USB规格书
USB摄像头需求规格书0.2
广电云-IP智能机顶盒配件USB摄像头需求规格书
1.产品规格
2.应用场景
2.1USB摄像头配件通过USB口与机顶盒连接：
机顶盒正常开机后，配件通过USB口与机顶盒连接，机顶盒通过USB口与配件通信并进行供电，要求即插即用，能够自动连接，提供视频和语音服务，见图2.1，具体实现方式请配件厂商提供一份概要设计方案以供讨论。
此方案中，机顶盒安装apk后，显示对端手机（或机顶盒）的语音和图像,USB摄像头采集本地语音和图像输入，和对端的手机（或机顶盒）进行视频通话。
图1组合模式
2.2 USB摄像头通过WIFI与机顶盒连接：
机顶盒正常开机后，配件距离机顶盒较远位置时，则配件自行配置电源适配器供电运行，USB摄像头作为一个WIFI终端设备，与机顶盒连接，提供视频和语音服务，见图具体实现
方式请配件厂商提供一份概要设计方案以供讨论。
此方案中，
监控模式：机顶盒安装apk后，显示usb摄像头采集的语音和图像，对摄像头区域进行监控。
图2监控模式
独立模式：独立使用USB 摄像头和远程手机（或机顶盒）进行通话或监控，机顶盒只提供网络接入功能。
图3独立模式。
32AWG USB 3.1 线材规格书资料
1. 适用范围本规格书制定了电线的结构和电气特性(32AWG+S 同轴线)*8C2. 结构单位-(No./mm)mm ---mm mm -（%）mm -mm mm -(No./mm)mm ---mm mm -mm中被颜色蓝色；黄色；橙色；白色；紫色；棕色；灰色；绿色FEP FEP0.070.38±0.05白色*绿色S //绞向对绞颜色芯线对绞绝缘层材料绝缘颜色绝缘厚度 绝缘线径导 体材料 镀锡铜丝构成7/0.08±0.005 (32AWG)外径0.24 绞向S缠绕屏蔽 外径0.84±0.05覆盖率外径0.06材料PFA 中被绝缘厚度绝缘层材料绝缘厚度 绝缘线径绝缘颜色0.62±0.05镀锡铜丝100%min 0.72白色；绿色0.070.38±0.05棕色；黄色；橙色；蓝色S FEP 0.18 材料白色项目详细资料材料导 体构成 绞向 外径绞合镀银铜丝7/0.08±0.005 (32AWG)0.24单位Ω/km M Ω·km V/ 1 Min ΩΩ ps/m4. 电线截面图示如下:颜色代码1.蓝色；2.黄色；3.橙色；4.白色；5.紫色；6.棕色；7.灰色；8.绿色9.棕色；10.黄色；11.橙色；12.蓝色13.白色；14.绿色；15.红色SKEW≥10绝缘电阻 耐压强度项目导体电阻详细资料32AWG:613(Max.) 24AWG:94100(Min.)1000 特性阻抗45±3差分阻抗90±3761813109543215141211。
USB工业相机规格书-创科
创科视觉
4. 硬件规格
相机型号 色彩
标准分辨率 Sensor 格式 快门格式 标准帧率(fps) 像素尺寸
ADC 视频数据输出 局部扫描模式
数字接口 传输速率 电源需求 动态范围
灵敏度 增益 快门
触发模式 信噪比
尺寸(长*宽* 高) 重量
镜头接口 电磁兼容 工作温度 存储温度
CK-H030U 黑白
752 x 480 1/3”CMOS Global shutter
6
USB2.0 Camera Specification
创科视觉
管脚定义 管脚号 1 2 3 4 5 6 7
名称 Ext_VCC TriggerTrigger+ Ext_StrobeExt_Strobe+ GND
图3
说明 电源 外触发输入（Trigger 地，GND_Trigger） 外触发输入 光源控制输出（Strobe 地，GND_Strobe） 控制光源输出的电压范围 电气接地 保留
10
10
8bit 数字信号
ROI orBining
USB2.0
480Mbit/s
USB 5V/外部供电<1W
80-100dB
68.2dB
4.8 V/lux-sec
2.1 V/lux-sec
手动 1-15dB
手动 54.2us～1s（因相机型号不同而略有不同）
软件触发，外部触发
37.3 dB
45 dB
7.2.2、Ext_Strobe+外接参考
பைடு நூலகம்
7.3 输出信号 Ext_Strobe+描述
Copyright © CKVISION Technology Co.,Ltd.
