外文翻译-自动浇花系统
自动浇水花盆 作文
自动浇水花盆作文英文回答：Self-watering planters are a type of container that allows plants to access water as needed, without the need for manual watering. They typically have a reservoir that holds water, and a wick or other absorbent material that draws water up to the plant's roots. This type of planteris particularly useful for people who are away from homefor extended periods of time, or who have difficulty watering their plants regularly.There are many different types of self-watering planters available, each with its own advantages and disadvantages. Some planters have a built-in reservoir, while others require the use of a separate container. Some planters have a wick or other absorbent material that draws water up to the plant's roots, while others use a capillary action to draw water up through the soil.When choosing a self-watering planter, it is important to consider the size of the plant, the type of soil, and the amount of water the plant needs. It is also important to consider the environment in which the planter will be used, and the amount of maintenance that is required.Self-watering planters can be a great way to keep plants healthy and hydrated, even when you are away from home. They can also be a good way to save water, and to reduce the amount of time you spend watering your plants.中文回答：自动浇水花盆是一种允许植物在需要时获取水分的容器，无需手动浇水。
外文翻译-自动浇花系统
本科毕业设计（外文翻译）题目自动浇花系统的设计姓名刘富强专业自动化学号 ********* 指导教师赵明冬郑州科技学院电气工程学院二○一四年五月New Environment Parameters Monitoring And Control System For Greenhouse Based On Master-slave DistributedAbstractAccording to the actual need of monitoring and control of greenhouse environment parameters in rural areas,a master-slave distributed measurement and control system is designed,in which PC is taken as the host. The system consists of PC ,soil moisture measurement and control module,temperature and humidity, and CO2 monitoring and control module. In the system,PC has large amount of data storage which is easy to make use of fuzzy control expert system,configuration software-KingView is used to develop software for PC,by which the development cycle is shorten and a friendly human-computer interaction is provided.Each monitoring and control module consists of STC12 series of microcontrollers,sensors,relays etc.Different modules are select based on the need if system to achieve control greenhouse in partition and block.I INTRODUCTIONTo modern indoor agriculture, the automatic measurement and control of environment parameters is the key to achieve crop yield and quality of greenhouse.In recent years,facilities agriculture develops vigorously in our country,matched with it,the monitoring and control instrument of greenhouse have also made certain development.After nearly 10 years of unremitting hard work,our research team of measurement and control system of agriculture environment parameters,designed an intelligent measurement and control system of distribution combined of greenhouse which can be popularized in the vast rural areas.This system is mainly control of temperature,humidity,CO2 concentration,soil moisture and illumination of greenhouse.OF SCM,as the data storage is small,display interface is single,amount of information is limited,but its capability price ratio is high,so it is used as a front unit of data acquisition and control;and of PC,it has a large amount of data storage,rich software,convenient human-computer interaction,and so on.If we use outdated andlow-priced PC,taking the PC as the upper machine,taking the different function control modules composed of multiple microcomputers as the lower machines,then a master-slave distributed and intelligent control system bases on microcomputer is made up,by which both better monitoring and control,display and data collection or management are achieved,but also lower cost of system is get according to the actual need.II SYSTEM STRUCTURE AND PRINCIPLEThe most marked feature of the distribution combined and intelligent control system greenhouse is that of incorporating with data acquisition, control and management as a whole,module combination, simple structure,convenient human-computer interaction,and using technology of intelligent expert fuzzy control,which can adapt to a variety of crop management control in greenhouse.The basic structure of the system is shown in Fig.1.The structure of the distributed system is composed of two layers:the upper and lower.In the top-price PC is taken as the host to make system management and experts fuzzy operation in