A380手册中文版[1]

合集下载

A380机型运行数据(中文版)

A380-841/TRENT970制造商：AIRBUS公司制造国：法国航空器分类航程类型：远程(LR-TA)使用机场等级：4F消防分类：ARFF E / RFFS 10尾流分类：H近进分类：C（因Vref小于141kts）高度层分类：D飞行间隔：按B747-400型掌握ICAO领航报代号：A380-841几何尺寸机身长：70.73米翼展宽：79.75米机身宽：7.14米机身上部离地高：10.80米(562T/AFT CG)/ 11.03米(290T/MID CG)垂尾高：24.08(562T/AFT CG)/ 24.40米(290T/MID CG)内侧发动机离地高: 1.05米(562T/AFT CG)/ 1.25米(290T/MID CG) 外侧发动机离地高: 1.90米(562T/AFT CG)/ 2.27米(290T/MID CG) 翼尖离地高: 5.22米(562T/AFT CG)/ 6.05米（290T/MID CG)前、大翼轮距: 28.61米大翼主轮距: 12.46米发动机台数：4台客舱情况双通道/单通道：双座位数：555座紧急出口数：16个客舱门数：14个客舱高度：客舱门尺寸（宽×高）：1.26米×1.89米（M1L、M1R）客舱门尺寸（宽×高）：1.07米×1.92米（除M1L、M1R外）客舱门编号：主舱左侧：M1L、M2L、M3L、M4L、M5L 主舱右侧：M1R、M2R、M3R、M4R、M5R 上舱左侧：U1L、U2L、U3L 上舱右侧：U1R、U2R、U3R可用襟翼位置起飞襟翼：CONF1+F, CONF2, CONF3进近襟翼：CONF1+F, CONF2, CONF3着陆襟翼：CONF3, CONF FULL 限制重量最大滑行重量：562000 千克（1238998磅）最大起飞重量：560000千克（1234588磅）最大着陆重量：386000千克（ 850984磅）最大无油重量：361000千克（795869磅）典型使用空重：275000千克（595281磅）结构限制业载： 90985千克（200587磅）速度最大巡航速度（Vmo/Mmo）：340 KIAS/0.89 M 正常巡航马赫数：0.855 M穿越颠簸速度：0.85 M 最小光洁速度：跑道入口速度：138KT（最大着陆重量，海平面，ISA, FLAP FULL）航程满载最大航程：6550NM(PL=84000KG, MTOW)满客最大航程：7950NM(PL=52000KG, MTOW)满油最大航程：9500NM(PL=0KG, FULL FUEL) (Assumption : IAS, NO WIND, FL360, LRC, Holding 30MINS, Alternate Distance 200NM, 5% Enroute Reserve Fuel)满载最大航程：5453NM （PL=50044KG，684MINS）满客最大航程：6932NM （428YPAX@95KG，70FPAX@115KG，8FPAX@115KG，PL=48930KG，867MINS）满油最大航程：8059NM （PL=16478KG，1007MINS）满油最大航程：8651NM （PL=0KG，1086MINS）计算条件：MTOW=294835KG，国际燃油政策，IAS，NO WIND，阶梯巡航，LRC，等待30MINS，备降距离200NM，2%公司备份油跑道典型起飞距离：2800米（ISA+0、海平面、MTOW）典型起飞距离：2950米（ISA+15、海平面、MTOW）典型着陆距离：1900米（ISA+15、海平面, MLDW）*Based on- NOSE GEAR : tire pressure-205PSI，tire dimension-1270*455R22 32PR - MAIN GEAR : tire pressure-218PSI，tire dimension-1400*530R23 40PR最小转弯半径（70°转弯角）机头半径：36.52米翼尖半径：53.76米机尾半径：46.01米最大转弯角度：70°有效转弯角度：69.5°180°转弯所需最小道面宽：62.9边界余度为6米燃油/耗油最大载油量：310000L/241800KG（按密度0.78kg/l）参考小时耗油量：12T/Hr(FL350,ISA,M85, 500T) APU地面耗油率：300KG/Hr APU空中耗油率：400KG/Hr 地面滑行耗油率：40KG/MIN 有无空中放油装置：有复飞油：1250KG等待油：5400KG（半小时）运行数据最大飞行高度：13106M（43000FT）95%MTOW/LRC重量最佳高度：10800M（35500FT）典型单发升限（总高）：米（T,KIAS）油箱温度限制：℃－℃全发/一发失效最大爬升率/最大爬升梯度（见表）全发/一发失效最大下降率（见表）自动着陆等级：CATⅠⅡⅢISA，MTOW，单发，MCT，最大爬升率（最大爬升率速度）/最大爬升梯度（绿点速度）ISA，MTOW，全发/单发，IDLE，放出减速板，最大下降率（VMO/MMO）噪音依据FAR36：级起飞噪音侧向噪音着陆噪音。

