阀门的标准英文翻译
液压继动阀
Hydraulic relay valves
限位阀
Limit valves衬 Nhomakorabea三通旋塞阀
Lining T-Cock Valves
液位计
Liquid Indicator
浆液阀
Parallel Slide Valves
柱塞阀
Plunger valves
压力（増压）阀
泄压阀
Decompression valves
蒸汽疏水阀
Automatic steam trap valve
组合阀
Combination valves
针形阀
Pintle valve
仪表阀
Gauge Valves
仪表针形截止阀
Meter Needle Type Globe Valves
空气阀门
Air valves
电动楔式闸阀
Electric Actuated Wedge Gate Valves
平板闸阀
Flat Gate Valve
单闸板平板闸阀
Single Disc Flat Gate Valves
电动平行式双闸板闸阀
Electric Double Disk Parallel Gate Valves
双闸板平板闸阀
排灰阀
Ash valves
吸（抽）气阀
Aspirating valves
辅助（副）阀
Auxiliary valves
平衡阀
Balance valves
波纹管阀
Bellows valves
泄料（放空，排污）阀
Blowdown valves
制动阀
Brake valves
对焊连接阀
Buttwelding valves
金属密封蝶阀
Hard Seal Butterfly Valves
隔膜阀
diaphragm valve
旋塞阀
plug valve
安全阀
safety valve
管道安全阀
Piping Safety Valves
回转阀
rotary valve
减压阀
pressure reducing valve
减速阀
Deceleration valves
Pressure valve
快速排污阀
Quick Draining Valves
电磁阀
Solenoid valves
过滤器
Strainer
节流阀
Throttle Valves
法兰截止阀
Flange Globe Valves
衬里截止阀
Lining Globe Valves
直流式截止阀
Oblique Stop Valves
柱塞截止阀
Plunger Globe Valves
止回阀
Check valve
旋启式止回阀
Swing Check Valves
对夹式止回阀
Wafer Check Valves
蝶式缓冲止回阀
Butterfly Type Non-slam Check
蝶式缓冲止回阀
Butterfly Type Non-slam Check
升降式止回阀
Lift Check Valves
衬里止回阀
Lining Check Valves
微阻缓闭止回阀
Tiny Drag Slow Shut Check Valves
地下管道阀
Culvert valves
双口排气球
Double Opening Exhaust Valves
排水阀
Drainage valves
紧急切断阀
Emergeny Cut-off Valves
排气阀
Exhaust valves
浮球式疏水阀
Free Float Type Steam Trap
手动阀
立式止回阀
Vertical Lift Check Valves
蝶阀
Butterfly Valve
对夹蝶板阀
Wafer plate valve
衬里蝶阀
Lining Butterfly Valves
蜗轮传动蝶阀
Butterfly Valves with Gear Actuator
对夹式衬胶蝶阀
Wafer Type Butterfly Valves with Rubber Itning
CQ Thread Ball Valves
法兰球阀
Flange Ball Valves
衬里球阀
Lining Ball Valves
API球阀
API Ball valves
浮动球阀
Float Ball valves
固定球阀
Trunnion-mounted Ball valves
三通法兰球阀
Three Ball valves
阀门的标准英文翻译
上海西博思流体控制有限公司_最有名望阀门供应商之一2009-01-05 11:28:29作者:上海西博思流体控制有限公司来源:文字大小:[大][中][小]
阀门
valve
通用阀门
General valve
球阀
Ball valve
槽车球阀
Tank Lorry Ball Valves
CQ螺纹球阀
V型调节球阀
V-Regulating Ball valves
闸阀
Gate valve
楔式闸阀
Wedge Gate Valves
法兰闸阀
Flange Gate Valves
排渣闸阀
Scum Gate Valves
薄型闸阀
Thin Gate Valves
水封闸阀
Water Seal Gate Valves
Double Disc Flat Gate Valves
明杆平行式双闸板闸阀
Double Disk Parallel Gate Valves
截止阀
Globe valve
角式截止阀
Angle Globe valves
门角式截止阀
Angle Type Globe Valves
电动截止阀
Electric Actuated Stop Valves
