薄层层析板

薄膜层析是用作分离和辨识化学物质的层析分析方法中最具多样性的方法之一。

这是一个简单，快速且有效的分离工具，用作量化或质量分析。

身为全球市场的领导者，默克提供您值得信赖的TLC 产品，并拥有广泛的化学性质，尺寸和背景物质可以符合所有您应用的需要。

我们的薄膜板结合了机械性和表面同相性，呈现了不被干扰的分离效能。

供自动化使用的HPTLC 设立了质量控管中可信赖且快速分析的标准。

我们持续增加新的具创新性的产品以符合今日TLC 应用的需求。

为您的分离工作选择最好的TLC 板，进一步了解默克TLC 板如何能让您的实验结果比从前更值得信赖。

高效硅胶薄层层析板(HPTLC)TLC平板自制备用鬆散吸收剂超薄单石型硅平板(UTLC)制备级层析片(PLC)CN-, Diol-, NH2- 修饰硅平板(TLC和HPTLC)氧化铝薄层板(TLC)混合层平板(TLC)纤维素层析板(TLC and HPTLC)Concentrating Zone Plates (TLC, HPTLC和PLC)HPTLC特纯度平板Multiformat Plates (TLC和HPTLC)GLP平板(TLC和HPTLC)配套产品流动相经典硅胶薄层层析板(TLC)RP修饰硅平板(TLC和HPTLC)胜肽分析平板LiChrospher® 球状颗粒HPTLC平板高效硅胶薄层层析板(HPTLC)These HPTLC plates deliver fast and quantitative analysis of complexsamples for manual or automated use. Merck’s HPTLC silica plates wor kthree times faster than conventional TLC plates –and they’re moresensitive. This makes our HPTLC plates perfect for advanced separations.HPTLC and TLC plates use the same type of silica gel 60. But in HPTLC particle sizes range between 4-8 μm, and the mean particle size measures 5-6 μm. This yields a smoother surface and a higher separation power than conventional TLC plates. Highly compact sample bands (thanks to lower band diffusion) and an thin 200 µm layer translate into greatly enhanced sensitivity.目录编号产品105547 HPTLC silica gel 60 ( 高效硅胶层析板) 25 Aluminium sheets 20 x 20 cm105631 HPTLC Silica gel 60 ( 硅胶薄层层析板) 25 Glass plates 10 x 10 cm105641 HPTLC Silica gel 60 ( 高效硅胶层析板) 50 Glass plates 20 x 10 cm105633 HPTLC Silica gel 60 ( 高效硅胶层析板) 100 Glass plates 10 x 10 cm105556 HPTLC Silica gel 60 F254 ( 高效硅胶薄层层析板) 20 Aluminium sheets 5 x 7.5 cm105548 HPTLC Silica gel 60 F254 ( 高效硅胶层析板含荧光指示剂) 25 Aluminium sheets 20 x 20 cmIts small pore size of 100 Å provides larger surface area enabling additional105628 HPTLC Silica gel 60 F254 ( 硅胶薄层层析板含荧光指示剂) 25 Glass plates 10 x 10 cm105642 HPTLC Silica gel 60 F254 ( 硅胶薄层层析板含荧光指示剂) 50 Glass plates 20 x 10 cm105629 HPTLC Silica gel 60 F254 ( 硅胶薄层层析板含荧光指示剂) 100 Glass plates 10 x 10 cm105649 HPTLC silica gel 60 F254 ( HPTLC硅胶60 F254 ) Glass Plates 20 x 10 cm111764 HPTLC Silica gel 60 F254 AMD,extra thin ( 硅胶薄层层析板含荧光指示剂) 25 Glass plates 20 x 10 cm for AMD acc. to DIN 38407-F11115696 HPTLC Silica gel 60 F254s ( 硅胶薄层层析板含荧光指示剂亲水性处理) 25 Glass plates 20 x 10 cm105644 HPTLC Silica gel 60 Multiformat pre-scored to 5 x 5 cm ( 硅胶薄层层析板) 100 Glass plates 10 x 10 cm113749 HPTLC Silica gel 60 with concentrating zone 20 x 2.5 cm ( 高效薄层层析板) 50 Glass plates 20 x 10 cm115552 HPTLC Silica gel 60 WR F254s ( 硅胶薄层层析板含荧光指示剂亲水性处理) 25 Glass plates 20 x 10 cm112363 HPTLC Silica gel 60 WRF254s AMD extra thin ( 硅胶薄层层析板含荧光指示剂亲水性处理) 25 Glass plates 20 x 10 cm for AMD acc. to DIN 38407-F11105616 HPTLC Silica gel F254 ( 硅胶薄层层析板含荧光指示剂) 25 Glass plates 5 x 10 cm超薄单石型硅平板(UTLC)105007 UTLC Silica gel monolithic,10 µm ( 整体化硅胶层析板)制备级层析片(PLC)Preparative thin-layer plates allow users to separate samples that