嵌入式课程设计电子词典硬件设计说明

上海电力学院嵌入式系统课程设计报告题目：电子词典的设计姓名：学号：院系：专业年级：同组成员：年月日一、实验内容及要求在LCD屏幕左侧绘制出单词输入框和释义显示框以及一个搜索键，右侧绘制4*4键盘按钮，模拟出简易电子词典的功能，按钮操作用触摸屏或键盘实现均可。

实现功能：（1）LCD屏幕上显示4*4键盘，显示单词及其翻译、例句。

（2）一个键可完成2个英文字母的输入，如左上角第一个键可实现输入a,b两个字母，第一次按下时为输入a，如果需输入b，只需连续快速按键两次即可。

（3）在输入完单词后，点击搜索键，即可在释义显示框中显示该单词的词性、中文解释、示例词组和句子等。

（4）当发现输入的单词在库中不存在时，可实现将该单词添加入库的操作。

二、设计思路（1）通过LCD显示模块画出电子词典操作界面。

（2）对应界面中各键的位置设置键盘对应键值。

（3）设定功能键，实现以下3个功能：①退格键：删除最后一位字母；②搜索∕保存键：对输入框的单词进行判断，若单词存在于词库中，则显示单词词性、词义、例句；若单词不存在则自动进行保存；③转换键：按下后，字母键输出对应的第二个字母。

