Cisco ASR 9000系列汇聚多业务路由器
Cisco ASR 9000系列聚合服务路由器SIP和SPA硬件装配指南说明书
C H A P T E R1-1Cisco ASR 9000 Series Aggregation Services Router SIP and SPA Hardware Installation GuideOL-19944-071Overview: Cisco ASR 9000Series Router SPA Interface ProcessorsThis chapter describes the SPA interface processors (SIPs) that are supported on the Cisco ASR 9000Series Aggregation Services Routers and contains the following sections:•SIP and SPA Compatibility, page 1-1•Router Hardware Installation, page 1-2•SIP Software and Hardware Compatibility, page 1-3•Cisco ASR 9000 SIP-700 Overview, page 1-3SIP and SPA CompatibilityTable 1-1 shows the SPAs that are supported on the CiscoASR 9000Series Aggregation Services Routers and the SIPs that support them:T able 1-1SIP and SPA Compatibility on the Cisco ASR 9000Series RouterSPASIP-7002-Port Channelized OC-12/DS0 SPA X 1-Port Channelized OC48/STM16 DS3 SPA X2-Port OC-48/STM16 SPA X 8-Port OC12/STM4 SPAX 1-Port OC-192/STM-64 POS/RPR SPA X 4-Port OC-3/STM-1 POS SPA X 8-Port OC-3/STM-1 POS SPA X 2-Port and 4-Port Clear Channel T3/E3 SPA X4-Port Channelized T3 to DS0X 8-Port Channelized T1/E1 SPA X 1-Port Channelized OC-3/STM-1 SPA X 1-Port Channelized OC-3 ATM CEoP SPAX1-Port and 3-Port Clear Channel OC-3 ATM SPAXCisco ASR 9000 Series Aggregation Services Router SIP and SPA Hardware Installation GuideOL-19944-07Chapter 1 Overview: Cisco ASR 9000Series Router SPA Interface ProcessorsRouter Hardware InstallationRouter Hardware InstallationFor Cisco ASR 9000Series Router hardware installation and configuration information, refer to the installation and configuration guide for your router. The guide includes information on the router switch fabric and how it affects the operation of SIPs, as well as SIP slot locations, slot width, and other requirements.NoteReferences to line cards in the router hardware installation and configuration guides apply equally to SIPs.Supported PlatformsCisco ASR 9000 SIP-700 SIPs are supported on all Cisco ASR 9000Series Routers.SIP SummarySummary descriptions of all SIPs supported on the Cisco ASR 9000Series Router are shown in Table 1-2.1-Port Clear Channel OC-12 ATM SPA X 2-Port OC-3 STM-1/OC-12 STM-4 POS SPAX 4-Port OC-3 STM-1/OC-12 STM-4 POS SPAX 4-Port OC-48/STM-16 POS-RPR SPA X 2-Port Channelized T3/E3 ATM CEoP SPA X 24-Port Channelized T1/E1/J1 ATM CEoP SPAXT able 1-1SIP and SPA Compatibility on the Cisco ASR 9000Series Router (continued)SPASIP-700T able 1-2SIP SummarySIPProduct Number DescriptionMaximum Number of Each Type of SPA Supported per SIP Cisco ASR 9000 SIP-700A9K-SIP-700A9K-SIP-700-8G 20G SPA Interface Processor, 4GB memory20G SPA Interface Processor, 8GB memory2 single-width, double-height 4 single-width, single-height 11 double-width, double-height2 double-width, single-height1.The OC192 POS SPA is single-width, single-height, however it is “logically” double-width in that it cannot run with another SPA in theadjacent bay, unless the other SPA is shut down.Cisco ASR 9000 Series Aggregation Services Router SIP and SPA Hardware Installation GuideOL-19944-07Chapter 1 Overview: Cisco ASR 9000Series Router SPA Interface ProcessorsCisco ASR 9000 SIP-700 OverviewSIP Software and Hardware CompatibilityFor software configuration information, refer to the Cisco IOS XR software configuration and command reference publications for the installed Cisco IOS XR release. Also refer to the Cisco IOS XR software release notes for additional information. Table 1-3 lists the Cisco IOS XR releases that are compatible with supported SIPs.To ensure compatibility with the software, your SIPs should have a specific hardware revision number. The number is printed on a label affixed to the component side of the card. The hardware revision number can be displayed by using the show diag rack/slot/CPU0 command. Table 1-3 lists the hardware revision number for all supported SIPs.The show version command shows the system software version that is currently loaded and running. The show platform or show diag commands display the current hardware configuration of the router, including the ROMMON system software version that is currently loaded and running. For complete descriptions of show commands, refer to the Cisco IOS XR Configuration Fundamentals Configuration Guide and the Cisco IOS XR Configuration Fundamentals Command Reference for the installed Cisco IOS XR release.Cisco ASR 9000 SIP-700 OverviewThere are two types of Cisco ASR 9000 SIP-700 available; A9K-SIP-700 and A9K-SIP-700-8G.•A9K-SIP-700 supports 4GB of memory.•A9K-SIP-700-8G supports 8GB of memory.Both types of Cisco ASR 9000 SIP-700 are identical in appearance and can be identified by the PID located on the faceplate of the SIP.The following sections describe the Cisco ASR 9000 SIP-700:•Cisco ASR 9000 SIP-700 Board Components, page 1-4 •Cisco ASR 9000 SIP-700 LED, page 1-4•Cisco ASR 9000 SIP-700 Physical Specifications, page 1-5 •SPA Subslot Numbering on the Cisco ASR 9000 SIP-700, page 1-5 •SPA Interface Addresses on the Cisco ASR 9000 SIP-700, page 1-6T able 1-3SIP Hardware and Software CompatibilitySIP Part NumberMinimum Cisco IOS XR Software Release Minimum Hardware Revision Cisco ASR 9000 SIP-700A9K-SIP-700 3.91.0Cisco ASR 9000 SIP-700A9K-SIP-700-8G 4.3.1 1.01-4Cisco ASR 9000 Series Aggregation Services Router SIP and SPA Hardware Installation GuideOL-19944-07Chapter 1 Overview: Cisco ASR 9000Series Router SPA Interface ProcessorsCisco ASR 9000 SIP-700 OverviewChapter1 Overview: Cisco ASR9000Series Router SPA Interface ProcessorsCisco ASR 9000 SIP-700 OverviewThe Cisco ASR 9000 SIP-700 LED is described in Table1-4.T able1-4Cisco ASR 9000 SIP-700 LEDLED Label Color State MeaningStatus Amber On SIP is powered and IOS-XR is loading.Green On SIP is active.N/A Off SIP is not installed correctly or is not powered. Cisco ASR 9000 SIP-700 Physical SpecificationsThe Cisco ASR 9000 SIP-700physical specifications are shown in the following table.T able1-5Cisco ASR 9000 SIP-700 Physical SpecificationsDescription SpecificationsPhysical dimensions Occupies one line card slot on a Cisco ASR 9000 Series AggregationServices RouterShipping weight10kg (22 lbs)Operating temperature32 to 104°F (0 to 40°C)Relative humidity10 to 90 percent, noncondensingStorage temperature–4 to 149°F (–20 to 65°C)SPA Subslot Numbering on the Cisco ASR 9000 SIP-700The Cisco ASR 9000 SIP-700 supports up to 2 single-width, double-height SPAs, up to 4 single-width,single-height SPAs, or up to 2 double-width, single-height SPAs. The Cisco ASR 9000 SIP-700 does notsupport double-width, double-height SPAs.Note that while the OC192 POS SPA is single-width,single-height, it is “logically” double-width in that it cannot run with another SPA in the adjacent bay,unless the other SPA is shut down.Bay 2 (Top Left)Bay 0 (Top Right)Bay 3 (Bottom Left)Bay 1 (Bottom Right)Figure1-3 shows a Cisco ASR 9000 SIP-700 with 2 SPAs installed. The left SPA slot is subslot 0 andthe right SPA slot is subslot 1.Cisco ASR 9000 Series Aggregation Services Router SIP and SPA Hardware Installation Guide OL-19944-071-6Cisco ASR 9000 Series Aggregation Services Router SIP and SPA Hardware Installation GuideOL-19944-07Chapter 1 Overview: Cisco ASR 9000Series Router SPA Interface ProcessorsCisco ASR 9000 SIP-700 Overview1-7Cisco ASR 9000 Series Aggregation Services Router SIP and SPA Hardware Installation GuideOL-19944-07Chapter 1 Overview: Cisco ASR 9000Series Router SPA Interface ProcessorsCisco ASR 9000 SIP-700 Overview1-8Cisco ASR 9000 Series Aggregation Services Router SIP and SPA Hardware Installation GuideOL-19944-07Chapter 1 Overview: Cisco ASR 9000Series Router SPA Interface ProcessorsCisco ASR 9000 SIP-700 Overview。
cisco产品介绍
目录
Cisco集成多业务路由器
WAN汇聚服务路由器 服务供应商级路由器
3900系列集成多业务路由器
Cisco 3900 系列为从小型企业办公室到大型 企业办公室的灵活网络部署提供出色的性能 和灵活性，同时均提供行业领先的投资保护。
优势
服务集成 按需服务 高性能集成服务 网络灵活性 节能 投资保护
端口
