A simple method for solving unidirectional methane gas flow in coal seam based on similarity solutionZhou Yan a,⇑,Meng Qian b ,Lin Baiquan a ,Qin Jilong a ,Zhou Guiping aa Key Laboratory of Gas and Fire Control for Coal Mines (China University of Mining &Technology),Ministry of Education,Xuzhou 221116,China bSchool of Computer Science and Technology,Jiangsu Normal University,Xuzhou 221116,Chinaa r t i c l e i n f o Article history:Received 12February 2016Received in revised form 22May 2017Accepted 16June 2017Available online 16December 2017Keywords:Coalbed methane MigrationUnidirectional flow Similarity solution Simplified solving Numerical methoda b s t r a c tThe equation used to model the unidirectional flow of methane gas in coal seams is usually formulated as a nonlinear partial differential equation,which needs to be solved numerically with a computer program.Nevertheless,for people without access to the computer program,the conventional numerical method may be inconvenient.Thus,the objective here is to seek some method simpler than the conventional one for solving the flow problem.A commonly used model of the unidirectional methane gas flow is con-sidered,where the methane adsorption is described by the Langmuir isotherm and the free gas is treated as real gas.By introducing the similarity solution,a simple method for solving the flow model is pro-posed,which can be done on a hand calculator.It is shown by two examples that the gas pressure profile obtained by the proposed method agrees well with the direct numerical solution of the flow model.Ó2017Published by Elsevier B.V.on behalf of China University of Mining &Technology.This is an openaccess article under the CC BY-NC-ND license (/licenses/by-nc-nd/4.0/).1.IntroductionAs coal is porous in nature,significant amounts of methane can be retained in coal bed,and coalbed methane (CBM)is both a potentially valuable energy resource and a hazard in active coal mines [1–3].Understanding the methane gas migration in coal seams is essential for both CBM recovering and coal mine gas con-trol.But,the CBM flow equation is usually formulated as a nonlin-ear partial differential equation (PDE),which can hardly be solved by purely analytical techniques [4,5].The unidirectional flow is one of the three basic patterns of methane gas migration in coal seams,while the other two are radial flow and spherical flow [6].The unidirectional flow of methane gas is a kind of one-dimensional transient flow.It refers to the situation where the methane gas migrates towards a coal face,of which the height is equal to the thickness of the coal seam,as shown in Fig.1.For one-dimensional transient gas flow (without adsorption and desorption)in porous media,a traveling wave solution has been present by Hayek [7].Because the CBM flow is usually accompa-nied by methane desorption [8,9],and the coal methane content is nonlinearly dependent on the pore gas pressure [10,11],the problem of CBM flow is more complex,and we have to solve it numerically using a computer program.As is well known,there are many parameters controlling the methane gas flow in coal seams,such as gas pressure,coal seam permeability,adsorption coefficients,etc.While trying to investi-gate the effects of these parameters on the flow process,one needs to solve the flow model many times for different values of the parameters,and the computational cost rises rapidly as the param-eter number increases.Moreover,and importantly,the conven-tional numerical analysis may be inconvenient for those,such as field engineers,field technicians,and so on,who might not have access to the computer program.Thus,the objective of this study is to seek a method for solving the flow model,which