附录外文资料翻译1000千伏交流电源输电线路的雷电保护摘要:首先,结合日本和前苏联在闪电特高压输电线路的性能和分析的特点,以及1000kV输电线路的闪电跳闸率过高经验和教训的基础上,本文作者提出在中国1000千伏输电线关键技术研究中应该减少雷击损坏率的一个关键点,明确提出在防雷保护中保护失效的预防闪络为研究的主要方向。

本文提出,降低接地屏蔽线的角度和距离的差距与一个合适的长度是1000千伏输电线路跳闸率减少屏蔽失效一个重要的措施。

因此,尤其必须注意防护屏蔽失效的地面延长线更大倾斜的山区线路。

在本文中,作者介绍了在中国平原和山区用于特高压输电线路接地屏蔽线的角度以及中国特高压输电线路在最近的两年半的时间里运行情况。

目前在中国的特高压输电线路雷击跳闸的故障不会发生了,因此初步呈现出良好的防雷性能。

作者还介绍了在中国特高压变电站计算闪电侵入过电压的使用方法和原则和提出并行采取的两个措施降低最高雷电流的屏蔽故障输入线电流截面和优化布置闪电避雷器来限制过电压侵入变电站,因此,会限制需求过电压和避雷器的数量减少。

关键词:超高压,输电线路,变电站,雷电侵入波,过电压,1000V对特高压输电线路的防雷性能的研究A.特征特高压输电线路有两种功能的防雷性能:1)特高压输电线路绝缘水平是非常高的,因此具有引人注目的很低架空地线的可能性和塔顶导致导致发生雷电反击失败。

2)塔的高度对特高压输电线是非常高的,因此容易导致屏蔽失败。

前苏联特高压输电线路的运行经验[ 1 ] [ 2 ]表明,闪电剔除是输电线路的主要原因剔除。

从1985到1994这十年期间,在特高压雷击跳闸次数输电线路是16,占总数的84%数量的剔除。

然而,导致闪电剔除的主要原因是导体受到直接雷击屏蔽故障。

在前苏联特高压输电线路的地线保护角过大(超过20°),从而导致过高的剥离率使闪电防护失败。

在日本1000kV输电线路在同塔双回路线路,已用于500kV电压。