（4）按键后赋值并显示。

三、软件构架四、模块分析（1）键盘模块流程图：源代码：/****************************************************************************** **************** File：keyboard.c* Author: embest* Desc：keyboard source code* History:******************************************************************************* **************//*--- include files ---*/#include "44b.h"#include "44blib.h"#include "def.h"#include "keyboard.h"#include "lcd.h"#include "dict.h"#ifndef KEY_INT#define KEY_INT#endif#ifndef BUT_INT#define BUT_INT#endif/*--- global variables ---*/int input_char,n=0;char word[20];int wordIndex=0;int x = 15;int num=0;int counter=0;/* keyboard control address */volatile UCHAR *keyboard_base = (UCHAR *)0x06000000;/*--- function declare ---*/void init_keyboard();void close_keyboard();void KeyboardInt(void);// __attribute__ ((interrupt ("IRQ")));void Eint4567Isr(void);// __attribute__ ((interrupt ("IRQ")));/*--- function code ---*//****************************************************************************** **************** name: Test_Keyboard* func: test keyboard* para: none* ret: none* modify:* comment:******************************************************************************* *************/void Test_Keyboard(){Uart_Printf("\n Keyboard Test Example\n");Uart_Printf("\n Please press one key on keyboard and look at LED ...\n");// init keyboardinit_keyboard();while(1);// close keyboard// close_keyboard();}/****************************************************************************** **************** name: init_keyboard* func: init keyboard interrupt* para: none* ret: none* modify:* comment:******************************************************************************* *************/extern void isrEINT1(void);extern void isrEint4567(void);void init_keyboard(){/* enable interrupt */rINTMOD = 0x0;rINTCON = 0x1;/* set EINT1 interrupt handler */rINTMSK =~(BIT_GLOBAL|BIT_EINT1|BIT_EINT4567);pISR_EINT1 = (int)isrEINT1;pISR_EINT4567 = (int)isrEint4567;/* PORT G */rPCONG = 0xffff; // EINT7~0rPUPG = 0x0; // pull up enablerEXTINT = rEXTINT|0x20; // EINT1 falling edge moderI_ISPC = BIT_EINT1|BIT_EINT4567; // clear pending bitrEXTINTPND = 0xf; // clear EXTINTPND reg}/****************************************************************************** **************** name: close_keyboard* func: close keyboard interrupt* para: none* ret: none* modify:* comment:******************************************************************************* *************/void close_keyboard(){pISR_EINT1 = NULL;pISR_EINT4567 = NULL;/* Mask interrupt */rINTMSK = rINTMSK | BIT_EINT1 | BIT_EINT4567;}/****************************************************************************** **************** name: KeyboardInt* func: keyboard interrupt handler function* para: none* ret: none* modify:* comment:******************************************************************************* *************/void KeyboardInt(void){int nTemp,i,j,k,m=0;char bbyte;rI_ISPC = BIT_EINT1; // clear pending bitchar pbyte[10];nTemp = key_read();if(nTemp > -1){// Lcd_Draw_HLine(10, 310, 80, WHITE, 50);input_char = nTemp;Lcd_DspAscII8x16(15,45,WHITE,word);switch(input_char){case 0:num=1;break;case 1:num=2;break;case 2:num=3;break;case 3:num=4;break;case 4:num=5;break;case 5:num=6;break;case 6:num=7;break;case 7:num=8;break;case 8:num=9;break;case 9:counter=1;break;case 10:counter=2;break;case 11:counter=3;break;case 12:m=1;Lcd_Draw_HLine(15+n-10, 15+n, 45, WHITE, 16); n-=10;word[wordIndex]='\0';wordIndex--;break;/*if(n==0){word[20]=0;wordIndex=0;Lcd_Draw_HLine(10, 310,85, WHITE, 160);}break;*/case 13:word[wordIndex]='\0';wordIndex=0;for(i=0;i<20;i++){if(strcmp(word,vocab[i].c)==0){j=0;k=i;break;}elsej=1;}if(j==0){//#ifdef Eng_vLcd_DspAscII8x16(15,40,BLUE,vocab[k].c);Lcd_DspAscII8x16(15,60,BLUE,vocab[k].d);Lcd_DspAscII8x16(15,80,BLUE,vocab[k].f);//#elseLcd_DspHz16(15,100,BLUE,vocab[k].e);//#endif}else{Lcd_DspHz16(15,120,BLUE,"未找到相应的单词"); DelayMs(600);Lcd_DspHz16(15,120,WHITE,"未找到相应的单词"); }break;case 14:word[wordIndex]='\0';wordIndex=0;for(i=0;i<20;i++){if(strcmp(word,vocab[i].c)==0){j=0;k=i;break;}elsej=1;}if(j==0){//#ifdef Eng_vLcd_DspAscII8x16(15,40,BLUE,vocab[k].c);Lcd_DspAscII8x16(15,60,BLUE,vocab[k].d);Lcd_DspAscII8x16(15,80,BLUE,vocab[k].f);//#elseLcd_DspHz16(15,100,BLUE,vocab[k].e);//#endif}else{if(20>x>0){for(i = 0; i < 20; i++)vocab[x].c[i]=word[i];word[i]='\0';Lcd_DspAscII8x16(15,40,BLUE,vocab[x].c);x++;}elsex=15;//Lcd_DspAscII8x16(15,45,BLUE,word);for(i = 0; i < 20; i++)word[i]='\0';}break;case 15://Lcd_Draw_Box(10,40,310,80,GREEN);break;}if(num!