is simpler than the conventional numerical analysis,and is accurate enough,and can be done even without a computer.Of course,such a method can also be easily programmed to run efficiently on a computer.2.Basic equationWhile the methane adsorption is described by the Langmuir isotherm [12–14],and the free gas is treated as real gas [4,15],a commonly used model of the unidirectional methane gas flow can be written as [10,16]:https:///10.1016/j.ijmst.2017.12.0062095-2686/Ó2017Published by Elsevier B.V.on behalf of China University of Mining &Technology.This is an open access article under the CC BY-NC-ND license (/licenses/by-nc-nd/4.0/).⇑Corresponding author.E-mail address:zhouyan@ (Y.Zhou).International Journal of Mining Science and Technology 28(2018)331–334Contents lists available at ScienceDirectInternational Journal of Mining Science and Technologyjournal homepage:www.else v i e r.c o m /l o c a t e /i j m st@P @t ¼2M ffiffiffiP p 1þb ffiffiffiP p 21þU ð1þb ffiffiffiP p Þ2=p n Á@2P @x2ð1Þwhere P is the square of the coal seam gas pressure,MPa 2,and P =P (x ,t )=p 2(x ,t );p is the pore gas pressure,MPa;x is the spatial coor-dinate,m;t is the time coordinate,s;M ¼k =ðab Þ,m 2/(MPa s);k is the permeability coefficient of the coal seam,m 2/(MPa 2s);a is the maximum adsorbed gas content,m 3/m 3;b is the equilibrium con-stant,MPa À1;U ¼/=ðab Þ,MPa;/is the porosity;p n is the normal gas pressure,here taking p n %0.1MPa.If the free gas is ignored,Eq.(1)reduces to:@P@t ¼2M ffiffiffiP p 1þb ffiffiffiP p 2@2P @x 2ð2ÞFor both Eqs.(1)and (2),the initial and boundary conditions are as follows:P ðx ;0Þ¼P 0¼p 20P ð0;t Þ¼P 1¼p 2n P ð1;t Þ¼P 0¼p 208><>:ð3Þwhere P 0is the square of the original gas pressure in the coal seam,MPa 2;p 0is the original gas pressure,MPa;P 1is the square of the gaspressure at the coal face,and here we assume P 1=p 2n =0.01MPa 2.Obviously,Eqs.(1)and (2)with their initial and boundary con-ditions in Eq.(3)form two initial and boundary value problems (IBVP)of nonlinear PDE,which need to be solved numerically by using a computer program.3.A simple method for solving the flow model 3.1.Similarity transformationsBy introducing suitable similarity transformations,some PDEs can be reduced into ordinary differential equations (ODE)and the solutions of the ODEs are called the similarity solutions of the PDEs [17–21].If the similarity solutions are known in advance,the solu-tions of the original PDEs can be easily obtained.It is not too difficult to prove that both Eqs.(1)and (2)can be transformed into ODEs by introducing a similarity variable like x =ffiffit p .In order to reduce the number of the model parameters,and to make the initial and boundary conditions simpler,we define two similarity variables as follows:g ¼P =P 0n ¼xffiffiffiffiffiffiffiffiffiffiffiab4k P 1=20tr 8<:ð4Þwhere g and n are similarity variables,dimensionless.Substituting the similarity variables into Eqs.(1)–(3)separately leads toÀn g 0¼ffiffiffig p 1þr ffiffiffig p ÀÁ21þ10U 1þr ffiffiffigp ÀÁ2g00ð5ÞÀn g 0¼ffiffiffig p 1þr ffiffiffig p 2g00ð6Þandg ð0Þ¼g 0g ð1Þ¼1&ð7Þwhere g 0¼d g d n ,g 00¼d 2gd n 2,r ¼b ffiffiffiffiffiP 0p ¼bp 0,and g 0¼P 1=P 02(0,1).So,the original two IBVPs have been transformed into two boundary value problems (BVP).Eqs.(5)and (6)are the so called similarity equations of Eqs.(1)and (2),separately.Obviously,the similarity equation is easier to be solved than its original equation.Moreover,it is worth mentioning that there are only two model parameters,i.e.,r and g 0,left in Eq.(6)and its boundary condi-tions.That means the solving of Eq.(6)only needs to be repeated for every (r ,g 0).So,it will be not too difficult to tabulate or graph the solutions of Eq.