弯曲说明书
弯管机作业指导书
弯管机作业指导书标题：弯管机作业指导书引言概述：弯管机是一种常见的金属加工设备，用于将金属管材弯曲成不同形状的弯管。
正确操作弯管机可以提高生产效率，保证产品质量。
本文将详细介绍弯管机的作业指导，帮助操作人员正确使用弯管机。
一、操作前的准备工作1.1 清理工作区域：确保工作区域干净整洁，无杂物干扰操作。
1.2 检查设备状态：确认弯管机各部件完好无损，润滑油充足。
1.3 准备工件：将需要弯曲的金属管材准备好，长度符合要求。
二、调试设备参数2.1 设置弯管机参数：根据工件要求，设置弯管机的弯曲角度、弯曲半径等参数。
2.2 调整模具位置：根据金属管材直径和弯曲角度，调整模具位置。
2.3 校准传感器：确保传感器位置准确，能够准确检测金属管材位置。
三、操作步骤3.1 将金属管材放入弯管机：将准备好的金属管材放入弯管机的夹具中。
3.2 启动弯管机：按照设备说明书操作，启动弯管机进行弯曲。
3.3 观察弯曲情况：在操作过程中，注意观察金属管材的弯曲情况，及时调整参数。
四、安全注意事项4.1 穿戴防护装备：操作弯管机时，应穿戴好安全帽、护目镜等防护装备。
4.2 避免手部进入夹具：在弯管机运行过程中，严禁将手部或其他物品伸入夹具。
4.3 紧急停机：一旦发生异常情况，应立即按下急停按钮，切断电源。
五、设备维护保养5.1 定期清洁保养：定期清洁弯管机各部件，保持设备干净。
5.2 润滑维护：定期给弯管机各润滑部位添加润滑油，确保设备运行顺畅。
5.3 定期检查：定期检查弯管机各部件是否正常，发现问题及时处理。
结语：通过本文的作业指导，希望能够帮助操作人员正确、安全地操作弯管机，提高生产效率，保障工作安全。
正确的操作和维护保养能够延长弯管机的使用寿命，提高设备的稳定性和可靠性。
祝愿大家工作顺利！。
GF20钢筋弯箍机说明书
GF20钢筋弯箍机
• GF20钢筋弯箍机轻巧灵活，使用简便，性 能稳定、全自动弯曲，手控按钮，脚踏开 关，自行返回，安全性高。本机采用自行 规定行程，自动返回，回程迅速，是传统 弯曲机的4－5倍，是弯曲小直径钢筋的理 想设备，也是中大型钢筋弯曲机的重要补 充设备。
GF20钢筋弯箍机
• GF20Βιβλιοθήκη 筋弯箍机技术参数： • 钢筋螺纹钢直径 ф4-ф20mm 弯曲转速20-25次/分 • 弯曲转速：20-25转/分 • 电机功率：2.2kw • 电压：380V • 电机转速：1440转/分 • 外型尺寸：（长*宽*高）670*670*780mm • 整机重量：100kg
谢谢观看
gf20型钢筋弯箍机是一种工程用钢筋弯曲设备本机具有弯曲工序简化工作效率高角度调整方便弯曲整齐将材质为420毫米直螺纹钢弯曲成工程所需的各种几何形状gf20钢筋弯箍机轻巧灵活使用简便性能稳定全自动弯曲手控按钮脚踏开关自行返回安全性高
企业形象
营业执照
GF20钢筋弯箍机
GF20钢筋弯箍机
• GF20型钢筋弯箍机是一种工程用钢筋弯曲 设备，本机具有弯曲工序简化，工作效率 高，角度调整方便，弯曲整齐，将材质为 ф4-ф20毫米直螺纹钢弯曲成工程所需的 各种几何形状
弯曲模具设计(带全套cad图)
模具课程设计说明书——弯曲模课程设计学校：学院：专业：姓名：学号：指导教师：一、零件图二、工艺设计1.弯曲工序安排原则工序安排的原则应有利于坯件在模具中的定位；工人操作安全、方便；生产率高和废品率最低等。
弯曲工艺顺序应遵循的原则为：①先弯曲外角，后弯曲内角。
②前道工序弯曲变形必须有利于后续工序的可靠定位；并为后续工序的定位做好准备。
③后续工序的弯曲变形不能影响前面工序已成形形状和尺寸精度。
④小型复杂件宜采用工序集中的工艺，大型件宜采用工序分散的工艺。
⑤精度要求高的部位的弯曲宜采用单独工序弯曲，以便模具的调整与修正。
制订工艺方案时应进行多方案比较。
2.形状简单的弯曲件如V形、U形、Z形件等，可采用一次弯曲成形。
3.弯曲件展开尺寸计算。
（1）中性层位置的确定弯曲中性层位置并不是在材料厚度的中间位置，其位置与弯曲变形量大小有关，应按下式确定：P=r+kt式中 P----弯曲中性层的曲率半径；r----弯曲件内层的弯曲半径；t----材料厚度；k----中性层位移系数，板料可有表3-9查得，圆棒料由表3-10查得。
（2）弯曲件展开尺寸计算计算步骤：1）将标注尺寸转换成计算尺寸即将工件直线部分与圆弧部分分开标注，2）计算圆弧部分中性层曲率半径及弧长中性层曲率半径为P=r+kt，则圆弧部分弧长为： s=Pa式中 a----圆弧对应的中心角，以弧度表示。
3）计算总展开长度L=L1+L2+SL=∑L直+∑S弧4.回弹弯曲成形是一种塑性变形工艺。
回弹的表现形式：1）弯曲回弹会使工件的圆角半径增大，即r2＞rp,则回弹量可表示为△r=r2-rp2) 弯曲回弹会使弯曲件的弯曲中心角增大，即a＞ap.则回弹量可表示为△a=a-ap影响弯曲回弹的因素：1．材料的力学性能。
2. 材料的相对弯曲半径r/t。
3. 弯曲制件的形状。
4. 模具间隙。
5. 校正程度。
弯曲板件时，凸模圆角半径和中心角可按下式计算:Rp=r/(1+3Asr/Et)ap=ra/rp式中 r----工件的圆角半径；Rp----凸模的圆角半径；a----工件的圆角半径r对弧长的中心角；ap----凸模的圆角半径rp所对弧长的中心角；t----毛坯的厚度；E----弯曲材料的弹性模量；A----弯曲材料的屈服点减小回弹的措施：1）在弯曲件的产品设计时①弯曲件结构设计时考虑减少回弹，在弯曲部位增加压筋连接带等结构。
四点弯曲说明书(2010。01。10版)
四点弯曲细胞力学加载仪一、概述1、简介四点弯曲细胞力学加载仪是一种新型实验室仪器，由电子科大和华西医科大学联合研制。
根据生物力学和生物医学工程研究的发展，用细胞力学方法在不同力学载荷下研究骨组织、肌体组织在各种力学状态下发展状态是国际医学研究的热点，为研究正畸矫治力学、颌面畸形骨牵引成型、牙周组织和口腔种植材料在不同力学载荷下的变化研究了此仪器。
本仪器可产生拉应力或压应力，本仪器质优价廉、主要应用于牙科。
该治疗仪造型美观、设计合理、工作可靠。
2、产品特点⑴采用进口集成电路及控制芯片以保证仪器的正常工作；⑵本仪器可产生拉伸和压缩应力；⑶采用了多项新技术，以保证整机具有快速启动、高效、长寿命、稳定的特性；⑷选用进口步进电机和防腐耐磨材料，能够延时99小时启动，连续工作99小时；⑸功能选择触摸式开关控制方式设计，操作高效便捷。
3、使用环境条件⑴主机：环境温度：5℃～40℃，执行机构可工作于环境温度：5℃～65℃；⑵主机：相对湿度小于80%，执行机构可工作于相对湿度大于95%；⑶大气压力：86kPa～106kPa；⑷供电电源：～220V±22V 、50Hz±1Hz。
⑸功率消耗：≤200VA4、对环境及能源的影响本仪器对一般电子设备不会产生影响。
5、安全事项⑴仪器长期停用后再使用时，应通电半小时以上预热以去潮气。
⑵使用时应注意电缆的放置，应避免压迫和磨损。
⑶使用本仪器对外提供电源时，应注意功率大小，防止烧毁本仪器（≤20VA）。
⑷主机、执行机构的电机都应防水。
二、 主要结构与工作原理1、整机主要结构⑴本产品主要由主机、执行机构组成，其主机前面板如图一所示，后面板如图二所示，执行机构如图三所示，细胞培养皿如图四、五所示。
1—电源指示灯 ２—运行指示灯 ３—状态指示灯 ４－位移指示 ５—频率指示 ６—时间指示 ７—设置键 ８—确认键９—增加键 １0—减少键 １1—启/停键 １2—电源开关图一 主机前面板1—电源插座 ２—保险管 ３—控制驱动电缆插座 ４－散热风机图二 主机后面板123 4 56 7 8 9 10 11 12 2341四点弯曲细胞力学加载仪1—上盖板 2—顶推螺杆 3—并紧螺母 4—顶推轴承 5—顶推芯 6—上立柱 7—控制驱动插座 8—基准板 9—基准立柱 10—定位套 11—回位弹簧支架 12—零位开关杆 13—零位开关锁紧螺钉 14—零位开关座 15—上位开关触点 16—滑动臂 17—回位弹簧及支柱 18—上、下压头（含培养皿） 19—基板 20—脚垫 21—下位开关接头 22—百分表锁紧螺钉 23—百分表 24—下位开关触点 25—接地线图三 执行机构图四 拉应变上下压头 图五 压应变上下压头2、工作原理192021⑴原理方框图（如图六所示）。
JET PBF-1650D双面16ga盒胶囊钢筋弯曲机操作说明书和零部件手册
Operating Instructions and Parts ManualDual-Sided 16ga. Box and Pan BrakeModel PBF-1650DJET427 New Sanford RoadLaVergne, Tennessee 37086 Part No. M-752130 Ph.: 800-274-6848 Edition 1 09/2016 Copyright © 2016 JETThis .pdf document is bookmarked1.0 IMPORTANT SAFETYINSTRUCTIONSREAD ALL INSTRUCTIONS BEFORE USING THIS MACHINE.WARNING – To reduce the risk of injury:1. Read and understand the entire owner'smanual before attempting assembly or operation.2. Read and understand the warnings posted onthe machine and in this manual. Failure tocomply with all of these warnings may causeserious injury.3. Replace the warning labels if they becomeobscured or removed.4. This box and pan brake is designed andintended for use by properly trained and experienced personnel only. If you are notfamiliar with the proper and safe operation of abrake, do not use until proper training andknowledge have been obtained.5. Do not use this brake for other than its intendeduse. If used for other purposes, JET disclaimsany real or implied warranty and holds itselfharmless from any injury that may result fromthat use.6. Always wear ANSI Z87.1 approved safetyglasses or face shield while using this brake.(Everyday eyeglasses only have impact resistant lenses; they are not safety glasses.) 