手机USB充电器产品规格书
手机USB充电器产品规格书手机USB充电器产品规格书一、前言本规格书描述手机USB充电器的电气特性及使用环境要求等方面的规格说明。
二、产品特点1、本USB充电器连接手机后可对手机电池进行充电；2、恒压小电流充电模式，电池电压充满自动关断，将提高电池的使用寿命；3、全电压输入，全球适用。
三、电气参数1、输入:90-250V AC, 50/60Hz 80mA;2、输出：5VDC 500MA,最大2A;3、空载功耗:0. 2W MAX;4、充电满载功耗:5W MAX;5、电池充饱率:?90%。
四、环境条件1、使用环境:温度：0-40?湿度:?95,:2、存储环境:温度：-25, +60?湿度:?85,;3、匸作时本体温度:充电时壳体表面温度?50?,电池表面温度?45?o五、安全规格符合安全标准。
六、可靠性能参数1.输入特性 ........................................................................ ..31.1额定输入电压 ........................................................................ ......................................... 3 1.2输入电压范围 ........................................................................ ......................................... 3 1.3输入频率 ........................................................................ ........................................................ 3 1. 4输入频率范围 ........................................................................ ......................................... 3 1. AC输入电流 ........................................................................ .................................................. 3 1.6峰值输入电流 ........................................................................ ......................................... 3 1.7 效率 ........................................................................ ........................................................................................................... 32.输出特性 ........................................................................ .32.1输出额定电压 ........................................................................ ......................................... 3 2.2输出电压 ........................................................................ ........................................................ 3 2. 3额定输出电流 ................................................................................................................. 4 2. 4额定功率 ........................................................................ ........................................................ 4 2.5 LED指示功能） ...................................................................... ................................... 4 2.6充电器输出电压/电流特性图 ..........................2.7输出纹波、噪 (4)........... 4 2. 8输出电流纹波、噪音.2. 9启动延时 ........................................................................ ........................................................ 4 2. 10关断时延 ........................................................................ ......................................................4 2. 11 id冲 ........................................................................ ....................................................................... 4 2. 12电流倒灌 ........................................................................ ......................................................4 2. 13 保护 ........................................................................ ....................................................................... 4 2. 13. 1过压保护 ........................................................................................................................ 4 2. 13.2过流保护 ........................................................................ ................................................ 4 2.13.3短路保护 ........................................................................ ................................................ 4 3.信赖性项目 (4)3.1静电 ........................................................................ .......................................................................... 4 3.2高压测试 ........................................................................ ........................................................... 4 3. 3绝缘电阻 ........................................................................ ........................................................... 4 3. 4泄漏电流 ........................................................................ ........................................................... 4 3. 5 温升 ........................................................................ .......................................................................... 4 3.6连续工作时间 ........................................................................ ........................................ 5 3.7平均无故障时间 ........................................................................ .................................. 5 3. 