前言设计是教学过程中的一个重要环节，通过设计可以巩固各课程理论知识，了解变电所设计的基本方法，了解变电所电能分配等各种实际问题，培养独立分析和解决实际工程技术问题的能力，同时对电力工业的有关政策、方针、技术规程有一定的了解，在计算绘图、编号、设计说明书等方面得到训练，为今后从事供电技术工作奠定基础。
第一章：课程设计任务一、设计题目：110KV/35KV/10KV变电所一次接线设计二、设计的原始资料1、本变电所是按系统规划，为满足地方负荷的需要而建设的终端变电所。
2、该变电所的电压等级为110/35/10kV，进出线回路数为：110kV：2 回35kV：4 回（其中1 回备用）10kV：12 回（其中三回备用）3、待设计变电所距离110kV系统变电所（可视为无限大容量系统）63.27km。
4、本地区有一总装机容量12MW的35kV出线的火电厂一座，距待设计变电所12km。
5、待设计变电站地理位置示意如下图：6、气象条件：年最低温度：－5℃，年最高温度：＋40℃，年最高日平均温度：＋32℃，地震裂度6 度以下。
7、负荷资料（1）正常运行时由110kV系统变电所M向待设计变电所N供电。
（2）35kV侧负荷：（a）35kV侧近期负荷如下表：序号用户名称用类别最大负荷（MW）1治炼厂I 5.52河西变II或Ⅲ15.5（b）在近期工程完成后，随生产发展，预计远期新增负荷6MW。
（3序号用户名称用类别最大负荷（MW）备注1机械厂Ⅲ 1.32医院I0.5有备用电源3河东变Ⅲ 2.54铁路用电I0.9有备用电源5化工厂II 2.06电机厂II 1.07水泥厂Ⅲ 1.08印染厂Ⅲ 1.29农用电Ⅲ0.5（a）近期负荷如下表：（b）远期预计尚有5MW的新增负荷注：（1）35kV及10kV负荷功率因数均取为cosΦ=0.85（2）负荷同时率：35kV：kt=0.910kV：kt=0.85（3）年最大负荷利用小时均取为T maX=3500小时／年（4）网损率取为A%=5%~8%（5）所用电计算负荷50kW，cosΦ=0.87三、设计任务1、进行负荷分析及变电所主变压器容量、台数和型号的选择。
