热加工专业英语试题

3.Polarity has a direct relationship to the location of the liberated heat since it is possible to control the amount of heat going into the base metal.
8．A weld tha has the same properties as the base metal can only be made if the molten puddle is completely protected from the atmosphere during the welding process.
4.The preparation of metallographic specimens described in this article is applicable also to other types of studies ,such as electron microscopy,microhardness testing,image analysis ,and electron microprobe analysis.
( )19.flame cutting( )20.heat treatment
Options：A热脆性B正接C再结晶D白热E热处理F砂芯
G火焰切割H弹性模量I浇注系统J电阻焊K固体渗碳
L相图M耐磨性N弹性极限O加工硬化P机械性能
Q合金工具钢R夹渣S回火马氏体T抗拉强度
二、Transl ate the following terms into Chinese. (20 points)
5.The cause of the increasing use of metals is to be found in their characteristic properties ,such as: strength,or ability to support weight without bending or breaking; toughness ,or ability to bend rather than break under a sudden blow;resistance to atmospheric destruction;and malleability,deform permanently under compression without rupture.
四、Translate the following paragraphs into Chinese.（20points）
The simplest method of welding two pieces of metal together is known as pressure welding.The ends of metal are heated to a white heat-for iron,the welding temperature should be about1300℃---in a flame.At this temperature the metal becomes plastic.The ends are then pressed or hammered together,and the joint is smoothed off.Care must be taken to ensure that the surfaces are thoroughly clean first,for dirt will weaken the weld.Moreover,the heating of iron or steel to a high temperature causes oxidation,and a film of oxide is formed on the heated surfaces.For this reason,a flux is applied to the heated metal.At welding heat,the flux melts,and the oxide particles are dissolved in it together with any other impurities which may be present.The metal surface are pressed together,and the flux is squeezed out form the center of the weld.A number of different types of weld may be used,but for fairly thick bars of metal,a vee-shaped weld should normally be employed.It is rather stronger than the ordinary butt weld.
1.residual stresses2.fusion welding3.sand casting4.electrical conductivity
5.nonferrous metal6.finished part7.stainless steel8.low carbon steel
9.gear10.gas pocket11.surface finish12.electrode holder
2.For the spot,projection and seam welding processes ,the electrical conductivity of a metal is an additional factor affecting its weldability :high conductivity metals –such as copper and aluminium-allow the current to pass across the joint with less generation of heat than would be the case with,say ,steel,hence the need for exceptionally high currents for these metals.
13.14.15.16.
17.18.19.20.
三、Translate the following sentences into Chinese. (40points)
1.Ametal which oxidizes readily at welding temperatures,e.g.aluminium,is difficult to weld due to the need to minimize atmospheric contact with the molten metal and to use fluxes for elimination or control of any oxide formed.
考试学期
2013-2014-2
开课部门
模具技术系
考试课程
焊接专业英语（考查）期末试卷
考试班级
焊接1231、1232
考试形式
开卷（纸质任何资料）
题号
一
二
三
四
总分
得分
本试卷共2页，请核对试卷页数，班级、姓名等信息写在左侧，否则试卷无效。
一、Select the correct answer and fill in the appropriate brackets. (20 points)
( )10.wear resistance( )11.tempered martensite( )12.straight polarity
( )13.hot shortness( )14.tensile strength( )15.strain hardening
( )16.phase diagram( )17. elastic limit ( )18.slag inclusions
13.toughness14.bearing15.weld spatter16.the base metal
17.filler metal18.stress-relief anneal19.nondestructive testing20.butt weld
1.2.3.4.
5.6.7.8.9.10.1 Nhomakorabea.12.
6.Polarity is important because in DC welders the flow of current ,which is in one direction only,must be changed for some welding operations.
7．When a material under tension reaches the limit of its elastic strain and begins to flow plastically ,it is said to have yielded.
( )1. mechanical property ( )2.gating system( )3. alloy tool steel
( )4. modulus of elasticity( )5.recrystallization( )6.sand core
( )7.white heat( )8.resistance welding( )9. pack carburizing
