Pt-[HSO3-bvim]HSO4/SiO2双功能催化剂制备及其催化性能研究
崔咏梅, 王淑芳, 赵新强, 王延吉 (河北工业大学 化工学院, 天津 300130)
摘 要：针对离子液体固载中存在的使用物理方法固载的离子液体易流失的问题，采用化学键合的方法将离子液体固载于硅胶表面。合成了一种新型Brønsted酸性离子液体1-乙烯基-3-磺丁基咪唑硫酸氢盐([HSO3-bvim]HSO4)，并通过
自由基链转移反应将该酸性离子液体用化学键固定于氢硫基官能团化的硅胶表面，制备出了[HSO3-bvim]HSO4/SiO2固
体酸催化剂，再利用化学还原方法在该固体酸催化剂上负载金属铂，得到Pt-[HSO3-bvim]HSO4/SiO2双功能催化剂。采
用傅立叶红外光谱、核磁共振光谱、热重、元素分析和X射线衍射等方法对所制备的样品进行了结构表征。将该双功能催化剂应用于硝基苯催化加氢合成对氨基苯酚反应中，结果表明，其具有一定的催化活性。在85 ℃、4 h、0.4 MPa条件下，双功能催化剂可以多次重复使用，对氨基苯酚的收率大于3.1%。 关键词：铂-离子液体；双功能催化剂；结构表征；硝基苯；对氨基苯酚 中图分类号：O643.36；TQ426.6 文献标识码：A
Preparation and Catalytic Performance of Bi-Functional Catalyst Pt-[HSO3-bvim]HSO4/SiO2
CUI Yong-mei, WANG Shu-fang, ZHAO Xin-qiang, WANG Yan-ji (School of Chemical Engineering and Technology, Hebei University of Technology, Tianjin 300130, China)
Abstract: In order to solve the problem of ionic liquid leaking from its support, a chemical method was used to immobilize the ionic liquid on silica gel via covalent bond. A novel Brønsted type acidic ionic liquid 1-vinyl-3-sulfobutyl imidazolium hydrogen sulfate, [HSO3-bvim]HSO4, was synthesized. Then via free radical
chain transfer reaction, the [HSO3-bvim]HSO4 prepared was immobilized on silica gel functionalized by
sulphydryl to obtain [HSO3-bvim]HSO4/SiO2 solid acid catalyst. Finally, the metallic Pt was loaded on the
prepared solid acid catalyst by the chemical reduction method to obtain the bi-function catalyst Pt-[HSO3-bvim]HSO4/SiO2. The samples of prepared bi-function catalyst were characterized by FT-IR, NMR,
TG, elemental analysis and XRD, respectively. The hydrogenation of nitrobenzene to p-aminophenol (PAP) was used to evaluate the bi-function catalyst, and the results show that the PAP yield is higher than 3.1% under following conditions: hydrogenation temperature of 85℃, reaction time of 4 h and H2 pressure of 0.4 MPa. And
the bi-function catalyst can be reused for several times. Key words: Pt-ionic liquid; bi-functional catalysts; characterization; nitrobenzene; p-aminophenol
1 前 言 将均相前体固定在固体载体上是开发和制备非均相催化剂的一条重要路线，固载型催化剂具有易分离、回收和循环使用的优势[1]。