intelligent,and to provide a friendly human-computer interface,and to realize the united monitoring and management of greenhouse; the lower is composed of a series of modules of different function,and in each module,a single chip of AT89C is adopted as the lower machine,RS485 is used to communicate PC with all AT89C,and then the collection,processing and control of the greenhouse parameters is achieved.Each function module is completely isolated in electrical,any failure on the nodule does not produce any effect on other modules.The system collects separately ways of environment information through each monitoring andcontrol module,and sends it to host PC through the RS485 interface.And in the PC configuration control system,the acquired parameters are compared with the values of setting,then according to a variety of expert intelligent fuzzy control system of crops at different growth stages,the fuzzy control instructions on the environment temperature,humidity,CO2 concentration,soil water content and the corresponding operation instructions or alarm are given.The system is applied in rural greenhouses in ually at 1/4 near East and West end in a greenhouse,and at the height of 1.5m from the ground in the middle in the northern half (near the wet curtain) and the southern half (near the fan ),a module of air temperature and humidity ,CO2 concentration and a module of soil moisture content are set;a module of soil moisture content will be added in the middle of the greenhouse according to the actual condition;at the height of 1.5m in the main entrance,a water tank is set,of which the solenoid of drip tube should be set based on the need and controlled by module of soil moisture content;and the PC is placed in the main entrance to the greenhouse.III HARDWARE DESIGNA.The CP and communication systemIn the distributed system of data acquisition and control,as the micro control unit is limited in data storage and slow in calculating of complex functions,so PC is used and the master-slave module is adopted in the system,that is a system of,taking PC as the host and taking the SCM systems located in the scene as slave.In this distributed system,communication is the key to it.Generally,the serial port of PC is standard RS232,of which transmission distance is shorter.But in agriculture control system.its communication distance is of tens of meters or several kilometers, so RS232/RS485 converter is used to achieve communication between the PC and SCM.To reduce investment,both considering the user convenience and friendly human-computer interaction,low-price PC of above 486 and below PIV is adopted;and considering the operation of configuration software,it is required that memory is 64M or above and hard disk is 10Gb or above.B. The control modules of temperature and humidity,illuminance and CO2 concentrationEach control unit consists of SCM,sensors,signal processing circuit,RS485 interface and output circuit.The hardware structure of module of temperature andhumidity,CO2 concentration is shown in Fig.2.CO2 concentration is measured by sensor based on NDIR technology,measurement is of 0~2×103mol.Through the sensor,control system,by software of digital filter,linear interpolation and temperature compensation,the CO2 concentration is output as digital adhered to UART protocol,and then is input directly to the SCM.The new intelligent sensor of SHT11 based on CMOSens technology is chosen in the measurement of temperature and humidity.In SHT11,the temperature and humidity sensors,signal amplification,A/D,I2C bus are all integrated in a chip;it has full-scale calibration,second-line digital output,and humidity measuring range of 0~100% RH,temperature measurement range of -40℃~+123.8℃,humidity measurement accuracy of ±3.0% RH,temperature measurement accuracy of ±0.4℃,the response time of <4s.The illuminance sensor of JY1-TBQ-6 of silicon photovoltaic detection is used Light measuring.Its measurement range is 0~200,000 Lux;spectral range is 400~700(nm) visible light;measurement error is less than 2%; output is 4~20mA or 0~20mV;output signal can be directly send to the A/D of the SCM after being amplified to 0~4V.Modules accept the instructions form the the Upper,and output via the output circuit .The output circuit consists of optical isolation,the signal driver and the output relays.C. The measurement and control modules of soil moistureWater is a polar medium, the dielectric constant of the soil containing water is mainly determined by the water,when water content is