空中客车A380飞机维修手册说明书

21644Federal Register/Vol. 65, No. 79/Monday, April 24, 2000/Rules and Regulations(2) For the purposes of these mandatory inspections, piece-part opportunity means: (i) The part is considered completely disassembled when accomplished in accordance with the disassembly instructions in the manufacturer’s engine manual; and (ii) The part has accumulated more than 100 cycles in service since the last piece-part opportunity inspection, provided that the part was not damaged or related to the cause for its removal from the engine.’’(b) Except as provided in paragraph (c) of this AD, and notwithstanding contrary provisions in section 43.16 of the Federal Aviation Regulations (14 CFR 43.16), these mandatory inspections shall be performed only in accordance with the Airworthiness Limitations Section of the manufacturer’s ICA.Alternative Methods of Compliance(c) An alternative method of compliance or adjustment of the compliance time that provides an acceptable level of safety may be used if approved by the Engine Certification Office (ECO). Operators shall submit their requests through an appropriate FAA Principal Maintenance Inspector (PMI), who may add comments and then send it to the ECO.Note 2: Information concerning the existence of approved alternative methods of compliance with this airworthiness directive, if any, may be obtained from the ECO.Ferry Flights(d) Special flight permits may be issued in accordance with sections 21.197 and 21.199 of the Federal Aviation Regulations (14 CFR21.197 and 21.199) to operate the airplane toa location where the requirements of this AD can be accomplished.Continuous Airworthiness Maintenance Program(e) FAA-certificated air carriers that have an approved continuous airworthiness maintenance program in accordance with the record keeping requirement of §121.369(c) of the Federal Aviation Regulations (14 CFR 121.369 (c)) must maintain records of the mandatory inspections that result from revising the Airworthiness Limitations Section of the Instructions for Continuous Airworthiness (ICA) and the air carrier’s continuous airworthiness program. Alternately, certificated air carriers may establish an approved system of record retention that provides a method for preservation and retrieval of the maintenance records that include the inspections resulting from this AD, and include the policy and procedures for implementing this alternate method in the air carrier’s maintenance manual required by §121.369(c) of the Federal Aviation Regulations (14 CFR121.369(c)); however, the alternate system must be accepted by the appropriate PMI and require the maintenance records be maintained either indefinitely or until the work is repeated. Records of the piece-part inspections are not required under§121.380(a)(2)(vi) of the Federal Aviation Regulations (14 CFR 121.380(a)(2)(vi)). All other Operators must maintain the records of mandatory inspections required by the applicable regulations governing theiroperations.Note 3: The requirements of this AD havebeen met when the engine manual changesare made and air carriers have modified theircontinuous airworthiness maintenance plansto reflect the requirements in the enginemanuals.(f) This amendment becomes effective onOctober 23, 2000.Issued in Burlington, Massachusetts, onApril 14, 2000.Jay J. Pardee,Manager, Engine and Propeller Directorate,Aircraft Certification Service.[FR Doc. 00–10157 Filed 4–21–00; 8:45 am]BILLING CODE 4910–13–UDEPARTMENT OF TRANSPORTATIONFederal Aviation Administration14 CFR Part 71[Airspace Docket No. 99–AAL–18]Revision of Class E Airspace;Unalaska, AKAGENCY: Federal AviationAdministration (FAA), DOT.ACTION: Final rule.SUMMARY: This action revises Class Eairspace at Unalaska, AK. Theestablishment of a Global PositioningSystem (GPS) instrument approachprocedure at Unalaska Airport madethis action necessary. This rule providesadequate controlled airspace for aircraftflying IFR procedures at Unalaska, AK.EFFECTIVE DATE: 0901 UTC, June 15,2000.FOR FURTHER INFORMATION CONTACT: BobDurand, Operations Branch, FederalAviation Administration, 222 West 7thAvenue, Box 14, Anchorage, AK 99513–7587; telephone number (907) 271–5898; fax: (907) 271–2850; email:/at or ataddress http://162.58.28.41/at.SUPPLEMENTARY INFORMATION:HistoryOn November 19, 1999, a proposal toamend part 71 of the Federal AviationRegulations (14 CFR part 71) to revisethe Class E airspace at Unalaska, AK,was published in the Federal Register(64 FR 63261). The proposal wasnecessary due to the establishment of aGPS instrument approach procedure atUnalaska, AK. Interested parties wereinvited to participate in this rulemakingproceeding by submitting writtencomments on the proposal to the FAA.No public comments to the proposalwere received; thus, the rule is adoptedas written.The area would be depicted onaeronautical charts for pilot reference.The coordinates for this airspace docketare based on North American Datum 83.The Class E airspace areas designated as700/1200 foot transition areas arepublished in paragraph 6005 in FAAOrder 7400.9G, Airspace Designationsand Reporting Points, dated September1, 1999, and effective September 16,1999, which is incorporated byreference in 14 CFR 71.1. The Class Eairspace designations listed in thisdocument will be publishedsubsequently in the Order.The RuleThis amendment to 14 CFR part 71revises the Class E airspace at Unalaska,AK, through the establishment of a GPSinstrument approach. The area will bedepicted on aeronautical charts for pilotreference. The intended effect of thisrule is to provide controlled airspace forIFR operations at Unalaska, AK.The FAA has determined that thisregulation only involves an establishedbody of technical regulations for whichfrequent and routine amendments arenecessary to keep them operationallycurrent. It, therefore—(1) Is not a‘‘significant regulatory action’’ underExecutive Order 12866; (2) is not a‘‘significant rule’’ under DOTRegulatory Policies and Procedures (44FR 11034; February 26, 1979); and (3)does not warrant preparation of aregulatory evaluation as the anticipatedimpact is so minimal. Since this is aroutine matter that will only affect airtraffic procedures and air navigation, itis certified that this rule will not havea significant economic impact on asubstantial number of small entitiesunder the criteria of the RegulatoryFlexibility Act.List of Subjects in 14 CFR Part 71Airspace, Incorporation by reference,Navigation (air).Adoption of the AmendmentIn consideration of the foregoing, theFederal Aviation Administrationamends 14 CFR part 71 as follows:PART 71—DESIGNATION OF CLASS A,CLASS B, CLASS C, CLASS D, ANDCLASS E AIRSPACE AREAS;AIRWAYS; ROUTES; AND REPORTINGPOINTS1. The authority citation for 14 CFRpart 71 continues to read as follows:Authority: 49 U.S.C. 106(g), 40103, 40113,40120; E.O. 10854, 24 FR 9565, 3 CFR, 1959–1963 Comp., p. 389.21645 Federal Register/Vol. 65, No. 79/Monday, April 24, 2000/Rules and Regulations§71.1[Amended]2. The incorporation by reference in 14 CFR 71.1 of Federal Aviation Administration Order 7400.9G, Airspace Designations and Reporting Points, dated September 1, 1999, and effective September 16, 1999, is amended as follows:* * * * *Paragraph 6005Class E airspace extending upward from 700 feet or more above the surface of the earth.* * * * *AAL AK E5Unalaska, AK [Revised] Unalaska Airport(Lat. 53°53′57″ N., long. 166°32′ 42″ W.) Dutch Harbor NDB(Lat. 53°54′19″ N., long. 166°32′57″ W.) That airspace extending upward from 700 feet above the surface within 6.4-mile radius of the Unalaska Airport and within 2.9 miles each side of the Dutch Harbor NDB 360°bearing extending from the 6.4-mile radius to 9.5 miles north of the airport; and that airspace extending upward from 1,200 feet above the surface within 20-mile radius north of the airport between the Dutch Harbor NDB 305° bearing extending clockwise to the 075°bearing.* * * * *Issued in Anchorage, AK, on April 14, 2000.Anthony M. Wylie,Acting Manager, Air Traffic Division, Alaskan Region.[FR Doc. 00–10015 Filed 4–21–00; 8:45 am] BILLING CODE 4910–13–PDEPARTMENT OF JUSTICEDrug Enforcement Administration21 CFR Part 1310[DEA Number 199F]RIN 1117–AA52Placement of Gamma-Butyrolactone in List I of the Controlled Substances Act (21 U.S.C. 802(34))AGENCY: Drug Enforcement Administration, Justice.ACTION: Final rule.SUMMARY: Public Law 106–172, signed into law on February 18, 2000, and known as the ‘‘Hillory J. Farias and Samantha Reid Date-Rape Drug Prohibition Act of 1999,’’ amends section 102(34) of the Controlled Substances Act as amended (CSA) by designating gamma-butyrolactone (GBL), the precursor to gamma-hydroxybutyric acid (GHB), as a List I chemical. Reflecting this change in stature, the Drug Enforcement Administration (DEA) is amending itsregulation to reflect the status of GBL asa List I chemical subject to therequirements of the CSA and itsregulations. Establishment of athreshold for GBL will be the subject ofa separate rulemaking. Therefore, unlessand until a threshold is established, anydistribution of GBL is a regulatedtransaction as described by 21 CFR1300.02(b)(28). All handlers of GBLmust comply with the CSA regulatoryrequirements pertaining to List Ichemicals as described in the body ofthis document.FOR FURTHER INFORMATION CONTACT:Frank L. Sapienza, Chief, Drug andChemical Evaluation Section, Office ofDiversion Control, Drug EnforcementAdministration, Washington, DC 20537.DATES: Effective: April 24, 2000.Registration application deadline:DEA must receive a properly completedDEA–510 registration application withfee from handlers of GBL on or beforeJuly 24, 2000.SUPPLEMENTARY INFORMATION:What Is DEA Doing and Whom Does ItEffect?GBL is gamma-butyrolactone, theprecursor used in the clandestineproduction of gamma-hydroxybutyricacid (GHB). This Final Rule deals solelywith amending 21 CFR 1310.02(a) toreflect that GBL is a List I chemical asestablished by Public Law 106–172.Consequently any person who imports,exports, or distributes GBL must registerwith DEA and make required recordsand reports.What Authority Does DEA Have To DoThis?On February 18, 2000, Public Law106–172 was enacted. This law requiresthe Attorney General (AG) to addgamma-hydroxybutyric acid (GHB) toSchedule I no later than April 18, 2000.Effective on February 18, 2000, Congressalso specifically designated the GHBprecursor, gamma-butyrolactone (GBL)as a List I chemical.Why Is This Being Published as a FinalRule?This publication amends 21 CFR1310.02(a) to reflect the fact thatCongress made GBL a List I chemical.For regulatory purposes, this actionleaves DEA no discretion. Therefore,DEA is publishing this action as a FinalRule.Why Was Control of GBL Necessary?Law enforcement authorities haveidentified GBL in many GHBclandestine laboratories anddocumented its use as a precursor in theclandestine synthesis of GHB. There areno chemical substitutes for GBL as aprecursor in the clandestine synthesis ofGHB. Congress recognized that controlof GBL as a List I chemical is necessaryto prevent diversion for use in the illicitproduction of GHB and made it a ListI chemical. This Final Rule amends 21CFR 1310.02(a) to reflect the fact thatGBL is a List I chemical subject to therequirements of the CSA and itsregulations.Is GBL Subject to Any Other ControlsUnder the CSA?In addition to GBL functioning as achemical precursor for the manufactureof GHB, it also produces psychoactiveeffects. If taken for human consumption,GBL and other chemicals, including 1,4-butanediol, are swiftly converted intoGHB by the body. Abuse of these andother GHB-like substances is asignificant law enforcement and publichealth problem. GBL and 1,4-butanediolare structurally and pharmacologicallysimilar to GHB and are often substitutedfor GHB. Under certain circumstancesthey may satisfy the definition of acontrolled substance analogue (21U.S.C. 802(32)). Congress expresslycontemplated this possibility byamending 21 U.S.C. 802(32) to state thatthe designation of GBL or any otherchemical as a Listed chemical does notpreclude a finding that the chemical isa controlled substance analogue andsubject to the provisions of 21 U.S.C.813.Is There a Threshold for Transactionsin GBL?Public Law 106–172 did not establisha threshold for regulated transactionsinvolving GBL. Therefore, the DEA isreviewing available data, including thatprovided by commenters in response tothe Federal Register publication‘‘Industrial Uses and Handling ofGamma-butyrolactone; Solicitation ofInformation’’ (63 FR 56941), regardingan appropriate threshold. This will bethe subject of a separate rulemaking andwill provide an opportunity for publiccomment. Until and unless a thresholdis established, all covered transactionsinvolving any amount of GBL aresubject to the CSA regulatoryrequirements.Each regulated person who engages ina regulated transaction involving GBLmust keep a record of the transactionand file reports under certaincircumstances (21 CFR 1300.02(b)(28)).If a threshold is established for GBL, therecordkeeping and reportingrequirements will only apply totransactions, including cumulative。

A380手册中文版[1]

