SACS海事有限元软件培训教程Part 13 - Load out with no load gap elementsPreparation1)Under “Training Project”, create “Gap Loadout” subdirectory2)Copy SACINP.DAT model file from “Static PSI” directory to “Gap Loadout” directory. Modifying model to only include jacket for load outDelete all weight definitions for deck structure.In Precede, delete deck structures, plates and plate groups, all piles and wishbones.Using “Display” > “Zoom Box” > “Translate/Rotate” > “General”, select the wholestructure, pick rotation angle about Y, input rotation angle -90.0, input Z translation = 11.0 m to rotate and move the structure.Using “Display” > “Zoom Box” > “T ranslate/Rotate” > “General” again, select the whole structure, pick rotation angle about Z, input rotation angle 180.0. rotate the structure to final fabrication position.Delete all Ky and Ly definitions. Add Kz and Lz definitions for jacket horizontal framings.Add joints 1101, 1105, 1201, 1205, 1301, 1305, 1401 and 1405 relative to 101L, 105L, 201L, 205L, 301L, 305L, 401L and 405L correspondingly with dZ = -1.75;Add joints 2101, 2105, 2201, 2205, 2301, 2305, 2401 and 2405 relative to 1101, 1105, 1201, 1205, 1301, 1305, 1401 and 1405 correspondingly with dZ = -1.75;Connecting these joints vertically with members using member group label set to CAN.Modifying members 2101-1101, 2105-1105, 2201-1201, 2205-1205, 2301-1301, 2305-1305, 2401-1401 and 2405-1405 to compression only members.Modifying members 1101-101L, 1105-105L, 1201-201L, 1205-205L, 1301-301L, 1305-305L, 1401-401L and 1405-405L to set joint B Z direction offsets -53.50 cm.Set joint fixity 001000 to joints 2101, 2105, 2201, 2205, 2301, 2305, 2401 and 2405.Set joint fixity 110000 to joints 1101, 1105, 1201, 1205, 1301, 1305, 1401 and 1405.Add member properties for CAN: Member group CAN, Diameter = 76.20 cm, WallThickness = 2.54 cmThe added member group CAN, members and joints shall looks like following:------------------------------------------------------------------------------------------------------------- GRUP CAN 76.200 2.540 20.00 8.0024.80 1 1.001.00 0.50N 7.849…MEMBER11101101L CANMEMBER OFFSETS -53.50MEMBER11105105L CANMEMBER OFFSETS -53.50MEMBER11201201L CANMEMBER OFFSETS -53.50MEMBER11205205L CANMEMBER OFFSETS -53.50MEMBER11301301L CANMEMBER OFFSETS -53.50MEMBER11305305L CANMEMBER OFFSETS -53.50MEMBER11401401L CANMEMBER OFFSETS -53.50MEMBER11405405L CANMEMBER OFFSETS -53.50MEMBER 21011101 CAN CMEMBER 21051105 CAN CMEMBER 22011201 CAN CMEMBER 22051205 CAN CMEMBER 23011301 CAN CMEMBER 23051305 CAN CMEMBER 24011401 CAN CMEMBER 24051405 CAN C…JOINT 1101 -79.500 13.350 1.750 110000JOINT 1105 -79.500-13.350 1.750 110000JOINT 1201 -50.000 10.400 1.750 110000JOINT 1205 -50.000-10.400 1.750 110000JOINT 1301 -21.000 7.500 1.750 110000JOINT 1305 -21.000 -7.500 1.750 110000JOINT 1401 2.000 5.200 1.750 110000JOINT 1405 2.000 -5.200 1.750 110000…JOINT 2101 -79.500 13.350 0.000 001000JOINT 2105 -79.500-13.350 0.000 001000JOINT 2201 -50.000 10.400 0.000 001000JOINT 2205 -50.000-10.400 0.000 001000JOINT 2301 -21.000 7.500 0.000 001000JOINT 2305 -21.000 -7.500 0.000 001000JOINT 2401 2.000 5.200 0.000 001000JOINT 2405 2.000 -5.200 0.000 001000------------------------------------------------------------------------------------------------------------- Add load cases and load combinations for jacket load outAdd a load options LDOPT line to define unit in “MN”Add load case DEAD to include only structural selfweight;Add load case ANOD to create inertia gravity loads from weight group ANOD;Add load case LPAD to create inertia gravity loads from weight group LPAD;Add load case WKWY to create inertia gravity loads from weight group WKWY;Add 5 load combinations named as ALLS, LOS1, LOS2, LOS3 and LOS4 to combineDEAD, ANOD, LPAD and WKWY, and representing all supports effective and 2 out of 8 supports lost for each following load combination.Add gap load case selection LCSEL line to include ALLS, LOS1, LOS2, LOS3 and LOS4 for gap analysis.The added load lines shall looks like following:------------------------------------------------------------------------------------------------------------- LDOPT MN…LCSEL GP ALLS LOS1 LOS2 LOS3 LOS4…LOADLOADCNDEADDEADDEAD -Z MLOADCNANODINCWGT ANODACCEL 1.0 N CEN1 LOADCNLPADINCWGT LPADACCEL 1.0 N CEN1 LOADCNWKWYINCWGT WKWYACCEL 1.0 N CEN1 LCOMBLCOMB ALLS DEAD 1.0ANOD 1.0LPAD 1.0WKWY 1.0LCOMB LOS1 DEAD 1.0ANOD 1.0LPAD 1.0WKWY 1.0LCOMB LOS2 DEAD 1.0ANOD 1.0LPAD 1.0WKWY 1.0LCOMB LOS3 DEAD 1.0ANOD 1.0LPAD 1.0WKWY 1.0LCOMB LOS4 DEAD 1.0ANOD 1.0LPAD 1.0WKWY 1.0END------------------------------------------------------------------------------------------------------------- Create Gap input file GAPINP.DAT to define no load gap elementsFor Gap options,All gap elements defined in the model = Yes;Units = MN;Add Gap type override by member LCGAP line to define,No load member 2101-1101 and 2105-1105 for load case LOS1;No load member 2201-1201 and 2205-1205 for load case LOS2;No load member 2301-1301 and 2305-1305 for load case LOS3;No load member 2401-1401 and 2405-1405 for load case LOS4;The gap input file generated shall looks like following:------------------------------------------------------------------------------------------------------------- GAPOPT 0 MN 600 0.00001 MLCGAP LOS1 INC NL MEM 21011101 21051105LCGAP LOS2 INC NL MEM 22011201 22051205LCGAP LOS3 INC NL MEM 23011301 23051305LCGAP LOS4 INC NL MEM 24011401 24051405END------------------------------------------------------------------------------------------------------------- Create gap run file and run the analysis.Review results.。