different,the wave impedanceis different.The soil moisture is measured by standing wave radio method in this system.Based on the theory of Engineering Electromagnetic Field,for lossy medium,the electromagnetic wave impedance as follows:Z0=√μ/ε(1+jλ/(ωε))Where μ is medium permeability,and μ of soil is μ≈μ0 is the vacuum permeability;ε is medium dielectric constant;λ is medium conductivity;ω is electromagnetic wave frequency.In the very low audio(<2000Hz),the loss tangent of dry soil dielectric is λ/ωε≈0.07,if you choose the frequency of the signal source at above 20MHz.then,ε≈ε∞,the imaginary part of the soil wave impedance is neglect,only the real part,which amounts to a pure resistance.Soil moisture sensor consists of 100MHz signal source,a coaxial transmission line and a 4-pin stainless probe.The electromagnetic waves of signal transmit to the probe along the lines.As the probe impedance and line impedance are different,the superimposition of incident waves and reflected waves forms a standing waves.Taking the coaxial transmission line as a lossless uniform line,wave impedance is Z0,Z l is the load impedance.Then the reflected coefficient of voltage wave at the probe is:Γ=（Z L-Z0）/(Z L+Z0)Choosing the length of transmission line is l=λ/4,the maximum and minimum of both ends of the line are U max and U min,Then the standing wave radio in the line can be expressed as:S=U max /U min =(1-|Γ|)/(1+|Γ|)In the way,the soil moisture radio can be measured by measuring the standing wave rate of transmission line.As shown in Fig.3.,soil moisture module consists of sensors and controllers,the sensors are subordinated to controllers,controllers can be omitted without the need of irrigation in greenhouse.To simplify the control,irrigation technology of node-type in partition is adopted in the control soil moisture in this system.To a certain extent,the parameters of upper and lower the ground can be decoupled by adopting this technology.IV CONTROL SYSTEM PROGRAMMINGThe software of PC is developed by KingView 6.51 of Beijing-controlled Asia.This configuration software has high reliability,shorter development cycle,perfect capability of graphical interface generation,and friendly human-computer interaction;and can create dynamic images and charts in accordance with the layout of equipment in the scene;can visually display the changes of parameters,control status,and can give an alarm when over-limited;and can achieve fuzzy control of greenhouse parameters by using the history curve of environment parameters stored in the specific database and adopting the agricultural expert system.The software of SCM of the slave is developed by Keil C51 to achieve real-time collecting,processing,uploading of the parameters and accept the fuzzy control instructions from the host computer and complete local control of the device.A.Program design of the control moduleThe software of the sub-slave machine of soil moisture module,that include the main function,subroutines of data acquisition and processing,interrupt handling andcommunicating etc,read the value of standing wave voltage through the parallel data port and obtained the value of soil moisture content by function calculating.The software of the slave machine of monitoring and control of soil moisture mainly complete data communication with the sub-slave machine,uploading measurement data and current control state to the host computer,accepting the fuzzy control instructions from the host computer and output the implementation instructions.The software of the slave machine of temperature and humidity,and CO2 mainly complete reading data of CO2 concentrations and temperature and humidity through the I2C concentration,uploading measurement data and current control state to the host computer,accepting the fuzzy control instructions from the host computer and output the implementation instructions.The structure of the main program and interrupt subroutine of temperature and humidity module are shown in Fig.4.The serial interrupt mode 3 is adopted by all slaves to communicate with the host,transmit the digital collecting and receive instructions.B. Program design of PC and fuzzy control system1)The communication settings of KingView 6.51:In order to ensure the correctness of communication,the upper and lower must follow the same communication protocol,set the communication ually in communication,master-slave mode is adopted in style and responder is adopted in the process.That is ,the master sent a command to the slave first,then