Android自动化测试之MonkeyRunner录制和回放脚本2013-02-22 15:31:12 我来说两句作者：xifeijian
收藏我要投稿对于MonkeyRunner，有些人可能会想，既然是Android自动化测试，离不开测试脚本，那么，我们可不可以录制测试脚本呢，答案是可以的。

我们先看看以下monkeyrecoder.py脚本：
[html]
＃Usage: monkeyrunner recorder.py
＃recorder.py /linux/android/repository/platform/sdk/monkeyrunner/s cripts/monkey_recorder.py
com.android.monkeyrunner import MonkeyRunner as mr
com.android.monkeyrunner.recorder import MonkeyRecorder as recorder
device = mr.waitForConnection（）
recorder.start（device）
＃END recorder.py
首先，连接你已经打开调试模式的ANDROID设备或模拟器，然后运行上面的脚本，例如在cmd窗口中执行命令：monkeyrunner monkeyrecoder.py
执行下面的代码后，将运行录制脚本的程序：
＃Press ExportAction to save recorded scrip to a file
＃Example of result:
＃PRESS|{""name"":""MENU""，""type"":""downAndUp""，}
＃TOUCH|{""x"":180，""y"":175，""type"":""downAndUp""，}
＃TYPE|{""message"":""""，}
＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝
这种脚本需要另外一个monkeyrunner的脚本来解释执行。

monkeyplayback.py [html]
＃Usage: monkeyrunner playback.py "myscript"
＃playback.py /linux/android/repository/platform/sdk/monkeyrunner/s cripts/monkey_playback.py
import sys
com.android.monkeyrunner import MonkeyRunner
＃The format of the file we are parsing is very carfeully constructed.
＃Each line corresponds to a single command. The line is split into 2
＃parts with a | character. Text to the left of the pipe denotes
＃which command to run. The text to the right of the pipe is a python
＃dictionary （it can be evaled into existence）that specifies the
＃arguments for the command. In most cases，this directly maps to the
＃keyword argument dictionary that could be passed to the underlying
＃command.
＃Lookup table to map command strings to functions that implement that ＃command.
CMD_MAP = {
""TOUCH"": lambda dev，arg: dev.touch（**arg），
""DRAG"": lambda dev，arg: dev.drag（**arg），
""PRESS"": lambda dev，arg: dev.press（**arg），
""TYPE"": lambda dev，arg: dev.type（**arg），
""WAIT"": lambda dev，arg: MonkeyRunner.sleep（**arg）
}
＃Process a single file for the specified device.
def process_file（fp，device）:
for line in fp:
（cmd，rest）= line.split（""|""）
try:
＃Parse the pydict
rest = eval（rest）
except:
print ""unable to parse options""
continue
if cmd not in CMD_MAP:
print ""unknown command: "" + cmd
continue
CMD_MAP[cmd]（device，rest）
def main（）:
file = sys.argv[1]
fp = open（file，""r""）
device = MonkeyRunner.waitForConnection（）
process_file（fp，device）
fp.close（）;
if __name__ == ""__main__"":
main（）
＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝
Usage：monkeyrunner playback.py "myscript"。
