什么是以太网供电

什么是以太网供电(PoE)？以太网供电(PoE)是一种将功率从中央交换机传输到以太网连接设备（VoIP电话、WLAN发射机、安防摄像头）的供电方法。

利用现有的CAT-5电缆，这些设备可以不需要AC供电（同时节省配线成本）。

交换机也可以对分配给用电设备(PD)的功率进行控制，这样允许对某些重要系统进行精确不间断的功率管理。

工作方式基本上，一个PoE负载或用电设备（PD）为了实现与发送端PSE（功率发送设备）的连接，要完成三个步骤，包括检测、分级及欠压锁存。

检测阶段当具有PoE功能的以太网电缆插入到一个PD设备时，PSE会询问该PD设备以确定其是否为具有PoE功能的设备。

这段时间定为检测阶段。

在检测阶段，PSE会给PD施加一个斜坡电压，用来寻找负载端是否有25 kΩ的阻抗特性。

如果没有检测到该阻抗，PSE会假定负载不是具有PoE功能的负载，从而关断PoE发送端。

此时系统以标准的以太网连接方式工作。

如果检测阶段检测到识别阻抗，PSE会继续进行到分级阶段。

阻抗识别电压是介于2.5 V和10 V之间的斜坡电压。

在检测阶段，一个24.9 kΩ的电阻可以提供恰当的识别阻抗（参见图1）。

图1. 检测阻抗分级阶段PSE给PD提供的斜坡电压继续上升。

在15 V到20 V之间，开始进行分级。

在此电压过渡期间，PD设备必须拉出规定的电流以确定其设备级别（参见图2）。

使用24.9 kΩ识别电阻可以确定其为最简单的级别（0级）。

分级电流用来确定该PD设备在正常工作期间所消耗的总功率大小。

此电流信息由PSE反馈到控制器，由系统来确定功率预算的要求。

表1列出了分级电流的大小及相应PD工作时的功率要求。

级别P MIN P MAX I CLASS（最小值）I CLASS（最大值）R CLASS0 0.44 W 12.95 W 0 mA 4 mA 开路1 0.44 W 3.84 W 9 mA 12 mA 150 Ω2 3.84 W 6.49 W 17 mA 20 mA 82.5 Ω3 6.49 W 12.95 W 26 mA 30 mA 53.6 Ω4 保留保留36 mA 44 mA 38.3 Ω表1.分级功率级别。

启动阶段在分级阶段之后，PSE继续将输入斜坡电压上升至30 V，此时欠压锁存(UVLO)电路解除，PD设备开始有供电。

要求有软启动电路以限制从PSE拉出的电流。

图3为典型的欠压锁存电路。

图3. 使用MOSFET导通开关的0级PoE接口电路通过这样的过程，PSE与PD协同工作，确定了负载特性并仅向具有PoE功能的设备供电。

在中心位置的系统控制器可以确定负载要求，在停电期间根据UPS电源预算及各级工作需要对功率加以分配。

有关驱动PoE兼容负载设备和实现1级到3级分级的电路的其他信息，请参见设计参考DI-70和DI-88。