=0&&counter!=0){switch(3*(num-1)+counter-1){case 0:bbyte='a';break;case 1:bbyte='b';break;case 2:bbyte='c';break;case 3:bbyte='d';break;case 4:bbyte='e';break;case 5:bbyte='f';break;case 6:bbyte='g';break;case 7:bbyte='h';break;case 8:bbyte='i';break;case 9:bbyte='j';break;case 10:bbyte='k';break;case 11:bbyte='l';break;case 12:bbyte='m';break;case 13:bbyte='n';break;case 14:bbyte='o';break;case 15:bbyte='p';break;case 16:bbyte='q';break;case 17:bbyte='r';break;case 18:bbyte='s';break;case 19:bbyte='t';break;case 20:bbyte='u';break;case 21:bbyte='v';break;case 22:bbyte='w';break;case 23:bbyte='x';break;case 24:bbyte='y';break;case 25:bbyte='z';break;case 26:bbyte='y';break;}num=0;counter=0;if(m==0){word[wordIndex]=bbyte; wordIndex++;//n+=10;}Lcd_DspAscII8x16(15,210,BLUE,word);// Uart_Printf("Key is:%x \r",input_char);}}/****************************************************************************** **************** name: key_read* func: read key value* para: none* ret: key value, -1 -- error* modify:* comment:******************************************************************************* *************/inline int key_read(){int value;char temp;/* read line 1 */temp = *(keyboard_base+0xfd);/* not 0xF mean key down */if(( temp & KEY_VALUE_MASK) != KEY_VALUE_MASK){if( (temp&0x1) == 0 )value = 3;else if( (temp&0x2) == 0 )value = 2;else if( (temp&0x4) == 0 )value = 1;else if( (temp&0x8) == 0 )value = 0;while(( temp & KEY_VALUE_MASK) != KEY_VALUE_MASK) // releasetemp = *(keyboard_base+0xfd);return value;}/* read line 2 */temp = *(keyboard_base+0xfb);/* not 0xF mean key down */if(( temp & KEY_VALUE_MASK) != KEY_VALUE_MASK){if( (temp&0x1) == 0 )value = 7;else if( (temp&0x2) == 0 )value = 6;else if( (temp&0x4) == 0 )value = 5;else if( (temp&0x8) == 0 )value = 4;while(( temp & KEY_VALUE_MASK) != KEY_VALUE_MASK) // release temp = *(keyboard_base+0xfb);return value;}/* read line 3 */temp = *(keyboard_base+0xf7);/* not 0xF mean key down */if(( temp & KEY_VALUE_MASK) != KEY_VALUE_MASK){if( (temp&0x1) == 0 )value = 0xb;else if( (temp&0x2) == 0 )value = 0xa;else if( (temp&0x4) == 0 )value = 9;else if( (temp&0x8) == 0 )value = 8;while(( temp & KEY_VALUE_MASK) != KEY_VALUE_MASK) // release temp = *(keyboard_base+0xf7);return value;}/* read line 4 */temp = *(keyboard_base+0xef);/* not 0xF mean key down */if(( temp & KEY_VALUE_MASK) != KEY_VALUE_MASK){if( (temp&0x1) == 0 )value = 0xf;else if( (temp&0x2) == 0 )value = 0xe;else if( (temp&0x4) == 0 )value = 0xd;else if( (temp&0x8) == 0 )value = 0xc;while(( temp & KEY_VALUE_MASK) != KEY_VALUE_MASK) // releasetemp = *(keyboard_base+0xef);return value;}return -1;}/****************************************************************************** **************** name: Eint4567Isr* func:* para: none* ret: none* modify:* comment:******************************************************************************* **************/void Eint4567Isr(void){unsigned char which_int;Uart_Printf("\n SB2 or SB3 had pressed and light LED.");which_int=rEXTINTPND;rEXTINTPND=0xf; //clear EXTINTPND reg.rI_ISPC=BIT_EINT4567; //clear pending_bitif(which_int == 4) // SB2{Led_Display(0x0);Led_Display(0x1);}else if(which_int == 8) // SB3{Led_Display(0x0);Led_Display(0x2);}}（2）LCD模块流程图：源代码：/****************************************************************************** **************** File：lcd.c* Author: embest* Desc：LCD control and display functions* History:******************************************************************************* **************//*--- include files ---*/#include "lcd.h"//#include "bmp.h"#include "44b.h"/*--- global variables ---*/INT32U aLcdActiveBuffer[LCD_YSIZE][LCD_XSIZE/4];/*--- extern variables ---*/extern const INT8U aucTempBitmap[][76800];/*--- function code ---*//****************************************************************************** **************** name: Lcd_Init()* func: Initialize LCD Controller* para: none* ret: none* modify:* comment:******************************************************************************* **************/void