et slave give an answer after receiving the command,thus once communication is completed.In KingView ,a scheduled polling method is adopted to do reading and writing between the lower machine by PC.In the project browser of KingView,first,click device →COM1;in the wizard of device configuration,select intelligent modules→SCM→current SCM of HEX→serial port,and then ser parameters for the host computer’s communication.2)The connection of KingView 6.51 and database:Database is the core of the software,that not only contains the definition of variables,real-time parameters and the historical parameters,but also is needed by parameters alarming,fuzzy calculating,reporting ,and displaying.Access2003 desktop database is used as records database of the system,and by using SQL,it is operated by KingView via ODBC.The procedure is :to create data variables in KingView to create a body of records toestablish a data source of ODBC to create query screens and make the screen connection.To connected with Microsoft Access2003,the functions of SQLConnect(),SQLSelect(),SQLLast(),SQLNext(),SQLFist(),SQLPrew(),SQLInsrt() ,and so on,should be implemented in the command language,and then real-time storage and inquiry of data are completed.3)Software design of PC :For the control system of greenhouse,data storage capacity of the PC is unlimited,so if the existing mature software modules are include into the system,it both be relaxed and can improve the system reliability.The software of software consists of control module and management module.V CONCLUSIONAccording to the economic bearing capacity of farmer in Qinhuangdao ,with the existing technology of monitoring and control of environment parameters of greenhouse,a master-slave distributed automatic control system of greenhouse environment in which PC is taken as the host computer is developed.The system has following characteristics:1)With the large amount of data storage of PC,fuzzy control expert system is easy of data storage,modification and system upgrading.2)By using KingView to develop software of PC,the system reliability is improved,and the development cycle is shorten,and a friendly human-computer interface is get.3)A distributed and modular structure is used in the system,it makes the system maintenance easier and adapts to production needs more. The monitoring and control modules of the slave are connected to the host through the RS485 bus based on needs,then the control of greenhouse in partition or block can be achieved.基于新的温室环境参数监测和控制系统根据实际在农村地区的温室环境参数的监测和控制，主从分布式测量和控制系统的设计需要，以其中一台计算机作为主机，该系统由PC、土壤水分测量和控制模块，温度、湿度、CO2监测和控制模块组成。
[每日一酷]Blossom?智能灌溉控制器
![[每日一酷]Blossom?智能灌溉控制器](https://img.taocdn.com/s3/m/faf1c3320640be1e650e52ea551810a6f424c870.png)
[每日一酷]Blossom 智能灌溉控制器
bossom 是一个简单、智能且经济实用的灌溉控制器，它可以根据你花园的植物类型并结合天气情况为你定制精准的灌溉计划。
并通过你的智能设备将信息呈现给您，与传统靠感觉为植物浇水相比，bossom灌溉系统即科学合理而且还可以让你避免浪费水资源。
bossom灌溉系统包括三部分组成，控制器是整个系统的中枢系统，直觉与云端相连通过数据和智能算法为你优化灌溉计划。
桥接器可以将你的控制器通过wifi或者网线介入家里的路由让控制器接入互联网。
app应用，通过应用你可以随时随地查看灌溉系统的浇水状态。
bossom综合来看主要为我们解决了植物的合理灌溉，即为你简化了灌溉的繁琐工作，又节约了水资源，是不是非常实用呢？目前该产品在kickstarter上众筹，如果你家里有一片小花园你不妨一试。
[每日一酷] 用最简洁的文字、精美的图片每天为您推荐一款新奇特智能产品。
外文翻译-自动浇花系统
本科毕业设计（外文翻译）题目自动浇花系统的设计姓名刘富强专业自动化学号201042048 指导教师赵明冬郑州科技学院电气工程学院二○一四年五月New Environment Parameters Monitoring AndControl System For Greenhouse Based OnMaster-slave DistributedAbstractAccording to the actual need of monitoring and control of greenhouse environment parameters in rural areas,a master-slave distributed measurement and control system is designed,in which PC is taken as the host. The system consists of PC ,soil moisture measurement and control module,temperature and humidity, and CO2 monitoring and control module. In the system,PC has large amount of data storage which is easy to make use of fuzzy control expert system,configuration software-KingView is used to develop software for PC,by which the development cycle is shorten and a friendly human-computer interaction is provided.Each monitoring and control module consists of STC12 series of microcontrollers,sensors,relays etc.Different modules are select based on the need if system to achieve control greenhouse in partition and block.I INTRODUCTIONTo modern indoor agriculture, the automatic measurement and control of environment parameters is the key to achieve crop yield and quality of greenhouse.In recent years,facilities agriculture develops vigorously in our country,matched with it,the monitoring and control instrument of greenhouse have also made certain development.After nearly 10 years of