(6)in advance for further use to solve Eq.(2).However,there are three model parameters,i.e.,U ,r and g 0,left in Eq.(5)and its boundary conditions.So it will be difficult to tabulate or graph the solutions of Eq.(5)systematically in advance.3.2.Proposed methodsBecause the free gas is usually less than the adsorbed gas,Eq.(2)can be regarded as a rough approximation to Eq.(1),and Eq.(6)a rough approximation to Eq.(5).As the basis of following consider-ation,Eq.(6)is solved using the shooting method [22],and its numerical solution sets for a range of values of r and g 0are obtained as shown in Fig.2.Here,only the solution sets for the cases of r =0.56,1.8and 5.8are present because of the space restrictions.Without loss of generality,suppose we are looking for the solu-tion of Eq.(5)at n =n k ,with r and g 0known.Here,n k is a certain value of n ,which corresponds to some certain point of the space-time coordinate of (x ,t ).The basic ideas of the proposed method are as follows.Firstly,we get the solution of Eq.(6)corresponding to the known r and g 0at n =n k from the solution sets as shown in Fig.2,and denote this solution as g f,k .Secondly,we setB ¼1þ10U 1þr ffiffiffiffiffiffiffig f ;kp2ð8ÞThirdly,we rewrite Eq.(5)approximately asÀn d ^g d n ¼1Bffiffiffi^gq 1þr ffiffiffi^g q 2d 2^g d n 2ð9Þwhere ^gis an approximation of g .Fourthly,we set^n ¼ffiffiffiB p nð10Þand substitute it into Eq.(9),and getÀ^n ^g 0¼ffiffiffi^g q 1þr ffiffiffi^g q 2^g 00ð11Þwhere ^g 0¼d ^g d ^n and ^g 00¼d 2^g d ^n2.The boundary conditions for Eq.(11)is^gð0Þ¼g 0^gð1Þ¼1&ð12ÞObviously,Eq.(11)is identical in form to Eq.(6),and the bound-ary conditions in Eq.(12)are also identical to that in Eq.(7).So the solution of Eq.(11)can also be determined from the solution sets of Eq.(6)as shown in Fig.2.We can take the solution of Eq.(11)Fig.1.Unidirectional methane gas flow in coal seam.332Y.Zhou et al./International Journal of Mining Science and Technology 28(2018)331–334as an approximate solution of Eq.(5).With this approximate solu-tion,the solution of Eq.(1)can be obtained easily based on the def-inition of the similarity variables g and n .4.Examples4.1.A real field case exampleThe 3#coal seam in Jincheng coal field of China,of which parameters are given in Table 1,is chosen to show how to estimate the gas pressure profile by using the proposed method.This exam-ple is typical in that the free gas content is considerably high (the gas pressure is quite high and the porosity relatively large).Since r =bp 0%0.56and g 0=P 1/P 0=0.0025,the solution of Eq.(6)for this case happens to be the first curve from the bottom in Fig.2a.Obviously,for other values of r or g 0,the solution can be obtained by interpolation.Several data points in the solution of Eq.(6)for this example are listed in Table 2(the column labeled as g f ).Substituting the values of g f into the definition formula of g as shown in Eq.(4),we get the corresponding values of gas pres-sure as shown in the column labeled as p f in Table 2,which are indeed the gas pressure values we can obtain by ignoring the free gas.In other words,for the cases where the free gas can be ignored,the gas pressure profile can be determined directly from the simi-larity solutions as shown in Fig.2,and there is no more need to solve the differential equation Eq.(6)or Eq.(2).Next,we will take the following steps to finish the solving.Step 1:Using Eq.(8),we get the values of B ,as shown in the 4th column of Table 2.Step 2:Using Eq.(10),we get the values of ^n corresponding to different values of n ,as shown in the 5th column of Table 2.Step 3:According to the values of r and g 0,we determine the solution of Eq.