智能车辆交通标志分割算法程序

1三色分差程序clear;I=imread('4.jpg');[chang,kuan,gao]=size(I);for i=1:changfor j=1:kuanIR(i,j)=I(i,j,1);IG(i,j)=I(i,j,2);IB(i,j)=I(i,j,3);endendIR=double(IR);IG=double(IG);IB=double(IB);for i=1:changfor j=1:kuanif 1.6*IB(i,j)-IG(i,j)-IR(i,j)<0CA(i,j)=0;elseif 1.6*IB(i,j)-IG(i,j)-IR(i,j)>255CA(i,j)=255;elseCA(i,j)=1.6*IB(i,j)-IG(i,j)-IR(i,j);endendend%IGRAY=rgb2gray(I);%{for i=1:changfor j=1:kuanif CA(i,j)<200&IGRAY(i,j)<200CA(i,j)=0;endendend%}yuzhi=otsu(CA);for i=1:changfor j=1:kuanif CA(i,j)<=yuzhi;CA(i,j)=0;elseCA(i,j)=255;endendendCA=uint8(CA);imshow(CA);for i=1:changfor j=1:kuanif CA(i,j)==0I(i,j,1)=0;I(i,j,2)=0;I(i,j,3)=0;endendendfigure;I=uint8(I);imshow(I);2 二值分割程序function [k1]=otsu(f)%是otsu的分割算法，在论文基于三分量色差法的交通分割阀值分割那一块，所以要对照那块内容来看这个算法[a,b]=size(f);%获取图片f的长和宽N=a*b;%计算图像的总像素，长a和宽b的乘积for i=1:256n(i)=sum(sum(f==(i-1)));%统计像素值为i的像素个数，保存到n里面，n(i)就是像素值为i的像素个数p(i)=n(i)/N;%统计每个像素值在该图像中的比例，也就是概率endfor k=1:256w0(k)=0;w1(k)=0;u0(k)=0;u1(k)=0;u(k)=0;dx(k)=0;end%上面是初始化，全部是0for k=1:256for i=1:kw0(k)=w0(k)+p(i);%w0里面保存的是像素值为k的像素概率之和，也就是CO产生的概率endfor i=1:ku0(k)=u0(k)+((i*p(i))/w0(k));%求CO加权平均值，看公式10 endfor i=(k+1):256w1(k)=w1(k)+p(i);%C1产生的概率endfor i=(k+1):256u1(k)=u1(k)+((i*p(i))/w1(k));%求C1的加权平均值endu(k)=w0(k)*u0(k)+w1(k)*u1(k);dx(k)=w0(k)*w1(k)*(u0(k)-u1(k))^2;%公式13 看论文end[c,k]=max(dx);%求出最大值c1=c;k1=k;%我们只要k就可以了，就是我们的阀值k=(k-1)/255;y=k;end3 系统的主程序function varargout = jiaotong(varargin)% JIAOTONG MATLAB code for jiaotong.fig% JIAOTONG, by itself, creates a new JIAOTONG or raises the existing % singleton*.%% H = JIAOTONG returns the handle to a new JIAOTONG or the handle to % the existing singleton*.%% JIAOTONG('CALLBACK',hObject,eventData,handles,...) calls the local % function named CALLBACK in JIAOTONG.M with the given input arguments.%% JIAOTONG('Property','Value',...) creates a new JIAOTONG or raises the % existing singleton*. Starting from the left, property value pairs are% applied to the GUI before jiaotong_OpeningFcn gets called. An% unrecognized property name or invalid value makes property application % stop. All inputs are passed to jiaotong_OpeningFcn via varargin.%% *See GUI Options on GUIDE's Tools menu. Choose "GUI allows only one% instance to run (singleton)".%% See also: GUIDE, GUIDATA, GUIHANDLES% Edit the above text to modify the response to help jiaotong% Last Modified by GUIDE v2.5 20-May-2011 15:59:05% Begin initialization code - DO NOT EDITgui_Singleton = 1;gui_State = struct('gui_Name', mfilename, ...'gui_Singleton', gui_Singleton, ...'gui_OpeningFcn', @jiaotong_OpeningFcn, ...'gui_OutputFcn', @jiaotong_OutputFcn, ...'gui_LayoutFcn', [] , ...'gui_Callback', []);if nargin && ischar(varargin{1})gui_State.gui_Callback = str2func(varargin{1});endif nargout[varargout{1:nargout}] = gui_mainfcn(gui_State, varargin{:}); elsegui_mainfcn(gui_State, varargin{:});end% End initialization code - DO NOT EDIT% --- Executes just before jiaotong is made visible.function jiaotong_OpeningFcn(hObject, eventdata, handles, varargin) % This function has no output args, see OutputFcn.