Summary. To make life alot easier for control and tweaking the effect later on, we add some attributes to the particle shape node that is accessible outside the expression. With these controls we can animate snow flakes, rain and hail at slow, fast or turbulent speeds.

Dislcaimer: Even though the basic technique used is some what similar, this is not the exact way it was done on Happy Feet. Purely because I cant supply such information publicly. However, all the code and set up was re done from scratch at home and done a little bit more efficiently if I do say so myself :p. Also, at the end I will supply what I think is a more ‘director’ friendly method.

Create the Scene 1. Create a plane (poly or nurbs, doesnt matter) and make it into a surface emitter. 2. Particles->Emit from Object - option box. (surface emitter) 3. Change the speed and or speed random to 0, and the emission rate to just 100 for now. 4. Raise the plane up in Y and set up your camera underneath it as desired. For these tests i placed mine at 20 units in the Y and scaled the plane to 20 by 10 so that it sits across the screen above the camera, for now anyway(all units are default mayacentimetres) 5. Extend your scene frame range out to atleast 500. Maybe 1000 would be better so we can tweak the effect without rewinding.

Adding Attributes: 1. We need to add some custom attributes to the particle shape node. Manual Method: 1. Press play and select the particles or go to the outliner and select the particles. The attributes need to be on the shape node not the transform node so make sure we have the shape node visible in the attribute editor. 2. In the add dynamic attributes rollout select the general button and add these attributes.

-windDirection. Vector, scalar -windSpeed, Float, scalar, default value 4 -phase, Vector, scalar -twirlTurbulenceStrength, Float, scalar, default value 10 -noiseTurbulenceStrength, Float, scalar, default value 5 -turbulenceSize, Float, scalar, default value 2 -globalSize, Float, scalar, default value 0.1

-change the windDirection to 0,-1,1 (we can change/animate the phase later) -go up to the top of the attributes and change the conserve to 0.97 so we can contain the effect a bit.

Lazy Method: To do the same thing copy this script into your script editor select the particles (shape or transform doesnt matter) and run it (or source it)

http://www.modernmayhem.com/addAttrsForSnow.mel Adding the particle expression Manual Method:

1. Go to the particle tab and create this runtime before dynamics expression:

float $windSpeedMag = windSpeed + windSpeed * cos(time * 0.1); vector $windSpeed = <> * $windSpeedMag; vector $vel = globalSize * rot( dnoise ( ( position/ turbulenceSize) + <>) , (<>), time); vector $vel2 = globalSize * dnoise( position/( turbulenceSize*2) + time * 0.5); $vel = $vel * twirlTurbulenceStrength + $vel2 * noiseTurbulenceStrength + ($windSpeed* globalSize); velocity += $vel;

or similarly run this script http://www.modernmayhem.com/addExprForSnow.mel This is what it looks like so far at an emission rate of 100. Rendered in mental ray to get (a slight) motion blur (0.2)

You can see the ‘rotational’ noise in this render but if we want to accentuate that I have another method which I will add later. But first on to rendering.

Rendering: Ok first we need replace the particles with instances. We could use sprites but then we wouldn’t get the random rotations in 3 dimensions.

Shader and instance set up create a poly plane and change the divisions to 1 and 1.

1. duplicate it 2 more times. (we are being lazy for this tute and making only 3 variations but feel free to make as many different snowflakes as you like). 2. select the three planes then the particles and go to particles ->instancer replacement 3. We need to make 3 different shaders too. For this tute I just downloaded three different images off google and brought them into photoshop and created 3 square (about 200 by 200) tiffs on a transparent background. But then had to change to tga’s as my mental ray had a problem with tiffs. 4. bring it into maya and connect the outColor to the shaderscolour and outAlpha to the shaders transparency red green and blue. 5. one last trick for the shader is to mask out the specular otherwise it will shine for the whole square not just the snowflake shape. So the quickest way around that is to remap the colour into black and white and pipe that into the specular colour. Use the ramp to crush up the dark values as much as possible so that your left with a white silhouette of the snowflake. 6. to remap the colour simply go to effects in the file node/tab and select color remap. This will reconnect the output of the file to the colour of the shader and we dont want that so disconnect it and put the file straight back into the colour. 7. then change the ramp to black and white (the snowflake should be white and the background