unremitting hard work,our research team of measurement and control system of agriculture environment parameters,designed an intelligent measurement and control system of distribution combined of greenhouse which can be popularized in the vast rural areas.This system is mainly control of temperature,humidity,CO2 concentration,soil moisture and illumination of greenhouse.OF SCM,as the data storage is small,display interface is single,amount of information is limited,but its capability price ratio is high,so it is used as a front unit of data acquisition and control;and of PC,it has a large amount of data storage,rich software,convenient human-computer interaction,and so on.If we use outdated and low-priced PC,taking the PC as the upper machine,taking the different function control modules composed of multiple microcomputers as the lower machines,then a master-slave distributed and intelligent control system bases on microcomputer is made up,by which both better monitoring and control,display and data collection or management are achieved,but also lower cost of system is get according to the actual need.II SYSTEM STRUCTURE AND PRINCIPLEThe most marked feature of the distribution combined and intelligent control system greenhouse is that of incorporating with data acquisition, control and management as a whole,module combination, simple structure,convenient human-computer interaction,and using technology of intelligent expert fuzzy control,which can adapt to a variety of crop management control in greenhouse.The basic structure of the system is shown in Fig.1.The structure of the distributed system is composed of two layers:the upper and lower.In the top-price PC is taken as the host to make system management and experts fuzzy operation in intelligent,and to provide a friendly human-computer interface,and to realize the united monitoring and management of greenhouse; the lower is composed of a series of modules of different function,and in each module,a single chip of AT89Cis adopted as the lower machine,RS485 is used to communicate PC with all AT89C,and then the collection,processing and control of the greenhouse parameters is achieved.Each function module is completely isolated in electrical,any failure on the nodule does not produce any effect on other modules.The system collects separately ways of environment information through each monitoring and control module,and sends it to host PC through the RS485 interface.And in the PC configuration control system,the acquired parameters are compared with the values of setting,then according to a variety of expert intelligent fuzzy control system of crops at different growth stages,the fuzzy control instructions on the environment temperature,humidity,CO2 concentration,soil water content and the corresponding operation instructions or alarm are given.The system is applied in rural greenhouses in ually at 1/4 near East and West end in a greenhouse,and at the height of 1.5m from the ground in the middle in the northern half (near the wet curtain) and the southern half (near the fan ),a module of air temperature and humidity ,CO2 concentration and a module of soil moisture content are set;a module of soil moisture content will be added in the middle of the greenhouse according to the actual condition;at the height of 1.5m in the main entrance,a water tank is set,of which the solenoid of drip tube should be set based on the need and controlled by module of soil moisture content;and the PC is placed in the main entrance to thegreenhouse.III HARDWARE DESIGNA.The CP and communication systemIn the distributed system of data acquisition and control,as the micro control unit is limited in data storage and slow in calculating of complex functions,so PC is used and the master-slave module is adopted in the system,that is a system of,taking PC as the host and taking the SCM systems located in the scene as slave.In this distributed system,communication is the key to it.Generally,the serial port of PC is standard RS232,of which transmission distance is shorter.But in agriculture control system.its communication distance is of tens of meters or several kilometers, so RS232/RS485 converter is used to achieve communication between the PC and SCM.To reduce investment,both considering the user convenience and friendly human-computer interaction,low-price PC of above 486 and below PIV is adopted;and considering the operation of configuration software,it is required that memory is 64M or above and hard disk is 10Gb or above.B. The