(11)from Fig.2.Obviously,the solution is still the first curve from the bottom in Fig.2a.From this curve,wecan estimate the values of ^g at different values of ^n ,as shown in the column labeled as ^g in Table 2.Step 4:Based on the definition of g ,we get the values of gaspressure,as shown in the column labeled as ^pin Table 2,and here,^pis the approximation of p .Obviously,the calculations required for the above steps arequite simple,since only algebraic manipulations are involved.Even for someone who does not have a computer,he can still do the cal-culations on a hand calculator.In order to check the accuracy of the proposed method,we pre-sent the direct numerical solutions of Eq.(5)at different values of n in Table 2,as shown in the column labeled as g d .The correspond-ing values of gas pressure are listed in the column labeled as p d .From the data in Table 2,it can be found that the gas pressure profile obtained by the proposed method agrees well with the direct numerical solutions,and is much better than that obtained by ignoring the free gas.This can be seen more clearly in Fig.3.4.2.A fictitious extreme exampleIn order to further test the accuracy of the proposed method,we introduce a fictitious case example where the free gas content is extremely high.The parameters of this extreme case are shown in Table 3.From these parameters,we can calculate that the orig-inal free gas content is 8.0m 3/m 3,while the original adsorbed gas content about 5.4m 3/m 3.The results of the direct numerical solution,the method of ignoring free gas,and the proposed method are presented in Fig.4,respectively.Fig.2.Numerical solution sets of Eq.(6).Table 1Parameters of the real field case [23].p 0(MPa)a (m 3m À3)b (MPa À1)k (m 2MPa À2s À1)/2.041.50.2790.003840.173Table 2Calculating the gas pressure profile of the real field case.n g fp f (MPa)B ^n ^g ^p (MPa)g dp d (MPa)00.00250.100 1.15800.00250.1000.00250.1000.0200.0160.250 1.1710.0210.0170.2580.0180.2650.0900.0630.500 1.1940.0980.0680.5220.0710.5320.2050.1370.740 1.2170.2260.1500.7750.1550.7870.3890.250 1.00 1.2440.4340.276 1.050.282 1.061.020.563 1.50 1.300 1.160.618 1.570.622 1.582.370.9031.901.3492.760.9421.940.9421.94Fig.3.Results of different methods in the real field case.Y.Zhou et al./International Journal of Mining Science and Technology 28(2018)331–334333As seen in Fig.4,the gas pressure profile obtained by the pro-posed method still agrees fairly well with the direct numerical solutions,even for this extreme case.5.Conclusions(1)The model of unidirectional methane gasflow in coal seam isusually formulated as a nonlinear partial differential equa-tion,which needs to be solved numerically with a computer program.Nevertheless,for people without access to the computer program,the conventional numerical analysis may be inconvenient.(2)A commonly used model is considered where the methaneadsorption is described by the Langmuir isotherm and the free gas is treated as real gas.By introducing the similarity transformations,the model is reduced into an ordinary equation,of which the solutions are the similarity solutions of the original model.(3)For the case where the free gas is ignored,there are only twomodel parameters left in the similarity model.Based on the similarity solution sets tabulated or graphed in advance for such case,a method is proposed to solve the commonly used model.(4)Since only algebraic manipulations are involved,the pro-posed method is simple and can be done on a hand calculator.