A Memory-Efficient KinectFusion Using Octree

A Memory-Efficient KinectFusion Using OctreeMing Zeng,Fukai Zhao,Jiaxiang Zheng,and Xinguo LiuState Key Lab of CAD&CG,Zhejiang University,Hangzhou,China,310058mingzeng85@,xgliu@Abstract.KinectFusion is a real time3D reconstruction system based on a low-cost moving depth camera and commodity graphics hardware.It represents thereconstructed surface as a signed distance function,and stores it in uniform volu-metric grids.Though the uniform grid representation has advantages for parallelcomputation on GPU,it requires a huge amount of GPU memory.This paperpresents a memory-efficient implementation of KinectFusion.The basic idea isto design an octree-based data structure on GPU,and store the signed distancefunction on data nodes.Based on the octree structure,we redesign reconstructionupdate and surface prediction to highly utilize parallelism of GPU.In the recon-struction update step,wefirst perform“add nodes”operations in a level-ordermanner,and then update the signed distance function.In the surface predictionstep,we adopt a top-down ray tracing method to estimate the surface of the scene.In our experiments,our method costs less than10%memory of KinectFusionwhile still being fast.Consequently,our method can reconstruct scenes8timeslarger than the original KinectFusion on the same hardware setup.Keywords:Octree,GPU,KinectFusion,3D Reconstruction.1Introduction3D reconstruction for real scenes is an important research area in computer vision and computer graphics.For decades,researchers have developed all kinds of methods for efficient and accurate reconstruction.One popular method reconstructs scenes by fusing depth maps from different views.Especially,Newcombe et al.[9]and Izadi et al.[6] proposed KinectFusion,which used a commodity depth camera Kinect[8]to scan and model the dense surface of a room-size(about4m×4m×4m)scene in realtime.The algorithm leverages the parallel computing ability of the modern GPU to track the pose of the Kinect,and fuses the depth map of each frame into a scene volume.KinectFusion uses a uniformly divided volume,and stores the data of all voxels in this volume.In a real scene,however,large amount of space is not occupied by the object’s surface,therefore KinectFusion greatly wastes GPU memory,which hinders scene reconstruction in larger scale.To solve the problem,we introduce an octree struc-ture to efficiently store the scene data.Based on the octree,we propose an algorithm to maintain the octree and integrate depth maps online.Our method sufficiently ex-ploits the hierarchical structure of the octree and GPU parallelism.We adopt different Corresponding author.S.-M.Hu and R.R.Martin(Eds.):CVM2012,LNCS7633,pp.234–241,2012.c Springer-Verlag Berlin Heidelberg2012A Memory-Efficient KinectFusion Using Octree235 traversal manners in our method to update and trace the octree to achieve optimized per-formance.When updating the volume,we traverse the octree in a level-order manner to exploit GPU parallelism.When predicting the scene surface,we traverse the octree in a top-down way to skip large non-data spaces.Benefit from careful designs,our method performs better than KinectFusion both in memory and computational efficiency.2Related WorkThis section introduces the related works on3D reconstruction and octree construction on GPU.We only survey works most relevant to this paper.3D Reconstruction.3D reconstruction techniques capture scene information by RGB cameras or depth cameras,and then reconstruct the geometry of the scene.Lots of researchers capture RGB images of a scene,then utilize structure from mo-tion(SFM)and multi-view stereo(MVS)to locate cameras and recover a sparse point cloud of the scene[2,11].This kind of method is time consuming and unable to ob-tain dense scene surface.Recently,some studies used RGB sequence to reconstruct the dense surface[12,13,10]of a small scene(about1m×1m×1m)in real time.Depth cameras are able to capture a depth map of current scene on each frame. Leveraging this ability,we can align depth maps to form the whole scene surface.The most popular method for this task is Iterative Closest Point(ICP)[1].It was widely used to register views of depth maps into a global coordinate.With ICP,the KinectFusion proposed by Newcombe et al.