Cisco2900系列多业务路由器
所有 Cisco 2900 系列集成多业务路由器均提 供嵌入式硬件加密加速、支持语音和视频的 数字信号处理器 (DSP) 插槽、可选防火墙、 入侵预防、呼叫处理、语音信箱以及应用程 序服务。
优势
服务集成 按需服务 高性能的集成服务 网络灵活性 节能 投资保护
高性能交换－－支持高速介质和高密度配置；通过其基于 RISC和SRAM配置的系统处理器，Cisco 7200每秒可以交 换30万个信息包。 全面的Cisco IOS软件支持和高性能网络服务增强－－高速 执行服务质量、安全、压缩和加密等网络服务。 高密度端口－－提供高密度端口以及广泛的局域网和广域网 介质，大大降低了每端口成本，并允许灵活地进行配置。 公用端口适配器－－利用和Cisco 7200通用接口处理器 （VIP）相同的端口适配器，简化了备件存储，并提供接口 投资保护。
思科 Aironet 2600 系列无线接入点
思科 Aironet 2600 系列无线接入点在设计时考虑到 了快速发展的移动性需求，可帮助确保一种无干扰、 高速无线应用体验。基于 802.11n 标准，它包括 3x4 多输入多输出 (MIMO) 技术和三空间流，加上 思科 CleanAir、ClientLink 2.0 和 VideoStream。 新的无线接入点与竞争解决方案相比，速度更快， 距离无线接入点更远，从而提高了 450 Mbps 数据 速率的可靠性。2600 系列已经为消费电子设备进行 过优化，还可加速客户端连接，并且与竞争解决方 案相比，移动设备电池功耗更低。
ASR9000以太网线路卡-TR和-SE对照表和常见错误消息-Cisco
目录
简介 先决条件 要求 使用的组件 背景信息
台风，基于的印第安战斧- TR和- SE线卡资源对照表 ASR 9001内置的端口 优化的信息包传输(- TR)线卡普通的QoS错误消息
简介
本文描述以太网线路卡之间的主要一般差异(- TR和- SE)在9000系列Cisco聚合服务的路由器 (ASR)。
台风，基于的印第安战斧- TR和- SE线卡资源对照表
功能
信息包传输(TR)优化 服务边缘(SE)优化
队列总数
8每个端口
256,000/NP
策略
8000/NP
256,000/NP
以太网流点(EFPs) 16,000
64,000
FIB Routes(v4/v6) 4M/2M
4M/2M
MAC 地址
2M
2M
优化的信息包传输(- TR)线卡支持仅每个端口8个队列(请考虑此，如果使用sub-interface)。如果在 端口配置的队列数量超出7个队列+类别默认值队列那么Next错误信息被看到：
RP/0/RSP0/CPU0:ASR9000(config-if)#service-policy output 9Queues RP/0/RSP0/CPU0:ASR9000(config-pmap)#commit
前缀- TR和- SE用于台风和印第安战斧基于线卡。这些前缀代表：
SE -服务渐近优化 TR -优化的信息包传输
例如在台风和印第安战斧线卡中有同一种线卡的变形， ：
台风
A9K-MOD80-SE A9K-MOD80-TR
印第安战斧
A9K-8X100G-LB-SE A9K-8X100G-LB-TR
思科Cisco ASR 1000 系列聚合服务路由器 产品手册
产品手册Cisco ASR 1000 系列聚合服务路由器思科正在凭借Cisco®ASR 1000 系列聚合服务路由器重塑边缘路由技术。
该系列路由器是中端路由器产品组合，打造出全新的性价比产品等级，令服务提供商和企业均从中受益：●对于服务提供商，Cisco ASR 1000 系列路由器帮助其更灵活、高效和经济地为消费者和企业提供综合服务。
●对于企业，Cisco ASR 1000 系列路由器提供高可靠性和高性能的广域网边缘解决方案，将信息、通信、协作和商务融合在一起。
Cisco ASR 1000 系列路由器：●通过优化的智能服务提供出色的性能和高度可用性，从而提升服务。
●在企业高级路由、服务提供商边缘和宽带汇聚领域设立了全新的性价比产品基准。
●促进安全广域网聚合、托管客户端 (CPE) 服务和服务提供商边缘服务等领域中网络架构的重大创新。
●通过在相同的架构或运营环境下实现管理或托管服务来降低运营费用 (OpEx) 和资本支出 (CapEx)产品概述Cisco ASR 1000 系列分为以下不同版本（图 1）：Cisco ASR 1001 路由器、Cisco ASR 1002 固定式路由器、Cisco ASR 1002 路由器、Cisco ASR 1002 路由器、Cisco ASR 1004 路由器和 Cisco ASR 1006 路由器所有型号全部采用功能强大的创新 Cisco QuantumFlow 处理器，该处理器在网络处理器性能和恢复能力方面实现了巨大飞跃。
图 1. Cisco ASR 1000 系列聚合服务路由器与前几代的思科中端路由解决方案相比，Cisco ASR 1000 系列将服务运行性能提高了10 倍以上，从而显著提升了价值此外，该系列路由器具有硬件和软件冗余功能，并采用行业领先的低间断设计。
Cisco ASR 1000 系列提供多种嵌入在Cisco QuantumFlow 处理器中的服务，性能从2.5 Gbps 直至100 Gbps Cisco QuantumFlow 处理器支持的服务包括安全服务（例如，加密和防火墙）、服务质量(QoS)、网络应用识别(NBAR)、Cisco IOS®Flexible Packet Matching (FPM)、宽带聚合和思科统一边界要素(Cisco Unified Border Element)（SP 版）（之前称为会话边界控制或 SBC）等等。
CISCO ASR9k简介
交换矩阵-控制平面
福建富士通信息软件有限公司（ 福建富士通信息软件有限公司（FFCS） ）
Fujian Fujitsu Communication Software Co., Ltd. 12
All Rights Reserved, Copyright ©FFCS 2007
传统主播复制技术
LC2
T0
系统架构
福建富士通信息软件有限公司（ 福建富士通信息软件有限公司（FFCS） ）
Fujian Fujitsu Communication Software Co., Ltd. 8
All Rights Reserved, Copyright ©FFCS 2007
80G线卡架构
福建富士通信息软件有限公司（ 福建富士通信息软件有限公司（FFCS） ）
LC2
3 Bridge FPGA Replication
replicate packet to NPU based on MGID
T0
4 NPU Replication
B0
T1
T0
Multicast Source
LC1
replicate packet to egress port
Fabric Fabric Interface
B0
T1
Fabric Interface
T0
Multicast Source
LC1
B0
T1 T2 T3
B1
T2 T3
Fabric Interface Switch Fabric Fabric Interface
13
B1
LC3
IGMP joins
T0
B0
T1
Cisco ASR 1000系列聚合服务路由器系列产品介绍说明书
Cisco ASR1009-X Router and Cisco ASR1006-XRouter OverviewThis chapter contains the following topics:•Overview,on page1•Cisco ASR1009-X Router,on page1•Cisco ASR1006-X Router,on page4•Field-Replaceable Units for the Cisco ASR1009-X Router and Cisco ASR1006-X Router,on page6•Cisco Product Identification Standard,on page7•Serial Number and PID/VID Label Location,on page9OverviewThe Cisco ASR1000Series Aggregation Services Routers are mid-range edge routers that establish a newprice-to-performance class offering benefits to both enterprise and service providers alike.The Cisco ASR1000Series Aggregation Services Routers portfolio is based on an innovative custom-built ASIC calledQuantum Flow Processor that aggregates services at scale.The Cisco ASR1006-X Router and Cisco ASR1009-X Router create a future-proof modular routing platformto support next generation Forwarding and Route Processor modules with hardware redundancy.The CiscoASR1006-X Router and Cisco ASR1009-X Router provide up to200Gbps slot bandwidth to enable new highdensity Ethernet linecards utilizing the ASR1000-MIP100and Ethernet Port Adapters(EPAs),and integratingN+1power-on-demand design to the ASR1000portfolio.Cisco ASR1009-X RouterHardware Features of the Cisco ASR1009-X RouterThe Cisco ASR1009-X Router supports:•9Rack Units and3-line card slot chassis with redundant slots for forwarding and route processor boards•ASR1000-RP2module,future next generation ASR1000-RP3module,and ASR1000-ESP200,ASR1000-ESP100,and ASR1000-ESP40enginesFor information about the Cisco ASR1000-RP3module,see the Cisco ASR 1000Route Processor 3Installation and Configuration Guide .Note•Provides investment protection to support existing forwarding processor (ESP40,ESP100,and ESP200)•Provides future proof to support future next generation forwarding processor •100Gbps high density,modular Ethernet linecards (ASR1000MIP-100)•Three linecard slots support any of the following combinations:•ASR1000-SIP40with SPA•Ethernet linecard (ASR1000-6TGE and ASR1000-2T+20x1GE)•ASR1000-MIP100with EPA•New common fan modules to provide up to 30%better cooling for the chassis.Three fan modules per chassis•New power supplies are introduced for the chassis to provide greater power•Power-on-demand design with N+1power redundancy to meet any current and future power demand •Up to six AC or six DC power supplies that are aligned along the bottom of the chassis (power shelf)Cisco ASR 1009-X Overall Chassis Front ViewThe following figure shows the front of the Cisco ASR 1009-X Router.Cisco ASR 1009-X Router and Cisco ASR 1006-X Router OverviewCisco ASR 1009-X Overall Chassis Front ViewFigure 1:Cisco ASR 1009-X Router FrontViewSlot F06Slot F11Slot R07Slot R12Standby/ON switch 8Slot 23DB-25Alarm connector9Slot 14Power shelf that has power supplies from P0to P510Slot 05The Cisco ASR1009-X Router can support up to six AC or six DC power supplies.The chassis does not support mixed AC and DC configurationNoteCisco ASR 1009-X Chassis Rear ViewThe following figure shows the rear of the Cisco ASR 1009-X chassis with three fan modules and associated LEDs.Cisco ASR 1009-X Router and Cisco ASR 1006-X Router OverviewCisco ASR 1009-X Chassis Rear ViewFigure 2:Cisco ASR 1009-X Router RearViewFan Module 74Fan Module 8Status LED 1Fan Module 6Status LED 5Fan Module 82Fan Module 66Fan Module 7Status LED3The FAN OK LED can have three colors:Green,Red,and Amber.Green indicates Good,Red indicates Failed,and Amber indicates a Warning condition,when one or more fans may be operating at less than the expected speed,but not slow enough to call it a failure.NoteSee the Cisco ASR 1009-X Router and Cisco ASR 1006-X Router Power Supply LEDs section for more details.Cisco ASR 1006-X RouterHardware Features of the Cisco ASR 1006-X RouterThe Cisco ASR 1006-X Router supports:•6Rack Units and 2-line card slot chassis with redundant slots for forwarding and route processor boards •ASR1000-RP2module,future next generation ASR1000-RP3module,and ASR1000-ESP40and ASR1000-ESP100engines.For information about the Cisco ASR1000-RP3module,see the Cisco ASR 1000Route Processor 3Installation and Configuration Guide .Note•Provides investment protection to support existing forwarding processor (ESP40and ESP100)Cisco ASR 1009-X Router and Cisco ASR 1006-X Router OverviewCisco ASR 1006-X Router•Provides future proof to support future next generation forwarding processor.•100Gbps high density,modular Ethernet linecards (ASR1000-MIP100)•Two linecard slots support any of the following combinations:•ASR1000-SIP40with SPA•Ethernet linecard (ASR1000-6TGE and ASR1000-2T+20x1GE)•ASR1000-MIP100with EPA•New common fan modules to provide up to 30%better cooling for the chassis.Two fan modules per chassis.