Wilco FleetA380使用于微软模拟飞行飞行指南请勿在真实飞行中使用!质量第一！如果不使用盗版并且只有购买原版的WILCO产品，您将获得我们软件的继续升级以及完善的质量。

谢谢您。

E-mail: info@A. 额外的 WILCO FLEET : A380 (只为CD - ROM 版本)很高兴为您服务,我们已经提供了一套完整的额外的. 这些都位于您的CD-Rom, 额外的 WILCO 目录.ERJ 145 Pilot in Command Wilco Fleet CRJ 2004Track IR 3ProWilco FleetA380TrailerWilcoFleet A380 Paint Kit喷气机区域运输该架CRJ 是历史上最成功的支线飞机项目。

要充分享受三维虚拟座舱，红外可以让您在飞行中控制您的视野，只需环顾几度。

目前最大的和最先进的商用客机，运输555名乘客超过8000海里！创建您自己的A380飞机涂装和颜色。

Track IR 3 Pro 可购买自 Wilco 出版 .如果您已经制作了新涂装,请与我们联系 (info@) 。

我们可以把它上传到Wilco 出版社的网站上。

B. 快速启动WILCO FLEET : A3801. 驾驶Wilco Fleet : A3801. 开启模拟飞行2. 从菜单中，选择飞机3. 选择Airbus - Wilco Fleet : A380-8004. 选择飞机模式，根据你的电脑性能对于低配置，选择：- Full : 显示所有的选项- 2D Panel : 2D 面板- VC : 显示虚拟座舱- Wingview : 显示从座舱看机翼的模式。

存储巴士A380中文说明书 DATA BUS CHN

2 系统架设...........................................................................................................................................6
2.1 硬盘组装...................................................................................................................................6 2.2 更换硬盘...................................................................................................................................7 2.3 连接至电脑 ...............................................................................................................................7 2.4 关于资料备份 ...........................................................................................................................7
存储巴士
使用手册
Page 2
CN
目录
1 介绍 ..................................................................................................................................................1

A380集中熔化操作指导书 C.1

检制方法
反应计划
实施人员
铝液测氢
1.每班首次倒料后，转运包内取样 2.与图谱对比，并记录图谱编号
测氢仪
1次/班
No：QR-SP08.01-002
隔离/通知生产部
操作工
炉样检测
1.频率：生产启动时或者铝合金锭炉批号发生改变时； 2.使用舀汤勺将铝液浇入模具中，冷却后，再将铸件打磨，送至测量室。
要点转运过程中，注意行车安全
转运至机边炉
步骤 8
操作顺序
1.用铲车将装有铝液的转运包转移至机边炉 2.用铲车吊起转运包到相应高度后，将铝液缓慢倒入坩埚内 3.填写加料记录
要点转运过程中，注意行车安全
第 2 页，共 3 页
XXXXX科技有限公司
编号：QP-SP03.01-085.01 版本/版次：C.1
倒入转运包
步
倒料
骤
6
复位
操作顺序
1.将预热后的转运包放在熔炉出料口； 2.启动倒料开关，熔炉倾斜倒料； 3.倒料结束，启动复位开关，熔炉复位
要点倾到时，严禁周边有人
熔化
步
骤
A380
4
操作确认熔化炉挂牌与材料一致顺序性:A380
要点
转运
铝液液
面低于
步
倒料口
骤
底部以
7
下
操作顺序
铝液液面低于倒料口底部以下
回料添加比例
添加铝合金锭与废铝件/铝料柄的比例控制7：3以
铝锭与铝料柄/废铝件混合加料【不允许渣包，飞内（通过计算转换为40%以内），(铝锭重量以每根
边及料渣和表面涂层废料（如：外协喷漆件、表 5.5KG计算，废铝件/铝料柄重量以称重方式计

