SNA-02302235B-3SY01 Data Sheet

F or CV TEi n te rn al us e o nl yAsink CorporationTel：+86-755-2689 1081 Fax：+86-755-2682 6659Product SpecificationsCustomer Name: ______________Part Name: Aluminum Foil Heat SinkPart Description: 22.5X22X0.35mmPart Number: SNA-02302235B-3SY01PREPARED BY CHECKED BYCustomer SuggestionCustomer ApprovalF or CV TEi n te rn al us e o nl yUltra-thin,high performance productsA-sink Aluminum Foil Heat Sink is a ultera-thin Heat-sink with high thermal conductivity and high flexibility. The surface is coating with Nano Carbonpowder which has high thermal conductivity and high thermal radiation efficiency. Changing the heat to infrared RF, communicate coolingefficiency.Construction♦Product Cross-Sectional View ♦Products FundamentalFunctions♦Good flexibility,Rework,Processability♦EMI shielding and absorbing to protect sensitive electronic parts ♦RoHS compliant and UL94V0 flammability rated ♦Temperature performance>100°♦The top and bottom surfaces are insulated ♦Can be die-cut into customizable shapes ♦Applicable area of the phase difference♦Holds patents:our proprietary technology and know-how with competitors resolve patent issuesF or CV TEi n te rn al us e o nl yOutline Dimension:F orCV TEi n te rn al us e o nl yNano Carbon Super Thin Heat SinkPART NUMBER SNA-02302235B-3SY01 DESCRIPTION 22.5X22X0.35mmNano Carbon COATING ReportMain Feature Value Method Color BlackVisual Adhesion Crosscut100/100ASTM D3359 Impact testCollision-free spin-offDupont 500g×50㎝ Salt water spray test ＞500hr No blistering peeling ASTM B117Hardness HASTM D3363 Coating thickness 30~80μmASTM D1186 Resistance1.0 x 1012ΩANSI/ESD STM 11.11 Accelerated weathering test ＞600hr UV-A340 Color aberration △E≤1.0Colorimeter Glossiness10-15Gloss Meter Anti-alcoholWipe 20 times without fadingAnhydrous EthanolSGS Test ReportTest RequestedValue Fifteen (15) Substances of Very High Concern (SVHC) Screening Up to standard RoHS (2002/95/EC)Up to standard DIN (EN 71 Part 3:1994 with the incorporation of amendments A1:2000, AC:2000 and AC:2002) Up to standardASTM F963-07(4.3.5) Up to standardF or CV TEi nte rn al us e o nl yNano Carbon Coating CompositionMATERIAL Balance RESIN60-80 ﹪ FILLER/PIGMENT 10-20 ﹪ADDITIVE 10-15 ﹪ FLOWAGENT1 ﹪Conductive Adhesive Tape SpecificationItem ValueAdhesive Conductive Acrylic AdhesiveColor Transparent LinerReleasing PaperWeather resistant Yes Ageing resistant Yes Thickness Total0.13mm Adhesion to stainless steel （72 hour RT ）142N/100 mmF or CVTEi n te rn al us e o nl yReliability Test ItemsNo.Test Items Test standardTest method Inspection standard Conclusion1Salt Water Spray TestGB/T10125-1977In 35℃ for5%NaCI spray1000 hours testNo foaming, nopeeling, no rustpass2Acid resistanceJIS-K-56006.1Use the 5%H2SO4solution at room temperature for 300 hoursNo foaming, no peeling, no rustpass3AlkaliresistanceJIS-K-56006.1Use the 5%H2SO4 solution at room temperature for 24 hoursNo foaming, nopeeling, no rustPass4Boiling resistanceJIS-K-56006.3Boiling water and cook for 1 hourNo foaming, no peeling, no rustPassNote:1. Product surface without scratches, dirt, silk, mimeographed phenomenon.2. Thermal glue stick with Aluminum foil tightly, no bubble and breakage issues.3. The product surface in 100mm only allowed less than 2 convex points appear.F or CV TEi n te rn al us e o nl yPacking:TBD.F or CV TEi n te rn al us e o nl yPrecautions: Product Transportation and Storage1. The product is easy damaged on the way of transportation, it must be move carefully, don’t squeeze and press the product2. The product must be placed monolayer, don’t pile up two or more layers.3. As a result of above improper transportation and storage caused issues, we company without responsibility.。