[9]and Izadi et al.[6]leverages depth camera and GPU to reconstruct a dense surface of a room-size(about4m×4m×4m)scene in real time. Based on the KinectFusion,Whelan et al.[15]proposed a system“Kintinuous”which supports modeling on unbounded regions by shifting volume and extracting meshes continuously.This system utilized KinectFusion as a building block,and extended the ability to support large scale scanning.In contrast to[15],our method improves the core parts of the KinectFusion,and it can be a building block of large scale scanning systems like Kintinuous.Octree Construction on GPU.An octree adaptively splits the space of the scene ac-cording to the complexity of the scene to use memory efficiently[3].Though the sim-plicity of its definition,it is hard to be maintained using parallelism feature of GPU due to the sparseness of its nodes[16].Sun et al.[14]built an octree with only leaf nodes to store volume data and accelerated photon tracing based on the octree.Zhou et al.[16] constructed a whole octree structure on GPU to accelerate Poisson Reconstruction[7]. 3OverviewThe overviews of KinectFusion and our method are shown in Figure1left.The Kinect-Fusion contains four main stages:Surface Measurement,Camera Pose Estimation,Re-construction Update,and Surface Prediction(see[9,6]).In our method,we adopt the similarflowchart of KinectFusion.However,to overcome the large memory consump-tion due to the uniform voxel in KinectFusion,we introduce an octree structure to com-pactly organize the scene data in our method.Based on the octree,we design new algo-rithms for Reconstruction Update and Surface Prediction to utilize GPU parallelism.236M.Zeng et al.Fig.1.Overview and Data Structure of our method.Left:overview of KinectFusion and improve-ments of our method.The red dash rectangle indicates the improved parts.Right:illustration of the octree structure.In the following sections,wefirst introduce the octree structure in Section4,fol-lowed by Reconstruction Update and Surface Prediction.In Section7,we describe im-plementation details and experimental results,after which we give the conclusion.4Octree StructureOur octree structure is stored in arrays of different layers.One array corresponds to one layer of the octree.As illustrated in Figure1right,there are three kinds of layers in our octree structure:Branch Layer,Middle Layer and Data Layer.All possible nodes in the branch layer are allocated,and can be randomly accessed.Nodes of other layers are not fully allocated,which can only be visited by links betweens adjacent layers.–Branch Layer:The branch layer contains all nodes in its layer.Each node of the branch layer stores the index idChild of thefirst child.If the node doesn’t have children nodes,idChild is set to−1.–Middle Layer:Nodes in middle layers record both idChild and shuffled xyz key[16].The shuffled xyz key of a node at depth D is defined as a bit string: x1y1z1x2y2z2...x D y D z D,where each3-bit code x i y i z i encodes one of the eight subregions at depth i.idChild can be used to traverse an octree in the depth-first manner,while shuffled xyz key can be utilized for the level-order traversal.–Data Layer:Each node in this layer stores its shuffled xyz key and data of the scene[9,6]:Signed Distance Field SDF and weight w.In the data structure,the branch layer is the starting layer,and it is not necessarily the root layer.We use a symbol OT(T,L)to represent an octree with a branch layer at depth T,and data layer at depth L.Accordingly,OF(T,L)represents our algorithm based on OT(T,L).We also denote our algorithm with a n-depth octree as OF n.To represent the octree structure,we use following arrays to organize above data:–NodeBuf is a pre-allocated two-dimensional array to store nodes of each level.The ith node at level L is stored in NodeBuf[L][i].