Higher PCP limits gives engine OEMs a competitive advantage
4
Background
The SwRI Engine Design and Development Section has extensive experience in structural design of HD diesel cylinder heads Over 70 different cases analyzed and designed to date This experience has lead to the development of an extensive database of cylinder head structural performance based on an efficient analysis process SwRI is in a unique position to undertake this effort A three-step approach has been proposed PHASE 1: Identify the fundamental design parameters that have the strongest influence on cylinder head structural capability through a DOE study PHASE 2: Design a state-of-the-art cylinder head with high PCP capability PHASE 3: Procure a prototype cylinder head and test on an industry standard component fatigue test
40 30 20 10
Model Year
Specific Power (kW/L)
3
current (bar)
50
Why Increase PCP Capability?
Higher PCP capability allows:
Increased power density (HP per liter) More power from an existing engine package
2.
8
Baseline Cylinder Head Results
Cylinder Head EFR Stresses – ATP-AT Loading EFR Stress Limit – 70 MPa
MPa
193 Bar PCP
250 Bar PCP
9
Completed R&D Plan Phase 1
Task 2: Cylinder Head Geometry Sensitivity Study
1. Generate parametric CAD model(s) with primary design features Primary decks Ports Bolt bosses Structural walls No filleting
Background
The HD diesel engines in production today have a maximum peak firing pressure capability of about 190 bar Primary limitation is the structure – cylinder head and head gasket being the most common limiting components Compromise between ports, water jackets, valves and fuel injection results in complex geometry Emissions and performance requirements have pushed pressures to this limit Engines have either been de-rated in performance or increased in displacement to accommodate the pressure limit
1.
Evaluate novel structural features developed from experience Add stiffness within constraints of port flow, packaging and cooling requirements Apply novel structural features and optimize for high PCP
Task 4: Investigation of Material Options for HD Diesel Cylinder Heads :
1.
Material Option Identification and Analysis Consider state-of-the art iron-based casting materials – High moly grey iron (now widely used in HDD heads) – Compacted graphite iron (CGI) – Varifer iron (proprietary material from Fritz Winter) – Ductile iron
one-half upper water jacket diamond-shaped valve layout external water jacket three decks, each of optimum thickness port walls of optimum thickness cast injector sleeve structure
7
Completed R&D Plan Phase 1
Task 1: Background Analysis
1.
Thermodynamic Analysis Verification of 250 bar model year MY2015 PCP target using engine performance cycle simulation models Include effects of future combustion strategies such as HCCI, massive EGR, etc. Increased efficiency Increased power density Cylinder Head Baseline Analysis Run CAE models of an existing cylinder head design and benchmark PCP limits Determine weak points and limiting factors at target PCP Provide starting point for Phase 2 and 3 work
Operation at this PCP level represents a technical leap from what is currently achievable in the industry and promises competitive advantages for engine manufacturers who can achieve it. Phase 2 (03.R8004) is now complete and has resulted in the design of a cylinder head for an existing engine which meets all design criteria identified in Phase 1. Phase 3 proposal submitted to cast and test prototypes.
11
Deflection Locations
12
Deflection Locations
13
Deflection Locations
பைடு நூலகம்
14
Completed R&D Plan Phase 1
Task 3: Investigation of Novel Cylinder Head Design Features
6
Program Summary
Phase 1 (03.R9670) of this project established the following design criteria for a heavy duty diesel (HDD) engine to have structural durability at 250 bar Peak Cylinder Pressure (PCP):
®
Investigation of Heavy-Duty Diesel Engine Architecture to Meet Peak Cylinder Pressure Requirements for 2015
SwRI® Internal Research No. R9670,R8004 Marc C. Megel Mark Tussing Barry Westmoreland
5
Objective
Identify combinations of structural parameters and feasible material options in the cylinder head to achieve 250 bar PCP capability with minimal impact on existing machining lines