7. Before operating this machine, remove tie,rings, watches and other jewelry, and rollsleeves up past the elbows. Do not wear looseclothing. Confine long hair. Non-slip footwear oranti-skid floor strips are recommended.8. Wear ear protectors (plugs or muffs) if noisereaches unsafe levels.9. CALIFORNIA PROPOSITION 65 WARNING:This product contains chemicals known to theState of California to cause cancer, or birthdefects or other reproductive harm.10. This product, when used for welding, cutting, orworking with metal, produces fumes, gases, ordusts which contain chemicals known to theState of California to cause birth defects and, insome cases, cancer. (California Health andSafety Code Section 25249.5 et seq.) 11. Do not operate this machine while tired or underthe influence of drugs, alcohol or any medication.12. Remove adjusting keys and wrenches. Form ahabit of checking to see that keys and adjustingwrenches are removed from the machine before turning it on.13. Keep safety guards in place at all times whenthe machine is in use. If removed for maintenance purposes, use extreme cautionand replace the guards immediately after completion of maintenance.14. Check damaged parts. Before further use of themachine, a guard or other part that is damagedshould be carefully checked to determine that itwill operate properly and perform its intendedfunction. Check for alignment of moving parts,binding of moving parts, breakage of parts, mounting and any other conditions that mayaffect its operation. A guard or other part that isdamaged should be properly repaired or replaced.15. Provide for adequate space surrounding workarea and non-glare, overhead lighting.16. Keep the floor around the machine clean andfree of scrap material, oil and grease.17. Keep visitors a safe distance from the workarea. Keep children away.18. Make your workshop child proof with padlocks,master switches or by removing starter keys. 19. Give your work undivided attention. Lookingaround, carrying on a conversation and “horse-play” are careless acts that can result in seriousinjury.20. Maintain a balanced stance at all times so thatyou do not fall into the blade or other movingparts. Do not overreach or use excessive forceto perform any machine operation.21. Use recommended accessories; improperaccessories may be hazardous.22. Maintain tools with care. Keep blades sharp andclean for the best and safest performance.Follow instructions for lubricating and changingaccessories.23. Do not stand on the machine. Serious injurycould occur if the machine tips over.24. Remove loose items and unnecessary workpieces from the area before operating the machine.25. Do not use in dangerous environment. Do notuse machine in damp or wet location, or exposeto rain. Keep work area well lighted.26. Sheet metal stock has sharp edges; use cautionwhen handling to prevent cuts.27. Keep hands clear of bending area whileoperating. 28. Do not exceed rated capacity of brake.29. The brake should be secured to floor withappropriate fasteners.Familiarize yourself with the following safety notices used in this manual:This means that if precautions are not heeded, it may result in minor injury and/or possible machine damage.This means that if precautions are not heeded, it may result in serious, or possibly even fatal, injury.SAVE THESE INSTRUCTIONS2.0 About this manualThis manual is provided by JET, covering the safe operation and maintenance procedures for a JET Model BPF-1650D Dual-Sided Box and Pan Brake. This manual contains instructions on installation, safety precautions, general operating procedures, maintenance instructions and parts breakdown. Your machine has been designed and constructed to provide consistent, long-term operation if used in accordance with the instructions as set forth in this document.This manual is not intended to be a guide to sheet metal bending, bend allowances, material choice, etc. Consult a machinery’s handbook and/or experienced users for such information. Whatever accepted methods or materials are used, always make personal safety a priority.If there are questions or comments, please contact your local supplier or JET. JET can also be reached at our web site: .Retain this manual for future reference. If the machine transfers ownership, the manual should accompany it.Read and understand the entire contents of this manual before attempting assembly or operation! Failure to comply may cause serious injury!Register your product online -/us/en/service-and-support/warranty/registration/3.0 Table of contentsSection Page1.0 IMPORTANT SAFETY INSTRUCTIONS (2)2.0 About this manual (3)3.0 Table of contents (4)4.0 Specifications for 16x50 Box and Pan Brake (5)4.1 Floor Diagram (5)5.0 Features and terminology (6)6.0 Setup and assembly (7)6.1 Unpacking and cleanup (7)6.2 Contents of shipping container (7)6.3 Tools required for assembly (7)6.4 Assembly (7)7.0 Operation (7)7.1 Finger spacing (7)7.2 Adjusting setback (7)7.3 Adjusting clamping pressure (8)7.4 Repeat bends (8)7.5 General procedure (8)8.0 User-maintenance (8)8.1 Lubrication (8)8.2 Additional servicing (8)9.0 Troubleshooting PBF-1650D Box and Pan Brake (8)10.0 Replacement Parts (8)10.1.1 BPF-1650D Box and Pan Brake – Exploded View (9)10.1.2 PBF-1650D Box and Pan Brake – Parts List (10)11.0 Warranty and service (12)4.0 Specifications for 16x50 Box and Pan BrakeModel Number ...................................................................................................................................... PBF-1650D Stock Number (752130)Materials:Frame .......................................................................................................................... welded steel plate/tubing Clamping fingers .............................................................................................................................. ground steel Clamping block ................................................................................................................. p recision ground steel Capacities:Bending length .......................................................................................................................... 50 in. (1270 mm) Maximum thickness, mild steel ................................................................................................... 16 ga. (1.5 mm) Bending angle .................................................................................................................................. 0 – 135 deg. Maximum beam lift ................................................................................................................ 1-13/16 in. (46 mm) Maximum box depth ................................................................................................................. 2.5 in. (63.5 mm) Minimum flange in capacity material ............................................................................................. 0.4 in. (10mm) Nose angle (upper fingers) ...................................................................................................................... 42 deg. Nose radius ............................................................................................................................. 1/32 in. (0.79 mm) Number of fingers ............................................................................................................ ......12 upper, 12 lower Finger widths ........................................................... 1, 1-1/8, 1-3/8, 1-1/2, 1-3/4, 2, 3, 4, 6, 7-3/4, 10, 10-5/8 in. Weights:Net ............................................................................................................................................... 772 lb (350 kg) Shipping ....................................................................................................................................... 849 lb (385 kg) Dimensions:Height, floor to working surface ............................................................................................ 35-1/2 in. (902 mm) Shipping (LxWxH) .......................................................................... 67-3/8 x 28 x 51-1/2 in. (171 x 71 x 131 cm) Assembled (LxWxH) ................................................................................... 63 x 38 x 45 in. (160 x 97 x 114 cm) The specifications in this manual were current at time of publication, but because of our policy of continuous improvement, JET reserves the right to change specifications at any time and without prior notice, without incurring obligations.L=length, W=width, H=height4.1 Floor DiagramFigure 15.0 Features and terminologyFigure 21. Clamping leaf2. Clamping fingers3. Clamping adjustment nut (x2)4. Stop bolt5. Setback locking screw (x2)6. Setback knob (x2)7. Bending leaf fingers8. Bending leaf9. Foot pedal for clamping 10. Foot pedal lock11. Leg extension (x2)12. Crown adjustment rod13. Air spring14. Grease fitting (x2)15. Stop collar16. Stop collar screw17. Eccentric disc6.0 Setup and assemblyRead and understand all assembly instructions before attempting assembly. Failure to comply may cause serious injury.6.1 Unpacking and cleanupInspect contents of shipping container for shipping damage. Report any damage to your distributor. Remove all contents from carton, and compare to the contents list in this manual. Report any part shortages to your distributor.Do not discard carton or packing material until machine is assembled and working properly. Exposed metal areas may have a rust protectant applied. Remove this with a soft rag and solvent such as kerosene. (Do not use gasoline, paint thinner, acetone, etc., as these will damage painted surfaces.)6.2 Contents of shipping container1 Box and Pan Brake2 Support legs with screws1 Instructions and Parts Manual (not shown)1 Warranty Card (not shown)6.3 Tools required for assembly8mm hex key6.4 AssemblyNumbers in parentheses refer to items in Figure 2. 