varygreatly in size –from grams down to milligrams. Available with orwithout a fluorescence indicator, PLC plates come as thin as 0.5 cm andas thick as 2 cm. They also use the same proven Merck silica-bindertechnology as in analytical TLC plates.In PLC, samples are typically applied as a band across the entire width of the plate. UV detection is used almost exclusively to render substances visible. To isolate the substance by extraction, users can simply scrape the spot from the layer.目录编号产品105788 PLC Aluminium oxide 60 F254, 1.5 mm ( 制备氧化铝层析板) 12 Glass plates 20 x 20 cm105726 PLC Aluminium oxide 150 F254, 1.5 mm ( 氧化铝制备层析板) 12 Glass plates 20 x 20 cm105744 PLC Silica gel 60 F254, 0.5 mm ( 硅胶薄层层析板含荧光指示剂) 20 Glass plates 20 x 20 cm113895 PLC Silica gel 60 F254, 1 mm ( 制备薄层层析板含荧光指示剂) 15 Glass plates 20 x 20 cm105717 PLC Silica gel 60 F254, 2 mm ( 硅胶薄层层析板含荧光指示剂) 12 Glass plates 20 x 20 cm105637 PLC Silica gel 60 F254+366, 2 mm ( 硅胶薄层层析板含254+366 荧光指示剂2mm ) 12 Glass plates 20 x 20 cm105434 PLC Silica gel 60 RP-18 F254s, 1 mm ( 制备层析板RP-18 含荧光指示剂) 15 Glass plates 20 x 20 cm113894 PLC Silica gel 60, 0.5 mm ( 薄层分析用硅胶片) 20 Glass plates 20 x 20 cm105745 PLC Silica gel 60, 2 mm ( 制备薄层层析板) 12 Glass plates 20 x 20 cmCN-, Diol-, NH2- 修饰硅平板(TLC和HPTLC)These plates tackle extraordinary separation challenges. Our NH2, CN,and diol-modified silica sorbents are less polar then conventional silicaphases, making them ideal for separating hydrophilic or chargedsubstances. Our moderately polar cyano- and diol-modified silica platescan be used for both normal phase and reversed phase systems.An alternative to PEI cellulose, amino-modified NH2 plates provide weak basic ion exchange characteristics with special selectivity for charged compounds. Most modified plates contain F254s, the blue fluorescent, acid stable UV indicator. Fluorescence quenching is used on samples that absorb shortwave UV at 254 nm.目录编号产品116464 HPTLC Silica gel 60 CN F254s ( 硅胶薄层层析板氰基含F254s荧光指示剂) 25 Glass plates 10 x 10 cm112668 HPTLC Silica gel 60 DIOL F254s ( 薄层分析用层析片) 25 Glass plates 10 x 10 cm105636 HPTLC Silica gel 60 DIOL F254s ( Diol薄层层析板含荧光指示剂) 25 Glass plates 20 x 10 cm112572 HPTLC Silica gel 60 NH2 ( 高效薄层层析板) 25 Glass plates 20 x 10 cm113192 HPTLC Silica gel 60 NH2 F254s ( 高效薄层层析板) 25 Glass plates 20 x 10 cm115647 HPTLC Silica gel 60 NH2F254s ( 高效薄层层析板NH2含荧光指示剂) 25 Glass plates 10 x 10 cm105533 TLC Silice gel 60 NH2 F254s ( NH2层析板含荧光指示剂) 20 Aluminium sheets 20 x 20 cm氧化铝薄层板(TLC)These plates are used to analyze basic and neutral compounds atdifferent pH levels.Depending on the pH range in question, professionals can choosebetween two kinds of aluminum oxide plates. Under aqueous conditions,basic aluminum oxide plates are best for separating basic compounds, while neutral plates are ideal for separating neutral compounds.Available with or without a fluorescence indicator, our TLC aluminum plates handle a wide variety of applications thanks to neutral and basic aluminum oxides with 60Å and 150Å pore sizes.