control modules of temperature and humidity,illuminance and CO2 concentrationEach control unit consists of SCM,sensors,signal processing circuit,RS485 interface and output circuit.The hardware structure ofmodule of temperature and humidity,CO2 concentration is shown in Fig.2.CO2 concentration is measured by sensor based on NDIR technology,measurement is of 0~2×103mol.Through the sensor,control system,by software of digital filter,linear interpolation and temperature compensation,the CO2 concentration is output as digital adhered to UART protocol,and then is input directly to the SCM.The new intelligent sensor of SHT11 based on CMOSens technology is chosen in the measurement of temperature and humidity.In SHT11,the temperature and humidity sensors,signal amplification,A/D,I2C bus are all integrated in a chip;it has full-scale calibration,second-line digital output,and humidity measuring range of 0~100% RH,temperature measurement range of -40℃~+123.8℃,humidity measurement accuracy of ±3.0% RH,temperature measurement accuracy of ±0.4℃,the response time of <4s.The illuminance sensor of JY1-TBQ-6 of silicon photovoltaicdetection is used Light measuring.Its measurement range is 0~200,000 Lux;spectral range is 400~700(nm) visible light;measurement error is less than 2%; output is 4~20mA or 0~20mV;output signal can be directly send to the A/D of the SCM after being amplified to 0~4V.Modules accept the instructions form the the Upper,and output via the output circuit .The output circuit consists of optical isolation,the signal driver and the output relays.C. The measurement and control modules of soil moistureWater is a polar medium, the dielectric constant of the soil containing water is mainly determined by the water,when water content is different,the wave impedance is different.The soil moisture is measured by standing wave radio method in this system.Based on the theory of Engineering Electromagnetic Field,for lossy medium,the electromagnetic wave impedance as follows:Z0=√μ/ε(1+jλ/(ωε))Where μ is medium permeability,and μ of soil is μ≈μ0 is the vacuum permeabil ity;ε is medium dielectric constant;λ is medium conductivity;ω is electromagnetic wave frequency.In the very low audio(<2000Hz),the loss tangent of dry soil dielectric is λ/ωε≈0.07,if you choose the frequency of the signal source at above 20MHz.then,ε≈ε∞,the imaginary part of the soil wave impedance is neglect,only the real part,which amounts to a pure resistance.Soil moisture sensor consists of 100MHz signal source,a coaxial transmission line and a 4-pin stainless probe.The electromagnetic waves of signal transmit to the probe along the lines.As the probe impedance and line impedance are different,the superimposition of incident waves and reflected waves forms a standing waves.Taking the coaxial transmission line as a lossless uniform line,wave impedance is Z0,Z l is the load impedance.Then the reflected coefficient of voltage wave at the probe is:Γ=（Z L-Z0）/(Z L+Z0)Choosing the length of transmission line is l=λ/4,the maximum and minimum of both ends of the line are U max and U min,Then the standing wave radio in the line can be expressed as:S=U max /U min =(1-|Γ|)/(1+|Γ|)In the way,the soil moisture radio can be measured by measuring the standing wave rate of transmission line.As shown in Fig.3.,soil moisture module consists of sensors and controllers,the sensors are subordinated to controllers,controllers can be omitted without the need of irrigation in greenhouse.To simplify the control,irrigation technology of node-type in partition is adopted in the control soil moisture in this system.To a certain extent,the parameters of upper and lower the ground can be decoupled by adopting this technology.IV CONTROL SYSTEM PROGRAMMINGThe software of PC is developed by KingView 6.51 of Beijing-controlled Asia.This configuration software has high reliability,shorter development cycle,perfect capability of graphical interface generation,and friendly human-computer interaction;and can create dynamic images and charts in accordance with the layout of equipment in the scene;can visually display the changes of parameters,control status,and can give an alarm when over-limited;and can achieve fuzzy control of greenhouse parameters by using the history curve of environment parameters stored in the specific database and adopting the agricultural expert system.The software of SCM of the slave is developed by Keil C51 to achieve real-time collecting,processing,uploading of the parameters and accept the fuzzy