8 EMI 标准 ........................................................................ ....................................................... 5. 4.环境要求 (5)4.1工作温度 ........................................................................ .......................................................... 5 4.2储藏温度 ........................................................................ .......................................................... 5 4.3工作湿度 ........................................................................ .......................................................... 5 4.4储藏湿度 ........................................................................ .......................................................... 5 5.机械要求 (5)5.1尺寸 ........................................................................ ........................................................................... 5 5. 2 重量 ........................................................................ ........................................................................... 5 5. 3USB 接口类型 ........................................................................ ...................................... 5 5.4跌落试验 ........................................................................ .......................................................... 5 5. 5振动试验 ........................................................................ .......................................................... 5 5. 6插拔实验 .................................................................................................................................. 5 6.机械性能 (6)6.1外观 ........................................................................ ......................................................................... 5 6. 2夕卜壳材质 ........................................................................ . (6)7.环境性能 (5)7. 1低温工作实验 ........................................................................ ........................................ 5 7.2高温工作实验 ........................................................................ ........................................ 6 7. 3低温存储 ........................................................................ ......................................................... 67.4高温存储 ........................................................................ ......................................................... 67.5恒温恒湿工作） ...................................................................... .. (6)1.输入特性1.1额定输入电压额定输入交流100厂240V。
USB3.0 系列产品规格书
Product Specification---------------------xu dong bin11-08-124.2Electrical Performance:Item Test Description Test Methods Requirement4.2.1Low Level ContactResistance EIA364-23B(or MIL-STD-1344A,Method3002.1,Test Condition B)Subject mated contacts assembled inhousing to20mV maximum open circuitat100mA maximumThe object of this test is to detail astandard method to measure theelectrical resistance across a pair ofmated contacts such that the insulatingfilms,if present will not be broken orasperity melting will not occur.1)30mӨMaximum.Initial for VBUSand GND contacts.50mӨMaximum.Initial for all other contacts2)..After test:10mӨMaximumChange4.2.2Insulation Resistance EIA364-21(or MIL-STD-202F,Method302,Test Condition B)Test between adjacent contacts ofmated and unmated connectorassemblies.The object of this test procedure is todetail a standard method to assessthe insulation resistance of USB AF3.0connectors.This test procedure isused to determine the resistanceoffered by insulation connector to a DCpotential current through or on thesurface of the members.1).Initial:1000MӨMinimum2).Aftertest:1000MӨMinimumProduct Specification---------------------xu dong bin11-08-12 4.2Electrical Performance:(Continued)Item Test Description Test Methods Requirement4.2.3DielectricWithstanding Voltage EIA364-20(or MIL-STD-202F,Method301,Test Condition B)Test between adjacent contacts of matedand unmated connector assemblies.The object of this test procedure is to detaila test method to prove that a USB AF3.0connector can operate safely at its ratedvoltage and withstand momentary overpotentials due to switching,surges and/orother similar phenomena.500VACforoneminuteatsealevel1).No flashover or insulationbreakdown2).Leakage current:0.5mA Maximum.4.3Mechanical Performance:(Continued)Item Test Description Test Methods Requirement4.3.1Durability EIA364-09Mate and unmate Connectorassemblies for1500-5000cycles atmaximum rated of200cycles per hour.