W.D.Zhu1Professore-mail:wzhu@umbc.edu

H.RenGraduateResearchAssistante-mail:renhui1@umbc.edu

C.XiaoVisitingGraduateResearchAssistante-mail:chuangx@umbc.edu

DepartmentofMechanicalEngineering,UniversityofMaryland,BaltimoreCounty,1000HilltopCircle,Baltimore,MD21250

ANonlinearModelofaSlackCableWithBendingStiffnessandMovingEndsWithApplicationtoElevatorTravelingandCompensationCables

Anonlinear,planarmodelofaslackcablewithbendingstiffnessandarbitrarilymovingendsisdeveloped.Themodelusestheslopeangleofthecentroidlineofthecabletodescribethemotionofthecable,andtheresultingintegropartialdifferentialequationwithconstraintsisderivedusingHamilton’sprinciple.Anewmethodisdevelopedtoobtainthespatiallydiscretizedequations,andtheBaumgartestabilizationprocedureisusedtosolvetheresultingdifferential-algebraicequations.Themodelcanbeusedtocalculatetheequilibriaandcorrespondingfreevibrationcharacteristicsofthecable,aswellasthedynamicresponseofthecableunderarbitrarilymovingends.Theresultsforanequilibriumandfreevibrationcharacteristicsaroundtheequilibriumareexperimen-tallyvalidatedonalaboratorysteelband.Themethodologyisappliedtoelevatortrav-elingandcompensationcables.Itisfoundthataverticalmotionofthecarcanintroduceahorizontalvibrationofatravelingorcompensationcable.Theresultspresentedareveriﬁedbyacommercialﬁniteelementsoftware.Thecurrentmethodisshowntobemoreefﬁcientthantheﬁniteelementmethodasitusesamuchsmallernumberofelementstoreachthesameaccuracy.Someotherinterestingfeaturesincludetheconditionforatravelingorcompensationcableequilibriumtobeclosesttoanaturalloopandadirectproofthatthecatenarysolutionisunique.͓DOI:10.1115/1.4003348͔

Keywords:elevatortravelingcables,slopeangle,integropartialdifferentialequation,ﬂexiblemultibodydynamics,differential-algebraicequations

1IntroductionAtypicalelevatorsystem,asshowninFig.1,hasthreetypesofcables:suspensioncables,compensationcables,andtravelingcables.Atravelingcabletransmitspowerandcontrolsignalsbe-tweentheelevatorcarandcontroller.Oneendofthetravelingcableisusuallyﬁxedtothewallinthemiddleofthehoistway,andtheotherendisattachedtothecar,whichmovesupanddownalongthehoistway.Acompensationcablebetweenthecarandcounterweightcompensatesfortheweightofthesuspensioncables.Asthecarmovesupanddown,thetravelingandcompen-sationcablescanundergohorizontalvibrationsinthecableplanes.Whilethedynamicsofthesuspensioncableshasbeenstudiedbyseveralresearchers͓1,2͔,thatofthetravelingandcom-pensationcablesinFig.1hasnotbeenstudiedinliterature.Whenthebendingstiffnessofacableisnegligible,Cartesiancoordinatesareoftenusedtodescribethemotionofthecable.ThelinearandnonlineardynamicsofcableswithoutbendingstiffnesswerestudiedbyIrvineandCaughey͓3͔andIrvine͓4,5͔.Whenthesag-to-spanratioislessthan1/8,theequilibriumofthecable,whichcorrespondstothecatenarysolution͓4͔,canbeapproxi-matedbyaparabolicfunction.Animportantdimensionlesspa-rameterthatdeterminesthedynamicsofthecableis͓3͔

␭c2󰀁

ͩ␳gLTͪ2EA

T͑1͒

whereEAand␳aretheaxialstiffnessandmassperunitlengthof

thecable,respectively;Listhelengthofthecable;Tistheten-sion;andgisthegravitationalacceleration.When␭c

2Ͻ24,the

cablebehaveslikeatautstring,andwhen␭c

2Ͼ24,thecablebe-

haveslikeaseesaw͓5͔.ThelineardynamicsoftautinclinedcableswasstudiedbyTriantafyllou͓6͔andTriantafyllouandGrinfogel͓7͔usingasymptoticanalyses.Anonlinear,three-dimensionaltranslatingcablemodelwasderivedandanalyzedbyPerkinsandMote͓8͔.SincetherearenoexternaltensionsinthetravelingandcompensationcablesinFig.1besidesthoseduetogravity,theaxialdeformationsofthecablescanbeneglected.Duetosmalltensionsinthelowerloopsofthecables,thebendingstiffnessesofthecablesneedtobeconsidered.Whenthebendingstiffnesseffectisconsidered,bendingandtorsionalanglescanbeusedtodescribethemotionofthecable,andtheformulationisreferredtoastheKirchhoff–Loverodtheory͓9͔.Antman͓10͔studiedindetailthemathematicalprob-lemsassociatedwiththerodtheory.Forlinearelasticmaterials,thedynamicequationsfromtherodtheoryreduceto12ﬁrst-ordernonlinearpartialdifferentialequations͑PDEs͒,whichcanalsobederivedusingtheNewton–Eulermethod͓11͔.Goyal͓12͔andGoyaletal.͓13͔usedtheﬁnitedifferencemethodtosolvethe12ﬁrst-orderPDEsintheirstudiesofthedynamicsofcablesandDNA.KimandChirikjian͓14͔presentedagrouptheoryapproachtocalculatingtheequilibriaandfreevibrationcharacteristicsoftherod.Santillanetal.͓15͔theoreticallyandexperimentallystud-iedtheequilibriaandstabilityofaloopwithtwoendsclampedtogether.Therearetwomainapproachesinthenumericalsimula-
