■Electrical Specifications
Item Type TFAN 43 Power Rating at 70°C 1/16W Operating Temp. Range -55 ~ +155°C Max. Operating Voltage 50V Max. Overload Voltage 100V Resistance Range ±0.1% ±0.25% 100Ω~33KΩ ±0.5% TCR (PPM/°C) ±25 ±50
Accuracy Grade Table Code B0 B3 C0 C2 C3 D0 D1 D2 F0 F1 Tolerance Grade Absolute Tolerance Tolerance Matching ±0.1% N/A ±0.1% 0.1% ±0.25% N/A ±0.25% 0.25% ±0.25% 0.1% ±0.5% N/A ±0.5% 0.5% ±0.5% 0.25% ±1% N/A ±1% 0.5% Rsistance Value 100~33K 100~33K 100~33K 100~33K 100~33K 100~33K 100~33K 100~33K 100~33K 100~33K Code B0 B3 N0 N3 C0 C2 C3 D0 D1 D2 TCR Grade Absolute TCR TCR Tracking ±10ppm N/A ±10ppm 15ppm ±15ppm N/A ±15ppm 15ppm ±25ppm N/A ±25ppm 25ppm ±25ppm 15ppm ±50ppm N/A ±50ppm 50ppm ±50ppm 25ppm Rsistance Value 100~2K 100~2K 100~2K 100~2K 100~33K 100~33K 100~33K 100~33K 100~33K 100~33K
2
Revision: 10-Apr-2013
深圳捷比信－－高品质精密元件供应商
ｗｗｗ．ｊｅｐｓｕｎ．ｃｏｍ
【 TFAN Series 】
■Derating Curve
Power ratio(%) .
Derating Curve
100 80 60 40 20 0 0 20 40 60 80 100 120 140 160 180
深圳捷比信－－高品质精密元件供应商
ｗｗｗ．ｊｅｐｓｕｎ．ｃｏｍ
【 TFAN Series 】
Thin Film Array Chip Resistor (TFAN Series)
■Features
— — — — — Advanced thin film technology Very tight tolerance down to ±0.1% Extremely low TCR down to ±10PPM/C TCR tracking down to 15ppm(±7.5ppm) and tolerance matching down to 0.1%(±0.05%) RoHS compliant component, compatible with lead (Pb)-free
0.1 1.5 0
T 0.85±0.1
■Marking
TFAN 43: 4 digits marking Example: Resistance marking 100Ω 1000 2.2KΩ 2201 10KΩ 1002 49.9KΩ 4992 100KΩ 1003
■Recommend Land Pattern
Paper Tape Specifications
Bottom Tape
Top Tape A
ψ D0 E F B W
Paper Tape
T
Resistor
P1
P2
P0
Direction of unreeling
Unit: mm Type TFAN-43 A 1.95±0.1 B 3.50±0.1 W 8.0±0.2 E 1.75±0.1 F 3.5±0.05 P0 4.0±0.1 P1 4.0±0.05 P2 2.0±0.05 ΦD0
■Applications
— Voltage divider — Feedback circuits — Signal conditioning
■Construction
8 ○
7 ○
3 ○ 4 ○ 5 ○ 6 ○
Alumina Substrate Bottom Electrode (Ag) Top Electrode (Ag-Pd)
深圳捷比信－－高品质精密元件供应商
ｗｗｗ．ｊｅｐｓｕｎ．ｃｏｍ
【 TFAN Series 】
■ Dimensions
Type TFAN43
Number of Resistors 4
L 3.20±0.15
W 1.60±0.15
H 0.55±0.10
A 0.50±0.15
B 0.80±0.05
C 0.30±0.15
RCWV(Rated continuous working voltage)= √(P*R) or Max. Operating voltage whichever is lower Storage Temperature: 25±3C; Humidity < 80%RH
▓Reflow
4
Revision: 10-Apr-2013
Endurance
Damp Heat with Heat with Load(85C/85% R.H) ΔR±0.5% Dry Heat Bending Strength Solderability Resistance to Soldering Heat Dielectric Withstand Voltage Thermal Shock Low Temperature Operation 1000Hr：ΔR±0.25% 8000Hr：ΔR±0.5% ΔR±0.2% 95% min. coverage ΔR±0.2% 100V ΔR±0.25% ΔR±0.25%
Unit: mm Type TFAN-43 A 2.85 B 3.10 C 0.45 I 0.80 P 0.80
5
Revision: 10-Apr-2013
Y 0.30±0.15
■Part Numbering
TFAN Product Type
43
B0
T Packaging Code T: Taping Reel B: Bulk
C0
Y
1001
N Marking Code : Standard Marking for E96 N: No Marking
Dimensions 0603X4
3
Revision: 10-Apr-2013
深圳捷比信－－高品质精密元件供应商
ｗｗｗ．ｊｅｐｓｕｎ．ｃｏｍ
【 TFAN Series 】
■Environmental Characteristics
Item Temperature Coefficient of Resistance As Spec. (T.C.R.) Short Time Overload Insulation Resistance ΔR±0.1% >1000 MΩ 1000Hr：ΔR±0.15% 8000Hr：ΔR±0.3% Requirement Test Method MIL-STD-202 Method 304 +25/-55/+25/+125/+25C JIS-C-5201-1 5.5 RCWV*2.5 or Max. overload voltage whichever is lower for 5 seconds MIL-STD-202 Method 302 Apply 100VDC for 1 minute MIL-STD-202 Method 108A 702C, RCWV with 1.5 hrs “ON” and 0.5 hrs “OFF” MIL-STD-202 Method 103B 402C, 90~95% R.H., RCWV for 1000 hrs with 1.5 hrs “ON” and 0.5 hrs “OFF” 852C, 80~90% R.H. 10% of RCWV for 1000 hrs with 1.5 hrs “ON” and 0.5 hrs “OFF” At +125℃ JIS-C-5201-1 6.1.4 Bending amplitude 3 mm for 10 seconds MIL-STD-202 Method 208H 2455C for 3 seconds MIL-STD-202 Method 210E 260±5C for 10 seconds MIL-STD-202 Method 301 Max. overload voltage for 1 minute MIL-STD-202 Method 107G -55C ~150C, 100 cycles JIS-C-5201-1 7.1 1 hour, -65C, followed by 45 minutes of RCWV
Tolerance
Grade Reference Tolerance Grade Table
TCR Grade Reference TCR Grade Table
Power Rating : Standard Y:1/16W
Resistance 0010: 1Ω 4R70: 4.7Ω 1001: 1KΩ 1004: 1MΩ
■Special Specifications
Item Type TFAN 43 Power Rating at 70°C 1/16W Operating Temp. Range -55 ~ +155°C Max. Operating Voltage 50V Max. Overload Voltage 100V Resistance Range ±0.1% ±0.25% 100Ω~2KΩ ±0.5% TCR (PPM/°C) ±10 ±15