目录编号产品105713 TLC Aluminium oxide 60 F254, basic ( 氧化铝薄层层析板含荧光指示剂) 25 Glass plates 20 x 20 cm105731 TLC Aluminium oxide 60 F254, basic ( 氧化铝薄层层析板) 100 Glass plates 5 x 20 cm105550 TLC Aluminium oxide 60 F254, neutral ( 氧化铝60薄层层析板含荧光指示剂中性) 25 Aluminium sheets 20 x 20 cm105581 TLC Aluminium oxide 60 F254, neutral ( 薄层层析用氧化铝片片含荧光指示剂中性) 25 Plastic sheets 20 x 20 cm105551 TLC Aluminium oxide 150 F254, neutral ( 氧化铝150薄层层析板含荧光指示剂中性) 25 Aluminium sheets 20 x 20 cm混合层平板(TLC)Kieselguhr is a natural diatomaceous earth that can used for theseparation of polar or moderately polar substance. Mercks mixed layerplates utilize a combination of classical silica gel 60 and kieselguhrproviding good separation properties for inorganic ions, herbicides andsome steroids.目录编号产品105568 TLC Kieselguhr F254 ( 硅藻土薄层层析板) 25 Aluminium sheets 20 x 20 cm105738 TLC Kieselguhr F254 ( 硅藻土薄层层析板) 25 Glassplates 20 x 20 cm105567 TLC Silica gel 60/kieselguhr F254 ( 硅藻土薄层层析板含荧光指示剂) 25 Aluminium sheets 20 x 20 cm纤维素层析板(TLC and HPTLC)Cellulose plates are used to analyze polar substances. An organicsorbent, cellulose is perfect for separating hydrophilic substances bypartition chromatography. Typical applications include the analysis of amino acids, carbohydrates, and phosphates as well as nucleic acid and nucleic acid derivatives. Merck offers cellulose plates in two grades: TLC for conventional and HPTLC for demanding, high-performance separations.目录编号产品116092 HPTLC Cellulose ( 高效薄层层析板) 25 Aluminium sheets 20 x 20 cm105787 HPTLC Cellulose ( 纤维素薄层层析板) 25 Glass plates 10 x 10 cm105786 HPTLC Cellulose ( 高效纤维素薄层层析板) 50 Glass plates 20 x 10 cm115035 HPTLC Cellulose F ( 高效薄层层析板) 25 Glass plates 10 x 10 cm115036 HPTLC Cellulose F ( 高效薄层层析板) 50 Glass plates 20 x 10 cm105552 TLC Cellulose ( 纤维素薄层层析板) 25 Aluminium sheets 20 x 20 cm105716 TLC Cellulose ( 纤维素薄层层析板) 25 Glass plates 20 x 20 cm105577 TLC Cellulose ( 纤维素薄层层析板) 25 Plastic sheets 20 x 20 cm105730 TLC Cellulose ( 纤维素薄层层析板) 50 Glass plates 10 x 20 cm105632 TLC Cellulose ( 纤维素薄层层析板) 100 Glass plates 10 x 10 cm105574 TLC Cellulose F ( 纤维素薄层层析板) 25 Aluminium sheets 20 x 20 cm105718 TLC Cellulose F ( 纤维素薄层层析板) 25 Glass plates 20 x 20 cm105565 TLC Cellulose F ( 纤维素塑料层析板) 25 Plastic sheets 20 x 20 cm105728 TLC Cellulose F ( 纤维素薄层层析板) 50 Glass plates 10 x 20 cmConcentrating Zone Plates (TLC, HPTLC和PLC)These plates allow users to quickly and easily apply any kind of sample,even large volumes of diluted samples.Merck concentrating zone plates are based on different adsorptionproperties of two adsorbents. The first is a large pore concentratingadsorbent where the samples are applied; the second is a selective layerfor separation. Regardless of the spots’ shape, size, or position, the sample always concentrates as a narrow band where the two adsorbents overlap and where the separation starts.