–IdStart is a pre-allocated one-dimensional array to record the current starting in-dex of the available buffer of each level,as black arrows shown in right of Figure1.The current starting index of level L is recorded in IdStart[L].A Memory-Efficient KinectFusion Using Octree237 Algorithm1.Add Nodes for the Octree at Level L1://Step1:Predict whether a node needs further split16://Step2:Scan the splitflag array2:for Node O i at Level L in parallel do17:(ScanOut,nNewNodeCount)←Scan(ScanIn,+)3:if O i in view frustum4:v g←PosFromNode(O i,L)18://Step3:Assign child index and compute xyz key5:v←WorldCoord2CamCoord(v g)19:for O i at level L in parallel6:p←perspective project vertex v20:if ScanIn[i]==17:dir←v g−v cam21:idx=IdStart[L+1]+(ScanOut[i]<<3)8:sd f= v cam−v g −D(p,dir)22:NodeBuf[L][i].idChild=idx9:if IsSplit(O i,sd f)and O i has no child23:key=O i.xyzkey10:ScanIn[i]=124:for k=0to7do11:else25:NodeBuf[L+1][idx+k].xyzkey=(key<<3)|k 12:ScanIn[i]=026:end for13:endif27:end if14:endif28:end for15:end for29://Step4:Update IdStart30:IdStart[L+1]+=8∗nNewNodeCount5Reconstruction Update Based on OctreeThere are two operations in the step of reconstruction update:add nodes for new scene data,and SDF data update.5.1Add Nodes for OctreeTo add new nodes for the octree,we adopt a top-down level-order manner to traverse the octree.We split nodes and assign children indices level by level,starting from the branch layer and moving towards the data layer,one level at a time.For level L,the pseudo code of the procedure is listed in Algorithm1.At thefirst step,we predict whether a node needs further split in parallel.For the node in the view frustum,we calculate the signed distance sd f from its center to the current depth map(Line4to8).Then,given sd f,we use the function IsSplit(described later) to predict node splits and mark1/0in an auxiliary array ScanIn.At step2,we take Parallel Prefix Sum(Scan)[5]with the add operation“+”on ScanIn to compute the unique id of new split nodes.At step3,we assign index of itsfirst child to the node to be split.At this step,we alsofigure out and store the shuffled xyz key of each new child node according to the shuffled xyz key of its parent node and its relative position in all eight children.Finally at step4,we update the index of thefirst available node in the memory pool of the child layer.In the function IsSplit,we assume the scene near the node is approximately a plane. We denote distance between center of the node and scene surface as sd f,diagonal length of the node as d,then distances from all points within the node to the surface must be in[sd f−d/2,sd f+d/2].Take the further consideration that the distancefield stored in scene volume is in[−U,U],U is the maximal truncation value.To ensure a correct split prediction,the node split iff[sd f−d/2,sd f+d/2]intersects with[−U,U],i.e. sd f∈[−U−d/2,U+d/2].5.2Update SDF for OctreeAfter updating the structure of the octree,the current depth map should be integrated into the scene volume to update signed distance function.We only need to update the238M.Zeng et al.Algorithm2Surface Prediction1:for each pixel u in imaging plane in parallel do18://estimate position and normal2:Ray dir←direction of the ray19:if l==level of thefinest layer then 3:g←first voxel along ray dir in thefinest level20:if zero crossing from g prev to g then 4:Ray step←021:P←estimate surface position 5:while voxel g within volume bounds do22:N←estimate surface normal 6://determine the marching step23:break7:xyzkey←Grid2Key(g)24:end if8:l←level of the branch layer25:end if9:node←Key2Node(xyzkey,l,NodeBuf,null)26:end while10:while node has children do27:end for11:l++12:node←Key2Node(xyzkey,l,NodeBuf,node)13:end while14:Ray step←NextStepLen(g,Ray dir,node)15://march forward16:g prev←g17:g+=Ray dir·Ray stepnodes at the data layer to integrate the depth map.We adopt the similar integration algorithm as the method in[6]except that we compute positions of data nodes from shuffled xyz code while[6]directly compute them from their grid indices.6Surface Prediction Based on OctreeAfter structure and data update of the octree,like[9,6],a ray tracer is taken to ray-cast the scene volume and estimate the scene surface.Algorithm2lists the pseudo code. Each ray marches forward until crossing the object’s