•New power supplies are introduced for the chassis to provide greater power•Power-on-demand design with N+1power redundancy to meet any current and future power demand.•Up to six AC or six DC power supplies that are aligned along the bottom of the chassis (power shelf)Cisco ASR 1006-X Overall Chassis Front ViewThe following figure shows the front of the Cisco ASR 1006-X Router.Figure 3:Cisco ASR 1006-X Router FrontViewSlot R06Slot F11Standby/ON switch 7Slot R12DB-25Alarm Connector8Slot 13Power shelf that has power supplies from P0to P59Slot 04Cisco ASR 1009-X Router and Cisco ASR 1006-X Router OverviewCisco ASR 1006-X Overall Chassis Front ViewSlot F05The Cisco ASR 1006-X Router can support up to six AC or six DC power supplies.The chassis does not support mixed AC and DC configuration.NoteCisco ASR 1006-X Chassis Rear ViewThe following figure shows the rear of the Cisco ASR 1006-X Router with two fan modules and associated LEDs.Figure 4:Cisco ASR 1006-X Router RearViewFan Module 6Status LED 3Fan Module 7Status LED 1Fan Module 64Fan Module 72The FAN OK LED can have three colors:Green,Red,and Amber.Green indicates Good,Red indicates Failed,and Amber indicates a Warning condition,when one or more fans may be operating at less than the expected speed,but not slow enough to call it a failure.NoteSee the Cisco ASR 1009-X Router and Cisco ASR 1006-X Router Power Supply LEDs section for more details.Field-Replaceable Units for the Cisco ASR 1009-X Router and Cisco ASR 1006-X RouterThe Cisco ASR 1009-X Router and Cisco ASR 1006-X Router has a number of FRUs.These include:•Route Processors •Forwarding ProcessorsCisco ASR 1009-X Router and Cisco ASR 1006-X Router OverviewCisco ASR 1006-X Chassis Rear View•Line Cards •SPAs •EPAs•AC and DC power supplies •FanmodulesFor information about the Cisco ASR1000-RP3module,see Cisco ASR 1000Route Processor 3Installation and Configuration Guide .NoteCisco Product Identification StandardThis section describes the Cisco products and services product identification standard.This feature provides you with the ability to effectively integrate and manage Cisco products in your network and business operations.Unique Device IdentifierThe Unique Device Identifier (UDI)is the Cisco product identification standard for hardware products.A product identification standard removes barriers to enterprise automation and can help you reduce operating expenses.The UDI provides a consistent electronic,physical,and associated business-to-business information product identification standard.The UDI is a combination of five data elements.The following table lists the UDI elements.Table 1:UDI ElementsDescriptionPhysical Visibility Electronic Visibility UDI Data Element Product ID,also known as product name,model name,product number YesYesPIDVersion IDYes Yes VID Serial number,the unique instance of the PID Yes Yes SN Type,such as chassis,slot,or power supply __Yes Entity Name Additional product information__YesProduct DescriptionThe combination of serial number and product ID (PID)is unique and consistent across all Cisco products.The PID that is coded on hardware is called a base product identifier.Cisco ASR 1009-X Router and Cisco ASR 1006-X Router OverviewCisco Product Identification StandardCisco ASR1009-X Router and Cisco ASR1006-X Router Overview Unique Device IdentifierAdditional orderable PIDs can be associated to a base PID.For instance,an orderable PID may describe apackaging configuration for a product or a bundled group of products sold,tested,and shipped together.Specific unique device identifier(UDI)benefits include the following:•Identifies:•Individual Cisco products in your networks•PIDs and serial numbers for service and replaceable products•Version IDs(VIDs)for product version visibility•Facilitates discovery of products subject to recall or upgrade•Enhances inventory automation of Cisco productsThe Cisco product identification standard provides the following features:•Version visibility—Cisco continuously improves products through feature additions.Product changesare indicated by incrementing the VID,which provides version visibility to help you understand andmanage product changes.VID management ensures consistency of changes from product to product.•Operating expense reduction—Cisco UDIs provide accurate and detailed network inventory information;identifying each Cisco product in a network element through a standard interface.Cisco operating systemscan view and use this data,allowing you to automate your electronic inventory.•Consistency across product layers—The UDIs are embedded in the hardware products and cannot beoverwritten.Operating and management systems discover UDIs through standard interfaces and displayUDIs in standard outputs.Standard interfaces include the IETF standard ENTITY-MIB.The show diag chassis eeprom detail command displays the PID,VID,PCB serial number,hardware revision,and other such information.The following is sample output from the show diag chassis eeprom detail command:ASR1009-X-2#show diag chassis eeprom detailMIDPLANE EEPROM data:EEPROM version:4Compatible Type:0xFFController Type:3172Hardware Revision:0.2PCB Part Number:73-16095-02Board Revision:01Deviation Number:0-0Fab Version:01PCB Serial Number:FXS1842043HRMA Test History:00RMA Number:0-0-0-0RMA History:00Top Assy.Part Number:68-5423-01CLEI Code:SAMPL00XYZProduct Identifier(PID):ASR1009-XVersion Identifier(VID):V00Chassis MAC Address:0c09.2a0f.0000MAC Address block size:320Chassis Serial Number:FXS1845Q1QTAsset ID:Vendor ID:00Environment Monitor Data:000800F8Environment Monitor Data :0411DF 000CASR1006-X-1#sho diag chassis eeprom detail MIDPLANE EEPROM data:EEPROM version :4Compatible Type :0xFF Controller Type :3171Hardware Revision :0.2PCB Part Number :73-16102-03Board Revision :01Deviation Number :0-0Fab Version:01PCB Serial Number :FXS1842046Z RMA Test History :00RMA Number :0-0-0-0RMA History:00Top Assy.Part Number :68-5481-01CLEI Code:SAMPL00XYZ Product Identifier (PID):ASR1006-X Version Identifier (VID):V00Chassis MAC Address :0c06.2a0e.0000MAC Address block size :256Chassis Serial Number :FXS1846Q415Asset ID :Vendor ID:00Environment Monitor Data :000800F8Environment Monitor Data:040F BE 002FCommon Language Equipment Identification (CLEI)code is a ten-digit character code that identifies a specific product.A CLEI code is applied to each part within a Cisco ASR 1009-X Router or Cisco ASR 1006-X Router as they are programmed in manufacturing for shipment to customers.NoteFor complete information on the product identification standard,see /go/udi/.Note Serial Number and PID/VID Label LocationThe following figure shows a Cisco ASR 1009-X Router along with the location of the serial number and the PID/VID label.Cisco ASR 1009-X Router and Cisco ASR 1006-X Router OverviewSerial Number and PID/VID Label LocationFigure 5:Cisco ASR 1009-X Router Serial Number and PID/VID LabelLocationThe following figure shows a Cisco ASR 1006-X Router along with the location of the serial number and the PID/VID label.Cisco ASR 1009-X Router and Cisco ASR 1006-X Router OverviewSerial Number and PID/VID Label LocationFigure 6:Cisco ASR 1006-X Router Serial Number and PID/VID LabelLocation1009-X 1006-X 11Cisco ASR 1009-X Router and Cisco ASR 1006-X Router OverviewSerial Number and PID/VID Label Location1009-X1006-X 12Cisco ASR1009-X Router and Cisco ASR1006-X Router OverviewSerial Number and PID/VID Label Location。
ASR9000
