司机控制器S640U-B CC.005型使用维护说明书版本：第2版批准总工校核开发部编制开发部姓名部门日期签名目录1 说明 (3)1.1产品描述 (3)1.2技术参数 (4)1.3工作原理 (5)1.4结构及技术说明 (5)2 检修和维护 (9)2.1 检修准备 (9)2.2 检修与维护 (10)2.2.1 检修与维护方法 (10)2.2.1.1 发光装置更换方法 (10)2.2.1.2弹片组件更换方法 (19)2.2.1.3 速动开关S847W2A2b的更换方法 (19)2.2.1.4 电位器输出值整定及电位器更换方法 (21)2.2.2 检修与维护时应注意的内容 (24)2.3 检修周期 (27)2.4 调试 (27)2.5 调试及退出调试 (28)2.6 常见故障处理与维护 (29)3 零件目录及备件采购 (29)3.1 零件目录 (29)1 说明1.1产品描述S640U-B CC.005司机控制器是HXD3C型电力机车司机用来操纵机车运行的主令控制器，是利用控制电路的低压电器间接控制主电路的电气设备。
用来控制机车的运用工况和行车速度。
该司机控制器符合TB1333-2002《机车电器基本技术条件》和TB/T1391-2007《机车司机控制器》。
司机控制器的特点与型号：该司机控制器的特点：结构紧凑、体积小、重量轻、高可靠、长寿命、少维修或免维修。
速动开关采用德国沙尔特宝公司先进的速动开关模块，速动开关为速动自净型、密封结构。
该司机控制器具有夜间档位显示功能。
司机控制器的型号规格为：S640U-B CC.005。
正常使用环境条件：a) 海拔不超过2500m；b) 使用环境温度在-25℃～40℃之间，最高周围空气温度见表1；表1 最高周围空气温度海拔 1400m及以下1400～2500m最高周围空气温度 40℃ 由40℃起，海拔每升高100m，递降0.5℃c) 温度保持40℃不变时，相对湿度为95%；温度从-25℃～+30℃快速变化时，相对湿度为95%，最大绝对湿度为30g/m3；d) 振动和冲击条件按TB/T 1391-2007的规定；e) 污染条件按TB/T 1391-2007的规定；f) 过电压条件按TB/T 1391-2007的规定；g) 装在有防雨、雪、风、沙的车（箱）体内。
正常使用安全条件：a) 本产品使用应有正确的选型、维护保养、储存。
正确的使用还包括整机系统与司机控制器之间应有良好的技术配合，整机系统提供的环境条件、工作条件不应超过本技术条件规定的技术参数要求。
b) 本产品设计具有防火性能要求，整机系统各电器室（屏、柜、箱）也应采取防火措施。
c) 安装地点不应有能影响灭弧或正常工作的强磁场存在。
d) 产品安装不应由于连接、安装位置不当造成维护保养不便，装卸不便、减小电气间隙、减小爬电距离，容易飞弧等不良现象。
e) 使用电路的额定电压和额定电流不应大于司机控制器组的额定参数。
使用本产品的电路内产生的过电压不高于产品规定的耐受过电压水平；f) 当本产品使用工作条件要求与安装点环境条件超出本技术条件要求时应与制造厂协商另行解决。
安全说明：警告拆装司机控制器时，司机控制器必须断电1.2技术参数a) 速动开关S847W2A2b额定值额定电压（Ue）： DC 110V约定发热电流（Ith）： DC 10A额定电流（Ie）： DC 1.0Ab) 速动开关特点接点为速动型；密封式结构；接点具有自净功能，可提高用作计算机信号时的可靠性；c) 电位器特性输出电位器型号为： FSG PW70；输出平滑性： ≤0.1％；绝缘电压： 500VDC, 50HZ；工作温度范围： －30°C～＋70°C；d) 手柄操作力主手柄操作力： 不大于49N换向手柄操作力： 不大于49Ne) 防护等级 (污染等级3)整机 IP00速动开关S847W2A2b IP00 (接线部分)IP60 (触点部分)f) 逆变器输入电压 110VDC；g) 寿命机械寿命 >1×106电寿命 >1×105h) 重量： 约 10Kgi) 接线方式：速动开关(司控器内部)； M3螺钉司控器对外连接：司控器内部（20芯插座）为： JL16-20ZY操纵台（20芯插头）为： JL16-20TY1.3工作原理司机控制器的面板上有主手柄、换向手柄和牵引联锁按钮三种可操作机构。
主手柄有：”0”位、牵引指示档位“*-2-4-6-8-10-12-13”和制动指示档位“*-1-3-5-7-9-11-12”；换向手柄有：“后”、“0”、“前”三个档位。