室温离子液体具有不挥发、高热稳定性、可设计性等特点，在催化、有机合成及萃取分离等领域应用广泛[2~4]。功能化Brønsted酸性离子液体是一类“可设计”的材料，因为其兼有固体酸无挥发和低腐蚀
收稿日期：2008-09-07；修订日期：2008-12-29。 基金项目：国家自然科学基金(20476022，20636030，20706011)；天津市自然科学基金(07JCZDJC00100)；河北省教育厅资助项目(2005005D)。 作者简介：崔咏梅(1969-)，女，河北石家庄人，河北工业大学博士生。通讯联系人：王延吉，E-mail：yjwang@hebut.edu.cn 618 高 校 化 学 工 程 学 报 2009年8月 图式1 [HSO3-bvim]HSO4离子液体的合成路线 Scheme 1 Synthesis route of [HSO3-bvim]HSO4 ionic liquid
H2SO4
O
NNS
O
O
+NN++
NN.3SO−4
HSO−SO3H
及液体酸流动性好、酸性位密度高和酸强度分布均匀等优点，已经在环境友好的酸催化方面表现出很大的潜力[5]。但是目前在用化学键将Brønsted酸性离子液体固定于固体载体上的研究极少，Qiao等[6]通过自
由基链转移反应首次将含有[CF3SO3]
−的酸性离子液体固定于氢硫基官能团化的硅胶表面，该体系可作为
酯化及硝基化反应的有效固相催化剂，催化剂的稳定性增强，产物的分离更容易，然而无论是酯化还是硝基化反应，都是相对简单的反应体系。 对氨基苯酚(PAP)是一种重要的化工原料及有机中间体，在医药和染料等行业中具有广泛的应用。尤其在医药工业中其需求量较大，主要用于扑热息痛和安诺明等药物的生产。硝基苯催化加氢法合成PAP，因其生产工序少，产品收率高，工艺条件也不十分苛刻，成为目前广泛采用的一种合成工艺，一般采用担载型金属铂作为加氢催化剂，如Pt/AC、Pt/SiO2及Pt/Al2O3等[7]。但该反应在硫酸溶液中进行，存在设
备腐蚀和酸液后处理等问题。为此，人们对固体酸负载Pt双功能催化剂上硝基苯加氢合成PAP反应进行了研究，试图用固体酸替代硫酸。武森涛等[8]以HF-SiO2、H-ZSM5及担载型杂多酸为载体制备了铂-
固体酸双功能催化剂，该催化剂在一定程度上降低了反应对硫酸浓度的要求，但在非酸性介质中催化剂的活性非常低。Chaudhari等[9]提出采用固体酸催化剂与Pt-S/C同时使用，将硝基苯与水混合后催化氢化，
也得到了PAP。所用的固体酸催化剂为离子交换树脂(Indion 130)，用量为3%~7%。硝基苯与水的物质量比为1:(5~7)，反应温度为50~100℃，反应压力为2.0 ~2.5 MPa，反应3 ~7 h，硝基苯转化率达97%，PAP收率为13.9％。Takayuki等[10]对金属-沸石型双功能催化剂上硝基苯气相加氢合成对氨基苯酚进行了研
究，发现Pt/HZSM-5具有最好的加氢和重排反应活性，在250℃条件下PAP收率最高为20%。马原辉[11]
制备了Pt-S2O82−/ZrO2催化剂，以水为反应介质，于反应温度150℃，氢气压力0.4 MPa条件下，Pt负载量为0.1%时，对氨基苯酚的收率为14.6%。可见，采用双功能固体酸催化剂虽然不使用硫酸，但目前仍存在反应条件苛刻、PAP收率较低及易失活等问题，并且，现有的研究表明，还未有人对双功能固体酸催化剂的重复使用进行探索。 本文设计合成了一种新型Brønsted酸性离子液体1-乙烯基-3-磺丁基咪唑硫酸氢盐([HSO3-bvim]HSO4，简称IL)，并通过自由基链转移反应首次将该酸性离子液体用化学键固定于氢硫基官
能团化的硅胶表面，制备出了[HSO3-bvim]HSO4/SiO2固体酸催化剂，再利用化学还原方法在该固体酸催
化剂上负载金属铂，得到Pt-[HSO3-bvim]HSO4/SiO2双功能催化剂。并将该双功能催化剂应用于硝基苯催
化加氢合成对氨基苯酚的反应中。
2 实验部分 2.1 [HSO3-bvim]HSO4/SiO2固体酸催化剂的制备
2.1.1 酸性离子液体[HSO3-bvim]HSO4合成
合成离子液体[HSO3-bvim]HSO4的反应式见图式1。将等摩尔的1-乙烯基咪唑和1,4-丁烷磺内酯在冰
浴中混合后于室温下搅拌72 h，得到白色两性离子固体，用无水乙醚洗涤、离心分离后真空干燥至恒重。将等摩尔的浓硫酸滴加到干燥后的两性离子中，在室温下反应4 h，用甲苯、乙醚洗涤后于40 ℃下真空干燥至恒重，得到[HSO3-bvim]HSO4离子液体，为褐色粘稠状液体。
2.1.2 3-巯丙基三甲氧基硅烷(MPS)改性硅胶(SiO2)制备
将10 g天津化工研究院生产的HV-01型SiO2加入到200 mL(2 mol⋅L
−1)的盐酸溶液中回流2 h，过滤