Data SheetCisco ASR 9000 Series Aggregation Services RoutersProduct OverviewThe Cisco® ASR 9000 Series represent an exciting new paradigm in the world of Carrier Ethernet transport with exceptional scalability, carrier-class reliability, environmentally conscious design, incredible flexibility, and an enticing new price-to-performance benchmark. It is Carrier Ethernet evolution, redefined.The Cisco ASR 9000 Series has two form factors (Figure 1): the Cisco ASR 9010 Router and the Cisco ASR 9006 Router. Cisco ASR 9000 Series Routers are designed to provide true carrier-class reliability using the Cisco IOS® XR operating system, comprehensive system redundancy, and a full complement of network resiliency schemes. The Cisco ASR 9000 Series also offers service and application-level intelligence focused on optimized video delivery and mobile aggregation. Finally, the Cisco ASR 9000 Series is designed to simplify and enhance the operational and deployment aspects of service-delivery networks.Figure 1. Cisco ASR 9000 SeriesThe Cisco ASR 9000 Series is an operationally simple, future-optimized platform utilizing next-generation hardware and software. Some highlights of this next-generation platform are:●Cisco IOS XR modular operating system: The Cisco ASR 9000 Series leverages Cisco IOS XR operating systemmade famous by the highly successful Cisco CRS Carrier Routing System platform in core deployments. Cisco IOS XR operating system is purpose-built for distributed systems such as the Cisco ASR 9000 Series and uses a microkernel architecture to achieve true modularity. This modularity provides the path to nonstop operationsduring software image upgrades or module changes, without affecting normal platform operations.●Fully distributed system: “The Cisco ASR 9000 Series operates in a fully distributed fashion, that is, allpacket-forwarding decisions and actions take place on the individual line cards. These high-density Ethernet line- cards are equipped with a specialized network processor that provides a flexible programminginfrastructure with high-density Hierarchical Quality-of-Service (H-QoS) services, security, and integratedSynchronous Ethernet. The distributed nature of the Cisco ASR 9000 Series improves resiliency by adding a new dimension in scale for features such as Bidirectional Forwarding Detection (BFD) and EthernetOperations, Administration, and Maintenance (E-OAM).”●Operationally efficient and redundant hardware: The Cisco ASR 9000 Series provides an infrastructure whereall common components, Route Switch Processors (RSPs), switching fabric, fans, and power supplies, are completely redundant. In addition, the platform is designed such that power is used on an as-needed basis depending on system requirements. Power has been modularized for a true pay-as-you-grow approachreducing capital expenditures (CapEx) and again providing an operationally efficient deployment. The Cisco ASR 9000 also provides a space-optimized small-platform option which uses the Series’ commoncomponents and retains a central office deployment-ready capability using a patent pending side-to-backairflow design.●Environmentally conscious design: In today’s world of increasing awareness of human impact on theenvironment and the resultant fiscal implications, Cisco ASR 9000 Series Routers bring a fresh new“conscious” approach to product development. From optimal thermal design to the architecture of the power infrastructure, from the placement of line card components to the pitch of each slot, every design aspect had one goal in mind – reduced environmental impact through lowered power consumption and decreasedcooling requirement. Even the product packaging process was evaluated to minimize the use of packaging material and thereby reduce waste at customer locations. The Cisco ASR 9000 Series is an example of the continued Cisco commitment to efficient and future-friendly product design.The Cisco ASR 9000 Series offers a significant value-add compared to the prior generations of Carrier Ethernet routing offerings by more than doubling the switching capacity (up to 400 Gbps per line-card slot), optimizing power and cooling requirements, offering an innovative modular power architecture, incorporating a grounds-up High Availability design, and taking advantage of the Cisco IOS XR modular operating system to significantly lower the Total Cost of Ownership (TCO) for Service Providers the world over.Solving the Challenges of Tomorrow, TodayThe Cisco ASR 9000 Series is built upon the premise of addressing the challenges that service providers face when deploying current networks and planning for the networks of tomorrow.●Power-efficient deployments: The Cisco ASR 9000 Series has a significantly improved energy efficient designthanks to its low Gbps/Watt ratio. This amazing breakthrough ultimately translates to lower power costs, lower carbon footprint, and the ability to serve more customers and deliver more services in less rack space.●Increasing average revenue per user (ARPU): Service providers may increase the price models of existingservices or increase the service offerings per user. While traditional service prices continue to decline, the Cisco ASR 9000 Series helps establish a new financial reality by facilitating reliable and scalable video, next-generation mobile aggregation, and advanced Carrier Ethernet service offerings.●Managing services efficiently: The Cisco ASR 9000 Series provides leading-edge network, device, andservice management through a full complement of management solutions. Cisco Active Network Abstraction (ANA) provides a framework for service activation provisioning, assurance, and management. Combiningthese elements with a comprehensive set of Ethernet and Multiprotocol Label Switching (MPLS) OAMcapabilities, the Cisco ASR 9000 provides an operator-friendly environment.●Network convergence: A common objective among service providers is to migrate their networks to a single,converged infrastructure that supports all services. This goal is compelling because it ultimately results in lessCapEx and operating expenses (OpEx) because of a reduction in network elements. The Cisco ASR 9000 isa critical component in optimizing service transport infrastructure because of its service flexibility, rich featureset, wide interface capability and seamless integration of Carrier Ethernet and WAN interfaces as thefoundation for services delivery. The Cisco ASR 9000 Series provides a powerful single solution to theproviders’ Multi Service Edge (MSE), Ethernet optimized MSE (E-MSE) and Carrier Ethernet (CE) needs.●Meeting tomorrow’s service requirements: Designed into the Cisco ASR 9000 are critical capabilities enablingthe services of tomorrow. Providing increased bandwidth capabilities for network devices at economicallyviable prices is one of the primary criteria for true carrier transport platforms. The Cisco ASR 9000 can scale up to 400 Gbps per slot and up to 6.4 Tbps per system, providing the ideal foundation for a full suite of next-generation services. Another crucial component for true network and service convergence is the integration of service intelligence in network elements. The Cisco ASR 9000 has been designed to offer advancedsubscriber management as well as use the QuantumFlow Processor to deliver silicon-based security services and video. Video being the “voice” of tomorrow, the Cisco ASR 9000 offers integrated video-on-demand(VoD) streaming and caching, inline video quality monitoring, accelerated fast channel change, and real-time video error correction.HardwareThe Cisco ASR 9000 Series provides an in-place upgrade roadmap to a switching capacity of up to 400 Gbps per slot without the need for a complete chassis replacement. This game changing ball is set rolling with a set of high density GE and 10GE Ethernet Services line cards utilizing versatile network processors to support an array of Carrier Ethernet applications. These Line-Cards, offered in base and extended-scale configurations, are complemented by the non-blocking fabric on the Route Switch Processor (RSP) and the future ready Back-Plane (BP), thermal and power infrastructure on the chassis.The modular power architecture of Cisco ASR 9000 Series (available in