surface.Line6to14determine the current amount offinest steps to march forward.In Line7,Grid2Keyfigures out the xyzkey.Then in Line8to13,with xyzkey,we adopt a top-down way tofind the most compact octree node holding the position g.The most compact node for g means no surface data is in the node,so the ray can“bravely”marches across this most compact node.So in Line14,we compute the marching step according to the depth(level)of the most compact node by the function NextStepLen.After marching forward,if the ray crosses surface,we estimate the position and normal of the hitting points between the ray and the object’s surface.The position and normal of the intersection point are estimated in a trilinear interpo-lation way[9,6].Normals of points around two sides of the zero-crossing surface can be calculated by forward/backward differences according to the relative position of the node of its siblings.7Implementation and Experiments7.1Implementation DetailsWe have implemented the whole pipeline of our algorithm in C++with Nvidia CUDA, and test it on a desktop computer with an Intel Core2Duo E74002.80GH CPU(use one core)and a Nvidia GeForce GTX480graphics card.For the operator Scan,we used the implementation provided in the highly optimized GPU library CUDPP[4].A Memory-Efficient KinectFusion Using Octree 239All data data structures are stored in the global memory.For a layer at depth D of an OT (T,L ),the node count N of the GPU memory buffer is as follows:N = 23D ,D ≤T µ·23D ,D >T(1)where µis proportion to all possible nodes at its depth.In our current implementation,µis set to 0.05for depth no deeper than 9,and 0.03for depth 10.7.2ExperimentsThis section compares our method with KinectFusion from three aspects:memory con-sumption,computation time,and reconstruction for large scene.Memory Comparison.We compare memory consumption between KinectFusion and our method on a depth map sequence “chairs”(Figure 2).For KinectFusion,we adopt the 5123resolution (KF512),and for our method,we test both 9-depth (OF9)and 10-depth octree (OF10).In this experiment,branch layers of both OF9and OF10are set at depth 7.Figure 2middle shows the memory consumptions on each frame of “chairs”with KF512,OF9,and OF10.KF512cost 512MB memory constantly,while OF9and OF10increase the memory as the camera scans new parts of the scene.At the begin-ning,OF9and OF10pre-allocate 81.6MB and 362.6MB,respectively.Finally,OF9uses 55.6M,and OF10uses 227.4MB.With 5123resolution,memory consumption of OF9is 81.6/512≈15.9%of KF512.With 10243resolution,KinectFusion will consume 4GB GPU memory,which is ≥10times larger than that of our method.Figure 2right gives details of memory consumption of each layer.Time Comparison.We show time comparisons on a test scene in Figure 3,where OF(7,9)processes a frame in about 19ms,and OF(7,10)processes a frame less than 25ms.They are both faster than KF512.OF(7,9)gains about 2×speed up on the improved parts than KF512.This is because KF512needs to update its all 5123voxels,while our method only updates existing nodes,and it can skip large spaces on the ray-cast rge Scale Scene.Our octree based method efficiently uses memory,and OF10can reach a maximal 10243resolution,which is able to robustly track the camera in a large scale scene and reconstruct it.We scan an office in a 8m ×8m ×8m bounding box using OF10,which captures about 3800frames of depth maps.The scene data costs 299MB in 363MB pre-allocated GPU memory,and the extracted mesh from the scene volume contains 6200K triangle faces and 3400K vertices.As shown in Figure 4,though the size of the scene is large,the reconstructed model still possesses abundant details.Fig.2.Memory comparison of a static scene “chairs”240M.Zeng et al.Fig.3.Processing time for a test scene.Left are the Phong-shaded rendering and the normal map of the test scene,respectively.Right is the processing time on each stage of different methods.Fig.4.Reconstruction result of a large scene and two zoom-in parts8Conclusion and Future WorkWe propose an octree based KinectFusion.Our method represents the scene data in an octree structure,and maintains this octree by“add