1. Remove any straps or screws securing thebrake, and raise machine using properly ratedlifting equipment. See Figure 3 for lifting strapplacement.Figure 3Continue to stabilize machine while installing support legs. 2. Attach the two leg extensions (11) with theprovided socket head screws and flat washers. 3. Secure brake to floor using lag screws or similarsystem. See diagram, Figure 1. Also level thebrake; use shims if needed.4. The stop collar screw (16) has been tightenedfor shipping purposes. This screw must beloosened to allow clamping machine adjustments.7.0 OperationNumbers in parentheses refer to items in Figure 2. 7.1 Finger spacingUpper (2) and lower (7) fingers are mounted on T-nuts that slide within the underlying channel. Remove fingers by removing the screw(s); or reposition fingers at any place along the beam by loosening screw and sliding the T-nuts. Firmly tighten screws on fingers before operating.7.2 Adjusting setbackThe bending leaf lower fingers (7) must be adjusted for proper clearance or “setback” (A, Figure 3) based on material thickness (B, Figure 3). Generally, setback for material within four gauges of capacity should be twice the thickness of material. For lighter gauges, use 1-1/2 times the material thickness. Consult a machinery handbook for bend allowances.Figure 31. Loosen setback locking screws (5).2. Rotate setback knobs (6) in equal amounts(clockwise decreases distance). Refer to adjoining scale, marked with 0.002-inch graduations.Note: When increasing distance (counter-clockwise), you may have to pull back slightlyon the bending leaf to take up any backlash.3. Bring clamping leaf into position and checksetback.4. Repeat above steps until proper distance isachieved.5. Tighten locking screws (5).If a crown develops in the material, this can be adjusted out by loosening or tightening the hex nuts on the crown adjustment rod (12). Note: This rod has been correctly set by the manufacturer and should only be adjusted when needed.7.3 Adjusting clamping pressure Clamping pressure may vary depending upon material gauge. Pressure should be great enough to hold material securely, but not so much that it becomes difficult to clamp.Rotate clamping adjustment nuts (3) equally to set clamping pressure. Proper adjustment will allow foot pedal (9) to be locked (10).7.4 Repeat bendsLoosen stop collar screw (16) and adjust stop bolt (4) to limit swing of bending leaf. Retighten screw (16).7.5 General procedure1. Adjust upper and/or lower fingers for width ofmaterial and type of bend.2. Adjust for setback and clamping pressure.3. Position stop bolt if needed.4. Align material in machine and press foot pedaluntil it locks.5. Raise bending leaf to desired angle.6. Lower bending leaf and press foot pedal lock torelease material.8.0 User-maintenance Periodically wipe down machine with a soft rag. Keep upper and lower fingers clean and clear of debris. Apply light coat of SAE30 oil to upper and lower fingers.Periodically check tightness of fasteners.8.1 LubricationDaily insert a multi-purpose grease into the two fittings (14).Lightly apply grease to pivot points around machine, such as setback rods and eccentric disc.Apply light coat of SAE30 oil to all machined (unpainted) parts when not in use, to inhibit rust. 8.2 Additional servicingAny additional servicing should be performed by an authorized service technician.9.0 Troubleshooting PBF-1650D Box and Pan Brake Symptom PossibleCause CorrectionBends created with great difficulty.Machine capacity exceeded. Use material within capacity. Incorrect setback. Increase setback.Clamping leaf will not clamp properly.Improper adjustment.Decrease distance between fingers andbeam.Clamping not even across width. Rotate adjustment nuts equal amount.Bend radius not consistent across material.Machine capacity exceeded. Use material within capacity.Bending leaf edge not parallel to fingers. Adjust bending leaf equally on both ends. Bending leaf has crown. Correct with crown adjustment rod.10.0 Replacement PartsReplacement parts are listed on the following pages. To order parts or reach our service department, call 1-800-274-6848 Monday through Friday, 8:00 a.m. to 5:00 p.m. CST. Having the Model Number and Serial Number of your machine available when you call will allow us to serve you quickly and accurately.Non-proprietary parts, such as fasteners, can be found at local hardware stores, or may be ordered from JET. Some parts are shown for reference only, and may not be available individually.10.1.1 BPF-1650D Box and Pan Brake – Exploded View10.1.2 PBF-1650D Box and Pan Brake – Parts ListIndex No Part No Description Size Qty1 ................ H40-210 .................... Adjusting Nut ........................................................... .. (2)2 ................ PBF1650D-02 ........... Clamping Leaf. ........................................................ .. (1)3 ................ PBF1650D-03 ........... T-Nut ........................................................................ (48)4-1 ............. PBF1650D-04-1 ........ Upper Finger ............................................................ 1” .. (1)4-2 ............. PBF1650D-04-2 ........ Upper Finger ............................................................ 1-1/8” . (1)4-3 ............. PBF1650D-04-3 ........ Upper Finger ............................................................ 1-3/8” . (1)4-4 ............. PBF1650D-04-4 ........ Upper Finger ............................................................ 1-1/2” . (1)4-5 ............. PBF1650D-04-5 ........ Upper Finger ............................................................ 1-3/4” . (1)4-6 ............. PBF1650D-04-6 ........ Upper Finger ............................................................ 2” .. (1)4-7 ............. PBF1650D-04-7 ........ Upper Finger ............................................................ 3” .. (1)4-8 ............. PBF1650D-04-8 ........ Upper Finger ............................................................ 4” .. (1)4-9 ............. PBF1650D-04-9 ........ Upper Finger ............................................................ 6” .. (1)4-10 ........... PBF1650D-04-10 ...... Upper Finger ............................................................ 7-3/4” . (1)4-11 ........... PBF1650D-04-11 ...... Upper Finger ............................................................ 10” (1)4-12 ........... PBF1650D-04-12 ...... Upper Finger ............................................................ 10-5/8” .. (1)5 ................ TS-1505021 .............. Socket Head Cap Screw ......................................... M10x20 .. (66)6 ................ PBF1650D-06 ........... Clamping Block ........................................................ .. (1)7 ................ PBF1650D-07 ........... Adjusting Nut Spring ................................................ .. (2)8 ................ TS-155011 ................ Flat Washer ............................................................. 20mm . (6)9 ................ PBF1650D-09 ........... Grease Fitting .......................................................... M8x1 .. (2)10 .............. H40-227 .................... Bushing .................................................................... .. (2)11 .............. H40-226 .................... Flat Washer ............................................................. 30 . (2)12 .............. H40-209 .................... Bending Leaf Pin ..................................................... .. (1)13 .............. TS-1505051 .............. Socket Head Cap Screw ......................................... M10x35 . (1)14 .............. H40-204 .................... Stop Collar ............................................................... .. (1)15 .............. TS-1540071 .............. Hex Nut .................................................................... M10 . (1)16 .............. TS-1505061 .............. Socket Head Cap Screw ......................................... M10x40 . (1)17 .............. PBF1650D-17 ........... Leg ........................................................................... .. (2)18 .............. BPF1240-18 .............. Ext. Retaining Ring .................................................. 25mm .. (13)19 .............. H40-208 .................... Leg Pin .................................................................... .. (3)20 .............. TS-1505041 .............. Socket Head Cap Screw ......................................... M10x30 . (4)21 .............. H40-217-3G .............. Extension Bracket .................................................... .. (2)22 .............. PBF1650D-22 ........... Disc Spring .............................................................. Ø40xø20x1mm . (4)23 .............. H40-205 .................... Rod .......................................................................... .. (2)24 .............. H40-206 .................... Foot Pedal Lever ..................................................... .. (4)25 .............. H40-207.................... Lever Pin .................................................................. .. (4)26 .............. PBF1650D-26 ........... Foot Pedal ............................................................... .. (1)27 .............. H40-402 .................... Tread Plate Rubber ................................................. .. (1)28 .............. H40-211 .................... Roll Pin .................................................................... .. (1)29 .............. BPF1240-29 .............. Ext. Retaining Ring .................................................. 10mm . (2)30 .............. H40-213.................... Foot Pedal Lock ....................................................... .. (1)31 .............. BPF1240-31 .............. Spring Pin ................................................................ 