A380手册中文版

谢谢您。

要充分享受三维虚拟座舱，红外可以让您在飞行中控制您的视野，只需环顾几度。

目前最大的和最先进的商用客机，运输555名乘客超过8000海里！创建您自己的A380飞机涂装和颜色。

Track IR 3 Pro 可购买自 Wilco 出版 .如果您已经制作了新涂装,请与我们联系 (info@) 。

我们可以把它上传到Wilco 出版社的网站上。

a380缩略语手册(中国南方航空) a380 abbrv 汇总

A Amber琥珀色A Air空气A Alternate备用的A Area区域，范围，面积A.ICE Anti-ice防冰A.ICE Anti-icing防冰A/BRK Autobrake自动刹车A/C Aircraft飞机A/COLL Anti-Collision防撞A/D Analog/Digital模/数A/DC Analog-to-Digital Converter模/数转换器A/F Auto Flight自动飞行A/G Air to Ground空/地A/L Airline航线；航空公司A/N Alphanumeric字母/数字的A/N SIZE Alpha Numeric Size字母/数字尺寸(大小)A/P Airport机场A/R Audio Reproducer放音机A/S Airspeed空速A/S Auto Stabilization自动安定；自动稳定(性) A/SKID Anti-Skid防滞A/STAB Auto Stabilizer 自动安定面；自动稳定装置,自动稳定器A/T Adjustment/Test调节/测试A/THR Autothrust自动推力A/XFMR Autotransformer自耦变压器AA Airworthiness Authorities适航管理局;适航当局AA Arithmetical Average算术平均值AAA Airworthiness Approval Attestation适航批准证明,适航批准认证AAAH Airbus Approved Abbreviations Handbook空客批准缩写手册AAC Airline Administrative Communications航空行政通讯AADC Analog Air Data Computer模拟大气数据计算机AAL Above Aerodrome Level高于机场水平面的高度AAMG Airbus Application Management Group空客应用软件管理小组AAP Additional Attendant Panel附加乘务员面板AAR Air-to-Air Refueling空中加油ABBR Abbreviation缩写ABCD Airbus Collective Data Dictionary空客收集数据词典ABCM Alternate Brake Control Manifold备用刹车控制总管ABCU Alternate Braking Control Unit备用刹车控制组件ABD Airbus Directive and Procedure空客指令和程序ABDC Avionics Broadcast Data Collector电子广播数据采集器ABEC Airbus (Beijing) Engineering CentreCompany Limited空客（北京）工程技术中心有限公司ABM APU Build-up Manual APU装配手册ABM Abeam正切ABN Abnormal不正常的ABNORM Abnormal不正常的ABRN Airborne机载的；在空中ABS Autobrake System自动刹车系统ABS VAL Absolute Value绝对值第 1 页，共 92 页ABSELV Alternate Brake Selector Valve备用刹车选择活门ABSORB Absorber减震器，缓冲器ABV Above在...之上，高于；上述，上文AC Airplane Characteristics for AirportPlanning用于机场计划的飞机特性；适应机场的飞机特性AC Alternating Current交流电AC Advisory Circular咨询通告ACARS Aircraft Communication Addressing andReporting System飞机通信寻址和报告系统ACAS Airborne Collision Avoidance System机载防撞系统ACAU ARINC600 Connecting Assembly Unit ARINC600连接装配组件ACC Active Clearance Control主动间隙控制ACC Area Control Center区域管制中心，区调ACCEL Acceleration/Accelerate加速度/加速ACCESS Accessory附件, 零件ACCLRM Accelerometer加速度表ACCU Accumulator储压器ACCUR Accuracy准确性，精度ACD Additional Control Device附加的控制装置ACD Airframe Certification Document飞机取证文件ACD Airworthiness Certification Dossier适航取证档案ACDB Aircraft Component Data Base飞机部件数据库ACE Airbus Concurrent Engineering空客合作工程ACE Altimeter Control Equipment高度表控制设备ACFT Aircraft飞机ACFU Aircraft Check Follow Up飞机检查（定检）跟踪ACG Aircraft Center of Gravity飞机重心ACGS Aircraft GSM Server飞机GSM服务器ACI Avionics Communication Interface电子通讯接口ACIA Asynchronous Communications InterfaceAdaptor异步电子通讯接口适配器ACJ Advisory Circular-Joint联合咨询通告ACK Acknowledge感谢，承认；确认收悉ACL Aircraft Configuration List飞机构型清单ACM Air Cycle Machine空气循环机ACM Abbreviated Component Maintenance Manual简化部件维修手册ACM Aircraft Configuration Matrix飞机构型矩阵ACM Aircraft Conversion Manual飞机换算手册ACMB Aircraft Configuration Management Board飞机配置管理委员会ACMM Abbreviated Component Maintenance Manual简化部件维修手册ACMM Aircraft Configuration Meta Model飞机构型Meta模型ACMP Airframe Condition Monitoring Procedure飞机状态监控程序ACMR Aircraft Configuration Management Rules飞机构型管理标准ACMS Aircraft Condition Monitoring System飞机状态监控系统ACMT Aircraft Component Management Team飞机部件管理小组ACN Aircraft Classification Number飞机类别编号ACO Airworthiness Certification Office适航认证办公室ACO Automatic Call Out自动报告ACOB Automatic Call Out Box自动报告盒ACOC Air Cooled Oil Cooler空气冷却滑油冷却器ACP Area Call Panel区域呼叫面板第 2 页，共 92 页ACP Audio Control Panel音频控制面板ACP Altimeter Check Point高度表检查点ACQ Acquire获取，获得ACQN Acquisition获取，获得ACR Avionics Communication Router电子通讯路由器ACRIF ACR Instrumentation Function ACR仪表功能ACRT Additional Cross Reference Table附加交叉索引表ACS Access接近ACS Alternating Current Supply交流供电ACS Air Conditioning System空调系统ACSC Air Conditioning System Controller空调系统控制器ACT Active主动的，工作的，作动的ACT Additional Center Tank附加中央油箱ACT Activity活动ACTD Actuated(被)作动的;(被)驱动的ACTG Actuating作动ACTIV Active主动的，工作的，作动的ACTN Action动作ACTR Actuator作动筒ACTVN Activation作动;活动ACTVT Activate作动;使活动，引发ACU Air Cooling Unit空气冷却组件ACU Antenna Coupler Unit天线耦合器组件ACVR Alternating Current Voltage Ratio交流电电压比值，交流电压比ACWP Actual Cost of Work Performed实际工作成本AD Aerodrome机场AD Airplane Datum飞机基准面AD Airworthiness Directive适航指令A-D Airbus Deutschland空客德国公司)ADAM Airbus Spares Distribution and MaterialsSystem空客备件配送和航材系统ADAU Auxiliary Data Acquisition Unit辅助数据采集组件ADB Airport DataBase机场数据库ADB Area Distribution Box区域分配盒ADB Aeronautical DataBase航空数据库ADC Air Data Computer大气数据计算机ADC Airbus Delivery Centre空客交付中心ADCL Airworthiness Directives Compliance List适航指令符合性清单ADCN Avionics Data Communication Network航空电子数据通讯网络ADCOMS Advanced Configuration Management System先进的配置管理系统ADCSIP Acceptance and Delivery CustomerSatisfaction Improvement Programme验收和交付客户满意度提升计划ADD Addition加装ADD Additional附加的ADD Aircraft Description Data Base飞机描述数据库，飞机概述数据库ADD Aircraft Design Declaration飞机设计声明，飞机设计宣言ADD BY Added By被…附加；被增加ADF Automatic Direction Finder自动定向机ADG Air Driven Generator空气驱动发电机ADI Attitude Director Indicator姿态指引仪ADIRS Air Data/Inertial Reference System大气数据惯性基准系统第 3 页，共 92 页ADIRU Air Data/Inertial Reference Unit大气数据惯性基准组件ADJ Adjust调节ADJMT Adjustment调节ADL Airborne Data Loader机载数据装载机ADL Aircraft Data Loader飞机数据装载机ADM Air Data Module大气数据组件ADMZ Aircraft DeMilitarized Zone飞机非武装区域ADNS Airbus Document Numbering Service空客文档编号服务ADO Airbus Documentation Office空客文档办公室ADOPT Airbus Design and Operational Philosophyin Training空客培训设计和操作原理ADPM Aircraft Deactivation Procedures Manual 飞机偏差程序手册；飞机限动程序手册ADPTN Adaptation采用，应用；适配ADPTR Adapter适配器，转接器ADR Air Data Reference大气数据基准ADR Advisory Route咨询航路ADRES Aircraft Documentation Retrieval System飞机文件检索系统ADRS Address地址，寻址ADS Air Data System大气数据系统ADS Automatic Dependent Surveillance自动附属监控ADU Area Distribution Unit区域分配组件ADU Align Display Unit校准显示组件ADV Advisory咨询A-E Airbus Espana空客西班牙(公司) AEB Airline Engineering Bulletin航空公司工程通告AECMA The European Association of AerospaceIndustries欧洲航空航天工业协会AEDS Axle Equipment Drive Shaft轮轴设备传动轴AEDS Airbus Enterprise Directory Service空客企业目录服务AEEC Airlines Electronic EngineeringCommittee航空公司电子工程委员会AERO Aviation Routine Weather Report航空定期气象报告AES Aircraft Earth Station飞机地面站AESS Aircraft Environment Surveillance System飞机环境监视系统AESU Aircraft Environment Surveillance Unit飞机环境监视装置AEU Audio Electronic Unit音频电子装置AEVC Avionics Equipment Ventilation Computer电子设备通风计算机AEX Access Authorized访问授权；开启许可（电脑程序）AF Audio Frequency音频频率AF Acceptance Flight许可飞行AF