(standard Durability Class1500cyclesmini,High Durability Class5000cyclesmini)The object of this test procedure isto detail a uniform test method fordetermining the effects caused bysubjecting a USB AF3.0connector tothe conditioning action of inserting andextraction,simulating the expected lifeof the connectors.Durability cycling witha gauge is intended only to producemechanical stress.Durability performedwith mating components is intended toproduce both mechanical and wearstress.1).Shall meet visual requirement,show no physical damage.2).Shall meet requirements of additional tests as specified in TEST SEQUENCE in Section5Product Specification---------------------xu dong bin11-08-124.3.2Mechanical Shock EIA-364-27BSubject mated connector to30G’shalf-sine shock pulses of11msecduration.Three shocks in each directionapplied along three mutuallperpendicular planed for a total of18shocks No discontinuities of1microsecond or long duration.See note4.3.3Vibration EIA-364-28DSubject mated connectors to10~55~10Hz traversed in1minute at1.52mm amplitude2hours each of3mutually perpendicular planes.No discontinuities of1microsecond or long duration.See note4.3.4Connector MatingForceEIA364-13Shall be measured with TENSIONGAUGE or TENSION TESTER.Measure force necessary to mateassemblies at maximum rate of12.5mm(or0.492”)per minute.The object of this test is to detail astandard method for determining themechanical forces required for insertinga USB AF3.0connector.1).Initial:35Newtons(or3.57Kgf)Maximum2).After test:35Newtons(or3.57Kgf)MaximumProduct Specification---------------------xu dong bin11-08-124.3.5Connector UnmatingForce EIA364-13Shall be measured with TENSIONGAUGE or TENSION TESTER.Measure force necessary to mateassemblies at maximum rate of12.5mm(or0.492”)per minute.The object of this test is to detail astandard method for determining themechanical forces required forextracting a USB AF3.0connector.1).Initial:10Newtons(or1.02Kgf)Minimum2).After test:8Newtons(or0.82Kgf)Minimum4.3.6Contact RetentionForce EIA364-35Shall be measured with TENSIONGAUGE or TENSION TESTER in samedirection.1).Initial:0.4Kgf minimum2).After test:0.4Kgf minimumProduct Specification---------------------xu dong bin11-08-12 4.4Environmental Performance:Item Test Description Test Methods Requirement4.4.1Thermal Shock EIA364-32,Test Condition I,(orMIL-202F,Method107G Condition A.)Subject mated connectors to tencycles between–55кto+85к.The object of this test is to determinethe resistance of a USB AF3.0connector to exposure at extremes ofhigh and low temperatures and to theshock of alternate exposures to theseextremes,simulating the wrost caseconditions for storage,transportationand application.1).Shall meet visual requirement,show no physical damage.2).Shall meet requirements of additional tests as specified in TEST SEQUENCE in Section54.4.2Humidity EIA364-31,Test Condition A MethodIII,(or MIL-202F,Method103B TestCondition B.)Subject mated connectors to168Hours(seven complete cycles)The object of this test procedure is todetail a standard method for theevaluation of the properties of materialsused in USB AF3.0connectors asthese influenced by the effects of highhumidity and heat.1).Shall meet visual requirement,show no physical damage.2).Shall meet requirements of additional tests as specified in TEST SEQUENCE in Section54.4.3Salt Spray MIL-STD-202F,Method101D,TestCondition BSubject mated connectors to8hours at35кwith5%-Salt-solutionconcentration.1).Shall meet visual requirement,show no physical damage.2).Shall meet requirements of additional tests as specified in TEST SEQUENCE in Section54.4.4Temperature Life EIA364-17Test Condition3MethodA,Subject mated connectors totemperature life at105кfor120hours 1).Shall meet visual requirement,show no physical damage.2).Shall meet requirements of additional tests as specified in TEST SEQUENCE in Section5xu dong binProduct Specification---------------------11-08-12 5.0Test Sequence:Test Group(a)Sample GroupsTest Item Test Description A B C D E F G H I J K L 4.1.1Examination of product1,131,51,81,3131,513164.2.1Low Level Contact Resistance ,102,42,4254.2.2Insulation Resistance , 2,64.2.3Dielectric Withstanding Voltage4,123,74.3.1Durability74.32Mechanical Shock34.33Vibration44.3.4Connector Mating Force ,84.3.5Contact Unmating Force6,94.3.6Catact Retention Force24.4.1Thermal Shock54.4.2Humidity44.4.3Salt Spray34.4.4Temperature Life(see note c)34.4.5Solderability24.4.6Resistance to Soldering Heat2Number of Test Samples(Minimum)55555555。