8x50mm (1)32 .............. TS-1550061 .............. Flat Washer ............................................................. 8mm (1)33 .............. H40-212 .................... Pedal Lock Spring ................................................... .. (1)34-1 ........... PBF1650D-34-1 ........ Lower Finger ............................................................ 1” .. (1)34-2 ........... PBF1650D-34-2 ........ Lower Finger ............................................................ 1-1/8” . (1)34-3 ........... PBF1650D-34-3 ........ Lower Finger ............................................................ 1-3/8” . (1)34-4 ........... PBF1650D-34-4 ........ Lower Finger ............................................................ 1-1/2” . (1)34-5 ........... PBF1650D-34-5 ........ Lower Finger ............................................................ 1-3/4” . (1)34-6 ........... PBF1650D-34-6 ........ Lower Finger ............................................................ 2” .. (1)34-7 ........... PBF1650D-34-7 ........ Lower Finger ............................................................ 3” .. (1)34-8 ........... PBF1650D-34-8 ........ Lower Finger ............................................................ 4” .. (1)34-9 ........... PBF1650D-34-9 ........ Lower Finger ............................................................ 6” .. (1)34-10 ......... PBF1650D-34-10 ...... Lower Finger ............................................................ 7-3/4” . (1)34-11 ......... PBF1650D-34-11 ...... Lower Finger ............................................................ 10” (1)34-12 ......... PBF1650D-34-12 ...... Lower Finger ............................................................ 10-5/8” .. (1)35 .............. BPF1240-31 .............. Spring Pin ................................................................ 8x50mm (2)37 .............. PBF1650D-37 ........... O-Ring ..................................................................... 25x3.55mm . (2)38 .............. PBF1650D-38 ........... Setback Rod ............................................................ .. (2)Index No Part No Description Size Qty39 .............. PBF1650D-39 ........... Setback Knob .......................................................... .. (2)40 .............. PBF1650D-40 ........... Operating Handle .................................................... .. (2)41 .............. PBF1650D-41 ........... Adjusting Rod .......................................................... .. (1)42 .............. PBF1650D-42 ........... Bending Leaf ........................................................... .. (1)43 .............. TS-1550111 .............. Flat Washer ............................................................. 20 . (2)44 .............. TS-2310201 .............. Hex Nut .................................................................... M20 . (2)45 .............. TS-2228161 .............. Hex Cap Screw ........................................................ M8x16 (2)46 .............. PBF1650D-46 ........... Fixing Plate .............................................................. .. (1)47 .............. PBF1650D-47 ........... Air Spring ................................................................. .. (1)48 .............. TS-2211451 .............. Hex Cap Screw ........................................................ M12x45 . (2)49 .............. TS-2311121 .............. Hex Nut .................................................................... M12 . (2)50 .............. PBF1650D-50 ........... Eccentric Holder ...................................................... .. (1)51 .............. TS-155011 ................ Flat Washer ............................................................. M20 . (2)52 .............. TS-1502021 .............. Socket Head Cap Screw ......................................... M5x10 (2)53 .............. PBF1650D-53 ........... Rubber Pad ............................................................. .. (2)54 .............. PBF1650D-54 ........... Bushing .................................................................... .. (4)55 .............. TS-1521031 .............. Socket Set Screw .................................................... M4x8 .. (2)56 .............. PBF1650D-56 ........... Scale ........................................................................ .. (2).................. LM000240 ................. ID/Warning Label, PBF-1650D (not shown) ............ .. (1).................. JET-165 ..................... JET Logo (not shown) ............................................. 165x68mm .. (1)11.0 Warranty and serviceJET warrants every product it sells against manufacturers’ defects. If one of our tools needs service or repair, please contact Technical Service by calling 1-800-274-6846, 8AM to 5PM CST, Monday through Friday.Warranty PeriodThe general warranty lasts for the time period specified in the literature included with your product or on the official JET branded website.