Basic Application Technologies of Bifacial Photovoltaic Solar ModulesTOSHIO JOGE,1 YOSHIO EGUCHI,1 YASUHIRO IMAZU,1 ICHIRO ARAKI,1 TSUYOSHI UEMATSU,2 and KUNIHIRO MATSUKUMA3
1Hitachi, Ltd., Power & Industrial Systems Division, Japan
2Central Research Laboratory, Hitachi, Ltd., Japan
3Sojo University, Japan
SUMMARYIn order to realize a photovoltaic (PV) solar powersystem which is low cost and flexible on its installation, theauthors have studied vertical installations of bifacial solarmodules. Simulation studies and field tests were performedin order to evaluate daily and yearly output energies whenbifacial modules are vertically installed at various azimuthangles. It is clarified that the yearly generated energies bya vertically installed bifacial module are equivalent to thoseof a monofacial module facing south with an optimum tilt,regardless of the azimuth angles. According to the aboveresults, some applications have been successfully demon-strated including a fence-integrated PV system and a pole-mounted PV system. © 2004 Wiley Periodicals, Inc. ElectrEng Jpn, 149(3): 32–42, 2004; Published online in WileyInterScience (www.interscience.wiley.com). DOI10.1002/eej.10370
Key words: photovoltaic solar cell; bifacial solarcell; vertical installation.
1. IntroductionAt present, the photovoltaic solar cells commonly inuse are monofacial cells, and photovoltaic solar cells whichcan generate electricity by receiving light on both sides arereferred to as bifacial photovoltaic cells. Bifacial photovol-taic solar modules rapidly gained attention as a way tocreate a low-cost photovoltaic system because the quantityof silicon substrate materials that represent the majority ofmanufacturing costs can be reduced, and the total electricalconversion efficiency can be increased because sunlight isreceived on both faces. Research on bifacial photovoltaicsolar modules has been performed since the 1980s [1–4].
Given the complex manufacturing processes required andthe high-quality silicon substrates needed, as of the presenttime it would not be an exaggeration to say that massproduction of bifacial photovoltaic solar modules is virtu-ally nonexistent. The authors have developed a low-costbifacial photovoltaic cell for mass production. The expec-tation is that lower costs can be realized by making use ofthinner solar-grade CZ-type single-crystal silicon sub-strates, and developing efficient manufacturing processesand vastly reducing the use of materials such as electrodepastes. The bifacial photovoltaic cell developed is an n+pp+ type cell created with a back surface field (BSF) throughboron dispersion on the cell surface at a 125-mm angle. Thebifacial photovoltaic solar module is a flat module thatencloses two transparent protective surfaces (reinforcedwhite glass) over the cell.The bifacial photovoltaic module can generate elec-tricity due to solar light on the front and back side when setup facing south, as is done with an ordinary single-sidedphotovoltaic module. The amount of sunlight striking theback side is only about 10% of the amount of sunlightstriking the front side. Systems that use the bifacial photo-voltaic solar module are not that much better. The authorshave considered a method to set up the bifacial photovoltaicsolar modules vertically. They believe that this will allowfor a solar power generation system with characteristics thatwere previously unavailable, and which can contribute tothe development and spread of solar power generators. Notethat with respect to setting up the bifacial photovoltaic solarmodules vertically, an example of a system which is incor-porated into the sound barriers along a highway that runsnorth–south has been set up in Switzerland as a proof ofconcept.In this paper, the authors report the results of simula-tions for setting up the bifacial photovoltaic solar modulesbeing discussed vertically as well as the results of verifica-tion experiments performed outside. In addition, the results
© 2004 Wiley Periodicals, Inc.
Electrical Engineering in Japan, Vol. 149, No. 3, 2004Translated from Denki Gakkai Ronbunshi, Vol. 123-B, No. 8, August 2003, pp. 947955
32