目录编号产品113187 HPTLC Silica gel 60 F254 with concentrating zone 5 x 2.5 cm ( 高效薄层层析板) 25 Glass plates 5 x 10 cm113727 HPTLC Silica gel 60 F254 with concentrating zone 10 x 2.5 cm ( 高效层析硅胶片) 25 Glass plates 10 x 10 cm113728 HPTLC Silica gel 60 F254 with concentrating zone 20 x 2.5 cm ( 高效硅胶层析片) 50 Glass plates 20 x 10 cm115498 HPTLC Silica gel 60 RP-18 F254s with concentrating zone 20 x 2.5 cm ( 薄层层析板RP-18 含荧光指示剂) 25 Glass plates 20 x 10 cm115037 HPTLC Silica gel 60 RP-18 with concentrating zone 20 x 2.5 cm ( 高效薄层层析板) 25 Glass plates 20 x 10 cm for PAH determination acc. to DIN 38409-H13113748 HPTLC Silica gel 60 with concentrating zone 10 x 2.5 cm ( 高级率层析硅胶片) 25 Glass plates 10 x 10 cm113794 PLC Silica gel 60 F254, 0.5 mm with concentrating zone 20 x 4 cm ( 制备层析硅胶片含荧光指示剂) 20 Glass plates 20 x 20 cm 113792 PLC Silica gel 60 F254, 1 mm with concentrating zone 20 x 4 cm ( 制备层析硅胶片含荧光指示剂) 15 Glass plates 20 x 20 cm 113793 PLC Silica gel 60 F254, 2 mm with concentrating zone 20 x 4 cm ( 制备层析硅胶片含荧光指示剂) 12 Glass plates 20 x 20 cm 111846 TLC Silica gel 60 F254 with concentrating zone 10 x 2.5 cm ( 薄层分析用硅胶片) 50 Glass plates 10 x 20 cm105583 TLC Silica gel 60 F254 with concentrating zone 20 x 2.5 cm ( 60 F254s硅胶薄层层析板，浓缩区20 x 2.5 cm ) 25 Aluminium sheets 20 x 20 cm111798 TLC Silica gel 60 F254 with concentrating zone 20 x 2.5 cm ( 硅胶薄层层析板含荧光指示剂) 25 Glass plates 20 x 20 cm111845 TLC Silica gel 60 with concentrating zone 2.5 x 20 cm ( 60硅胶薄层层析板，浓缩区2.5 x 20 cm ) 25 Glass plates 20 x 20 cm 111844 TLC Silica gel 60 with concentrating zone 10 x 2.5 cm ( 薄层分析用硅胶片) 50 Glass plates 10 x 20 cm105582 TLC Silica gel 60 with concentrating zone 20 x 2.5 cm ( 硅胶薄层层析板) 25 Aluminium sheets 20 x 20 cmHPTLC特纯度平板添加到分类最爱Ideal for advanced pharmacopoeia applications, this high-performance plate keeps separations free of contamination. The plate is highly pure and exhibits minimal background, even with middle-polar solvent systems. Its separation performance is an exact match to the related HPTLC plate product. Based on the proven HPTLC 60 F254 plate, the HPTLC premium purity plate comes carefully wrapped in a special, plastic-coated aluminum foil. This prevents plasticizers (such as phthalates) from leaving deposits. Without the foil, the plasticizers could appear as an “unknown extra zone” when mid-polar solvent systems (such as toluene/ethyl acetate (95/5)) are in use, and they could be stained by derivatization reagents (such as anis aldehyde).目录编号产品105648 HPTLC Silica gel 60 F254 Premium Purity ( HPTLC Silica gel 60_F254 Premium Purity ) 50 Glass plates 20 x 10 cm Multiformat Plates (TLC和HPTLC)These pre-scored glass plates fold into smaller formats with just oneeasy snap of the fingers.