•JET products carry a limited warranty which varies in duration based upon the product. (See chart below) •Accessories carry a limited warranty of one year from the date of receipt.•Consumable items are defined as expendable parts or accessories expected to become inoperable within a reasonable amount of use and are covered by a 90 day limited warranty against manufacturer’s defects. Who is CoveredThis warranty covers only the initial purchaser of the product from the date of delivery.What is CoveredThis warranty covers any defects in workmanship or materials subject to the limitations stated below. This warranty does not cover failures due directly or indirectly to misuse, abuse, negligence or accidents, normal wear-and-tear, improper repair, alterations or lack of maintenance. JET woodworking machinery is designed to be used with Wood. Use of these machines in the processing of metal, plastics, or other materials outside recommended guidelines may void the warranty. The exceptions are acrylics and other natural items that are made specifically for wood turning. Warranty LimitationsWoodworking products with a Five Year Warranty that are used for commercial or industrial purposes default to a Two Year Warranty. Please contact Technical Service at 1-800-274-6846 for further clarification.How to Get Technical SupportPlease contact Technical Service by calling 1-800-274-6846. Please note that you will be asked to provide proof of initial purchase when calling. If a product requires further inspection, the Technical Service representative will explain and assist with any additional action needed.JET has Authorized Service Centers located throughout the United States. For the name of an Authorized Service Center in your area call 1-800-274-6846 or use the Service Center Locator on the JET website.More InformationJET is constantly adding new products. For complete, up-to-date product information, check with your local distributor or visit the JET website.How State Law AppliesThis warranty gives you specific legal rights, subject to applicable state law.Limitations on This WarrantyJET LIMITS ALL IMPLIED WARRANTIES TO THE PERIOD OF THE LIMITED WARRANTY FOR EACH PRODUCT. EXCEPT AS STATED HEREIN, ANY IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE EXCLUDED. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU.JET SHALL IN NO EVENT BE LIABLE FOR DEATH, INJURIES TO PERSONS OR PROPERTY, OR FOR INCIDENTAL, CONTINGENT, SPECIAL, OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OF OUR PRODUCTS. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.JET sells through distributors only. The specifications listed in JET printed materials and on official JET website are given as general information and are not binding. JET reserves the right to effect at any time, without prior notice, those alterations to parts, fittings, and accessory equipment which they may deem necessary for any reason whatsoever. JET® branded products are not sold in Canada by JPW Industries, Inc.Product Listing with Warranty Period90 Days – Parts; Consumable items1 Year – Motors; Machine Accessories2 Year – Metalworking Machinery; Electric Hoists, Electric Hoist Accessories; Woodworking Machinery usedfor industrial or commercial purposes5 Year – Woodworking MachineryLimited Lifetime – JET Parallel clamps; VOLT Series Electric Hoists; Manual Hoists; Manual HoistAccessories; Shop Tools; Warehouse & Dock products; Hand Tools; Air ToolsNOTE: JET is a division of JPW Industries, Inc. References in this document to JET also apply to JPW Industries, Inc., or any of its successors in interest to the JET brand.。
钢筋弯曲机安全操作规程(三篇)
钢筋弯曲机安全操作规程钢筋弯曲机是一种用于加工钢筋的机械设备，它的使用需要遵守一系列的安全操作规程，以确保操作人员的安全。
以下是钢筋弯曲机的安全操作规程，共计____字：第一章总则第一条为了保证钢筋弯曲机的安全和稳定运行，保护操作人员的生命和财产安全，制定本安全操作规程。
第二条钢筋弯曲机安全操作规程适用于所有使用钢筋弯曲机的操作人员，包括设备的操作、维护和保养。
第三条钢筋弯曲机的使用人员必须熟悉和掌握本规程的内容，并服从指挥和管理。
第四条钢筋弯曲机操作人员必须持有效证件，经过必要的培训和考核，具有使用该设备的资格和能力。
第二章设备安全控制第五条钢筋弯曲机使用前，必须检查设备是否处于正常工作状态，如有异常现象和故障，必须报告上级或维修人员进行处理。
第六条钢筋弯曲机必须设置有效的安全控制装置，包括但不限于急停装置、限位装置、防护罩等。
第七条在操作钢筋弯曲机的过程中，不得私自拆除或改变设备的安全控制装置。
第八条操作人员使用钢筋弯曲机前，必须检查设备周围的工作环境，确保没有杂物和障碍物，保持通道畅通，并做好防滑措施。
第九条在使用钢筋弯曲机的过程中，操作人员不得随意触摸任何机器部件，必须使用操作杆或按钮进行操作。
第十条钢筋弯曲机操作人员必须保持机器和周围环境的清洁，防止灰尘、油污等物质进入机器内部。
第三章操作安全规范第十一条钢筋弯曲机的操作人员必须了解设备的使用说明书和安全注意事项。
第十二条在操作钢筋弯曲机之前，操作人员必须穿戴好相应的个人防护装备，如安全帽、防护眼镜、耳塞等。
第十三条钢筋弯曲机操作人员必须保持良好的工作状态，保证头脑清醒，不得饮酒、吸烟或服用药物。
第十四条在操作钢筋弯曲机之前，操作人员必须检查和调整设备的工作参数，确保设备运行平稳。
第十五条在操作钢筋弯曲机时，操作人员必须稳定身体姿势，不得跨越运动部件或放置身体在机器移动范围内。
第十六条在操作钢筋弯曲机时，操作人员必须集中注意力，专心操作，不得四处与他人交谈或分散注意力。
四点弯曲强度试验机说明书
四点弯曲强度试验机产品说明书前言感谢贵司选择了本公司的产品，本公司不仅给贵司提供质量优良的产品，而且将提供可靠的售后服务。
为确保使用人员之人身安全及仪器的完好性，请使用本仪器前充分阅览此操作手册，并留意其使用上的注意事项。
本操作手册详细介绍此仪器之设计原理、依据标准、构造、操作规范、校正、保养、可能故障的情形及排除方法、电气图等内容。
在本操作手册中如有提及之各种“试验规定”、标准时均只作参考用，如贵司觉得有异议请自行检阅相关标准或资料。