All Freighter全货机AF DME Arc to Fixed Waypoint测距机扇面到固定航路点A-F Airbus France空客法国(公司)AFB Antifriction Bearing耐磨轴承AFC Automatic Frequency Control自动频率控制AFCS Automatic Flight Control System自动飞行控制系统AFDX Avionics Full Duplex Switched Ethernet航空电子全双向交换式以太网AFECU Automatic Fire Extinguishing ControlUnit自动灭火控制组件AFFECTD Affected受影响的第 4 页，共 92 页AFFIRM Affirmative肯定的，确定的AFIS Airline In Flight Information System航空公司飞行信息系统AFL Auto Flush自动冲洗AFM Aircraft Flight Manual飞机飞行手册AFMC Auxiliary Fuel Management Computer辅助燃油管理计算机AFMR Airframer机身AFN ATS Facilities Notification ATS设备通告AFR Airframe机身AFRS AirFRamer Shell机身外形，机身外壳AFS Automatic Flight System自动飞行系统AFSA Airbus France Standard Architecture空客法国公司标准体系AFTN Aeronautical Fixed TelecommunicationNetwork航空固定通讯网络AFTR After在…之后AFU Artificial Feel Unit模拟感觉装置，人工感觉装置AGB Accessory Gearbox附件齿轮箱AGB Angle Gearbox角齿轮箱AGC APU Generator Contactor APU发电机接触器AGC Automatic Gain Control自动增益控制AGE Aircraft Ground Equipment飞机地面设备AGG Airbus General Guide空客通用指南AGL Above Ground Level离地高度AGMT Augment扩大，增加AGP Alternate Gauging Processor备用测量处理器，备用测量仪AGS Air Generation System空气发生系统AGU Air Generation Unit空气发生装置AGW Actual Gross Weight实际总重AHP Anti-Hijacking Panel反劫机面板AHRS Attitude and Heading Reference System姿态和航向基准系统AHRU Attitude and Heading Reference Unit姿态和航向基准组件AI Anti-Icing防冰AIB Airbus Industrie空中客车工业公司AIBU Advanced Illumination Ballast Unit改进型照明镇流器组件AIC Access Illustration Cards接近图解卡AIC Airbus Integrated Company空客综合公司AICC Aviation Industry CBT Committee航空工业CBT委员会A-ICE Anti-Ice防冰AICU Anti Ice Control Unit防冰控制装置AID Aircraft Installation Delay飞机安装延期AIDA Airbus Industrie Drawing Access空客工业公司工程图访问AIDA Attestation Integrated Delta Aggregation综合变量集合认证AIDS Aircraft Integrated Data System飞机综合数据系统AIG Accident Investigation事故调查AIL Aileron副翼AIM Aircraft Integrated Maintenance飞机整体维护AIM/CRM Airbus Integrated Management/CockpitResource Management空客综合管理/驾驶舱资源管理AIM-FANS Airbus Interoperable Modular-Future AirNavigation Sys空客相互操作（模块）组件－新一代空中导航系统AIMI Avionics Information ManagementInterface电子信息管理界面第 5 页，共 92 页AIMS Airbus Improvement Management System空客改进管理系统AIMS Airbus Industrie Material Specification空客工业公司原材料明细表AIMS Airbus Inventory Management System空客资产管理系统AIN Airbus Integrated Network空客综合网络AINA Airbus North America空客北美洲公司AINS Aircraft Information Network System飞机信息网络系统AIP Attendant Indication Panel乘务员指示面板AIP Aeronautical Information Publication航空信息出版物AIPS Airbus Process Specification空客工艺规范AIQI Airbus Industrie Quality Instruction空客工业公司质量规程AIR Aircraft Inspection Report飞机检验报告AIRCOND Air Conditioning空调AIRMAN Aircraft Maintenance Analysis飞机维修分析AIS Audio Integrated System音频综合系统AIS Aeronautical Information Service航空信息服务AISI American Iron and Steel Institute美国钢铁协会AITM Airbus Test Method空客测试方法AL Airline航空公司ALERFA Alert Phase警告阶段，警戒阶段ALF Aft Looking Forward从后往前看ALHP Airframe Life-History Program机身寿命－经历提纲ALIGN Alignment对正，校准ALIGND Aligned对正，校准ALLWD Allowed允许的ALNA Airline Network Architecture航空公司网络体系结构ALPHA Angle-of-Attack迎角，攻角ALPHANUM Alphanumerical字母数字的ALPS Aircraft Lease Portfolio Securitisation飞机租赁文件保密ALS Approach Light System进近灯光系统ALSCU Auxiliary Level Sensing Control Unit辅助水平感觉控制组件ALT Altitude高度ALT ACQ Altitude Acquire高度获得ALT TO Alternate To作…的备用ALTM Altimeter高度表ALTN Alternate备用的ALTN Alternative备用的，可选的ALTU Annunciator Light Test Unit信号灯测试组件ALU Arithmetic and Logic Unit算术和逻辑组件AM Amplitude Modulation调幅AM Airbus Means and Methods Document空客方式和方法文件AMAT Aircraft Multi Purpose Access Terminal飞机多用途接近终端AMB Ambient周围的AMC Acceptable Means of Compliance可接受的执行方法AMDB Airport Mapping DataBase机场地图数据库AMI Airline Modifiable Information航线可变更信息AMJ Advisory Material-Joint联合航材咨询AMM Aircraft Maintenance Manual飞机维修手册AMM Ammeter电表AMP Amperage安培数AMP Ampere安培AMPL Amplifier放大器第 6 页，共 92 页AMS Air-ground Message Server空-地信息服务器AMS Aeronautical Material Specifications航空材料规范AMS Aerospace Material Specification空间（宇航）材料规范AMS Aircraft Modification Status飞机改装状态AMTOSS Aircraft Maintenance Task OrientedSupport System飞机维修工作支持系统，飞机维修工作定向支援系统AMU Audio Management Unit音频管理组件AN Air Navigation空中导航ANCE Announce通知，声明ANCU Anti-Noise Control Unit防噪控制组件AND Aircraft Nose Down飞机机头向下；飞机俯冲ANI Analog Input模拟输入ANLG Analogic模拟逻辑ANN Annunciator指示器，信号牌ANN LT Annunciator Light指示灯ANNCE Announce通知，声明ANNCMT Announcement通知，声明ANO Analog Output模拟输出ANPT Aeronautical National Taper Pipe Threads航空国家锥形管螺纹ANS Anti-Noise System防噪系统，隔音系统ANSA At Nearest Suitable Airport就近备降的机场ANSI American National Standards Institute美国国家标准协会ANSU Aircraft Network Server Unit飞机网络服务器组件ANT Antenna天线ANU Aircraft Nose Up飞机抬升；飞机机头向上AO Access Opening检修孔；接近口AOA Angle Of Attack迎角，攻角AOAS Angle of Attack Sensor迎角传感器AOC Airline Operational Control航空公司运行控制AOC Air Operator's Certificate航空营运许可证AOD Audio on Demand音频点播AOG Aircraft On Ground飞机停场AOHX Air/Oil Heat Exchanger空气/滑油热交换器AOLS Airbus On-Line Services空客在线服务AOM Aircraft Operating Manual飞机运行手册AOMT Airbus Onboard Maintenance Tool空客机载维护工具AOP Airbus Operational Plan空客运作计划AOT All Operator Telex所有操作者电传AP Autopilot自动驾驶AP Airborne Printer机载打印机AP Airbus Procedure空客程序AP Access point接近点AP/FD Autopilot/Flight Director自动驾驶/飞行指引仪APASHE Aircraft Publication Automated ShippingExpedite飞机出版物自动发货APC Area Positive Control区域绝对管制API Application Programming Interface应用程序界面API Application Programming Interface应用编程界面APLC Aircraft Power Line Conditioner飞机供电线路调节器APM ARINC Processing Module ARINC处理组件APM Aircraft Performance Monitoring Program飞机性能监控方案第 7 页，共 92 页APM Airport Planning Manual机场计划手册APP Appearance出现；外貌APP Approach Control-Approach Control Office进近管制-进近管制办公室APPL Application应用软件APPR Approach进近APPROX Approximately大约APPU Asymmetry Position Pick Off Unit不对称位置传感组件APQ Airline Pre-Qualification航线预限制APS Avionic Printing Specification航空电子印刷规范APS Absolute Pressure Sensor绝对压力传感器APS Aircraft Prepared for Service准备作勤务工作的飞机APS Auxiliary Power Supply辅助电源APU Auxiliary Power Unit辅助动力装置APU AFE APU Automatic Fire Extinguishing ControlUnit APU自动灭火控制组件AQP Advanced Qualification Program高级资格认证程序AR As Required按需AR Audio Reproducer放音机ARC Air Refueling Computer空中加油计算机ARG Arresting Gear or Hook制动齿轮或掣子ARINC Aeronautical Radio Incorporated航空无线电公司ARINC Aeronautical Radio, INCorporated航空无线电公司ARM Aircraft Recovery Manual飞机恢复手册ARM Airworthiness Review Meeting适航回顾会议ARMD Armed预位的ARMG Arming启动准备，预位ARMT Armament武器装备，军队ARN Aircraft Registration Number飞机注册号ARND Around在..