both AC and DC versions) is powered by three different power supplies: 3-kW AC, 2-kW DC, and 1.5-kW DC. The power supplies are housed in field-serviceable Power Entry Modules (PEMs), which come in the AC and DC forms. Each PEM can hold up to 3 modules – of its corresponding type – with no power zones or placement restrictions (mixing of AC and DC supplies is not supported). Service Providers can add more power as their bandwidth and feature requirements increase over time, requiring addition of more line-cards to the chassis. This capability translates to lower CapEx initially and optimal OpEx over the product life.The Cisco ASR 9000 Series also features a fully integrated timing infrastructure, allowing the routers to take in timing inputs (Synchronous Ethernet, Building Integrated Timing Supply [BITS], Data Over Cable Service Interface Specification [DOCSIS] Timing Interface [DTI] etc.) and distribute them over the backplane to each slot. This capability allows rich support for transparent mobile convergence; mobile Radio Access Network (RAN) backhaul; and Time-Division Multiplexing (TDM) circuit emulation, without sacrificing performance or scale.The optimized thermal infrastructure of the Cisco ASR 9000 Series is designed to be scalable to support the future capacity requirements. Variable-speed high-efficiency fans provide reduced power requirements under normal operating environments while retaining capability to cool current and future line cards under extreme conditions.Table 1 lists the chassis hardware available for the Cisco ASR 9000 SeriesTable 1. Hardware Available for Cisco ASR 9000 SeriesProduct Description Product NumberCisco ASR 9000 Series ChassisCisco ASR 9010 chassis ASR-9010-ACASR-9010-DCCisco ASR 9006 chassis ASR-9006-ACASR-9010-DCCisco ASR 9000 Series Power InfrastructureAC, power supply, 3000 Watts A9K-3KW-ACDC, power supply, 2100 Watts A9K-2KW-DCDC, power supply, 1500 Watts A9K-1.5KW-DCCisco ASR 9000 Series Thermal InfrastructureCisco ASR 9010 fan, 2 fan-trays per chassis ASR-9010-FANCisco ASR 9006 fan, 2 fan-trays per chassis ASR-9006-FANCisco ASR 9010 fan filter, 1 per chassis ASR-9010-FILTERCisco ASR 9006 fan filter, 1 per chassis ASR-9006-FILTERMore details about the individual Cisco ASR 9000 Series components, such as the RSPs, the Ethernet line cards, the SPA Interface Processor (SIP) and Shared Port Adapter (SPA) are available in the respective data sheets:●Cisco ASR 9000 Series Route Switch Processor●Cisco ASR 9000 Series Ethernet Line Cards●Cisco ASR 9000 Series SPA Interface Processor 700SoftwareThe Cisco ASR 9000 Series Router delivers exceptional scale, service flexibility, and high availability into Carrier Ethernet transport networks. It is powered by Cisco IOS XR Software – an innovative self-healing, distributed operating system designed for always-on operation while scaling system capacity up to 6.4 Tbps. This is the same operating system that powers industry-leading routers such as the Cisco CRS Carrier Routing System – bringing the same reliability, scalability, performance, and feature richness to the world of Carrier Ethernet that has made the Cisco CRS the dominant entity in the Service Provider core. It also allows for an end-to-end IP/MPLS solution to Service Provider requirements based on the same software, thereby reducing the operational complexity of managing multiple operating systems. Cisco IOS XR Software Release 3.7.2 introduced support for the Cisco ASR 9000 Series Router, which is designed to address the Carrier Ethernet foundation for visual networking. The Cisco ASR 9000 further enhances the IP Next-Generation Network (NGN) Carrier Ethernet design for converged, resilient, intelligent, and scalable services transport of consumer, business, wholesale, and mobile services.Cisco ASR 9000 Series Carrier Ethernet applications include Business services such as Layer 2 VPN (L2VPN) and L3VPN, IPTV, Content Delivey Networks (CDNs), and Mobile Backhaul transport networks. Features supported include Ethernet Services; L2VPN; IPv4, IPv6, and L3VPN; Layer 2 and Layer 3 Multicast; IPoDWDM, Synchronous Ethernet (SyncE), Ethernet OA&M/Multiprotocol Label Switching (MPLS) OA&M, Layer 2 and Layer 3 access control lists (ACLs), H-QoS, MPLS Traffic Engineering Fast Reroute (MPLS TE-FRR), Multi-chassis LAG (MC-LAG), Integrated Routing and Bridging (IRB) and Nonstop Forwarding/Nonstop Routing (NSF/NSR).Cisco IOS XR Software Releases 4.0.0 and 4.0.1 introduce the support for a comprehensive portfolio of shared port adaptors (SPAs) to facilitate the multiservice edge (MSE) and Ethernet MSE (E-MSE) capability on the Cisco ASR 9000 Series. The Cisco ASR 9000 Series MSE and E-MSE capabilities allow enterprises to offer powerful business VPN services with strong SLA (service-level agreement) enforcement. Such services typically require simultaneousscale increases across multiple dimensions, for example, the number of Virtual Route Forwarding (VRF) interfaces, IPv4 and IPv6 route scaling, Bidirectional Forwarding Detection (BFD) sessions and instances of Border Gateway Protocol (BGP) Non-Stop Routing (NSR) interfaces. A Cisco ASR 9000 Series system configuration requiring high multiple dimensional scale requires the A9K-RSP-8G to support the increased system scale.Table 2 provides a snapshot of the software features the Cisco ASR 9000 Series offers. For complete details please refer to the product bulletin.Table 2. Software Feature HighlightsFeaturesCisco IOS XR Software●Modular software design●OS infrastructure protection●Process and thread protection●In Service Software Upgrade (ISSU)●Process restart●State checkpointEthernet Services●Ethernet Virtual Connections (EVCs)●Flexible VLAN classification●Flexible VLAN translation●IEEE bridging●IEEE 802.1s Multiple Spanning Tree (MST)●MST Access Gateway●L2VPN◦Virtual Private LAN Services (VPLS), Hierarchical VPLS (H-VPLS) ,Virtual Private Wire Service (VPWS), Ethernet over MPLS (EoMPLS), pseudowire redundancy, and multisegment pseudowire stitchingLayer 3 Services●Layer 3 Routing◦IPv4 Routing (Border Gateway Protocol [BGP], Intermediate System-to-Intermediate System [IS-IS], and Open Shortest Path First [OSPF]), Route Policy Language (RPL), Hot Standby Router Protocol (HSRP), Virtual Router Redundancy Protocol (VRRP), IPv6 Routing, and BGP Prefix Independent Convergence (PIC)●MPLS◦Label Distribution Protocol (LDP), Targeted LDP (T-LDP), Resource Reservation Protocol (RSVP), Differentiated Services (DiffServ)-aware traffic engineering, MPLS L3VPN (including Carrier Supporting Carrier [CSC]), IPv6 Provider Edge and IPv6 VPN to Provider Edge◦MPLS Traffic Engineering (including TE-FRR)◦MPLS TE Preferred PathMultiservice Edge (MSE) and Ethernet MSE (E-MSE)●Packet Over SONET and Packet Over Synchronous Digital Hierarchy (SDH)●Non-Ethernet interface support up to OC192/STM64●Frame Relay, Point-to-Point Protocol (PPP), High-Level Data Link Control (HDLC),●Frame Relay Fragmentation.16 (FRF.16) Multilink Frame Relay (MLFR), Multilink Point-to-Point Protocol (MLPPP), Link Fragment Interleaving,FRF.12●Any Transport over MPLS (AToM)●Internet Protocol header Compression (IPHC)●Link Noise Monitoring (LNM)●System granularity scales down to nxDS0●Full NetflowQoS●More than 3 million queues per system●Class-Based Weighted Fair Queuing (CBWFQ)●Weighted Random Early Detection (WRED)●Priority Queuing with propagation●2-rate 3-color (2R3C) Policing●Modular QoS CLI (MQC)●4-level H-QoS●In-Service ModificationFeaturesMulticast●IPv4 Multicast◦Source-based and shared distribution trees, Protocol Independent Multicast sparse mode (PIM-SM),, PIM Source Specific Multicast (PIM SSM), Automatic route processing (AutoRP), Multiprotocol BGP (MBGP), Multicast Virtual Private Network (MVPN), and Multicast Source Discovery Protocol (MSDP)●Internet Group Management Protocol Versions 2 and 3 (IGMPv2 and v3)◦IGMPv2 and v3 snoopingManageability and Availability●High Availability◦Cisco IOS XR high-availability feature set, MPLS TE-FRR, BFD, 802.3ad Link Aggregation Bundles, NSF, Multi-Chassis Link Aggregation (MC-LAG) and NSR●Manageability◦Cisco IOS XR manageability feature set, Cisco ANA, MIB, XML, and Simple Network Management Protocol (SNMP)●OAM◦Ethernet OAM (IEEE 802.3ah and IEEE 802.1ag)◦MPLS OAM (label switched path [LSP] ping, LSP traceroute, and Virtual Circuit Connectivity Verification [VCCV])Security●Cisco IOS XR Software: Cisco IOS XR Software provides comprehensive network security features, including access control lists (ACLs); control-plane protection; routing authentications; authentication, authorization, and accounting (AAA) and TACACS+; Secure Shell (SSH) Protocol;SNMPv3; and leading Routing Policy Language (RPL) support.