司机控制器的主手柄档位为无极调节、换向手柄在所有档位有定位；在牵引工况下主手柄向前推,在制动工况下主手柄向后拉，通过齿轮传动带动驱动电位器调节输入到电子柜的电压指令，从而达到调节机车牵引力和电阻制动的目的；换向手柄在每个档位均定位，换向手柄稳定在相应的档位中。
主手柄和换向手柄之间相互机械联锁；主手柄在“0”位自联锁。
主手柄是固定式；换向手柄是可取式(钥匙式)，且只能在“0”位插入或取出。
换向手柄同时也是辅助司机控制器的控制手柄，这样整台机车的司机控制器合用一只活动手柄(钥匙手柄)，从而保证了机车在运行中，只能操作一台司机控制器，其余均被锁在“0”位，不致引起电路指令发生混乱。
1.4结构及技术说明a) S640U-B CC.005司机控制器外形结构示意图见图1，主要结构零件表见表2司机控制器设有主手柄、换向手柄、牵引联锁按钮。
主手柄设有“牵引”区域、“0”位、“制动”区域。
图1 S640U-B CC.005司机控制器外形结构示意图表2 S640U-B CC.005司机控制器结构零件表序号说明序号说明1 控制手柄座组件 10 (换向侧)发光片组件2 换向手柄组件 11 左档位支座3 控制凸轮组件 12 右档位支座4 换向凸轮组件 13 速动开关S847W2A2b5 面板 14 电位器6 安装板 15 逆变器7 (控制侧)滚轮弹片组件16 20芯插座JL16-20ZY8 (换向侧)滚轮弹片组件17 20芯插头JL16-20TY9 (控制侧)发光片b) S640U-B CC.005司机控制器闭合表和接线图见图2图2 S640U-B CC.005司机控制器闭合表及接线图c) S640U-B CC.005司机控制器操纵台面板开孔图见图3图3 S640U-B CC.005司机控制器操纵台面板开孔图d) S640U-B CC.005司机控制器操纵台安装板安装开孔图见图4图4 S640U-B CC.005司机控制器操纵台安装板安装开孔图 e)速动开关S847W2A2b外形结构见图5图5 速动开关S847W2A2b外形结构图2 检修和维护2.1 检修准备表3 安全拧紧转矩表拧紧位置 螺纹公称尺寸 拧紧转矩(Nm) 备注档位支座 螺钉M4 2.7-3.0弹片组件 螺钉M4 2.7-3.0旋转板 螺钉M3 1.14-1.25电位器 螺钉M4 2.7-3.0电位器接线 螺钉M3 1.14-1.25电位器安装板 螺钉M5 5.4-5.9速动开关S847W2A2b螺钉M3 1.14-1.25速动开关S847W2A2b接线螺钉M3 最大0.5专用工具不采用测量和试验设备表4 测量和实验设备测量和试验设备数字万用表0-24V可调电源耐压测试仪500V兆欧表化学清洗剂表5 化学清洗剂清洗剂备注酒精 对于速动开关壳体的清洁材料见文件CS/XS 2008.03.02的要求易损件和备件表6 易损件和备件名称 规格型号 供应商速动开关 S847W2A2b 西安沙尔特宝电气有限公司弹片组件 弹片-80 发光片 发光片 EL110LN 发光片组件 发光片组件-80 电位器 FSG PW70 连接器20芯插座JL16-20ZY20芯插头JL16-20TY逆变器TGN-110A 2.2 检修与维护2.2.1 检修与维护方法 2.2.1.1 发光装置更换方法司机控制器发光装置应发光均匀，无闪烁或不发光现象。
如确有发光不均匀或不发光者，应更换控制侧发光片或换向侧发光片组件，更换时,按以下方法进行： 准备工作拆卸部分工具：长十字螺丝刀、一字螺丝刀、斜口钳、电烙铁、热风枪； 材料： 焊锡丝、Φ4绝缘热缩套管、尼龙扎带。
更换方法(控制侧)a) 去掉司机控制器换向手柄、面板；b) 用斜口钳剪掉图6或图7中所标记的用于固定发光片接线的尼龙扎带；图6 拆左档位支座时剪掉用于固定左档位支座上发光片接线的尼龙扎带图7 拆右档位支座时剪掉用于固定右档位支座上发光片接线的尼龙扎带b) 使用十字螺丝刀拆下安装控制侧的左(或右)档位支座M4螺钉，如图8、9、10；图8 待拆下的用于安装左档位支座的螺钉(左)、安装右档位支座的螺钉(右)图9 待拆下的用于安装左档位支座的螺钉(左)、安装右档位支座的螺钉(右)图10 拆下安装控制侧的左(或右)档位支座M4螺钉 c) 小心撕开贴在档位支座顶部的控制挡位标牌，如图11；图11 撕开贴在档位支座顶部的控制挡位标牌(此照片为同结构的S640U-B司机控制器照片)d) 档位支座组件结构中，绝缘套安装于档位支座两端的孔中，接线柱安装于绝缘套中，发光片两端的引出线穿过接线柱中的小孔用于与导线焊接。
档位支座组件结构示意图见图12；图12 档位支座组件结构示意图使用斜口钳剪开发光片引出线与导线焊接处的绝缘热缩套管，用电烙铁熔化焊接处的焊锡，使发光片与导线分离，将发光片从档位支座上取下，如图13、14。