目录编号产品105635 HPTLC Silica gel 60 F254 Multiformat pre-scored to 5 x 5 cm ( 硅胶高效层析板) ex Glass plates 10 x 10 cm105620 TLC Silica gel 60 F254 Multiformat prescored to 5 x 10 cm ( 硅胶薄层层析板含荧光指示剂含多种规格片) 25 Glass plates 20 x 20 cm,105608 TLC Silica gel 60 F254 Multiformat pre-scored to 5 x 20 cm ( 硅胶薄层层析板含荧光指示剂) 20 Glass plates 20 x 20 cmGLP平板(TLC和HPTLC)These plates feature individual laser coding for GLP applications.Designed for GLP applications, the tops of each of these plates bear anitem, batch, and individual plate number. As a result, lab professionalscan easily record and archive every plate they use. Based on provenMerck silica found in TLC and HPTLC plates, these GLP plates deliverequally unsurpassed separation performance.目录编号产品105564 HPTLC Silica gel 60 F254 GLP ( 硅胶薄层层析板含荧光指示剂GLP ) 25 Glass plates 10 x 10 cm105613 HPTLC Silica gel F254 GLP ( 硅胶薄层层析板含荧光指示剂GLP ) 25 Glass plates 20 x 10 cm105702 TLC Silica gel 60 F254 GLP 25 Glass plates 10 x 20 cm105566 TLC Silica gel 60 F254 GLP ( 硅胶薄层层析板含荧光指示剂GLP ) 25 Glass plates 20 x 20 cm经典硅胶薄层层析板(TLC)Silica gel is the universal adsorbent used in TLC. It allows to carry outalmost every type of separation by suitable choice of the mobile phase.Merck classical silica TLC plates are based on a combination of Mercksilica gel 60 and the addition of a unique polymeric binder resulting in avery adherent and hard surface that will not crack or blister and evenallow writing with a pencil on the surface without risk to damage the layer. The smooth and extremely dense plate surface ensures narrow bands for maximum separation efficiency with lowest background noise e.g. when performing scanning densitometry./classical-silica-tlc-plates-tlc/chinese/c_zWmb.s1LzOQAAAEWuOAfVhTlRP修饰硅平板(TLC和HPTLC)These plates serve two purposes: act as a pilot method for HPLC andallow to choose various solvent system for special separations.RP-modified silica layers from Merck are well suited for many separationchallenges that unmodified silica cannot overcome. These layers useaqueous solvent systems to separate extremely non-polar substances andanalyze particular polar substances that can adapt to ion-pair chromatography.What’s more, RP-modified silica layers are less dependent on atmospheric humidity. Unlike unmodified silica, RP-phases do not exhibit catalytic activity. This makes them the plates of choice for unstable substance that tend to experience oxidative degradation.目录编号产品113726 HPTLC Silica gel 60 RP-2 F254s ( 高效薄层层析板) 25 Glass plates 10 x 10 cm105914 HPTLC Silica gel 60 RP-18 ( 高效RP-18 薄层层析板) 25 Glass plates 20 x 10 cm113724 HPTLC Silica gel 60 RP-18 F254s ( 高级率逆相层析硅胶片) 25 Glass plates 10 x 10 cm114296 HPTLC Silica gel 60 RP-18 W ( 高效薄层层析板) 25 Glass paltes 10 x 20 cm113124 HPTLC Silica gel 60 RP-18 WF254s ( 高效薄层层析板亲水性处理含荧光指示剂) 25 Glass plates 10 x 10 cm113725 HPTLC Silice gel 60 RP-8 F254s ( 高效薄层层析板) 25 Glass plates 10 x 10 cm105746 TLC Silica gel 60 RP-2 ( RP-2 硅胶薄层层析板) 