●Layer 2 ACLs: You can use this security feature to filter packets under an EVC based on MAC addresses.●Layer 3 ACLs: This feature provides ACL matching by IPv4 packet attributes.●Security: Many critical security features are supported:◦802.1ad Layer 2 Control Protocol (L2CP) and bridge-protocol-data-unit (BPDU) filtering◦MAC limiting per EFP or bridge domain◦Unicast, multicast, and broadcast storm-control blocking on any interface or port◦Unknown Unicast Flood Blocking (UUFB)◦Dynamic Host Configuration Protocol (DHCP) snooping◦Unicast Reverse Path Forwarding (URPF)◦Control-plane security◦Dynamic ARP Inspection (DAI)◦IP Source Guard (IPSG)MIB●Support for a large number of hardware and product-specific as well as software feature MIBs; following is a partial list of MIBs supported; Ciscohas further documentation available on any restrictions related to these MIBs as part of the “Cisco ASR 9000 MIB Guide”; the SNMPimplementation and related details are also provided in the “System Manageability White Paper”:◦IP-MIB (RFC4293), CISCO-BULK-FILE-MIB, CISCO-CONFIG-COPY-MIB, CISCO-CONFIG-MAN-MIB, CISCO-ENHANCED-IMAGE-MIB, CISCO-ENHANCED-MEMORY-POOL-MIB, CISCO-ENTITY-FRU-CONTROL-MIB, CISCO-ENTITY-SENSOR-MIB, ENTITY-MIB, CISCO-ENTITY-ASSET-MIB, ENTITY-STATE-MIB, ENTITY-SENSOR-MIB, CISCO-ENTITY-ALARM-MIB, CISCO-FLASH-MIB, CISCO-IF-EXTENSION-MIB, CISCO-MEMORY-POOL-MIB, CISCO-RF-MIB (1:1 RP Card), CISCO-SYSLOG-MIB, EVENT-MIB, IF-MIB as well as RFC1213-MIB, SNMP-COMMUNITY-MIB, SNMP-FRAMEWORK-MIB, SNMP-NOTIFICATION-MIB, SNMP-TARGET-MIB, IPv6-MIB, BRIDGE-MIB, DOT3-OAM-MIB, CISCO-IETF-PW-MIB, CISCO-CLASS-BASED-QOS-MIB, ETHERLIKE-MIB, BGP4-MIB Including Cisco extensions, MPLS TE STD MIB, TE-FRR-MIB, and CISCO-IETF-IPMROUTE-MIB, IEEE-8021-CFM-MIB, DOT3-OAM-MIBProduct SpecificationsFigure 2. Cisco ASR 9000 Series (with Optional Doors)Table 3 provides details on the two chassis variants of the Cisco ASR 9000 Series: the Cisco ASR 9010 and the Cisco ASR 9006. Both of these systems are designed to the same high standards of performance and reliability, feature the same power and thermal innovations, and can share the RSPs, line cards (LCs), PEMs, and power supplies – for maximum flexibility in your network planning.Table 3. Product Specifications1Model Cisco ASR 9010 Cisco ASR 9006CategoriesPhysical Specifications Height: 36.75 in. (933.5 mm)Width: 17.5 in. (444.5 mm)Depth:●With doors: 31.45 in. (798.8 mm)●Without doors: 28.65 in (727.2 mm)Weight:●191 lbs (86.8 kg) (Unloaded)●375 lb (170.5 kg) (maximum) Height: 17.5 in. (444.5 mm)Width: 17.5 in. (444.5 mm)Depth:●With doors: 31.45 in. (798.8 mm) ●Without doors: 28.65 in (727.2 mm) Weight:●110 lbs (50 kg) (Unloaded)●230 lbs (106.8 kg) (Fully Loaded)Slot Orientation Vertical HorizontalCisco ASR 9000 Series RSP Dual redundant RSPs in 2 slots Same as Cisco ASR 9010 Cisco ASR 9000 Series LCs Eight line card slots Four line card slots“Commons” Components Two RSPsTwo fan traysTwo PEMs (either DC or AC)One fan filter Two RSPsTwo fan traysOne PEM (either DC or AC) One fan filterReliability and Availability Fabric redundancyFan redundancyFeed redundancyPower-supply redundancyRSP redundancySoftware redundancySame as Cisco ASR 9010 1Specific features are hardware and software dependentRack Mounting Yes●19-inch●21 and 23 inch adapters available Same as Cisco ASR 9010Note: Minimum 17.75-in. opening between posts is needed for proper operation.Cabinet Mounting YesNote: Doors not recommended in enclosed cabinetsSame as Cisco ASR 9010 Wall Mounting No Same as Cisco ASR 9010 Airflow Front-to-back Side-to-back PerformanceChassis Switching Capacity2Up to 6.4 Tbps Up to 3.2 TbpsFabric One per RSP●Active / Active non-blocking operation mode in dual RSPredundant configuration.●Fully redundant in dual RSP redundant configuration●Built-in service-intelligence and traffic-prioritization capabilitySame as Cisco ASR 9010Thermal Two fan trays●Twelve high-efficiency fans per tray●Variable-speed fans for optimal thermal performance●No single point of failure Two fan trays●Six high-efficiency fans per tray●Variable-speed fans for optimal thermalperformance●No single point of failurePowerModularity ●Up to 6 power modules (AC or DC) for future scalabilityMultiple power module types●3-kW AC power module●2.1 and 1.5-kW DC power modulesNote: Mixing of AC and DC modules is not supported. DCmodules can be mixed and matched.●Up to 3 power modules (AC or DC) forfuture scalabilityMultiple power module types●Same as Cisco ASR 9010Note: Mixing of AC and DC modules is not supported. DC modules can be mixed and matched.Redundancy ●Module redundancy: 1:N–1:1●Feed redundancy●PEM redundancy ●Module redundancy: 1:N–1:1 ●Feed redundancyPower Zones None●Fully load-sharing power infrastructureSame as Cisco ASR 9010Power Input Worldwide ranging AC (200–240V; 50–60 Hz; 16A maximum)Worldwide ranging DC (–40 to –72V; 50A nominal, 60Amaximum)Same as Cisco ASR 9010Power Consumption3Typical: 3140 Watts (full LC component) Typical: 1900 Watts (full LC component) Power Module Airflow Front-to-back Same as Cisco ASR 9010 Environmental SpecificationsOperating Temperature(nominal)41 to 104ºF (5 to 40ºC) Same as Cisco ASR 9010Operating Temperature(short-term)423 to 131ºF (–5 to 55ºC) Same as Cisco ASR 9010Operating Humidity (nominal)(relative humidity)5 to 95% Same as Cisco ASR 9010Operating Humidity (short-term) 5 to 90%Note: Not to exceed 0.024 kg water per kg of dry airSame as Cisco ASR 9010Storage Temperature –40 to 158ºF (–40 to 70ºC) Same as Cisco ASR 9010Storage (relative humidity) 5 to 95%Note: Not to exceed 0.024 kg water per kg of dry air.Same as Cisco ASR 9010Operating altitude –60 to 4000m (up to 2000m conforms to IEC/EN/UL/CSA 60950 Same as Cisco ASR 90102In dual-RSP mode3The system infrastructure is designed to work through 1.5kW – 9kW range while meeting redundancy requirements. Quoted Max power consumption extends over all operating conditions (e.g. short-term conditions specified in Environmental Specifications)4Short-term refers to a period of not more than 96 consecutive hours and a total of not more than 15 days in 1 year. (This number refers to a total of 360 hours in any given year, but no more than 15 occurrences during that 1-year period.)requirements) Regulatory ComplianceNetwork Equipment Building Standards (NEBS) Cisco ASR 9010 is designed to meet (qualification in progress):●SR-3580: NEBS Criteria Levels (Level 3)●GR-1089-CORE: NEBS EMC and Safety●GR-63-CORE: NEBS Physical Protection●VZ.TPR.9205: Verizon TEEERSame as Cisco ASR 9010European Telecommunications Standards Institute (ETSI) Standards Cisco ASR 9010 is designed to meet (qualification in progress):●EN300 386: Telecommunications Network Equipment (EMC)●ETSI 300 019 Storage Class 1.1●ETSI 300 019 Transportation Class 2.3●ETSI 300 019 Stationary Use Class 3.1Same as Cisco ASR 9010EMC Standards Emission Cisco ASR 9010 is designed to meet:●FCC Class 47CFR15 A●ICES 003 Class A●AS/NZS CISRP22 Class A●CISPR 22 (EN55022) Class A●VCCI Class