USB产品规格书
产品规格书1．适用范围本规格书适用于各类电器内部接通电路用USB系列接口的各项规格。
2．额定值2．1额定电压30V DC2．2额定电流 1.5A MAX2．3接触电阻30mΩ MAX2．4绝缘电阻100MΩ MAX2．5耐电压 500V MIN2．6使用寿命 5000 CYCLES2．7温度范围 -25℃―+60℃3．外观质量3．1主体色泽一致，无披锋、明显收缩、变形、缺胶、起泡、烧焦等缺陷。
3．2外壳表面光洁，无锈斑、裂纹、划伤、垫伤、变形等缺陷。
3．3端子镀层表面光洁，不得有脱层、发黄、色斑、划伤、变形缺陷。
4．结构尺寸：附产品图5．性能5．1接触电阻：在常态下，插头与插簧的接触部位之间≤30 mΩ。
5．2绝缘电阻：连接器相邻接触件之间的绝缘电阻均应大于或等于100 MΩ。
5．3抗电强度：连接器相邻接触件之间施加：500V DC，50Hz的电压，（漏电流不超过0.5mA）历时1MIN，不应发生飞弧或击穿现象。
5．4插入力与拔出力：连接器的插入力不大于35N/次，拔出力不小于10N/次。
5．5可焊性：连接器的接触件在230±5℃锡槽内，时间3±0.5秒，沾锡面积达95%以上。
5．6振动：连接器在二个相互垂直的方向上，振动频率10-500Hz,振幅为0.35mm,每一方向扫频循环次数为10次，结束后，产品不应有影响正常操作的损伤。
5．7耐热性：连接器放置在60℃，恒温槽中72小时取出后，室温外恢复30MIN应满足。
5．7．1接触电阻 30 mΩ MAX5．7．2绝缘电阻 100MΩ MIN5．7．3耐电压 DC500V 50Hz·1min无飞弧和击穿。
5．8耐寒性：连接器放置在-25℃，恒温槽中72小时取出后，室温下恢复30MIN应满足。
5．8．1接触电阻 30 mΩ MAX5．8．2绝缘电阻 100 MΩ MIN5．8．3耐电压 DC500V 50Hz·1min无飞弧和击穿。
USB电线产品规格书
除了特殊规格要求，所有测试与量测之环境须控制在下列范围。
室内温度：25℃——30℃
室内湿度：25%——85%（RH）
注：在环境测试时连接器须组装在实际使用之情况下。
5、必要标准、测试方法、测试结果
5-1外观
5-1-1 必要标准：外观不可有破裂、变形，及异色而导致影响其应有功能。
5-1-2 测试方法：环境测试前后以目视之方式检测。
JS2541-H
NYLON
UL94V-1 NAT
RAL
3、产品规格及特性要求
3-1 额定电压：）
3-3 耐电压：AC800V，5秒（端子及心线绝缘耐压）
3-4 绝缘阻抗：成品绝缘阻抗1MΩ/DC 250V
3-5 温度测试范围：-10℃——+60℃
5-1-3 测试结果：OK
产品规格书
1、产品品名规格、料号
料 号
品名规格
L020151126
2、产品结构及材料组成
品名
规格
材质
表面处理
线材（CABLE）
UL2725 28#*4C+D+AL
贝吉色（UL2725…）
连接器（USB）
USB A/M
BRASS
镀镍
连接器（端子）
JS2541-T
BRASS
GOLD PLALED
连接器（HSG）
USB3.0 产品规格书最新版
DOC. NO.:SPEC-USB-001 REV.:X8DATE:5/6/2011TITLE:USB3.0 AM TO uB CABLE ASSEMBLYTITLEUSB3.0 A TYPE PLUG TO micro USB3.0 B TYPE PLUG CABLE ASSEMBLYTABLE OF CONTENTS1.0 SCOPE2.0 APPLICABLE DOCUMENTS3.0 DESCRIPTION4.0 REQUIREMENTS5.0 TEST SPECIFICATIONS AND METHODS6.0 CABLE FLEXING TEST DIAGRAM7.0 HUMIDITY CONDITION8.0 TEST SEQUENCEDOC. NO.:SPEC-USB-001 REV.:X8DATE:5/6/2011TITLE:USB3.0 AM TO uB CABLE ASSEMBLY1.0 SCOPEThis product specification defines the product performance and the test methods, which includes mechanical, electrical and environmental requirements for USB3.0 A type plug to USB3.0 micro B type plug cable assembly series products.2.0 APPLICABLE DOCUMENTSThe following documents are consisting of a part of this specification. The product drawings shall take priority in events of conflict between these specification requirements and the product drawings.a) EIA-364: Electrical Conn./Socket Test Procedure Including Environmental.b) USB3.0: Universal Serial Bus 3.0 Connectors and Cable Assemblies Specificationc) QW-QA-43: ICT Internal Harmful Material and Process Control Std.3.0 DESCRIPTION3.1 CONSTRUCTIONCable assembly shall be designed, constructed and specified on the applicable drawing,3.2 MATERIALSRefer to the according BOM list, which defined in the engineering drawings4.0 REQUIREMENT4.1 GENERAL PERFORMANCE:Connector shall be defined to meet all of the requirements specified in section 5.0. Unless otherwise specified, all tests will be performed at following conditions:Temperature: 25°C +/- 10°CHumidity: 45% ～ 75%Pressure: 86 ~ 106 Kpa4.2 Current rating: 5A Max.4.3 Operating Temperature: +0°C--50°C4.4 Storage Temperature: -20°C --+60°C4.5 Marking:Only products that meet or exceed the compliance test requirements identified in this document at the time of testing are eligible to display the certified logo provided the product vendor has signed the USB IF logo trademark license agreement.5.0 TEST SPECIFICATIONS AND METHODSMethod of measuring resistance should be used to connector and assembly with USB3.0 cable, 5.1 ELECTRICAL REQUIREMENTSDOC. NO.:SPEC-USB-001 REV.:X8DATE:5/6/2011TITLE:USB3.0 AM TO uB CABLE ASSEMBLYDESCRIPTION TEST CONDITION REQUIREMENT5.1.1 Low LevelContactResistanceMeasure at 20 mV (Max) open circuit at100 mA with Mated connectors,(EIA-364-23)30 mΩ (Max) forVBUS and GND50 mΩ max forall other contactschange of delta +10mΩ max after test.5.1.2 ContactCurrentRatingA current of 1.8 A shall be applied to VBUS pinand its corresponding GND pin, a minimumcurrent of 0.25 A shall be applied to all the othercontacts.