% hObject handle to figure% eventdata reserved - to be defined in a future version of MATLAB % handles structure with handles and user data (see GUIDATA) % varargin command line arguments to jiaotong (see VARARGIN)% Choose default command line output for jiaotonghandles.output = hObject;% Update handles structureguidata(hObject, handles);% UIWAIT makes jiaotong wait for user response (see UIRESUME) % uiwait(handles.figure1);% --- Outputs from this function are returned to the command line. function varargout = jiaotong_OutputFcn(hObject, eventdata, handles) % varargout cell array for returning output args (see VARARGOUT); % hObject handle to figure% eventdata reserved - to be defined in a future version of MATLAB % handles structure with handles and user data (see GUIDATA)% Get default command line output from handles structurevarargout{1} = handles.output;% --- Executes on button press in pushbutton1.function pushbutton1_Callback(hObject, eventdata, handles)global tuglobal tu1%全局变量axes(handles.axes1)%在窗口1显示图片[filename,pathname]=uigetfile({ ...;'*.*','All Files(*.*)';},...'选择文件');%if isequal([filename,pathname],[0,0])returnelse%读取图片pic = fullfile(pathname,filename);b = imread(pic);imshow(b);%显示图片tu=b;tu1=b;title; （’原图’）%handle.axes1=b;end% hObject handle to pushbutton1 (see GCBO)% eventdata reserved - to be defined in a future version of MATLAB% handles structure with handles and user data (see GUIDATA)% --- Executes on button press in pushbutton2.function pushbutton2_Callback(hObject, eventdata, handles)global tuI=tu;flag1=get(handles.radiobutton1,'value');flag2=get(handles.radiobutton2,'value');flag3=get(handles.radiobutton3,'value'); %获取单选按钮的值，看是选取哪种类型的交通标志if flag1==1%如果选了红色警示牌的话[chase,erzhi,zuizhong]=biaozhifengeR(I);%调用红色分量计算函数axes(handles.axes2)imshow(chase);title（’红色分量效果图’）;axes(handles.axes3)imshow(erzhi)title（’二值分割效果图’）;axes(handles.axes4)imshow(zuizhong)title（’最终分割效果图’）;endif flag2==1 %如果选了蓝色指示牌的话[chase,erzhi,zuizhong]=biaozhifengeB(I);%调用蓝色分量计算函数axes(handles.axes2)imshow(chase);title（’蓝色分量效果图’）;axes(handles.axes3)imshow(erzhi)title （’二值分割效果图’）;axes(handles.axes4)imshow(zuizhong)title （’最终分割效果图’）;endif flag3==1%如果选了绿色指示牌的话[chase,erzhi,zuizhong]=biaozhifengeG(I); %调用蓝色分量计算函数axes(handles.axes2)imshow(chase);title （’蓝色分量效果图’）;axes(handles.axes3)imshow(erzhi)title （’二值分割效果图’）;axes(handles.axes4)imshow(zuizhong)title（’最终分割效果图’）;end% hObject handle to pushbutton2 (see GCBO)% eventdata reserved - to be defined in a future version of MATLAB% handles structure with handles and user data (see GUIDATA)% --- Executes on button press in