A●BSMI Class A●IEC/EN 61000-3-12: Power Line Harmonics●IEC/EN 61000-3-11: Voltage Fluctuations and Flicker●EN55022: Information Technology Equipment (Emissions)●EN 50121-4: Railway EMCSame as Cisco ASR 9010EMC Standards Immunity Cisco ASR 9010 is designed to meet:●IEC/EN-61000-4-2: Electrostatic Discharge Immunity (8kVContact, 15kV Air)●IEC/EN-61000-4-3: Radiated Immunity (10V/m)●IEC/EN-61000-4-4: Electrical Fast Transient Immunity (2kVPower, 1kV Signal)●IEC/EN-61000-4-5: Surge AC Port (4kV CM, 2kV DM)●IEC/EN-61000-4-5: Signal Surge Ports (1kV)●IEC/EN-61000-4-5: Surge DC Port (1kV CM, 1kV DM)●IEC/EN-61000-4-6: Immunity to Conducted Disturbances(10Vrms)●IEC/EN-61000-4-8: Power Frequency Magnetic FieldImmunity (30A/m)●IEC/EN-61000-4-11: Voltage DIPS, Short Interruptions, andVoltage Variations●EN55024: Information Technology Equipment (Immunity)●EN50082-1/EN-61000-6-1: Generic Immunity Standard●EN 50121-4: Railway EMCSame as Cisco ASR 9010Safety Cisco ASR 9010 is designed to meet:●UL/CSA/IEC/EN 60950-1●IEC/EN 60825 Laser Safety●ACA TS001●AS/NZS 60950●FDA – Code of Federal Regulations Laser Safety●OSHA acoustic requirementsSame as Cisco ASR 9010Cisco Services for Cisco ASR 9000Through a lifecycle services approach, Cisco delivers comprehensive support for service providers to help them successfully deploy, operate, and optimize their IP Next-Generation Networks (IP NGNs). Cisco Services for the Cisco ASR 9000 Aggregation Services Routers provide the services and proven methodologies that help assure service deployment with substantial return on investment, operational excellence, optimal performance, and high availability. These services are delivered using leading practices, tools, processes, and lab environments developed specifically for Cisco ASR 9000 deployments and postimplementation support. The Cisco Services team addresses your specific requirements, mitigates risk to existing revenue-generating services, and helps accelerate time to market for new network services.For more information about Cisco Services, contact your local Cisco account representative or visit:/go/spservices.Ordering InformationTo place an order, visit the Cisco Ordering Home Page. For more details about how to order, please refer to the Cisco ASR 9000 Series ordering guide.。
Cisco产品线
Cisco ASR 1000 系列汇聚服务路由器思科XR 12000系列路由器思科12400 系列路由器思科12000 系列路由器思科10000 系列路由器思科7600 系列路由器思科7500 系列路由器思科7300 系列路由器思科7201 系列路由器思科7200 系列路由器思科3800 系列路由器思科3700 系列路由器思科3600 系列路由器思科3200 系列路由器思科2800 系列路由器思科2600 系列路由器思科1800 系列路由器思科800 系列路由器思科精睿系列路由器Cisco SN 5400 Series Storage Routers and SoftwareSN5400 存储路由器机思科第二代集成多业务路由器（ISR G2）思科3900 系列集成多业务路由器思科2900 系列集成多业务路由器思科1900 系列集成多业务路由器思科800 系列集成多业务路由器思科SRP530W 千兆智能路由器产品周期终止声明(EOS/EOL)思科1700 系列路由器思科2600 系列路由器思科3700 系列路由器思科7200 系列路由器思科7300 系列路由器思科7600 系列路由器思科10000 系列路由器思科12000 系列路由器思科12400 系列路由器思科路由器及安全配置管理思科路由器及安全配置工具(SDM)思科运营商级路由系统思科运营商级路由系统(CRS-1)(二)思科交换产品Data Center SwitchesCisco Nexus 7000系列交换机Cisco Nexus 5000系列交换机Cisco Nexus 1000V虚拟交换机LAN SwitchesCisco IE3000系列交换机思科网络助理4.0中文版Catalyst Express 500 系列交换机Catalyst 6500系列交换机Catalyst 4900系列交换机Catalyst 4500 系列交换机Catalyst 3750 系列交换机Catalyst 3750-E 系列交换机Catalyst 3560 系列交换机Catalyst 3560-E 系列交换机WS-C2955C-12系列交换机WS-C2955S-12系列交换机WS-C2955T-12系列交换机Catalyst 2950 系列交换机Catalyst 2960 系列交换机Catalyst 2940 系列交换机Catalyst 2918 系列交换机Catalyst 2900 系列交换机思科精睿系列全网管交换机（SRW系列）思科精睿系列智能交换机（SLM系列）思科精睿系列非网管交换机(SD/SR系列)Cisco SFS 系列Cisco SFS 3000多矩阵服务器交换机系列Cisco SFS 3000多矩阵服务器交换机系列Cisco SFS 7012和7024 Infiniband服务器交换机VFrame：通过数据中心虚拟化降低总拥有成本理解计算网络与虚拟化－从服务器为中心到服务为中心利用思科服务器矩阵交换机降低设备投入LAN Switches (continued)Cisco EnergyWiseMetro Ethernet SwitchesCisco ME 2400系列以太网接入交换机Cisco ME 3400系列以太网接入交换机IE-3000-4TCIE-3000-4TC-EIE-3000-8TCIE-3000-8TC-EBMP-IE3000=CF-IE3000-E=CF-IE3000=DINCLP-IE3000=PWR-IE3000-CNCT=RPNL-IE3000=WAN SwitchesMGX SwitchesMGX 8850 系列IP＋A TM多服务交换机Other WAN Switching ProductsIGX 8400 系列交换机产品周期终止声明(EOS/EOL)Catalyst 2900 系列交换机Catalyst 2900 系列XL交换机Catalyst 2950 系列交换机Catalyst 2970 系列交换机Catalyst 3500 系列XL交换机Catalyst 3550 系列交换机Catalyst 3750 系列交换机Catalyst 5000 系列交换机Catalyst 6000 系列交换机Catalyst 6500 系列交换机Cisco Catalyst 6500系列交换机和7600系列上的SSL服务模块(三)网络安全产品异常检测与牵制异常检测与牵制产品思科流量异常检测器Cisco Guard DDoS 牵制产品(US)Cisco DDoS管理系统Cisco DDoS多设备管理系统(US)异常检测与牵制集成交换机/路由器服务模块Cisco Catalyst 6500/Cisco 7600路由器流量异常检测器模块(US) Cisco Catalyst 6500/Cisco 7600路由器异常抵御模块(US)应用优化与安全性Cisco A VS 3110 应用速度系统(US)思科策略管理(US)思科策略管理点(US)思科策略决策点(US)思科策略实施点(US)网络准入控制产品(US)Cisco NAC访客服务器Cisco NAC ProfilerCisco NAC管理器与服务器(US)思科Windows安全接入控制服务器(US)思科安全接入控制服务器解决方案引擎(US)思科安全代理电子邮件安全性Cisco IronPort电子邮件安全产品(US)思科垃圾邮件与病毒拦截器终端安全性Cisco NAC 设备(Clean Access)思科安全代理思科信任代理(US)防火墙防火墙产品Cisco ASA 5500系列自适应安全产品防火墙集成交换机/路由器服务Cisco Catalyst 6500系列防火墙服务模块(US) 防火墙管理思科自适应安全产品管理器(US)思科IP解决方案中心(US)Cisco PIX设备管理器思科路由器与安全设备管理器(US)思科安全管理器(US)集成路由器安全Cisco IOS防火墙身份管理思科安全监控、分析与响应系统思科验证代理(US)Cisco CNS Access Registrar(US)Cisco CNS Network Registrar(US)思科安全接入控制系统(US)Cisco Secure Access Control Server Express(US) 思科Windows安全接入控制服务器(US)思科安全接入控制服务器解决方案引擎(US) Cisco Secure Access Control Server View(US) 集成路由器/交换机安全集成路由器安全集成路由器安全(US)Cisco IOS信任与身份(US)思科路由器与安全设备管理器(US)集成威胁控制Cisco IOS防火墙Cisco IOS 入侵防御系统(IPS)(US)Cisco IOS 网络地址转换(NAT)(US)Cisco IOS灵活数据包匹配(FPM)(US)Cisco IOS网络基础保护(NFP)(US)Cisco IOS内容过滤(US)IOS VPNCisco IOS Easy VPN(US)Cisco IOS IPsec(US)群组加密传输VPN(US)动态多点VPN (DMVPN)(US)Cisco IOS SSLVPN(US)集成交换机安全Cisco 7600系列/Catalyst 6500系列IPSec VPN共享端口适配器Cisco Catalyst 6500系列防火墙服务模块(US) 多功能安全多功能安全产品Cisco ASA 5500系列自适应安全产品Cisco ASA 5500系列4-端口千兆以太网安全服务模块(US) Cisco ASA高级检测与防御(AIP)模块(US)Cisco ASA内容安全与控制(CSC)安全服务模块(US)多功能安全管理思科自适应安全设备管理器物理安全混合模拟与网络视频监视思科视频监视融合产品(US)思科视频监视集成服务平台(US)思科视频监视IP网关(US)思科视频监视服务平台(US)思科视频监视流管理器软件(US)以网络为中心的视频监视思科视频监视编码服务器(US)思科视频监视媒体服务器软件(US)思科视频监视运行管理器软件(US)思科视频监视存储系统(US)思科视频监视虚拟矩阵软件(US)物理接入控制思科物理接入网关(US)思科物理接入管理器(US)视频监视IP摄像头思科精睿视频监视摄像头(前Linksys产品)(US)Cisco Video Surveillance 2500 系列IP摄像头(US)Cisco Video Surveillance 4000系列IP摄像头(US)入侵防御系统(IPS)思科入侵防御系统(US)IPS产品Cisco ASA 5500系列自适应安全产品(US)Cisco IPS 4200系列传感器(US)思科安全监控、分析与响应系统IPS集成交换机/路由器服务Cisco Catalyst 6500系列入侵检测系统(IDSM-2)模块(US)IPS管理思科安全管理器(US)思科路由器与安全设备管理器(US)ASA IPS 模块Cisco ASA高级检测与防御(AIP)安全服务模块(US)集成路由器安全Cisco IOS入侵防御系统(IPS)(US)安全管理(US)设备管理思科自适应安全设备管理器Cisco PIX 设备管理器思科路由器与安全设备管理器(US)管理应用Cisco Trend Micro ProtectLink 网关安全服务(前Linksys产品)(US) 思科IP解决方案中心(US)思科安全管理器(US)思科安全监控、分析与响应系统Cisco IronPort安全管理产品虚拟专用网(VPN)(US)集成路由器安全Cisco IOS IPsec(US)Cisco IOS SSLVPN(US)VPN 客户端Cisco Easy VPN(US)Cisco VPN 客户端(US)VPN产品VPN 3000 系列集中器Cisco ASA 5500系列自适应安全产品VPN集成交换机/路由器服务Cisco Catalyst 6500 系列/7600系列WebVPN服务模块(US) Cisco 7600系列/Catalyst 6500 系列IPSec VPN共享端口适配器VPN管理思科自适应安全设备管理器思科IP解决方案中心(US)Cisco PIX设备管理器思科路由器与安全设备管理器(US)思科安全管理器(US)思科虚拟网络计算(US)SIMS 安全信息管理和思科安全监控分析和响应系统（MARS）Web安全Cisco IronPort Web安全产品(US)(四)语音和统一通信产品思科统一通信解决方案整合了固定和移动网络上的语音、视频、数据和移动应用，能够在企业、政府机构和研究机构的工作场所内提供多媒体协作体验。
思科推出第二代集成多业务路由器
思科推出第二代集成多业务路由器
佚名
【期刊名称】《《通信世界》》
【年(卷),期】2009(000)045
【摘要】近期，思科推出了无边界网络（Borderless Networks）架构和一个五阶段计划，旨在帮助企业实现随时随地、通过任何设备，向任何人无缝、可靠、安全地提供服务和应用。
思科同时宣布推出第二代集成多业务路由器ISRG2。
思科ISRG2可帮助企业和电信运营商简化并扩展交付按需网络业务服务，以满足其分支机构在视频和协作应用等方面的需求。
【总页数】1页(PI0002)
【正文语种】中文
【中图分类】TN915.05
【相关文献】
1.思科客户利用网络创新技术提高移动性与协作能力,并降低能耗和业务成本Cisco Catalyst交换机和集成多业务路由器系列增加大量新特性 [J], 思科系统(中国)网络技术有限公司
2.思科推出第二代集成多业务路由器 [J],
3.网络无边应用无界——思科推出第二代集成多业务路由器 [J], 张丽霞
4.第二代集成多业务路由器 [J],
5.思科集成多业务路由器网络应用安全灵活 [J], 仝培杰
因版权原因，仅展示原文概要，查看原文内容请购买。
ASR ASR 系列路由器基本操作
3.查看时钟
Rack1-ASR(config)# do show clock
07:07:51.806 china Wed Oct 17 2012
Page:6
ASR1000升级ROMMON
1.拷贝ROMMON文件到RP Bootflash或harddisk
Rack1-ASR#copy ftp://asr:asr@10.74.5.45/asr1000-rommon.152-1r.S.pkg bootflash:
Router#sh plat Chassis type: ASR1006
Slot
Type
State
Insert time (ago)
--------- ------------------- --------------------- -----------------
0
ASR1000-SIP40
ok
Slot Card Type
Ver. Device: "ID-Name" Version
Version
==== ====================== ====== ================== =========== ==============
0/1 SPA-1XOC3-AT<DISABLED> 1.80 ????????????