(EIA 364-70, Method 2)The delta temperatureshall not exceed +30 °Cat any point5.1.3 DielectricWithstandingVoltageApply 100 Volts AC (RMS) between adjacentcontacts of unmated and mated connectors(EIA 364-20)No breakdown shalloccur5.1.4Capacitance Test between adjacent contacts, unmatedconnector at 1 KHz.2 pF maximumD+/D- contacts only.5.1.5 InsulationResistanceApply 100 VDC for two minutes maximum, or untilstabilized between adjacent contacts of matedconnectors. (EIA 364-21)100 MΩ Min.5.1.6 Voltage Drop 5V nominal at 900mA.Apply through the mated connectors and cableBUS & GND each have225 mV max drop,5.1.7 Wiring Verify wiring to plugs to match appropriate tablesin the USB 3.0 Specification:Tables 5-9, 5-10, 5-11, 5-12 or 5-13Using an ohmmeter,verify wiring pin-to-pin5.1.8 ID PinResistanceVerify the resistance of the ID pin to ground.Micro-USB connectors onlyMust have a resistanceto ground greater than1M Ohms on the ID pin.DOC. NO.:SPEC-USB-001 REV.:X8DATE:5/6/2011TITLE:USB3.0 AM TO uB CABLE ASSEMBLY5.1.9DifferentialimpedanceMatedConnector EIA 364 – 108This test ensures that the signal conductors of theUSB 3.0 connectors have the proper impedance.(50ps rise time, 20%--80%, TDR)Mated connector includes cable termination areas90±15Ω(75Ω~105Ω)Super Speed pairs only5.1.10DifferentialimpedanceCableEIA 364 – 108This test ensures that the signal conductors of theUSB 3.0 connectors have the proper impedance.(200ps rise time, 20%--80%)90±7Ω(83Ω~97Ω)5.1.11Cross TalkDifferential Near and Far End Cross talks betweenSS Pairs and D+/D- pair of Mated Cable Assembly500ps (10-90%) rise time of a differential TDTStandard-A: 2%Micro family: 2%Near End Crosstalk between SS Pairs of MatedCable Assembly50ps (20-80%) rise time of a differential TDTSuper Speed pairs only. (EIA-360-90)Standard-A: 0.9%Micro family: 1.2%5.1.12D+/D- pairPropagationDelayD+/D- lines of the cable assembly.200 ps (10%-90%) rise time EIA 364 -10326ns max. no micro10ns max. with microD+/D-lines only5.1.13DifferentialInsertion Loss(SS)Mated Cable AssembliesNormalized with a 90-ohm differential impedance.100 MHz to 7.5 GHz (EIA-360-101)-1.5dB/cable 0.1GHz-5dB/cable 1.25GHz-7.5dB/cable 2.5GHz-25dB/cable 7.5GHz5.1.14PropagationDelay Intra-pair SkewThis test ensures that the signal on both the D+and D- lines of cable assembly arrive at thereceiver at the same time.200 ps (10%--90%) rise timeEIA 364 – 103D+/D- line: 100 ps max.5.1.15D+/D-PairAttenuation12 to 400 MHzThis test ensures the D+/D- pair of a cableassembly can provide adequate signal strength tothe receiver in order to maintain a low error rate.EIA 364 – 101-0.67 dB Max @ 12 MHz-0.95 dB Max @ 24 MHz-1.35 dB Max @ 48 MHz-1.90 dB Max @ 96 MHz-3.20 dB Max @ 200 MHz-5.80 dB Max @ 400 MHz5.1.16DifferentialCommonModeConversion(SS)Measure the single-ended S-parameters of themated cable assembly and derive the Differentialto Common Mode Conversion. See Appendix C.Normalized with a 90-ohm differential impedance.The main purpose of this requirement is to limitthe cable assembly EMI emission.100 MHz to 7.5 GHz-20dB/max @ 100MHzto 7.5GHzSuperSpeed pairs only.DOC. NO.:SPEC-USB-001 REV.:X8DATE:5/6/2011TITLE:USB3.0 AM TO uB CABLE ASSEMBLY5.2 MECHANICAL REQUIREMENTSDESCRIPTION TEST CONDITION REQUIREMENT5.2.1 AppearanceExaminationVisual inspection& DimensionalcheckingThere shall be no defects that wouldimpair normal operations anddimensions shall comply with thelatest version of USB Specification5.2.2 Insertion Force Insert connectors at a maximum rateof 12.5mm per minute. (EIA-364-13)35 N maximum5.2.3 WithdrawForceWithdraw connectors at a maximumrate of 12.5mm per minute.10N-25N at initial8N-25N after durability.No burs or sharp edges are allowedon top of locking latches5.2.4 Cable Pull- outForceClamp one end of the cable plug andapply 40N steady state axial load tothe cable for one minute.No electrical discontinuity and nophysical damage to the cableassembly shall occur5.2.5 Cable Flex Bend the cable with Dimension X =3.7 times the cable diameter and 100cycles in each of two planes. With 120degree arc. (EIA-364-41, Condition I)No physical damage or discontinuityover 1ms during flexing test.5.2.64-AxisContinuityApply 8N perpendicular force toconnection at 0, 90, 180 and 270degrees, 10 seconds duration at eachaxis. Verify electrical continuity of allpin contacts at each axis.Note: Applicable only to microconnectors with mated condition.No contact chatter greater than 1.0microsecond during 10 seconds ateach axis.Note: When testing a USB2.0 MicroUSB plug in a USB 3.0 receptacle, ifthe combination does not pass at 8Nat 180 degrees, then 7N may beused for the 180-degree direction.5.2.7Durability The durability test shall be done at amaximum rate of 200 cycles per hourmanually or 500 cycles maximumautomatically and no physicaldamage to any part of the connectorand cable assembly shall occur.