12.1. Including Debonding in a Contact Analysis Debonding can be defined in any model that includes surface-to-surface (CONTA171 through CONTA174), node-to-surface (CONTA175), line-to-line (CONTA176), or line-to-surface (CONTA177) contact. For a detailed discussion on how to set up a contact analysis, see Surface-to-Surface Contact.
To activate debonding for a contact pair, the following contact options must be defined for the contact element:
Augmented Lagrangian method or pure penalty method (KEYOPT(2) = 0 or 1)
Bonded contact (KEYOPT(12) = 2, 3, 4, 5, or 6) In addition, you must specify a cohesive zone material model with bilinear behavior for the contact elements. Two ways to specify the material data are available:
Bilinear material behavior with tractions and separation distances (TB,CZM command with TBOPT = CBDD)
Bilinear material behavior with tractions and critical fracture energies (TB,CZM command with TBOPT = CBDE)
This material model is discussed in more detail in the following section. Once you have defined the required input parameters, you can solve the analysis the same as you would for any nonlinear analysis (see Solving the Problem). After debonding is completed, the surface interaction is governed by standard contact constraints for normal and tangential directions. Frictional contact is used if friction is specified for contact elements.
12.1.1. Cohesive Zone Materials Used for Debonding A cohesive zone material model is needed to model debonding in a contact analysis. This material is defined using the data table method (TB and TBDATA commands). Temperature dependent data is also allowed (TBTEMP command). On the TB command, use Lab = CZM to denote a cohesive zone material, and use TBOPT = CBDD or CBDE to indicate the specific material data you will provide. The two data definitions are described below. For more information on this material, see Cohesive Zone Material Model in the Theory Reference for the Mechanical APDL and Mechanical Applications. 12.1.1.1. Bilinear Material Behavior with Tractions and Separation Distances (TBOPT = CBDD)
This is a linear elastic material behavior with linear softening characterized by maximum traction and maximum separation. To define this material, use the TB,CZM command with TBOPT = CBDD. Specify the material constants as data items C1 through C6 on the TBDATA command:
Constant Symbol Meaning C1 σmax maximum normal contact stress
C2 cnu contact gap at the completion of debonding C3 τmax maximum equivalent tangential contact stress C4 ctu tangential slip at the completion of debonding C5 η artificial damping coefficient C6 β flag for tangential slip under compressive normal contact stress
Sample command input for this material is shown below. TB,CZM,1,2,,CBDD TBDATA,1,σmax, cnu,τmax, ctu,η,β
12.1.1.2. Bilinear Material Behavior with Tractions and Critical Fracture Energies (TBOPT = CBDE)
This is a linear elastic material behavior with linear softening characterized by maximum traction and critical energy release rate. To define this material, use the TB,CZM command with TBOPT = CBDE. Specify the material constants as data items C1, through C6 on the TBDATA command:
Constant Symbol Meaning C1 σmax maximum normal contact stress C2 Gcn critical fracture energy for normal separation C3 τmax maximum equivalent tangential contact stress C4 Gct critical fracture energy for tangential slip C5 η artificial damping coefficient
C6 β flag for tangential slip under compressive normal contact stress Sample command input for this material is shown below. TB,CZM,1,2,,CBDE TBDATA,1,σmax,Gcn,τmax,Gct,η,β
12.1.2. Debonding Modes Debonding involves separation of surfaces forming an interface. The direction of separation determines the debonding mode. ANSYS detects the debonding mode based on material data that you input for normal and tangential directions:
Mode I debonding involves separation normal to the interface. It is activated by inputting data items C1, C2, and C5 on the TBDATA command.
Mode II debonding involves slip tangent to the interface. It is activated by inputting data items C3, C4, and C5 on the TBDATA command.
Mixed mode debonding involves both normal separation and tangential slip. It is activated by inputting data items C1, C2, C3, C4, and C5, and C6 on the TBDATA command.
Mixed mode debonding involves both normal separation and tangential slip. It is activated by inputting data items C1, C2, C3, C4, and C5, and C6 on the TBDATA command.
