max for½line cycle,per SPS at240V ACAC protection15A fuse,both phasesAC inlet type IEC320-C14appliance coupler with switchAC outlet type IEC320-C13appliance coupler,quantity twoCharge times190minutes maxAC failure detect time10ms maxTransfer time25ms max8Technical Specifications and Operating LimitsSPE,DAE,and SPS operating limitsThe ambient temperature specification is measured at the front bezelinlet.The site must have air conditioning of the correct size andplacement to maintain the specified ambient temperature range andoffset the heat dissipation listed below.Requirement DescriptionAmbient temperature10°C to40°C(50°F to104°F)Temperature gradient10°C/hr(18°F/hr)Relative humidity20%to80%noncondensingElevation2286m(7,500ft)at40°C3047m(10,000ft)at37°CIMPORTANT For systems mounted in a cabinet,the operating limits listedabove must not be exceeded inside the closed cabinet.Equipment mounteddirectly above or below an SPE must not restrict the front-to-rear airflowof the storage system.The cooling airflow through the storage system isapproximately64cubic feet per minute(cfm).Cabinet doors must not impedethe front-to-rear airflow.The cabinet must exhaust air at a rate that is equal toor greater than the sum of the exhaust rates of all the equipment mounted in thecabinet.For example,in a cabinet containing one SPE3(64cfm)and six DAEs(55cfm),the cabinet must exhaust at least64+6x55cfm,which equals394cfm.Environmental recoveryIf the system exceeds the maximum ambient temperature byapproximately10°C(18°F),the SPs begin an orderly shutdown thatsaves cached data,and then shut themselves down.Link control cards(LCCs)in each DAE3P power down their disks but remain poweredon.If the storage system detects that the temperature has dropped toTechnical Specifications and Operating Limits9an acceptable level,it restores power to the SPs and the LCCs restorepower to their disk drives.Shipping and storage requirementsRequirement DescriptionAmbient temperature-40°C to65°C(-40°F to149°F)Temperature gradient25°C/hr(45°F/hr)Relative humidity10%to90%noncondensingElevation7620m(25,000ft)10Technical Specifications and Operating LimitsCopyright©2008EMC Corporation.All Rights Reserved.EMC believes the information in this publication is accurate as of its publication date.Theinformation is subject to change without notice.THE INFORMATION IN THIS PUBLICATION IS PROVIDED"AS IS."EMC CORPORATIONMAKES NO REPRESENTATIONS OR WARRANTIES OF ANY KIND WITH RESPECT TOTHE INFORMATION IN THIS PUBLICATION,AND SPECIFICALLY DISCLAIMS IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.Use,copying,and distribution of any EMC software described in this publication requires an applicable software license.For the most up-to-date regulatory document for your product line,go to the Technical Documentation and Advisories section on EMC Powerlink.For the most up-to-date listing of EMC product names,see EMC Corporation Trademarks on.All other trademarks used herein are the property of their respective owners.Technical Specifications and Operating Limits11。