(EIA-364-09)Conn Std Durability High DurabilityUSB 3.0Std-A1.5K cyclesmin5K cycles minUSB 3.0Micro B10K cyclesmin10K cycles minChange form initial value:Contact: 30 milliohm Max.Shell: 50 milliohm Max.5.2.8 Vibration EIA 364-28Test Condition VII, Test Letter DThis test procedure tests the ability ofUSB 3.0 connectors to withstandconditions involving vibration.No evidence of physical damages.Test shall be done in sequencesdefined in EIA 364-1000.01.DOC. NO.:SPEC-USB-001 REV.:X8DATE:5/6/2011TITLE:USB3.0 AM TO uB CABLE ASSEMBLY5.3 ENVIRONMENT REQUIREMENTS5.3.1 TemperatureLifeEIA 364-17, Method A.The object of this test procedure is todetail a standard method to assessthe ability of a USB 3.0 connector towithstand temperature.105º C without applied voltage for 72hours when used as preconditioningin EIA 364-1000.01.5.3.2 TemperatureShock10 Cycles –55O C and +85O C.The USB 3.0 connectors under testmust be mated.Test shall be done in sequencesdefined in EIA 364-1000.01.There shall be no evidence of anyphysical damage.5.3.3 Temperature &Humidity24 cycles as defined in Test Group 2of EIA 364-1000.01.25°C ± 3°C at 80% ± 3%RH and65°C ± 3°C at 50% ± 3%RH. Ramptimes should be 0.5 hour and dwelltimes should be 1.0 hour.There shall be no evidence of anyphysical damage.DOC. NO.:SPEC-USB-001 REV.:X8DATE:5/6/2011TITLE:USB3.0 AM TO uB CABLE ASSEMBLY6 CABLE FLEXING TEST DIAGRAM7.0 HUMIDITY CONDITIONDOC. NO.:SPEC-USB-001 REV.:X8DATE:5/6/2011TITLE:USB3.0 AM TO uB CABLE ASSEMBLY8.0 TEST SEQUENCEItem (Item NO.)GroupA B C D E F G H1 Appearance (5.2.1) 1,13 1,9 1,8 1,7 1,7 1,7 1,7 12 Dielectric WithstandingVoltage (5.1.3)2 2,7 2,6 2,5 2,5 2,5 2,5 23 Low Level Contact Resistance(5.1.5)3,124 Insertion Force (5.2.2) 7,105 Withdrawal Force (5.2.3) 8,116 Durability (5.2.7) 97 Capacitance (5.1.4) 58 Insulation Resistance (5.1.5) 4 3,8 7 3,6 3,6 3,6 3,6 39 Cable Pull Out (5.2.4) 610Cable Flex (5.2.5) 4114-Axil Continuity (5.2.6) 512Voltage Drop (5.1.6) 413 Wiring (5.1.7) 414 ID Pin Resistance (5.1.8) 515 Vibration (5.2.8) 616 Temperature life (5.3.1) 417 Temperature Humidity (5.3.3) 418 Temperature Shock (5.3.2) 419High Speed (5.1.9—5.1.16) 4 20 Sample Quantity 3pcs 3pcs3pcs3pcs3pcs3pcs3pcs3pcs。
USB系列规格书
USB系列规格书1.一般事项General requirements1.1 适用范围Scope of Application本插座适用于打印机、彩色液晶电视接收机、电脑以及网络等电子设备外接数字信号装置之用。
This socket is used by color TV, component stereo, video disc players,computers and equivalent electronic equipment to connect with externalaudio and video device.1.2 标准状态Standard State除另规定外,测量应在以下状态进行:The test should be tested in the following state unless otherwise specified 温度: 15℃~ 35℃Temperature: 15℃~ 35℃相对湿度: 45% ~ 70%Relative Humidity: 45% ~ 70%气压: 86K pa ~ 106 K paAir Pressure: 86K pa ~ 106 K pa1.3 使用温度范围：-25℃~ +70℃Operating Temperature Range：-25℃~ +70℃1.4 环保要求：符合欧盟RoHS 指令的环保要求。
Environmental Requirement：Comply with the EU environmentalrequirements ofRoHS directive2. 额定规格Rated voltage and currenta.额定电压为：（AC、DC、34 V）Rated voltage: AC, DC, 34Vb.额定电流为：2.0 ARated current: 2.0 A3. 测试要求Test Requirements3.1 外观、机械性能Appearance & Mechanical Performance:测试项目(Items) 测试方法(Test Method) 测试要求(Requirement)A 外观、尺寸Appearance、Dimensiona：目视b：卡尺a：by visual observationb：beam calipersa：插座的金属零件表面应清洁、无锈蚀和镀层起层现象，塑料件应无肿胀气泡和裂缝。
USB数据线规格说明_
USB数据线规格说明
一、USB数据线接口spec
手机端母座采用10pin mini USB连接器，型号为LINKTEK:USBXN-01015-TP0X（也可用其它厂商兼容产品），管脚排列如图1所示（内视）：
图1 10 pin mini USB 接口母座引脚图
注意：主板母座型号为：USBIN-01015-TP01-X1，规格书如下，请选用与之匹配的公头：
USBIN-01015-TP01-
X1.pdf
二、USB数据线接口定义：
引脚序号名称功能定义
1 悬空悬空
2 VCHG 充电电压
3 悬空悬空
4 USB_D－USB数据－
5 悬空悬空
6 USB_D＋USB数据＋
7 悬空悬空
8 悬空悬空
9 悬空悬空
10 GND 接地
三、线材要求：
1、PC端接口为标准Stand A接口。
2、USB接口规格尺寸请参考USB2.0协议标准中详细规定。
3、手机端接口为上述10 pin MINI USB接口公头，请选用相匹配的接口。
4、下载线两端分别为手机连接端口和PC端 USB端口,线长为1米,线径为3.8mm,线材为的标准网织
Page 1 of 2
屏蔽线,线外被及SR为75度阻燃PVC。
Page 2 of 2。
- 1、下载文档前请自行甄别文档内容的完整性，平台不提供额外的编辑、内容补充、找答案等附加服务。
- 2、"仅部分预览"的文档,不可在线预览部分如存在完整性等问题,可反馈申请退款(可完整预览的文档不适用该条件!)。
- 3、如文档侵犯您的权益，请联系客服反馈,我们会尽快为您处理(人工客服工作时间：9:00-18:30)。
USB 測試標准 USB Electrical,Mechanical,and Environmental Compliance Standards Test Descriptio Performance Requirement
Visual and
Dimensional
Inspection
Must meet or exceed the requirements specified by the most current version of Chapter 6 of the USB Specification. Insulation Resistance 絕緣電阻
大于等于1，000Ω
Dielectric
Withstanding Voltage 耐電壓
The dielectric must withstand 500V AC for one minute at sea level.