pushbutton3.function pushbutton3_Callback(hObject, eventdata, handles)global tuI=tu;flag1=get(handles.radiobutton1,'value');flag2=get(handles.radiobutton2,'value');flag3=get(handles.radiobutton3,'value');if flag1==1%和上面是一样的，另外这里的函数又和biaozhifengeR的函数一样，具体解释看该函数文件，这里不再解释axes(handles.axes2)[chang,kuan,gao]=size(I);for i=1:changfor j=1:kuanIR(i,j)=I(i,j,1);endendimshow(IR);title（’红色分量效果图’）;endif flag3==1axes(handles.axes2)[chang,kuan,gao]=size(I);for i=1:changfor j=1:kuanIG(i,j)=I(i,j,2);endendimshow(IG);title （’绿色分量效果图’）;endif flag2==1axes(handles.axes2)[chang,kuan,gao]=size(I);for i=1:changfor j=1:kuanIB(i,j)=I(i,j,3);endendimshow(IB);title（’蓝色分量效果图’）;end% hObject handle to pushbutton3 (see GCBO)% eventdata reserved - to be defined in a future version of MATLAB % handles structure with handles and user data (see GUIDATA)% --- Executes on button press in pushbutton4.function pushbutton4_Callback(hObject, eventdata, handles) global tuI=tu;flag1=get(handles.radiobutton1,'value');flag2=get(handles.radiobutton2,'value');flag3=get(handles.radiobutton3,'value');if flag1==1axes(handles.axes3)[chang,kuan,gao]=size(I);for i=1:changfor j=1:kuanIR(i,j)=I(i,j,1);IG(i,j)=I(i,j,2);IB(i,j)=I(i,j,3);endendIR=double(IR);IG=double(IG);IB=double(IB);for i=1:changfor j=1:kuanif 1.6*IR(i,j)-IG(i,j)-IB(i,j)<0CA(i,j)=0;elseif 1.6*IR(i,j)-IG(i,j)-IB(i,j)>255CA(i,j)=255;elseCA(i,j)=1.6*IR(i,j)-IG(i,j)-IB(i,j);endendendyuzhi=otsu(CA);for i=1:changfor j=1:kuanif CA(i,j)<=yuzhi;CA(i,j)=0;elseCA(i,j)=255;endendendCA=uint8(CA);imshow(CA);title （’二值分割效果图’）;endif flag3==1axes(handles.axes3)[chang,kuan,gao]=size(I);for i=1:changfor j=1:kuanIR(i,j)=I(i,j,1);IG(i,j)=I(i,j,2);IB(i,j)=I(i,j,3);endendIR=double(IR);IG=double(IG);IB=double(IB);for i=1:changfor j=1:kuanif 1.6*IG(i,j)-IR(i,j)-IB(i,j)<0CA(i,j)=0;elseif 1.6*IG(i,j)-IR(i,j)-IB(i,j)>255CA(i,j)=255;elseCA(i,j)=1.6*IG(i,j)-IR(i,j)-IB(i,j);endendendyuzhi=otsu(CA);for i=1:changfor j=1:kuanif CA(i,j)<=yuzhi;CA(i,j)=0;elseCA(i,j)=255;endendendCA=uint8(CA);imshow(CA);title（’二值分割效果图’）;endif flag2==1axes(handles.axes3)[chang,kuan,gao]=size(I);for i=1:changfor j=1:kuanIR(i,j)=I(i,j,1);IG(i,j)=I(i,j,2);IB(i,j)=I(i,j,3);endendIR=double(IR);IG=double(IG);IB=double(IB);for i=1:changfor j=1:kuanif 1.6*IB(i,j)-IR(i,j)-IG(i,j)<0CA(i,j)=0;elseif 1.6*IB(i,j)-IR(i,j)-IG(i,j)>255CA(i,j)=255;elseCA(i,j)=1.6*IB(i,j)-IR(i,j)-IG(i,j);endendendyuzhi=otsu(CA);for i=1:changfor j=1:kuanif CA(i,j)<=yuzhi;CA(i,j)=0;elseCA(i,j)=255;endendendCA=uint8(CA);imshow(CA);title（’二值分割效果图’）;end% hObject handle to pushbutton4 (see GCBO)% eventdata reserved - to be defined in a future version of MATLAB % handles structure with handles and user data (see GUIDATA)% --- Executes on button press in pushbutton5.function pushbutton5_Callback(hObject, eventdata, handles)global