ok
00:03:15
检查SPA FPD版本
Page:8
Router# show hw-module subslot all fpd
==== ====================== ====== =============================================
- 1、下载文档前请自行甄别文档内容的完整性，平台不提供额外的编辑、内容补充、找答案等附加服务。
- 2、"仅部分预览"的文档,不可在线预览部分如存在完整性等问题,可反馈申请退款(可完整预览的文档不适用该条件!)。
- 3、如文档侵犯您的权益，请联系客服反馈,我们会尽快为您处理(人工客服工作时间：9:00-18:30)。
产品简介Cisco ASR 9000系列汇聚多业务路由器产品概述Cisco®ASR 9000系列具备卓越的可扩展性、运营商级可靠性、出色的环保设计、高度的灵活性，以及富有吸引力的全新性价比，它为运营商以太网传输领域树立了一个全新的标杆，同时还重新定义了了运营商以太网演进路线。
Cisco ASR 9000系列有两种型号(图1):Cisco ASR 9010路由器和Cisco ASR 9006路由器。
Cisco ASR 9000系列路由器采用Cisco IOS®XR操作系统，并拥有全面的系统冗余特性和完善的网络永续性机制，旨在提供真正的运营商级可靠性。
Cisco ASR 9000系列还提供了服务和应用级智能特性，致力于实现优化的视频交付和移动汇聚。
最后，Cisco ASR 9000系列还可简化并增强服务交付网络的运营和部署工作。
图1. Cisco ASR 9000系列Cisco ASR 9000系列是一款操作简单、面向未来进行优化的平台，采用了下一代硬件和软件。
这款下一代平台的部分亮点包括:™Cisco IOS XR模块化操作系统:Cisco ASR 9000系列采用了Cisco IOS XR操作系统，后者因在核心网部署中大获成功的Cisco CRS运营商级路由系统平台而闻名。
Cisco IOS XR操作系统专为Cisco ASR 9000系列等分布式系统而构建，使用微内核架构来实现真正的模块化。
这种模块化特性可支持软件映像升级或模块变更期间的不间断操作，而丝毫不会影响正常的平台运行。
完全分布式系统:"Cisco ASR 9000系列以完全分布的方式运行，即所有数据包转发决定和动作都在各个线卡上完成。
这些高密度以太网线卡配备了专门的网络处理器，可提供灵活的编程基础设施以及高密度分层服务质量(H-QoS)服务、安全性、以及集成同步以太网。
Cisco ASR 9000系列的分布式特性通过相应地扩大规模有效改进了永续性，支持诸如双向转发检测(BFD)和以太网运行、管理和维护(E-OAM)等特性。
"高效运营和冗余硬件:Cisco ASR 9000系列提供了一种基础设施，使所有通用组件、路由交换处理器(RSP)、交换矩阵、风扇和电源都可实现全面冗余。
此外，该平台支持根据系统要求按需使用电力。
电源采用模块化配置，支持真正的随增长随付费方法，可减少资本支出(CapEx)并提供高效运营的部署。
Cisco ASR 9000还提供了节省空间的小平台方案。
该方案使用这一产品系列的通用组件，同时借助己申请专利的侧后式气流设计保留了支持中央办公室部署的能力。
环保设计:在当今世界，有关人类对环境的影响及相关财政影响的认识不断提高，而Cisco ASR 9000系列路由器也带来了全新的"环保式"产品开发方法。
从最佳散热设计到电力基础设施的架构，从线卡组件的放置到每个插槽的间距，每个设计细节都力求实现一个目标，即通过降低功耗和散热要求，减少对环境的影响。
就连产品包装流程也经过严格评估，以最大限度地减少包装材料的使用，从而减少在客户地点的浪费。
Cisco ASR 9000系列是思科坚持高效、环保产品设计的最佳例证。
相比前几代运营商以太网路由产品，Cisco ASR 9000系列提供了大量增值特性，包括超过超过两倍的交换容量 (每线卡插槽高达880Gbps,双向1760Gbps，支持将来的2Tbps每槽位)、优化的电源和散热要求、创新的模块化电源架构和全新的高可用性设计等，并充分利用了Cisco IOS XR模块化操作系统来帮助世界各地的电信运营商显著降低总体拥有成本(TCO)。
即刻解决未来的挑战Cisco ASR 9000系列旨在解决电信运营商在部署当前网络和规划未来网络时面临的挑战。
高能效部署:得益于较低的吞吐量效率比(Gbps/watt)，Cisco ASR 9000系列的设计能效得到了显著提高。
这种惊人的突破最终可带来更低的电费、碳足迹，并能够服务于更多客户，在更少的机架空间内提供更多服务。
不断增长的每用户平均收入(ARPU):电信运营商可以提高现有服务的价格模型或提高每用户服务产品。
在传统服务价格不断下降的今天，Cisco ASR 9000系列通过促进可靠、可扩展的视频、下一代移动汇聚、以及先进的运营商以太网服务产品，有助于开创新的财务收入来源。
高效地管理服务:Cisco ASR 9000系列通过全面的管理解决方案，提供了领先的网络、设备和服务管理能力。
Cisco Active Network Abstraction (ANA)为服务激活配置、保证和管理提供了一个框架。
通过将这些要素与全套以太网和多协议标签交换(MPLS) OAM 能力相结合，Cisco ASR 9000打造了一个易于运营商使用的出色环境。
网络融合:电信运营商的一个共同目标是将其网络迁移到单一的支持所有服务的融合式基础设施土。
这一目标最终能够通过减少网元，降低资本支出(CapEx)和运营支出(OpEx)，因此极具吸引力。
Cisco ASR 9000是优化服务传输基础设施的关键组件，它具备出色的服务灵活性、丰富的特性集、广泛的接口能力、以及与运营商以太网及广域网接口的无缝集成能力，包括FE、GE、10GE、40GE、100GE、E1、T3/E3、OC3/OC12/OC48/OC192 POS、以及信道化OC3 CPOS等，可以为服务交付奠定一个坚实的基础。
Cisco ASR 9000系列提供了强大的单一解决方案，可满足运营商的多业务边缘(MSE)、以太网优化MSE(E-MSE)和运营商以太网(CE)需求。
满足未来的服务要求:Cisco ASR 9000设计用于提供能够满足未来服务要求的关键能力。
以经济实惠的价格为网络设备提供增强的带宽能力，这是衡量真正的运营商传输平台的首要标准。
Cisco ASR 9000的吞吐量能够扩展至每插槽880 Gbps和每系统14 Tbps，为支持全套下一代服务提供了理想的基础平台。
真正网络和服务融合的另一个关键组成部分是在网元中集成服务智能。
Cisco ASR 9000可提供先进的用户管理能力，并使用QuantumFlow处理器提供基于芯片的安全服务和视频。
视频是未来的"语音"，Cisco ASR 9000提供了集成的视频点播(VoD)流和缓存、内嵌的视频质量监控、加速的快速信道改变、以及实时视频纠错等能力。
硬件Cisco ASR 9000系列提供了完善的升级路线图，每插槽交换容量最高可达880Gbps，而无需彻底更换机箱。
这一创新产品采用了一组高密度GE和10GE以太网服务线卡，并采用通用网络处理器来支持一系列运营商级以太网应用。
这些线卡在基础和扩展级配置中提供，辅以路由交换处理器(RSP)土的非阻塞交换矩阵和机箱土的未来就绪型背板(BP)、散热和电源基础设施。
Cisco ASR 9000系列的模块化电源架构(有AC和DC两种版本)通过三种不同的电源供电:3-kW AC、2-kW DC 和1.5-kW DC。
电源安置在现场可维护的电源接入模块(PEM)中。
PEM有AC和DC两种版本。
每个PEM 可容纳多达3个相应类型的模块，不受电源区或位置的限制(不支持混合使用AC和DC电源)。
随着时间的推移，带宽和功能要求会不断提高，此时电信运营商可以增加更多的电源，以便在机箱中添加更多线卡。
这一能力最初可降低资本支出，在整个产品生命周期可带来最佳的运营支出。
Cisco ASR 9000系列还采用全面集成的时钟基础设施，允许路由器采取时钟输入信息(同步以太网、楼宇综合定时供应系统[BITS])、有线电缆数据服务接口规范[DOCSIS]定时接口[DTI]等)并通过背板将其分配到各插槽。
这一能力可以为透明的移动融合、移动无线接入网络(RAN)回传，以及时分复用(TDM)电路模拟提供有力的支持，而无需牺牲性能或扩展能力。
Cisco ASR 9000系列优化的散热基础设施具有出色的可扩展性，能够有效地支持未来的容量要求。
高效的变速风扇能够在正常运行的环境中降低电力要求，同时确保在极端条件下为当前和未来的线卡提供冷却。
表1列出了可用于Cisco ASR 9000系列的机箱硬件表1. 可用于Cisco ASR 9000系列的硬件关于诸如RSP、以太网线卡、SPA接口处理器(SIP)和共享端口适配器(SPA)等Cisco ASR 9000系列组件的详细信息，请在其各自的产品简介中查看:Cisco A SR 9000系列路由交换处理器Cisco ASR 9000系列以太网线卡Cisco ASR 9000系列SPA接口处理器700软件Cisco ASR 9000系列路由器为运营商以太网传输网络提供了卓越的扩展能力、服务灵活性和高可用性。
它采用Cisco IOS XR软件，这是一种创新的自我修复、分布式操作系统，旨在实现不间断的运行，同时可将系统容量扩展至14 Tbps。
这一操作系统还应用在Cisco CRS运营商路由系统等业界领先的路由器上，为运营商以太网领域带来了相同的可靠性、可扩展性、性能和丰富特性，使Cisco CRS成为了电信运营商核心网的统领者。
它还可基于相同的软件支持符合电信运营商要求的端到端IP/MPLS解决方案，从而降低管理多个操作系统的运营复杂性。
Cisco IOS XR软件3.7.2版推出了Cisco ASR 9000系列路由器支持功能，旨在为虚拟网络奠定运营商以太网基础。
Cisco ASR 9000进一步增强了IP下一代网络(NGN)运营商以太网设计，可支持个人、企业、批发和移动服务实现融合、永续、智能和可扩展的服务传输。
Cisco ASR 9000系列运营商以太网应用包括诸多商务服务，例如二层VPN(L2VPN)和L3VPN、IPTV、内容分发网络(CDN)以及移动回传网络等。
支持的特性包括:以太网服务;L2VPN;IPv4、IPv6和L3VPN;第二层和第三层组播;IPoDWDM、同步以太网(SyncE)、以太网OA&M/多协议标签交换(MPLS)OA&M、第二层和第三层访问控制列表(ACL)、H-QoS、MPLS流量工程快速重路由(MPLS TE-FRR)、多机箱LAG (MC-LAG)、集成路由与桥接(IRB)和不间断转发/不间断路由(NSF/NSR)。
Cisco IOS XR软件4.0.0版和4.0.1版支持全面的共享端口适配器(SPA)组合，可改进Cisco ASR 9000系列的多业务边缘(MSE)和以太网MSE(E-MSE)能力。
借助Cisco ASR 9000系列MSE和E-MSE能力，企业能够提供强大的商用VPN服务以及高效的SLA(服务等级协议)实施。