周围；大约ARO After Receipt Order收到指令之后ARP Aerospace Recommended Practice航空推荐施工法ARP Aerodrome Reference Point - AirportReference Point航站基准点—机场参考点ARPT Airport机场ARR Arrival进港，到达ARR Arriving进港，到达ARS Airworthiness Review Sheet适航性回顾表ART Active Repair Time实际修理时间/主动修理时间ARTCC Air Route Traffic Control Centre 航路交通控制中心，航路流量管制中心ARTCLD Articulated铰接(的)ARTF Artificial人工的，模拟的ARU Aircraft Router Unit飞机路由器装置ARU Audio Reproducer Unit放音机组件ARV Alternate Refill Valve备用加油活门AS Airscoop空气进气口AS Airspeed空速ASA All Speed Aileron全速副翼ASA Audio and Sign Adapter音频/符号适配器ASAP As soon as possible尽快ASC APU Starter Contactor APU启动机接触器第 8 页，共 92 页ASCII American Standard Code for InformationInterchange美国信息交换标准代码ASCO Airbus Service Company Inc.空客服务有限公司ASD Accelerate Stop Distance加速停止距离ASDC Airline Service Data Collection航空公司服务数据收集ASE Airborne Support Equipment机载支援设备ASE Airbus Supplied Equipment空客提供的设备ASF Amperes per Square Foot安培/平方英尺，每平方英尺安培数ASG Airbus Security Group空客安全小组，空客安全委员会ASI Airspeed Indicator空速指示器，空速表ASIC Application Specific Integrated Circuits专用集成电路ASM Aircraft Schematics Manual飞机图解手册,飞机系统原理图手册ASM American Society for Metals美国金属协会ASMA Aircraft Systems Maintenance Aids飞机系统维护援助ASN Aerospatiale Norme (Standard)航空标准（标准）ASP Audio Selector Panel音频选择面板ASPSU Autonomous Standby Power Supply Unit自主备用电源组件ASR Airport Surveillance Radar机场监视雷达ASSY Assembly装配ASYM Asymmetric(al)不对称的AT Autothrust自动推力AT Autothrottle自动油门ATA Actual Time of Arrival实际到达时间ATA Air Transport Association of America美国航空运输协会ATAM Airbus Takeoff Analysis Module空客起飞分析组件ATB ATA 100 Breakdown ATA100细节分类ATC Air Traffic Control空中交通管制ATC Airbus Training Center空客培训中心ATCA Air Traffic Control Board空中交通管制委员会ATCDB Aircraft Technical Characteristics DataBase飞机技术特性数据库ATCH Attach(ment)附件,附属物ATCI Air Traffic Control and Information空中交通管制和信息ATCK Attack迎角ATCRB Air Traffic Control Radar Beacon空中交通管制雷达信标ATCSS Air Traffic Control Data Link SignallingSystem空中交通管制数据链信号系统ATD Actual Time of Departure实际出发时间ATD Aircraft Technical Definition飞机技术定义ATE Automatic Test Equipment自动测试设备ATEC Automatic Test Equipment Complex自动测试综合设备ATI Air Transport Indicator航空运输指示器ATIMS Air Traffic and Information ManagementSystem空中交通和信息管理系统ATIS Automatic Terminal Information Service自动终端信息服务ATLAS Abbreviated Test Language for AvionicsSystems电子系统简短测试语言ATLAS Abbreviated Test Language for AllSystems所有系统适用的简化测试语言ATM Air Traffic Management空中交通管理ATM Aircraft Transportability Manual飞机运输性手册,飞机运营手册第 9 页，共 92 页ATM Available Ton-Mile可用的吨-英里数ATMG Airbus Technical Management Group空客技术管理小组ATMS Advanced Text Management System先进的文档管理系统ATN Aeronautical Telecommunications Network航空无线电通讯网络ATO Authorization to Offer授权提供ATR Austin Trumbull Radio奥斯汀特兰伯尔电台ATRCCS Automatic Turbine Rotor ClearanceControl System自动涡轮转子间隙控制系统ATS Air Traffic Service空中交通服务ATS Autothrottle System自动油门系统ATS Airbus Technical Specification空客技术规范ATS Autothrust System自动推力系统ATSU Air Traffic Service Unit空中交通服务组件ATT Attitude姿态ATT Attitude Reference姿态基准ATTEN Attenuation衰减ATTND Attendant服务员,乘务员ATZ Aerodrome Traffic Zone机场交通区域AUD Audio音频AUDSWTGSYS Audio Switching System音频转换系统AUDSWTGUNIT Audio Switching Unit音频转换组件A-UK Airbus UK空客英国公司AUTH Authorize批准，授权AUTO Automatic自动的AUTOCAL Autocalibration自动校准,自动标定AUTOLAND Automatic Landing自动着陆AUW All-Up Weight空中总重，总飞行重量AUX Auxiliary辅助的AVAIL Availability可用性AVAIL Available可用的AVG Asset Value Guarantee资产价值保证AVG Average平均AVIONICS Aviation Electronics航空电子AVNCS Avionics航空电子设备AVOD Audio/Video on Demand音频/视频点播AVRS Audio/Video Recording System音频/视频记录系统AVS Avionics Ventilation System电子通风系统AWACS Advanced Warning (on) AircraftCommercial Sales改进的飞机商务销售警告AWB Air Waybill运单AWG American Wire Gage美国导线量规AWG Audible Warning Generator音频警告发生器AWL Aircraft Wiring List飞机导线清单AWLS All Weather Landing System全气象着陆系统，全天候着陆系统AWM Aircraft Wiring Manual飞机线路图手册AWS American Welding Society美国焊接协会AWY Airway航路;航空公司AX Longitudinal Acceleration纵向加速度AX Access Authorized访问授权，授权接近AY Lateral Acceleration横向加速度AZ Azimuth方位，方位角第 10 页，共 92 页AZ Vertical Acceleration垂直加速度AZFW Actual Zero Fuel Weight实际零油重量B Blue蓝色（的）B/B Back-Beam反向波束，后梁B/C Business Class公务舱B/D Bottom of Descent下降的末段，下降底点BAABI Basic Approved ATA Breakdown Index经批准的基本ATA分解索引BAC Battery to APU Contactor APU电瓶接触器BAF BITE Access Function自检接近功能BAF Baffle缓冲隔板BAFO Best and Final Offer最优和最后报价BAG Bandwidth Allocation Gap带宽分配间距BAL Basic Assembly Language基本汇编语言BARC Barometric Altitude Rate Computer气压高度速率计算机BARO Barometric气压的BAT Battery (Electrical)电瓶（电源）BATC Battery Contactor电瓶接触器BBAND Broadband宽带BBRG Ball Bearing球形轴承，滚珠轴承BC Baggage Container Train集装箱拖车BCC Bleed Control Computer引气控制计算机BCD Binary Coded Decimal 二进制编码的十进制计数法，二进制标出的十进位数BCDS BITE Centralized Data System自测中央数据系统BCF Brake Cooling Fan刹车冷却风扇BCL Battery Charge Limiter电瓶充电限制器BCM Backup Control Module备用控制组件BCN Beacon信标BCP Business Continuity Plan商务连续性计划BCRC Bulk Crew Rest Compartment散装货舱机组休息舱BCRU Battery Charge and Rectifier Unit电瓶充电与整流组件BCS Brake Control System刹车控制系统BCU Brake Control Unit刹车控制组件BCWP Budgeted Cost of Work Performed工作完成的费用预算BCWS Budgeted Cost of Work Scheduled计划工作的费用预算BDD BITE Description Document自检记述文件BDIE Base de Données Installation Electrique电气安装数据库BDLI Bundesverband der Deutschen Luft-undRaumfahrt Industrie德国航空航天协会BDSG BundesDatenSchutzGesetz (Federal DataProtection Act in Germany)德国联邦数据保护行动BEA Bureau d'Enquête Accident事故调查局BEL CRK Bellcrank摇臂，钟形曲柄BER Beyond Economical Repair非经济修理，超出修理价值BETW Between在…之间BEV Bevel斜面,斜角BEW Basic Empty Weight基本空重BFD Bi-Folding Door双边折叠门BFDAS Basic Flight Data Acquisition System基本飞行数据采集系统BFE Buyer Furnished Equipment买方提供设备第 11 页，共 92 页BFEMS BFE Management System BFE管理系统,买方提供设备管理系统BFO Beat Frequency Oscillator拍频振荡器BFR Buffer缓冲器，阻尼BG Build Group (Assembly Group)装配组BGC Build Group Component装配组部件BGM Boarding Music登机音乐BGS Build Group Stack-Up装配组分层BH Block Hours轮挡小时BHD Bulkhead舱壁, 隔板BIST Built-in Self Test机内自我测试BITE Built-in Test Equipment内装测试设备，自测设备BIU BITE Interface Unit自检接口组件BK Black黑色(的)BKFLW Backflow逆流,回流BKUP Backup备份（的）；备用的BL Bleed放气，引气BLC Basic Lines Catalog基本航线目录BLC BCRU Line Contactor BCRU（电瓶充电与整流组件）线路接触器BLES Brake Life Extension System刹车寿命延长系统BLG Body Landing Gear机身起落架BLK Black黑色(的)BLK Block阻塞BLKT Blanket隔热棉，毯BLOW Blower鼓风机BLST Ballast镇流器BLT Bolt螺栓，螺杆BLV Bleed Valve引气活门；放气活门BLW Below在…以下，低于BLWG Blowing吹风，鼓风BM Beam梁，桁条BMC Bleed Monitoring Computer引气／放气监控计算机BMI BITE Monitoring Interface自检监控界面BMP Bit MaP位图BMS Bulletin Météo Spécial特殊气象通告BND Bonded连接的，焊接的BNDG Bonding连接，焊接BNDRY Boundary边界，边缘；范围，极限BNR Binary二进制的BNR Binary Words二进制码BO Blocking Oscillator间歇振荡器BO Body Odour身体气味BOH Brake-Off Weight刹车重量，开始滑行时的重量BOT Begin of Tape磁带起始端BOT Bottom底部，末端BP Bottom Plug底部堵盖BPPU Back-up Position Pick-Off