control instructions from the host computer and complete local control of the device.A.Program design of the control moduleThe software of the sub-slave machine of soil moisture module,that include the main function,subroutines of data acquisition and processing,interrupt handling and communicating etc,read the value of standing wave voltage through the parallel data port and obtained the value of soil moisture content by function calculating.The software of the slave machine of monitoring and control of soil moisture mainly complete data communication with the sub-slave machine,uploading measurement data and current control state to the host computer,accepting the fuzzy control instructions from the host computer and output the implementation instructions.The software of the slave machine of temperature and humidity,and CO2 mainly complete reading data of CO2 concentrations and temperature and humidity through the I2C concentration,uploading measurement data and current control state to the host computer,accepting the fuzzy control instructions from the host computer and output the implementation instructions.The structure of the main program and interrupt subroutine of temperature and humidity module are shown in Fig.4.The serial interrupt mode 3 is adopted by all slaves to communicate with the host,transmit the digital collecting and receive instructions.B. Program design of PC and fuzzy control system1)The communication settings of KingView 6.51:In order to ensurethe correctness of communication,the upper and lower must follow the same communication protocol,set the communication ually in communication,master-slave mode is adopted in style and responder is adopted in the process.That is ,the master sent a command to the slave first,then et slave give an answer after receiving the command,thus once communication is completed.In KingView ,a scheduled polling method is adopted to do reading and writing between the lower machine by PC.In the project browser of KingView,first,click device →COM1;in the wizard of device configuration,select intelligent modules→SCM→current SCM of HEX→serial port,and then ser parameters for the host computer’s communication.2)The connection of KingView 6.51 and database:Database is the core of the software,that not only contains the definition of variables,real-time parameters and the historical parameters,but also is needed by parameters alarming,fuzzy calculating,reporting ,and displaying.Access2003 desktop database is used as records database of the system,and by using SQL,it is operated by KingView via ODBC.The procedure is :to create data variables in KingView to create a body of records to establish a data source of ODBC to create query screens and make the screen connection.To connected with Microsoft Access2003,the functions of SQLConnect(),SQLSelect(),SQLLast(),SQLNext(),SQLFist(),SQLPrew(),SQLInsrt(),and so on,should be implemented in the command language,and then real-time storage and inquiry of data are completed.3)Software design of PC :For the control system of greenhouse,data storage capacity of the PC is unlimited,so if the existing mature software modules are include into the system,it both be relaxed and can improve the system reliability.The software of software consists of control module and management module.V CONCLUSIONAccording to the economic bearing capacity of farmer in Qinhuangdao ,with the existing technology of monitoring and control of environment parameters of greenhouse,a master-slave distributed automatic control system of greenhouse environment in which PC is taken as the host computer is developed.The system has following characteristics:1)With the large amount of data storage of PC,fuzzy control expert system is easy of data storage,modification and system upgrading.2)By using KingView to develop software of PC,the system reliability is improved,and the development cycle is shorten,and a friendly human-computer interface is get.3)A distributed and modular structure is used in the system,it makes the system maintenance easier and adapts to production needs more. The monitoring and control modules of the slave are connectedto the host through the RS485 bus based on needs,then the control of greenhouse in partition or block can be achieved.基于新的温室环境参数监测和控制系统根据实际在农村地区的温室环境参数的监测和控制，主从分布式测量和控制系统的设计需要，以其中一台计算机作为主机，该系统由PC、土壤水分测量和控制模块，温度、湿度、CO2监测和控制模块组成。
AUTOSPRAY（全润）智能喷灌控制器说明书（PDF）-一、功能：
