Active Optical Cable (AOC)
Datacenter Solutions
QSFP28 100G
100G QSFP28 to 4x 25G SFP28
FanOut DAC
QSFP+ 56G
SFP28 25G
QSFP+ to 4 SFP+ FanOut
QSFP+40G
SFP+10G
Active Optical Cable (AOC)
Direct Attach Cable (DAC)
Transceiver Module
Loopback Module
Optical Fiber Patch Cord Cable
Ethernet LAN Cable
Consumer Premise Solutions
General Description
Teralux® SFP+ Active Optical Cable (AOC) is a direct attach fiber
assembly with SFP+ connector interface. It’s suitable for short
distance and offers a costeffective way to connect within racks
and across adjacent racks.
Applications
Highspeed storage area network
Computer cluster crossconnect
Custom highspeed data pipes
Inter and cross racks connection
Features
1 channel operating at up to 10.3125 Gbps
Fiber link up to 100m
BER @ 1012
Hot pluggable
Bend insensitive fiber
Compliant with SFF8431 specifications for 10 Gigabit small
form factor pluggable module “SFP+”
Allmetal housing for superior EMI performance
Low power consumption < 1W
Cost effective SFP+ solution enables higher port densities and
greater bandwidth
RoHS compliant
Part Number List
Teralux P/NLength(M)Passive/ActiveMaterial of Conduct
BBS01E1ActiveFiber
BBS02E2ActiveFiber
BBS03E3ActiveFiber
BBS04E4ActiveFiber
BBS05E5ActiveFiber
BBS06E6ActiveFiber
BBS07E7ActiveFiber
BBS08E8ActiveFiber