特别声明：●本操作手册不能向本公司提出任何要求的依据；●本操作手册的解释权在本公司。
目录一、简介 -------------------------------------------------- 1二、执行标准 ----------------------------------------------- 1三、主要技术参数 ------------------------------------------- 2四、仪器正常工作的环境要求 --------------------------------- 2五、仪器结构 ----------------------------------------------- 3六、操作面板及功能 ----------------------------------------- 3七、仪器的操作 --------------------------------------------- 4-6八、软件操作指南 ------------------------------------------- 7-9九、维护保养----------------------------------------------- 10十、故障排除与维修----------------------------------------- 10 十一、产品成套一览----------------------------------------- 11一、简介1.1 用途本机是一款专业适用于手机、平板电脑、液晶、触控、光伏玻璃和塑料等材料进行三点、四点弯曲试验的仪器。
钢筋弯曲机安全技术操作规程（2篇）
钢筋弯曲机安全技术操作规程钢筋弯曲机是一种重要的施工机械设备，用于将钢筋进行弯曲加工，广泛应用于建筑施工行业。
然而，由于其操作过程中存在一些安全隐患，因此有必要建立一套完整的安全技术操作规程来指导操作人员的工作。
以下是钢筋弯曲机的安全技术操作规程，共____字。
一、前言为了保障钢筋弯曲机的安全操作，有效预防事故的发生，保证施工的安全性和质量，制定本规程。
二、安全技术操作规程2.1 操作人员的要求1. 操作人员必须经过相关专业培训，具备一定的机械设备操作经验和技术知识。
2. 操作人员必须具备身体健康状况、良好的职业素质和责任心。
3. 操作人员应熟悉钢筋弯曲机的结构和工作原理，熟悉操作方法。
4. 操作人员必须掌握安全操作规程和紧急事故处理措施。
2.2 前期准备工作1. 在操作前，操作人员应对钢筋弯曲机进行全面的检查，确保设备完好无损、安全可靠。
2. 检查钢筋弯曲机的电源是否正常，电线是否破损，电源插头是否接地。
3. 清理钢筋弯曲机的工作平台和周围区域，确保无杂物、障碍物和易燃物。
4. 检查钢筋弯曲机的润滑情况，确保各润滑部位充满润滑油。
5. 检查钢筋弯曲机的保护装置，如限位开关、安全传感器等，确保其正常工作。
2.3 操作流程1. 操作人员应穿戴好劳动防护用品，如安全帽、工作服、防护手套、防护眼镜等。
2. 打开电源开关，检查设备的电源是否正常，设备的各个按钮和开关是否灵活可用。
3. 轻轻将钢筋放入弯曲机的夹具中，确保钢筋的位置正确，并松动紧固夹具。
4. 调整弯曲机的工作参数，包括弯曲角度和弯曲半径等，根据具体要求和工程图纸进行设置。
5. 确认操作人员和周围人员远离钢筋弯曲机的工作区域，确保安全。
6. 按下启动按钮，启动钢筋弯曲机，观察设备工作情况是否正常。
7. 当钢筋完成弯曲后，及时停止设备的运行，取出弯曲后的钢筋，进行下一道工序的加工。
2.4 安全操作要点1. 操作过程中，严禁将手臂、手指等身体部位放入钢筋弯曲机的夹具中，以免造成伤害。
- 1、下载文档前请自行甄别文档内容的完整性，平台不提供额外的编辑、内容补充、找答案等附加服务。
- 2、"仅部分预览"的文档,不可在线预览部分如存在完整性等问题,可反馈申请退款(可完整预览的文档不适用该条件!)。
- 3、如文档侵犯您的权益，请联系客服反馈,我们会尽快为您处理(人工客服工作时间：9:00-18:30)。
第一组弯曲模具
方案设计
组长：李志宏
弯曲负责：郑勇黄洋
班级：机械（汽车）
2.材料板弯曲模设计
2.1材料板弯曲工艺性分析
图2—1
弯曲是使材料产生塑性变形、形成有一定角度形状零件的冲压工序。
弯曲工序可以用模具在普通压力机上进行，也可以在专用的弯曲机上或弯曲设备上进行。
具有良好的工艺性的弯曲件，不仅能简化弯曲工艺过程和模具设计，而且能够提高弯曲件的精度和节省材料。
具有良好工艺性的弯曲件，不仅能简化弯曲故意过程和模具设计，而且能提高弯曲件精度和节省材料。
弯曲件的工艺性可以从最小弯曲半径，弯曲件直边高度，弯曲件孔边距离，增添工艺孔，槽和转移弯曲线，连接带和定位工艺孔，弯曲件的精度等几个方面进行分析：
由零件图2-1所示，材料板属于板材弯曲。
材料板厚度1.6mm,内弯曲半径是R0.5 mm，弯曲角度成90º，弯边长130.3mm，符合弯曲的工艺性要求，角度回弹量Δθ=7º，足以达到制件精度质量要求。
2.2模具结构方案的确定
弯曲零件常见的模具结构有以下几种。
如图2—2所示：
图2—2 弯曲模结构方案示意图
鉴于本零件的实际要求，及相关的定位和精度要求，以上几种方案图中，图（b）能够达到设计要求，结构清晰、简单、可行性高。
具体设计如下图2—3：
图2—3
2.3有关工艺与设计计算
2.3.1校正弯曲力按下面的公式近似计算：
F
=Aq
校
——校正弯曲力，N；
式中F
校
A——校正部分投影面积；mm2；
q—单位校正力，MPa，查手册取p=40MPa。
可以通过软件测得：A= 1824.2mm2
F
校
=Aq=1824.2×40=72968 N =72.968 KN 2.3.2自由弯曲力可按下式计算：对于U形件
F
自=
0.7kbt2R m
r+t
式中F
自
——自由弯曲力，N；
b——弯曲件宽度，mm；
t——弯曲件厚度，mm；
r——弯曲件的内弯曲半径，mm；
Rm——材料的抗拉强度,30刚取500MPa； K——安全系数，一般取K=1.3。
可以算得：
F
自
=16750 N =16.75 KN
顶件力可按下式计算：
F=（0.3—0.8） F
自
，取0.5
式中F
自
——自由弯曲力，N；
F——顶件力，N。
可以算得：
F=0.5F
自
=0.5×16.75 KN=8.375 KN
工艺压力P
∑= F
校
+F+ F
自
=72.968+8.375+16.75=98.093 KN
2.4材料板弯曲件的回弹
1）压弯过程并不完全是材料的塑性变形过程，其弯曲部位还存在着弹性变形。
弯曲工件从模具中取出后，由于弹性变形的恢复，使工件的弯角和弯曲半径发生变化，所以被弯曲零件的形状与模具的性质不完全一致，这种现象称为回弹。
回弹的大小通常用角度回弹量Δα和曲率回弹Δρ来表示。
2）影响回弹的因素
（1）材料的力学性能角度回弹量及曲率回弹量与材料的屈服点σs成正比，与弹性模量E成反比。
（2）材料的相对弯曲半径R/t 当其他条件相同时，R/t值越小，则：Δα/α与Δρ/ρ也越小。
（3）弯曲工件的形状 一般弯制U 形工件要比弯制V 形工件的回弹量要小。
（4）模具间隙 在弯曲U 形工件时，凸模与凹模之间的间隙越小，则回弹量越小；Z/2<t 时，可能产生负回弹。
（5）校正弯曲时的较正力 校正力小，回弹量大，增加校正力可减小回弹量。
3） 回弹量的确定
由于影响角度回弹量数值的因素较多，而各种因素又互相影响，理论分析计算较复杂，且不够精确，所以在一般的情况下，设计模具时对回弹量的确定大多按照经验数值，计算后在实际试模中再进行修正。
只有当弯曲工件的圆角半径R 》（5-8）t 时，计算才近似正确。
当R <（5-8）t 时，工件的弯曲半径一般变化不大，只考虑角度回弹。
本零件的R=1.6，远小于（5-8）t=10-16 mm,只考虑角度回弹量Δα，查角度回弹的经验数值表可得：
Δα=7 º
2.5弯曲模工作部分的设计
2.5.1 弯曲时凸模与凹模之间的单边间隙C 弯曲U 形件时，凸，凹模间隙对弯曲件的回弹、等有很大影响。
间隙越小，弯曲力越大；间隙过小，会使工件壁变薄，并降低凹模寿命；间隙过大，则回弹较大。
当C<t 时，可能出现负回弹。
间隙值C 一般按经验公式进行计算：对钢板，C=（1.05—1.15）t
取C=1.1t=1.1X1.6=1.76 mm
2.5.2 凸，凹模工作部分尺寸 按零件内形尺寸计算，模具以凸模为基准，间隙取在凹模上。
1）凸模宽度
Lp=(L +x Δ)−σp 0=(14+0.5x0.1)−0.020=14.05−0.020 mm
2)凹模宽度
Ld=(L +2C)0+σd =(14+2x1.76)0
+0.03=17.520+0.03 mm 2.5.3 模具圆角半径和凹模的深度的确定
（1）凸模圆角半径 一般来讲，凸模圆角半径等于或小于工件内侧的圆角半径：
R
= 0.5 mm
凸
(2) 凹模圆角半径凹模的圆角半径并不直接影响工件的尺寸，但太小是会在弯曲时擦伤毛坯，使材料表面出现划痕，太大回增加凹模深度。
凹模半径可查表2-4；
表2-4 凹模圆角半径与凹模深度对应关系
查表取：R
=8mm l=25 mm
凹
2.6确定模具总体结构
工件形状简单，2xΦ8可作弯曲时定位孔，定位销钉直径应根据凹模尺寸确定。
为了取件和压料，设置弹性顶件装置。
为了使顶板不产生横向窜动，顶板应与凹模滑配，并用弹簧产生压料力和顶件力。
（图2-5）
图2—5具有弹性顶料的弯曲模具
2.7主要模具零件的设计
1）凹模的设计
=0.5 mm。
其他尺寸根据零件要求和安装固定要求确定，材工作部分圆角R
凸
料可以选用45钢，热处理硬度55～63HRC。
2）凸模的设计
工作部分圆角R
=8 mm。
其他尺寸根据零件要求和安装固定要求确定，材
凹
料可以选用30钢，热处理硬度56～62HRC。
3）模架设计
⑴上模座
根据零件尺寸查GB/T2855.9取200x100x35，材料可以选用Cr12MoV, 安装固定按要求确定。
⑵下模座
根据零件尺寸查GB/T2855.9取200x100x40，材料可以选用HT400, 安装固定按要求确定。
⑶模柄
选用旋入式模柄。
根据冷冲模标准，选用：
表2.6 旋入式模柄摘自JB/T7646.2-1994
模柄A50JB/T7646.1
材料：Q235
技术条件：按JB/T7653-1994的规定
（4）导柱
根据手册查GB/T2861.3-1990取A25x180。
（5）导套
根据手册查GB/T2861.6-1990取A25x70x28。
（6）定位装置设计
<1> 定位销
根据冷冲模标准，选用适当尺寸的销：
销GB119.1-2000 m8x16
材料：35# 热处理HRC28-38
<2> 内六角圆柱螺钉
根据冷冲模标准，选用适当尺寸的内六角圆柱螺钉：螺钉GB70.1-2000 M8×45
表2-7 圆柱头六角螺钉JB/T70.1-2000
(7) 销
根据冷冲模标准，选用适当尺寸的销：表2-8
销1 销M8×45 GB/T119.1-2000
销2 销M8×14 GB/T119.1-2000
2.8确定压力机及模具的闭合高度的确定
1）根据设计前面的计算，应选取的压力机公称压力为
F
压机≥1.3P
∑
=1.3( F
校
+F)=1.3x9.718=116.633 KN
F
压机
≈120 KN
查有关资料可以选取压力机型号为开式倾式曲柄压力机J23-16，其
公称压力 160 KN
最大封闭高度：220 mm，封闭高度调节量： 60 mm。