AUTO SPRAY (全润)智能喷灌控制器操作使用手册一、 功能：1、全润(Auto Spray)智能喷灌控制器的功能及作用：1.1、科学合理地保证地面喷灌与空中喷雾，通过有效保证植物叶面湿度、降低植物叶面蒸腾系数，从而有效降低植物体内生理水份散失，提高苗木特别是返苗期的成活率；1.2、通过人工智能控制，可以有效保证土壤合理含水量、保证土壤具有良好的通气性能，促进植物根系呼吸作用，提高各类植物成活率，减少施工企业由于苗木死亡带来无谓的重复投资；1.3、人工智能管理园林施工及后期养护工作中的浇灌工作，最大限度降低浇灌人工费用投入，可节约浇灌人工费的98%；1.4、可将灌溉与园林喷药及叶面施肥相灵活结合，更大程度地节约人工。
1.5、一次投资、多次使用、节省浇灌人工投入、多次受益。
全润人工智能灌溉控制系统在总结多年植物种植及养护工程实践中的经验，拆卸、安装方便，运行稳定，启动方便，一套系统可多次使用，特别适合于园林施工企业投资购买。
2、全润智能喷灌控制器的适用范围：2.1、草坪草籽播种后的浇灌工作；2.2、播种草坪的成坪期浇灌工作；2.3、草坪植生带栽植后的返苗浇灌工作；2.4、灌木种植过程浇灌工作；2.5、灌木返苗期期浇灌工作；2.6、乔木返苗期浇灌工作；2.7、模糊灌溉工作；3、全润智能喷灌控制器的比较优势国内外市面上现有的喷灌控制器如索罗润（Solo Rain）、托罗（Toro）、雨鸟（Rain Bird）、亨特（Hunter）等控制器，都是在设定的时间段内进行浇灌控制，这些控制器大部分都可以设定每天几个时间段进行浇灌、每个时间段有多长时间等，由操作员对每个控制器按每天计划浇灌的时间进行设定，虽然也可以节省人工，但并不能合理地为植物提供水份需求。
我们知道，不同植物在不同生长时期对水份的需求是有很大差异的，而植物返苗期间或炎热的夏季仅仅通过地面浇水也是片面的，对植物的浇灌工作应从更为全面的情况考虑。
关于花草自动浇水系统研究-外文文献
1 introduction
With the social modernization step speeding up, automation has become a development topics in today's world. Flower's growth needs to have certain environmental conditions, these conditions are mainly temperature, moisture, illumination, air composition, composition, physical and mechanical properties of soil and nutrient solution temperature and composition, etc. Flowers can be a good growth is most important of which is the suitability for soil moisture. How to control soil moisture effectively and timely problem has already become the flowers AiHuaZhe most issue of concern. Flower proverbs said: "don't live in the water, long is fat". Potted flowers and plants due to the volume small, poor water retention performance, large evaporation nor groundwater supply limited by certain conditions, such as the reason, not to drought, water is particularly important. If potted flower water, plant physiological activities will damage in the body, the absorption of potassium, boron, calcium phosphate is weak, and the lack of these elements can lead to poor growing point nearby growth. Potted flower water shortage will cause soil nutrient concentrations are relatively high, also appear the most easily hurt "fat" [. Flowers grow, most come from the soil absorption, keep soil moisture content, appropriate is the normal development of flowers and necessary conditions to obtain higher GuanShangPin qualitative. Common flowers according to the water requirement of habits and the different water environment adaptability, can be divided into aquatic flowers and plants, wet flowers, flowers and xerophytic flowers in four. The amount of water in different we need to water the flowers are not the same as [3]. Different flower water demand is different, the same flower in different growth stage required quantity is also different. Flowers requirement for soil water varies in each growth stage. We according to the growing season and growth period of flower arrange . To sum up, the reasonable water potted flower is
自动浇花器作文
自动浇花器作文The automatic watering system is a technological innovation that has revolutionized the way we care for our plants. 这种自动浇水系统是一种技术创新，已经彻底改变了我们照顾植物的方式。
One of the key advantages of an automatic watering system is the convenience it offers. 通过自动浇水系统，我们可以轻松地对植物进行定时浇水。
Imagine not having to worry about remembering to water your plants every day – the automatic watering system takes care of that for you. 想象一下不用担心每天记得给植物浇水——自动浇水系统为你打理这些。
This can be especially helpful for individuals who may have busy schedules or are forgetful when it comes to plant care. 这对于那些可能有忙碌日程或在植物护理方面健忘的人来说尤其有帮助。
Another benefit of an automatic watering system is the ability to provide consistent and precise watering for your plants. 自动浇水系统的另一个好处是能够为植物提供一致和精确的浇水。
This can help prevent both over-watering and under-watering, which are common problems that can lead to damaged or unhealthy plants. 这可以帮助防止过度浇水和欠水，这是可能导致植物受损或不健康的常见问题。
基于AT89S52自动浇花系统的设计
基于AT89S52自动浇花系统的设计汪晓晨【摘要】This stystem use AT89S52 as the core chip,use SLHT5-4 as the soil moisture content.Through information col ection、information comparing 、through the relay control imformation ,It can drive pump control system,the automatic flower watering work is completed,this stystem provide hardware design block diagram and software design process.%本系统采用AT89S52单片机为核心芯片，利用温度传感器SLHT5-4来采集土壤的湿度。
经过信息采集、信息比较、通过继电器控制信息，驱动水泵控制电路工作，实现自动浇花，给出硬件设计电路框图、软件设计流程。
【期刊名称】《电子制作》【年(卷),期】2015(000)002【总页数】1页(P2-2)【关键词】AT89S52;自动浇花;SLHT5-4【作者】汪晓晨【作者单位】新乡学院物理与电子工程学院河南新乡 453000【正文语种】中文【中图分类】TP368.2现代生活的节奏越来越快，很多人喜欢在工作地点、生活区间、公共场所等地方用绿色植物来点缀。
但对绿色植物的维护、保养是需要花不少时间去完成的，当由于种种原因忘记定时对花卉及时浇水时，设计一个家用自动浇花系统就十分必要。
本系统主要使用AT89S52单片机为控制芯片，输入信号由土壤湿度传感器SLHT5-4提供，系统中还包含电源部分、独立键盘、LCD显示和继电器控制部分等组成。
软件部分采用C语音编程，对各功能部分采用模块化设计思路。
系统设计框图如图1所示。