Unit备用位置获取组件BPR By-Pass Ratio旁通率BPS Backup Power Supply备用电源BPTU Brake Pedal Transmitter Unit刹车脚蹬传感组件第 12 页，共 92 页BR Brown褐色(的)BRC Brace支架,吊杆BRD Braid饰带,编织物BRDG Bridge桥，电桥BRG Bearing轴承BRK Brake刹车BRKNG Braking刹车BRKR Breaker跳开关，断路器BRKS Brakes刹车BRKT Bracket支架BRT Bright明亮的BRT Brightness亮度BSCS Braking and Steering Control System刹车和转弯控制系统BSCU Braking and Steering Control Unit刹车和转弯控制组件BSHG Bushing衬套BSU Beam Steering Unit梁转弯组件BT Bus Tie汇流条连接BTA Bogie Trim Actuator小车式起落架配平作动器BTAC Bus Tie Alternating Contactor汇流条连接转换接触器BTC Bus Tie Contactor汇流条连接接触器BTCC Bus Tie Continuous Contactor汇流条持续连接接触器BTCM Brake Temperature Compensation Module刹车温度补偿组件BTL Bottle瓶体BTMS Brake Temperature Monitoring System刹车温度监控系统BTMU Brake Temperature Monitoring Unit刹车温度监控组件BTN Button按钮，按键BTR Bus Tie Relay汇流条连接继电器BTS Base Transceiver Station基地收发站BTS Brake Temperature Sensor刹车温度传感器BTU British Thermal Unit英制热量单位BU Battery Unit电瓶组件BUS Busbar汇流条BVID Barely Visible Impact Damage可视撞伤BWS Body Wheel Steering机身轮子转弯BYDU Back-Up Yaw Damper Unit备用偏航阻尼组件BYP Bypass旁通C Celsius摄氏的C Centigrade摄氏温度的C Close闭合,关闭C Cyan蓝绿色,青色C Clear清晰的；消除；清洁C Cold (Electric Point)冷（电路指示）C Comparator比较器C Convertible可转换的c Equal Margin等幅C of A Certificate of Airworthiness适航授权C/B Circuit Breaker电路跳开关C/L Check List检查单C/M Command/Monitor指令、监控C/M Crew Member机组成员第 13 页，共 92 页C/O Change Over转换C/S Call Sign呼叫信号C/SSR Cost/Schedule Status Report成本/计划状态报告CA Cable Assembly电缆组件CA Cable电缆，钢索CA Constituent Assembly组装CA Certification Authority证书授权CA/CRL Certification Authority/CertificateRevocation List证书授权、证书废除单CAA Central Aviation Archive航空中心档案文件CAA Civil Aviation Authority民航当局CAATS Computer Assisted Aircraft TroubleShooting计算机辅助飞机故障排除CAB Cabin客舱CAB PRESS Cabin Pressurization客舱增压CAD Computer Aided Design计算机辅助设计CADB Component for Attestation Data Base数据库认证部件CADETS Computer Assisted DocumentationEducation Tutorial System计算机辅助文档教育教程系统CAG Circulation Aérienne Générale通用航空交通;一般空间交通CAGE Commercial And Government Entity商业和政府机构CAI Combustion Area Inspection燃烧区域检查CAL Calibration校验，校准CAL Calibrated校验的CALC Cargo Acceptance and Load Control货物验收和装载控制CAM Cabin Assignment Module客舱分配组件CAM Computer Aided Manufacturing计算机辅助制造CAM Customer Acceptance Manual客户验收手册CAN Controller Area Network控制器区域网CAN Canopy座舱盖CANC Cancellation取消CANC Cancel取消CANCD Cancelled已取消，取消的CANTIL Cantilever上反角；悬臂CAO Cargo Aircraft Only仅货机CAOA Corrected Angle Of Attack修正迎角CAOM Cabin Attendant Operating Manual客舱乘务员操作手册CAP Capacitor电容器CAPLTY Capability容量CAPT Captain机长CAR Cargo货舱CAR Civil Aviation Requirements民用航空要求CARE Common Airbus Requirements Engineering通用的空中客车公司工程要求CARE Continuing Airframe - Health Review andEvaluation整体机身-健康回顾和评估CARP Carpet地毯CAS Calibrated Air Speed校准空速CAS Calculated Air Speed计算空速CAS Collision Avoidance System防撞系统CAS Computed Air Speed计算空速CAT Category类别，分类，目录第 14 页，共 92 页英文缩写英文全称中文全称CAT Clear Air Turbulence晴空湍流，晴空颠簸CATCH Complex Anomaly Tracking and Search复杂异常跟踪与调查CAUT Caution警戒，注意CAX Compartment Air Extraction抽风舱(箱)CBAL Counterbalance补偿；抵消CBB Connexion By Boeing通过波音联系CBIT Continuous BITE连续自测试CBM Circuit Breaker Monitoring跳开关监控CBMF Circuit Breaker Monitoring Function跳开关监控功能CBMS Circuit Breaker Monitoring System跳开关监控系统CBMU Circuit Breaker Monitoring Unit跳开关监控组件CBO Cycles between Overhaul大修周期CBORE Counterbore埋头孔；扩孔；平头钻，镗孔CBR California Bearing Ratio加州轴承比CBS Cost Breakdown Structure结构疲劳损伤CBSV Cycles Between Scheduled Visits例行检查周期CC Current Comparator电流比较器CCB Configuration Control Board构型控制委员会CCB Change Control Board变更控制委员会CCC Crash Crew Chart坠毁机组图表;飞机坠毁机组图CCC Component Change Card部件更换卡CCC Configuration Control Committee构型控制委员会CCCP Compressor Cavity Control Pressure压气机内腔控制压力CCD Cursor Control Device光标控制装置CCG Cabin Configuration Guide客舱构型指引CCITT Consultative Committee InternationalTelegraphy & Teleph国际电传电话顾问委员会CCMD Configuration Conformity Management andDocumentation构型符合管理和文件CCMU Centralized Crypto Management Unit集中密码管理组件CCOM Cabin Crew Operating Manual客舱乘务组操作手册CCQ Cross Crew Qualification交叉驾驶资格CCR Credit Card Reader信用卡读卡机CCR Customer Change Register客户改变登记CCRC Cabin Crew Rest Compartment客舱机组休息间CCRM Cabin Crew Rest Module客舱机组休息间CCS Cabin Communications System客舱通讯系统CCW Counter Clockwise逆时针CD Compact Disk光盘CD Control Display控制显示CD Cold Drawn冷拔，冷拉伸CD Count Drag反向阻力，计算阻力CDAM Centralized Data Acquisition Module集成数据采集组件CDAU Centralized Data Acquisition Unit集成数据采集组件CDB Configuration DataBase构型数据库CDBT Component Design and Build Team部件设计和构造团队CDC Cargo Door Controller货舱门控制器CDDS Component Documentation Data System部件文件数据系统CDE Consumption Data Exchange Card消耗数据交换卡CDIM Component Data Instruction Manual部件数据说明手册第 15 页，共 92 页CDIS Customization Definition InformationSystem客户化定义信息系统CDL Configuration Deviation List构型偏离清单，外形缺损清单CDLCU Cockpit Door Locking Control Unit驾驶舱门锁控制组件CDLS Cockpit Door Locking System驾驶舱门锁系统CDP Compressor Discharge Pressure压气机出口压力CDR Critical Design Review临界设计检查CD-ROM Compact Disc - Read Only Memory光盘-只读内存CDS Component Documentation Status部件文档状态CDS Control and Display System控制和显示系统CDS Cold Drawn Steel冷拉伸钢CDSS Cockpit Door Surveillance System驾驶舱门监测系统CDSU Cockpit Door Surveillance Unit驾驶舱门监测组件CDT Cabin Door Trainer客舱门培训员CDU Center Drive Unit中央驱动组件CDU Control and Display Unit控制和显示组件CD-WD Component Data Working Document部件数据工作文件CE Central Entity中央机构CE Change Event变更事件CECAM Centralized Cabin Monitoring集中客舱监控CED Cooling Effect Detector冷却效果探测器CEET Cabin Emergency Evacuation Trainer客舱紧急撤离培训员CEL Component Evolution List部件变化清单CELLI Ceiling Emergency LED Light天花板紧急LED灯CEO Chief Executive Officer首席执行官，行政总裁CEPT Council of European Posts and Telegraphs欧洲邮政和电信理事会CER Contrôle Essais et Réception控制测试和接待CEV Centre d'Essais en Vol飞行测试中心CEV Clutch Electro Valve离合器电子活门CF Course to a Fixed Waypoint到某一固定航路点的航道CF Configuration File构型文件CFDIU Centralized Fault Display Interface Unit中央故障显示接口组件CFDS Centralized Fault Display System中央故障显示系统CFE Customer Furnished Equipment客户提供设备CFIT Controlled Flight Into Terrain可控的飞行撞地CFM Cable Fabrication Manual钢索制造手册CFM Cubic Feet per Minute每分钟立方英尺CFMI CFM International CFM国际发动机公司CFP Computerized Flight Plan计算飞行计划CFR Code of Federal Regulations联邦规章代码CFRP Carbon Fiber Reinforced Plastic碳纤维强化塑料CFS Cabin File Server客舱文件服务器CFS Cold Finished Steel冷凝钢CFT Call For Tender招标公告CFVCU Cargo Fire Verification Control Unit货舱火警测试控制组件CFVS Cargo Fire Verification System货舱火警测试系统CG Center of Gravity重心CGC Customer Ground Check客户地面检查CGCS Center of Gravity Control System重心控制系统CGM Computer Graphics Metafile计算机绘图文件CH Character特性第 16 页，共 92 页。