tuI=tu;flag1=get(handles.radiobutton1,'value');flag2=get(handles.radiobutton2,'value');flag3=get(handles.radiobutton3,'value');if flag1==1[chase,erzhi,zuizhong]=biaozhifengeR(I);axes(handles.axes4)imshow(zuizhong)title（’最终分割效果图’）;endif flag2==1[chase,erzhi,zuizhong]=biaozhifengeB(I);axes(handles.axes4)imshow(zuizhong)title（’最终分割效果图’）;endif flag3==1[chase,erzhi,zuizhong]=biaozhifengeG(I);axes(handles.axes4)imshow(zuizhong)title（’最终分割效果图’）;end% hObject handle to pushbutton5 (see GCBO)% eventdata reserved - to be defined in a future version of MATLAB % handles structure with handles and user data (see GUIDATA)4 警示牌标志的分割程序function [chase,erzhi,zuizhong]=biaozhifengeR(I)%是按照论文基于三色分差的交通标志分割所得[chang,kuan,gao]=size(I);%获取图片I的长和宽for i=1:changfor j=1:kuanIR(i,j)=I(i,j,1);%提取图片的红色分量IG(i,j)=I(i,j,2); %提取图片的绿色分量IB(i,j)=I(i,j,3); %提取图片的蓝色分量endendIR=double(IR);IG=double(IG);IB=double(IB); %将提取的分量转换为双精度型，方便计算for i=1:changfor j=1:kuanif 1.6*IR(i,j)-IG(i,j)-IB(i,j)<0%论文中式5，目的是为了是提取的红色分量颜色更亮，其他的颜色更暗，下面两个一样，其他两个函数文件是相应的功能CA(i,j)=0;elseif 1.6*IR(i,j)-IG(i,j)-IB(i,j)>255CA(i,j)=255;elseCA(i,j)=1.6*IR(i,j)-IG(i,j)-IB(i,j);endendendchase=uint8(IR); %将红色分量图保存在chase变量中yuzhi=otsu(CA); %通过调用otsu来得到红色分量图的阀值yuzhifor i=1:changfor j=1:kuanif CA(i,j)<=yuzhi;CA(i,j)=0;elseCA(i,j)=255; %低于阀值的都变为0也就是黑色，高于阀值的都变味白色，这样就成了二值图了endendendCA=uint8(CA); %将处理后的红色分量图转换为8位图像类型的图%imshow(CA);erzhi=CA;for i=1:changfor j=1:kuanif CA(i,j)==0I(i,j,1)=0;I(i,j,2)=0;I(i,j,3)=0; %对照处理过的红色分量二值图，如果是黑色的话，就使原彩色图变为黑色，如果是白色的地方，就让原始色彩图保留元色彩色endendendI=uint8(I);zuizhong=I; %将处理后的彩色图赋值给zuizhong%imshow(I);5 蓝色指示牌标志的分割程序function [chase,erzhi,zuizhong]=biaozhifengeB(I)[chang,kuan,gao]=size(I);for i=1:changfor j=1:kuanIR(i,j)=I(i,j,1);IG(i,j)=I(i,j,2);IB(i,j)=I(i,j,3);endendIR=double(IR);IG=double(IG);IB=double(IB);for i=1:changfor j=1:kuanif 1.6*IB(i,j)-IG(i,j)-IR(i,j)<0CA(i,j)=0;elseif 1.6*IB(i,j)-IG(i,j)-IR(i,j)>255CA(i,j)=255;elseCA(i,j)=1.6*IB(i,j)-IG(i,j)-IR(i,j);endendendchase=uint8(IB);yuzhi=otsu(CA);for i=1:changfor j=1:kuanif CA(i,j)<=yuzhi;CA(i,j)=0;elseCA(i,j)=255;endendendCA=uint8(CA);%imshow(CA);erzhi=CA;for i=1:changfor j=1:kuanif CA(i,j)==0I(i,j,1)=0;I(i,j,2)=0;I(i,j,3)=0;endendendI=uint8(I);zuizhong=I;%imshow(I);6 绿色指示牌标志的分割程序function [chase,erzhi,zuizhong]=biaozhifengeG(I) [chang,kuan,gao]=size(I);for i=1:changfor j=1:kuanIR(i,j)=I(i,j,1);IG(i,j)=I(i,j,2);IB(i,j)=I(i,j,3);endendIR=double(IR);IG=double(IG);IB=double(IB);for i=1:changfor j=1:kuanif 1.6*IG(i,j)-IR(i,j)-IB(i,j)<0CA(i,j)=0;elseif 1.6*IG(i,j)-IR(i,j)-IB(i,j)>255CA(i,j)=255;elseCA(i,j)=1.6*IG(i,j)-IR(i,j)-IB(i,j);endendendchase=uint8(IG);yuzhi=otsu(CA);for i=1:changfor j=1:kuanif CA(i,j)<=yuzhi;CA(i,j)=0;elseCA(i,j)=255;endendendCA=uint8(CA);%imshow(CA); erzhi=CA;for i=1:changfor j=1:kuanif CA(i,j)==0I(i,j,1)=0;I(i,j,2)=0;I(i,j,3)=0;endendendI=uint8(I); zuizhong=I;%imshow(I);。