(5)Two examples are introduced to test the accuracy of the pro-posed method.One is a realfield case example,and another is afictitious extreme example.It is shown that the gas pres-sure profile obtained by the proposed method agrees well with the direct numerical solution.AcknowledgmentsFinancial support for this work,provided by the Priority Academic Program Development of Jiangsu Higher Education Institutions(PAPD),is gratefully acknowledged.References[1]Pillalamarry M,Harpalani S,Liu S.Gas diffusion behavior of coal and its impacton production from coalbed methane reservoirs.Int J Coal Geol2011;86(4):342–8.[2]Zhou LH,Pritchard C,Zheng Y.CFD modeling of methane distribution at acontinuous miner face with various curtain setback distances.Int J Min Sci Technol2015;25(4):635–40.[3]Lin HF,Huang M,Li SG,Zhang C,Cheng L.Numerical simulation of influence ofLangmuir adsorption constant on gas drainage radius of drilling in coal seam.Int J Min Sci Technol2016;26(3):377–82.[4]Wang JG,Kabir A,Liu JS,Chen Z.Effects of non-Darcyflow on the performanceof coal seam gas wells.Int J Coal Geol2012;93(1):62–74.[5]Hooman K,Tamayol A,Dahari M,Safaei MR,Togun H,Sadri R.A theoreticalmodel to predict gas permeability for slipflow through a porous medium.Appl Therm Eng2014;70(1):71–6.[6]Zhou SN.Application of computer in research of gasflow equation.J China CoalSoc1983;8(2):29–35.[7]Hayek M.Exact solutions for one-dimensional transient gasflow in porousmedia with gravity and Klinkenberg effects.Transp Porous Media2014;107(2):403–17.[8]Zhang HB,Liu JS,Elsworth D.How sorption-induced matrix deformationaffects gasflow in coal seams:a new FE model.Int J Rock Mech Min Sci 2008;45(8):1226–36.[9]Weniger S,Weniger P,Littke R.Characterizing coal cleats from opticalmeasurements for CBM evaluation.Int J Coal Geol2015;s154–155:176–92. [10]Zhou SN,Lin BQ.The theory of gasflow and storage in coalseams.Beijing:China Coal Industry Publishing House;1999.[11]Mazzotti M,Pini R,Storti G.Enhanced coalbed methane recovery.J SupercritFluids2009;47:619–27.[12]Ziarani AS,Aguilera R,Clarkson CR.Investigating the effect of sorption time oncoalbed methane recovery through numerical simulation.Fuel2011;90(7):2428–44.[13]Clarkson CR.Production data analysis of unconventional gas wells:workflow.Int J Coal Geol2013;109–110:147–57.[14]Xue S,Wang YC,Xie J,Wang G.A coupled approach to simulate initiation ofoutbursts of coal and gas–model development.Int J Coal Geol2011;86(2–3):222–30.[15]Alexeev AD,Feldman EP,Vasilenko TA.Methane desorption from a coal-bed.Fuel2007;86(16):2574–80.[16]Xu T,Tang CA,Yang TH,Zhu WC,Liu J.Numerical investigation of coal and gasoutbursts in underground collieries.Int J Rock Mech Min Sci2006;43(6):905–19.[17]Iqbal M,Mustafa MT,Siddiqui AA.A method for generating approximatesimilarity solutions of nonlinear partial differential equations.Abstract Appl Anal2014;5:1–6.[18]Zhao GC,Du X,Song LP,Kong JR.Similarity solutions and approximationsolutions of velocity and temperature in laminar boundary layer of subsonic and supersonic wedgeflows.J Aerosp Power2014;29(12):2785–94.[19]Kolomenskiy D,Moffatt HK.Similarity solutions for unsteady stagnation pointflow.J Fluid Mech2012;711:394–410.[20]Ancey C,Cochard S,Rentschler M,Wiederseiner S.Existence and features ofsimilarity solutions for non-Boussinesq gravity currents.Physica D2007;226(1):32–54.[21]Mortensen J,Olsen S,Parlange JY,Telyakovskiy AS.Approximate similaritysolution to a nonlinear diffusion equation with spherical symmetry.Int J Numer Anal Model2012;9(1):105–14.[22]Gerald CF,Wheatley PO.Applied numerical analysis.Boston:Addison-Welsley;2004.[23]Ma DM,Zhang SA,Wang PG,Lin Y,Wang C.Mechanism of coalbed methanedesorption at different temperatures.Coal Geol Expl2011;39(1):20–3.Table3Parameters of thefictitious extreme example.p0(MPa)a(m3mÀ3)b(MPaÀ1)k(m2MPaÀ2sÀ1)/4.0150.13950.003840.2Fig.4.Results of different methods in thefictitious extreme example.334Y.Zhou et al./International Journal of Mining Science and Technology28(2018)331–334。
