常见金属的功函数,具体出处忘了,仅供参考
- 1、下载文档前请自行甄别文档内容的完整性，平台不提供额外的编辑、内容补充、找答案等附加服务。
- 2、"仅部分预览"的文档,不可在线预览部分如存在完整性等问题,可反馈申请退款(可完整预览的文档不适用该条件!)。
- 3、如文档侵犯您的权益，请联系客服反馈,我们会尽快为您处理(人工客服工作时间：9:00-18:30)。
常见金属的功函数集中，以备查询
Metal Work Function （eV）
银Ag (silver) 4.26
铝Al (aluminum) 4.28
金Au (gold) 5.1
铯Cs (cesium) 2.14
铜Cu (copper) 4.65
锂Li (lithium) 2.9
铅Pb (lead) 4.25
锡Sn (tin) 4.42
铬Cr (Chromium) 4.6
钼Mo(Molybdenum) 4.37
钨Tungsten 4.5
镍Nickel 4.6
钛Titanium 4.33
铍Beryllium 5.0
镉Cadmium 4.07
钙Calcium 2.9
碳Carbon 4.81
钴Cobalt 5.0
钯Pd(Palladium) 5.12
铁Iron 4.5
镁Magnesium 3.68
汞Mercury 4.5
鈮Niobium 4.3
钾Potassium 2.3
铂Platinum 5.65
硒Selenium 5.11
钠Sodium 2.28
铀Uranium 3.6
锌Zinc 4.3
Notes:
Source: various (listed in my dissertation).
The actual work function is VERY dependent (usually) several factors including morphology, preparation, gas on surface, oxidation...
Aluminum is a strange one... Once exposed to atmosphere the surface oxidizes and the effective work function increases to values of 10 or 11 !!!!
Most common metals can be roughly assumed to have a work function of ~4.5