25 Glass plates 20 x 20 cm105747 TLC Silica gel 60 RP-2 F254 (silanized) 25 Glass plates 20*20cm ( TLC硅胶60 RP-2 F254硅烷化25玻板，20*20cm )115684 TLC Silica gel 60 RP-8 F254s ( RP-8薄层层析板含荧光指示剂) 25 Glass plates 5 x 10 cm115388 TLC Silica gel 60 RP-8 F254s ( 薄层层析板RP-8 含荧光指示剂) 25 Glass plates 20 x 20 cm115424 TLC Silica gel 60 RP-8 F254s ( 薄层层析板RP-8 含荧光指示剂) 50 Glass plates 10 x 20 cm105560 TLC Silica gel 60 RP-18 F254s ( 60 RP-18 F254s硅胶薄层层析板) 20 Aluminium sheets 5 x 7.5 cm105559 TLC Silica gel 60 RP-18 F254s ( RP-18薄层层析板含荧光指示剂) 20 Aluminium sheets 20 x 20 cm115685 TLC Silica gel 60 RP-18 F254s ( RP-18薄层层析板含荧光指示剂) 25 Glass plates 5 x 10 cm115389 TLC Silica gel 60 RP-18 F254s ( 薄层层析板RP-18 含荧光指示剂) 25 Glass plates 20 x 20 cm115683 TLC Silica gel 60 RP-18 F254s ( 薄层层析板) 50 Glass plates 5 x 20 cm115423 TLC Silica gel 60 RP-18 F254s ( 薄层层析板RP-18 含荧光指示剂) 50 Glass plates 10 x 20 cm胜肽分析平板At Merck, we’ve enhanced our ProteoChrom® plates to makeseparation highly efficient – especially when peptides and protein digestsneed to be analyzed.ProteoChrom® plates take performance to new levels. Applications arehighly reproducible thanks to optimized separation and staining procedures. With extra-thin 100µm layers, the plates are incredibly sensitive. They’re also perfect for use with aqueous solvent systems since they prove highly stable in water. For added convenience, our ProteoChrom® plates include easy-to-read and detailed protocols.目录编号产品105651 ProteoChrom® HPTLC cellulose plate ( 高效薄层层析板) for peptide analysis 10 x 10 cm105650 ProteoChrom® HPTLC silica gel 60 ( 高效薄层层析板) for peptid analysis 20 x 10 cm105655 ProteoChrom® Peptide Staining Kit ( 多肽染色套组) For 25 stainings of HPTLC platesLiChrospher® 球状颗粒HPTLC平板Unique HPTLC LiChrospher® plates are the first thin layerchromatography plates based on spherical silica particles. They offer theultimate in thin layer chromatography performance and speed enablinghigh throughput analysis of complex samples.HPTLC LiChrospher® plates guarantee:Fast separationsHighly compact spotsLower detection limitsHPTLC LiChrospher® plates are based on Merck proven spherical shaped silica 60 with a rather small particle size of 6-8 µm and narrow particle size distribution of 3-5 µm as it is normally used in HPLC. LiChrospher® posses the very similar broad selectivity as the respective HPTLC plate however plate height, separation numbers and velocity constants are significantly improved.目录编号产品105586 HPTLC LiChrospher® Silica gel 60 F254s ( 硅胶薄层层析板球状颗粒含荧光指示剂) 25 Aluminium sheets 20 x 20 cm115445 HPTLC LiChrospher® Silica gel 60 F254s ( 硅胶薄层层析板Lichrospher 含荧光指示剂) 25 Glass plates 20 x 10 cm105646 HPTLC LiChrospher® Silica gel 60 RP-18 WF254s ( 硅胶薄层层析板Lichrospher RP-18 含荧光指示剂亲水性处理) 25 Glassplates 20 x 10 cm105647 HPTLC LiChrospher® Silica gel 60 WRF254s AMD extra thin ( 硅胶薄层层析板Lichrospher 含荧光指示剂亲水性处理) 25 Glass plates 20 x 10 cm。
