Immobilization of glucose oxidase on Fe3O4SiO2 magnetic
生物分子固定化方法
生物传感器中生物组分的固定化方法生物传感器由两部分组成: 生物敏感元件与信号转换器。
生物传感器的选择性主要取决于敏感材料的选取,而灵敏度的高低则与转换器的类型、生物组分的固定化技术等有很大的关系。
因此固定化技术的发展就是提高传感器性能的关键因素之一。
生物传感器要呈现良好的工作性能, 其固定化技术应满足以下条件:(1) 固定化后的生物组分仍能维持良好的生物活性;(2) 生物膜与转换器须紧密接触,且能适应多种测试环境;(3) 固定化层要有良好的稳定性与耐用性;(4) 减少生物膜中生物组分的相互作用以保持其原有的高度选择性。
为了研制廉价、灵敏度高而且选择性好的生物传感器,固定化技术已成为研究者们努力探求的目标。
经过近20年的不懈探索,已建立了对各种不同生物功能材料的固定化方法。
1、1、3、1 物理吸附法此法就是通过生物分子的极性键、氢键、疏水键的作用将生物组分吸附于不溶性的惰性载体上。
文献已经报道了一些材料可用作吸附其它材料的载体,比如,石墨粉[25]、石墨-聚四氟乙烯[26]、活性碳[27]、离子交换树脂[28]等。
物理吸附法的特点就是方法简便、操作条件温与,缺点就是生物分子与载体表面的结合力弱,在表面进行任意取向的不规则分布,因此使制得的生物传感器容易发生生物分子的脱落与泄漏,从而造成传感器的灵敏度低,重现性差。
1、1、3、2 包埋法将生物组分与合成高分子经溶剂混合而使生物组分包埋于其中,制成敏感膜的方法称作包埋法。
采取的包埋方式通常包括凝胶包埋法与胶囊包埋法二种形式[29,30]。
包埋法的优点就是操作条件比较温与,膜的孔径与形状可随意控制,对生物组分活性的影响较小,缺点就是需控制很多实验因素,而且生物组分在聚合物膜内的活性会受到影响。
1、1、3、3 共价键合法将生物组分通过共价键与电极表面结合而固定的方法称作共价键合法。
该法就是利用基体表面进行活化处理,然后与生物组分偶联,从而使生物组分结合到基体表面。