500 V AC ，一分鐘 Low Level Contact Resistance 低電平接觸電阻 30 m Ω maximum when measured at 20mV maximum open circuit at 100mA.Mated test contacts must be in a connector housing.
在開路最大電流為100 mA 電壓為20mV 情況下最
大為30m Ω
Contact Current Rating 溫升 1.5A at 250V AC minimum when measured at an ambient temperature of 25℃.with power applied
to the contacts ,the △T must not exceed +30℃
at any point in the USB connector under test.
相對溫度為25℃，250VAC ，最小為1.5A 。
接通電
壓，測試中端子任一點的溫度不超過＋30℃。
Contact Capacitance 接觸電容 2 pF maximum unmated per contact.
最大為2pF
Insertion Force 插入力 35 N maximum at a maximum rate of
12.5㎜ per minute
在插入速度不超過每分鐘12.5㎜時不超過35N
Extraction Force 撥出力 10 N minimum at a maximum rate of 12.5㎜
per minute
在拔出速度不超過每分鐘12.5㎜時不超過10N
Durability 耐用性 1,500 insertion/extraction cycles at a maximum rate of 200 cycles per hour.
在速度不超過每小時200個循環下經受1，500次插
入與撥出。
Cable Pull-Out 電纜拉出
After the application of a steady state axial load
of 40 N for one minute 固定后施加40N 的軸向力,一分鐘。
Test Descriptio
Performance Requirement
Physical Shock 物理沖擊 No discontinuities of 1μs,or longer duration when mated USB connectors are subjected to 11ms duration 30 Gs half-sine shock pulses.Three shocks in each direction applied
along three mutually perpendicular planes for a
total of 18 shocks.
匹配USB 端子，中斷不得大于或等于1μs,30Gs 的
半波脈沖承受11ms.從三個正交的方向施加沖
擊，總沖擊數為18次
Random vibration 任意振動 No discontinuities of 1μs,or longer duration when mated USB connectors are subjected to
5.35Gs RMS.15minutes in each of three
mutually perpendicular planes
匹配USB 端子，中斷不得大于或等于1μs,承受
5.35Gs RMS.朝各個正交的方向各振動15分鐘。
Thermal Shock 熱沖擊 10 cycles -55℃ and ＋85℃.The USB connectors under test must be mated.
在-55℃至＋85℃中循環10次，端子必須緊密配合。
Cable impedance 阻抗 Impedance must be in the range specifiedin Z 0=90±15%;
Z CM =30±30%
Signal Pair Attenuation 衰減
Refer to Section 7.1.17
Frequency att(max) 0.064 0.08
0.256 0.11
0.512 0.13
0.772 0.15
1 0.2
4 0.39
8 0.54
12 0.67
24 0.95
48 1.35
96 1.9
200 3.2
400 5.8
Test Descriptio Performance Requirement
Propagation Delay 傳輸延遲See Section 7.1.1.1,Section 7.1.4,Section 7.1.16, and Table 7-9
5.2ns/m MAX
Propagation Delay Skew
延遲偏移Propagation skew must met the requirements as listed in Section 7.1.3
最大不超過100ps/cable
Solderability 可焊性USB contact solder tails must pass 95% coverage after one hour steam aging as specified in Category 2
在經過一個小時的蒸氣老化后焊接端的覆蓋率大于95%。
Humidity 抗潮性168 hours minimum.The USB connectors under test must be tested in accordance with EIA
364-31.
大于168個小時。
如EIA364-31測試
Flammability The manufacturer will require its thermoplastic
resin vendor to supply a detailed C of C with
each resin shipment.The C of C shal clearly
show the resin’s Ul listing number,lot
number,date code,etc.
94V-0。