node”operations according to changes of the scene.We also modify KinectFusion to adapt the octree representation to highly utilize parallelism computation ability of GPU.Experiments show that our method costs only about10%memory of original KinectFusion and runs about2×faster than original KinectFusion on the improvement parts.Our method can reconstruct 3D scenes8times larger than that of KinectFusion.The system can be extended in several ways.One is to design a more efficient mem-ory management solution to replace current pre-allocation method.Another possible improvement may come from the combination of our method and Kintinuous[15].A straightforward way is to use our method as a building block in Kintinuous,which may also involve some modifications both on data structures and the volume shifting algo-rithm of Kintinuous.Acknowledgments.We would like to thank the anonymous reviewers for their valu-able comments,and thank Bo Jiang,Zizhao Wu and Xuan Cheng for proof reading and video editing.This work was partially supported by NSFC(No.60970074),China973 Program(No.2009CB320801),Fok Ying Tung Education Foundation and the Funda-mental Research Funds for the Central Universities.A Memory-Efficient KinectFusion Using Octree241 References1.Chen,Y.,Medioni,G.:Object modeling by registration of multiple range images.Image andVision Computing(IVC)10(3),145–155(1992)2.Fitzgibbon,A.W.,Zisserman,A.:Automatic Camera Recovery for Closed or Open ImageSequences.In:Burkhardt,H.-J.,Neumann,B.(eds.)ECCV1998.LNCS,vol.1406,pp.311–326.Springer,Heidelberg(1998)3.Frisken,S.F.,Perry,R.N.,Rockwood,A.P.,Jones,T.R.:Adaptively sampled distancefields:a general representation of shape for computer graphics.In:Proceedings of the27th An-nual Conference on Computer Graphics and Interactive Techniques,SIGGRAPH2000,pp.249–254.ACM Press/Addison-Wesley Publishing Co.,New York(2000)4.Harris,M.,Owens,J.D.,Sengupta,S.,Zhang,Y.,Davidson,A.:Cudpp homepage(2007),/developer/cudpp5.Harris,M.,Sengupta,S.,Owens,J.D.:Parallel prefix sum(scan)with CUDA,ch.39.Addison Wesley(August2007)6.Izadi,S.,Kim,D.,Hilliges,O.,Molyneaux,D.,Newcombe,R.,Kohli,P.,Shotton,J.,Hodges,S.,Freeman,D.,Davison,A.,Fitzgibbon,A.:Kinectfusion:real-time3d recon-struction and interaction using a moving depth camera.In:Proceedings of the24th Annual ACM Symposium on user Interface Software and Technology,UIST2011,pp.559–568.ACM,New York(2011)7.Michael,K.,Matthew,B.,Hugues,H.:Poisson surface reconstruction.In:Proceedings ofthe Fourth Eurographics Symposium on Geometry Processing,SGP2006,pp.61–70.Euro-graphics Association,Aire-la-Ville(2006)8.Microsoft.Microsoft kinect project(2010),/kinect9.Newcombe,R.A.,Izadi,S.,Hilliges,O.,Molyneaux,D.,Kim,D.,Davison,A.J.,Kohli,P.,Shotton,J.,Hodges,S.,Fitzgibbon,A.:Kinectfusion:Real-time dense surface mapping and tracking.In:Procedings of IEEE/ACM International Symposium on Mixed and Augmented Reality,pp.127–136(2011)10.Newcombe,R.A.,Lovegrove,S.,Davison,A.J.:Dtam:Dense tracking and mapping in real-time.In:International Conference on Computer Vision,pp.2320–2327(2011)11.Pollefeys,M.,Gool,L.V.,Vergauwen,M.,Verbiest,F.,Cornelis,K.,Tops,J.,Koch,R.:Visual modeling with a hand-held camera.International Journal of Computer Vision59(3), 207–232(2004)12.Richard,A.J.D.,Newcombe,A.:Live dense reconstruction with a single moving camera.In:IEEE Computer Society Conference on Computer Vision and Pattern Recognition(CVPR), pp.1498–1505(June2010)13.St¨u hmer,J.,Gumhold,S.,Cremers,D.:Real-Time Dense Geometry from a Handheld Cam-era.In:Goesele,M.,Roth,S.,Kuijper,A.,Schiele,B.,Schindler,K.(eds.)DAGM2010.LNCS,vol.6376,pp.11–20.Springer,Heidelberg(2010)14.Sun,X.,Zhou,K.,Stollnitz,E.,Shi,J.,Guo,B.:Interactive relighting of dynamic refractiveobjects.ACM Trans.Graph.27(3),35:1–35:9(2008)15.Whelan,T.,McDonald,J.,Kaess,M.,Fallon,M.,Johannsson,H.,Leonard,J.J.:Kintinuous:Spatially extended kinectfusion.In:RSS Workshop on RGB-D:Advanced Reasoning with Depth Cameras(July2012)16.Zhou,K.,Gong,M.,Huang,X.,Guo,B.:Data-parallel octrees for surface reconstruction.IEEE Transactions on Visualization and Computer Graphics(TVCG)17(5),669–681(2011)。