精益A380扫描仪使用说明书

第四章、常见问题............................................................................................. 23 扫描仪的连接 ............................................................................................................ 23
第一章、安装扫描仪.............................................................................................7 软件安装需求 .............................................................................................................. 7 硬件需求 ..................................................................................................................... 7 安装与设定扫描仪 ....................................................................................................... 7 第一步、解除扫描仪安全保护锁 ........................................................................................... 8 第二步、连接您的扫描仪和计算机 ....................................................................................... 8 第三步、安装软件 ................................................................................................................. 9 第四步、测试扫描仪 ........................................................................................................... 11 安装其它软件 ............................................................................................................ 12

1、下载文档前请自行甄别文档内容的完整性，平台不提供额外的编辑、内容补充、找答案等附加服务。
2、"仅部分预览"的文档,不可在线预览部分如存在完整性等问题,可反馈申请退款(可完整预览的文档不适用该条件!)。
3、如文档侵犯您的权益，请联系客服反馈,我们会尽快为您处理(人工客服工作时间：9:00-18:30)。

谢谢您。

要充分享受三维虚拟座舱，红外可以让您在飞行中控制您的视野，只需环顾几度。

目前最大的和最先进的商用客机，运输555名乘客超过8000海里！创建您自己的A380飞机涂装和颜色。

Track IR 3 Pro 可购买自 Wilco 出版 .如果您已经制作了新涂装,请与我们联系 (info@) 。

我们可以把它上传到Wilco 出版社的网站上。

5. 然后，选择涂装2. 启动发动机选项1使用CTRL + E, 默认的模拟飞行发动机启动顺序。

选项2要手动启动引擎，请参阅该小组的第一章完整的程序。

C. 机舱-主舱面Array1. 驾驶舱2. 头等舱3. 休息室-酒吧-图书馆-楼梯4. 商务舱5. 经济舱6. 商店-楼梯注：飞机内饰配置根据航空公司的要求。

为了移动和进入机舱内，我们已经包括了对工具的CD - ROM （目录：EXTRA / F1View ），也可以从我们的网站。

这个工具是善意所提供的飞行 1 。

此模块需要一个滚轮鼠标（滚轮的中心，也作为一个鼠标中心按钮）。

虚拟驾驶舱:∙鼠标滚轮前后移动∙CTRL+向前右移CTRL + 向后左移.∙SHIFT+向前上移SHIFT + 向后下移.∙CTRL+SHIFT+向前放大CTRL+SHIFT+向后缩小.当平移模式(按住鼠标滚轮) 在虚拟座舱内:∙移动鼠标向左，视野向左边.∙移动鼠标向右，视野向右边.∙移动鼠标向前，视野向右上.∙移动鼠标向后，视野向右下.此实用工具提供其他强大的功能。

我们建议您阅读的指示页包括在内。

D. 乘务员的声音Wilco Fleet : A380为您带来了一套数字化乘务员的声音。

他们是自动播放，或根据飞行员的要求。

∙ 欢迎辞1当门关闭时.∙欢迎辞2 当引擎启动时.∙ 系紧安全带当安全带标志开或关时∙酒吧开放当到达巡航高度. 巡航高度必须在起飞前编辑到FMGC. 它将计算航点的高度和在ND显示器显示垂直可视化.∙下降当飞机开始下降巡航高度.∙降落当飞机降落后接触地面时.E. A380 背景1. 什么是A380 独有的?∙目前为止最先进,最宽敞和最高效的飞机∙世界上第一种双层,双通道客机∙三客舱布局提供555个坐位(或更多)∙最大航程8000海里空中客车A380的设计与大约60个主要机场，以确保机场的兼容性并顺利进入服务。

空中客车A380提供了最社会和经济负责任的解决日益增长的空中交通和机场的拥挤。

另一种办法，进一步提高现有的飞机运能，不仅需要数十亿美元的投资，机场-在新的跑道，终端，甚至机场-而且也将有助于更大的拥挤和显着增加对环境的影响。

空中客车公司的观点已得到确认，通过全行业参与该方案从一开始通过已经显着的成功的A380飞机在市场上。

在结束12月13日，客户已宣布确认订单和承诺总数139架A380飞机，其中包括17个货机版本。

A380的家庭从基线客机可容纳555名乘客在三个舱，航程可达15000千米/8000海里。

该货机版本 A380F ，将携带150吨（ 33万磅）以上货物,航程10400千米 / 5,600海里左右。

拉伸，缩短和扩大范围变种的基线版本将适应市场需求。

A380飞机可以采用罗尔斯罗伊斯遄达900发动机或GP7200发动机的发动机联盟（通用电气和普惠的合资企业）。

凭借其较大的翼展给予更大的升力及新一代发动机， A380飞机可以起飞和降落距离不比其他大型飞机长。

它可以使用现有的跑道和它的周转时间可比其他大型飞机。

四架A380飞机-被用作试验机-空中客车公司在欧洲的网点现在正在按计划组装和生产的主要组成部分和其他3. 生产设施德国机身和垂直尾翼-商业设施，其中包括机舱内部安装，涂装，最后检查-疲劳试验法国中央翼盒-机身组装-安装和测试设备，其中包括液压系统，空调，燃料和电力系统-飞机机头部分-总装线英国设计和装配机翼和起落架-燃油系统测试-安装燃料，气动和液压系统和电线西班牙生产的飞机水平尾翼，后机身尾锥和腹整流罩。

其他国家也有助于A380飞机制造。

4. 机舱空中客车A380是空中客车飞机的运营通用系列的成员,与空客A320 ， A330和A340飞机类似的机舱及作业程序，为飞行员过渡培训提供方便，交叉飞行员资格飞行和混合机型飞行.泰雷兹航空电子设备开发和提供了8个高版本，高分辨率，150毫米x 200毫米（ 6英寸x 8英寸）的液晶显示器，并提供数字抬头平视显示器（ HUD ）。

美国的霍尼韦尔公司已经被选定为提供下一代新一代飞行管理系统，这将增加数据处理速度和图形用户界面的弹出式菜单和光标控制，而不是基于文本的界面。

霍尼韦尔还将提供卫星通信系统。

古德里奇将提供空中数据系统。

罗克韦尔柯林斯公司将提供通讯系统，包括甚高频和高频无线电台和多模接收机。

诺斯罗普格鲁门公司已经被选定为提供LTN - 101E惯性导航系统。

史密斯工业公司将负责提供视频管理系统将包括显示从驾驶舱门和机舱监控系统。

与L - 3航空录像机佛罗里达州将提供飞行数据和驾驶舱语音记录器。

5. 关于空中客车公司空中客车公司是EADS和BAE系统公司组成的一个财团公司。

EADS，是欧洲宇航防务集团，由法国马特拉宇航公司，德国戴姆勒克莱斯勒宇航和西班牙的CASA公司（前空中客车的成员）合并成立。

空中客车公司的现代和全面的产品线由四个非常成功的家族的飞机：在单通道A320系列飞机（ A318/A319/A320/A321 ），在宽体A300/A310系列，远程A330/A340型家族将不久将加入新的A350飞机，以及超远程，高容量的A380飞机家族。

空中客车公司独特的家族观念最大程度的确保空中客车飞机机体，机载系统，驾驶舱和处理特性的共同性，从而显著降低航空公司的营运成本。

这方面的民航技术，现在也正在投入使用在军事领域的A400M军用运输机计划。

根据全面负责空中客车军事，空中客车公司负责开发这一军用运输机，其第一架飞机于2008年组装于西班牙的塞维利亚。

这一方案将使用与空中客车相同的卓越核心，综合工程和方案的管理方法以及认证程序的任何其他空中客车公司的方案。

此外，空中客车公司提供新的解决方案，以满足全球的空中加油机/运输机与多用途加油运输机部队的不同需要。

6. 技术特点A380-800 A380-800F承载力典型的客运/货运负荷(吨) 555 152,4头等舱+ (商务舱+) 经济舱布局(22+96+437) N/A最大载客量853 N/ALD3航空集装箱数量38 -航程典型的客运/货运负荷(千米) 15000 10400动力系统44引擎数量Trent 900Trent 900选择引擎GP7200GP7200引擎推力(千牛顿)311340飞机规格飞机直径(米)7.14 (水平)7.14 (水平)总长度(米)72,772,7翼展(米)79,879,8总高度(米)24,124,1机翼面积(平方米)846846机翼弯曲(度)33,533,5典型巡航速度(马赫)0,850,85最大巡航速度(马赫)0,890,89重量以及燃料最大起飞重量(吨)560590最大着陆重量(吨)386427最大载重量(吨)84150最大燃料容积(升)310000310000日期开发日期十月2000十月2000首架交付航空公司春季2006夏季2008F. 空中客车A380 面板1. 大体面板布局主面板主要包括飞机的仪器:- 3个主飞行仪表: 主飞行显示器, 导航显示器和引擎/警告显示器o Primary Flight Display (PFD) 主飞行显示器o Navigation Display (ND) 导航显示器o Engine/Warning Display (E/WD) 引擎/警告显示器- The Flight Control Unit (FCU) 飞行控制单元- The EFIS Control Panel 电子飞行仪器系统控制面板- The Digital Standby Instruments 备用数字仪表- Others: Gear lever, altimeter setting, warning lights其他:起落架手柄,高度表设置,警告灯- 这4个电子飞行仪器系统: 系统显示(SD) 是唯一可见的虚拟座舱或作为弹出式窗口。

其他部分的面板都可以通过按键:- Shift-2 MCDU (多功能控制显示单元), 也被称为飞行管理计算机。

- Shift-3 顶板.- Shift-4 中央油门基座.2. EFIS 用法EFIS (PFD, ND, E/WD) 设计采用矢量图形技术。

为此, 他们完全没有任何质量缺失并且其亮度是完全可调.这张图片展示了ND的重要区域(绿色). 如果您在这个中心区按一下,这个EFIS将显示出一个弹出窗口. 然后，点击并拖动出绿色区域,你就可以移动EFIS 到周围. 如果你再点击一次中央绿色区域, 这个EFIS 将回到原来位置. 这同样适用于虚拟座舱视角.您还可以按下Shift-5, 6, 7 或8 来显示/隐藏PFD, ND, E/WD 和SD. 这同样适用于虚拟座舱模式和其他模式(卫星, 塔台, …)注: 当EFIS缩放在自己的窗口, 您可以取消，并显示在另一个显示器,如果你有。