Lcd_Init (void){rDITHMODE=0x12210;rDP1_2 =0xa5a5;rDP4_7 =0xba5da65;rDP3_5 =0xa5a5f;rDP2_3 =0xd6b;rDP5_7 =0xeb7b5ed;rDP3_4 =0x7dbe;rDP4_5 =0x7ebdf;rDP6_7 =0x7fdfbfe;// disable,8B_SNGL_SCAN,WDLY=16clk,WLH=16clk,rLCDCON1=(0x0)|(2<<5)|(MVAL_USED<<7)|(0x3<<8)|(0x3<<10)|(CLKVAL_COLOR<<12);// LINEBLANK=10 (without any calculation)rLCDCON2=(LINEVAL)|(HOZVAL_COLOR<<10)|(10<<21);rLCDCON3=0;// 256-color, LCDBANK, LCDBASEUrLCDSADDR1= (0x3<<27) | ( ((unsigned int)aLcdActiveBuffer>>22)<<21 ) | M5D((unsigned int)aLcdActiveBuffer>>1);rLCDSADDR2= M5D((((unsigned int)aLcdActiveBuffer+(SCR_XSIZE*LCD_YSIZE))>>1)) | (MVAL<<21);rLCDSADDR3= (LCD_XSIZE/2) | ( ((SCR_XSIZE-LCD_XSIZE)/2)<<9 );//The following value has to be changed for better display.rREDLUT =0xfdb96420; // 1111 1101 1011 1001 0110 0100 0010 0000rGREENLUT=0xfdb96420; // 1111 1101 1011 1001 0110 0100 0010 0000rBLUELUT =0xfb40; // 1111 1011 0100 0000rLCDCON1=(0x1)|(2<<5)|(MVAL_USED<<7)|(0x3<<8)|(0x3<<10)|(CLKVAL_COLOR<<12); // rPDATE=rPDATE&0x0e;rPDATE=0xfe;Lcd_Clr();}/****************************************************************************** **************** name: Lcd_Clr()* func: clear LCD screen* para: none* ret: none* modify:* comment:******************************************************************************* **************/void Lcd_Clr(void){INT32U i;INT32U *pDisp = (INT32U*)aLcdActiveBuffer;for (i = 0; i < (SCR_XSIZE * SCR_YSIZE / 4); i++){*pDisp++ = ALLWHITE;}}/****************************************************************************** **************** name: LcdClrRect()* func: fill appointed area with appointed color* para: usLeft,usTop,usRight,usBottom -- area's rectangle acme coordinate * ucColor -- appointed color value* ret: none* modify:* comment: also as clear screen function******************************************************************************* **************/void LcdClrRect(INT16 usLeft, INT16 usTop, INT16 usRight, INT16 usBottom, INT8U ucColor){INT32U i, j;INT8U *pDisp = (INT8U*)aLcdActiveBuffer;for(i=usTop;i<=usBottom;i++){for(j=usLeft;j<=usRight;j++){LCD_PutPixel(j, i, ucColor);}}}#ifdef MON_LCD/****************************************************************************** **************** name: LcdClrRect()* func: fill appointed area with appointed color* para: usLeft,usTop,usRight,usBottom -- area's rectangle acme coordinate * ucColor -- appointed color value* ret: none* modify:* comment: also as clear screen function******************************************************************************* **************/void LcdClrRect(INT16 usLeft, INT16 usTop, INT16 usRight, INT16 usBottom, INT8U ucColor){INT16 i=0;INT16 k,l;INT16 m;INT32U ulColor = (ucColor << 28) | (ucColor << 24) | (ucColor << 20) | (ucColor << 16) |(ucColor << 12) | (ucColor << 8) | (ucColor << 4) | ucColor;if((usRight-usLeft)<=8){for(i=usTop;i<=usBottom;i++){for(m=usLeft;m<=usRight;m++){LCD_PutPixel(m, i, ucColor);}}return;if((usLeft%8)==0)k=usLeft;else{k=(usLeft/8)*8+8;}if(( usRight%8)==0)l= usRight;else{l=( usRight/8)*8;}for(i=usTop;i<=usBottom;i++){for(m=usLeft;m<=(k-1);m++){LCD_PutPixel(m, i, ucColor);}for(m=k;m<l;m+=8){(*(INT32U*)(aLcdActiveBuffer + i * SCR_XSIZE / 2 + m / 2)) = ulColor;}for(m=l;m<=usRight;m++){LCD_PutPixel(m, i, ucColor);}}}#endif/****************************************************************************** **************** name: Lcd_Draw_Box()* func: Draw rectangle with appointed color* para: usLeft,usTop,usRight,usBottom -- rectangle's acme coordinate* ucColor -- appointed color value* ret: none* modify:* comment:******************************************************************************* **************/void Lcd_Draw_Box(INT16 usLeft, INT16 usTop, INT16 usRight, INT16 usBottom, INT8U ucColor){Lcd_Draw_HLine(usLeft, usRight, usTop, ucColor, 1);Lcd_Draw_HLine(usLeft, usRight, usBottom, ucColor, 1);Lcd_Draw_VLine(usTop, usBottom, usLeft, ucColor, 1);Lcd_Draw_VLine(usTop, usBottom, usRight, ucColor, 1);}/****************************************************************************** **************** name: Lcd_Draw_Line()* func: Draw line with appointed color* para: usX0,usY0 -- line's start point coordinate* usX1,usY1 -- line's end point coordinate* ucColor -- appointed color value* usWidth -- line's width* ret: none* modify:* comment:******************************************************************************* **************/void Lcd_Draw_Line(INT16 usX0, INT16 usY0, INT16 usX1, INT16 usY1, INT8U ucColor, INT16U usWidth){INT16 usDx;INT16 usDy;INT16 y_sign;INT16 x_sign;INT16 decision;INT16 wCurx, wCury, wNextx, wNexty, wpy, wpx;if( usY0 == usY1 ){Lcd_Draw_HLine (usX0, usX1, usY0, ucColor, usWidth);return;}if( usX0 == usX1 ){Lcd_Draw_VLine (usY0, usY1, usX0, ucColor, usWidth);return;}usDx = abs(usX0 - usX1);usDy = abs(usY0 - usY1);if( ((usDx >= usDy && (usX0 > usX1)) ||((usDy > usDx) && (usY0 > usY1))) ){GUISWAP(usX1, usX0);GUISWAP(usY1, usY0);}y_sign = (usY1 - usY0) / usDy;x_sign = (usX1 - usX0) / usDx;if( usDx >= usDy ){for( wCurx = usX0, wCury = usY0, wNextx = usX1,wNexty = usY1, decision = (usDx >> 1);wCurx <= wNextx; wCurx++, wNextx--, decision += usDy ) {if( decision >= usDx ){decision -= usDx;wCury += y_sign;wNexty -= y_sign;}for( wpy = wCury - usWidth / 2;wpy <= wCury + usWidth / 2; wpy++ ){LCD_PutPixel(wCurx, wpy, ucColor);}for( wpy = wNexty - usWidth / 2;wpy <= wNexty + usWidth / 2; wpy++ ){LCD_PutPixel(wNextx, wpy, ucColor);}}}else{for( wCurx = usX0, wCury = usY0, wNextx = usX1,wNexty = usY1, decision = (usDy >> 1);wCury <= wNexty; wCury++, wNexty--, decision += usDx ) {if( decision >= usDy ){decision -= usDy;wCurx += x_sign;wNextx -= x_sign;}for( wpx = wCurx - usWidth / 2;wpx <= wCurx + usWidth / 2; wpx++ ){LCD_PutPixel(wpx, wCury, ucColor);}for( wpx = wNextx - usWidth / 2;wpx <= wNextx + usWidth / 2; wpx++ ){LCD_PutPixel(wpx, wNexty, ucColor);}}}}/****************************************************************************** **************** name: Lcd_Draw_HLine()* func: Draw horizontal line with appointed color* para: usX0,usY0 -- line's start point coordinate* usX1 -- line's end point X-coordinate* ucColor -- appointed color value* usWidth -- line's width* ret: none* modify:* comment:******************************************************************************* **************/void Lcd_Draw_HLine(INT16 usX0, INT16 usX1, INT16 usY0, INT8U ucColor, INT16U usWidth){INT16 usLen;if( usX1 < usX0 ){GUISWAP (usX1, usX0);}while( (usWidth--) > 0 ){usLen = usX1 - usX0 + 1;while( (usLen--) > 0 ){LCD_PutPixel(usX0 + usLen, usY0, ucColor);}usY0++;}}/****************************************************************************** **************** name: Lcd_Draw_VLine()* func: Draw vertical line with appointed color* para: usX0,usY0 -- line's start point coordinate* usY1 -- line's end point Y-coordinate* ucColor -- appointed color value* usWidth -- line's width* ret: none* modify:* comment:******************************************************************************* **************/void Lcd_Draw_VLine (INT16 usY0, INT16 usY1, INT16 usX0, INT8U ucColor, INT16U usWidth){INT16 usLen;if( usY1 < usY0 ){GUISWAP (usY1, usY0);}while( (usWidth--) > 0 ){usLen = usY1 - usY0 + 1;while( (usLen--) > 0 ){LCD_PutPixel(usX0, usY0 + usLen, ucColor);}usX0++;}}/*--- extern variables ---*/extern INT8U g_auc_Ascii8x16[];/********************************************************************************************** name: Lcd_DspAscII8x16()* func: display 8x16 ASCII character string* para: usX0,usY0 -- ASCII character string's start point coordinate* ForeColor -- appointed color value* pucChar -- ASCII character string* ret: none* modify:* comment:******************************************************************************* **************/void Lcd_DspAscII8x16(INT16U x0, INT16U y0, INT8U ForeColor, INT8U * s){INT16 i,j,k,x,y,xx;INT8U qm;INT32U ulOffset;INT8 ywbuf[16],temp[2];for( i = 0; i < strlen((const char*)s); i++ ){if( (INT8U)*(s+i) >= 161 ){temp[0] = *(s + i);temp[1] = '\0';return;}else{qm = *(s+i);ulOffset = (INT32U)(qm) * 16; //Here to be changed tomorrowfor( j = 0; j < 16; j ++ ){ywbuf[j] = g_auc_Ascii8x16[ulOffset + j];}for( y = 0; y < 16; y++ ){for( x = 0; x < 8; x++ ){k = x % 8;if( ywbuf[y] & (0x80 >> k) ){xx = x0 + x + i*8;LCD_PutPixel(xx, y + y0, (INT8U)ForeColor);}}}}}}/*--- extern variables ---*/extern INT8U g_auc_Ascii6x8[];#define XWIDTH 6/****************************************************************************** **************** name: Lcd_DspAscII6x8()* func: display 6x8 ASCII character string* para: usX0,usY0 -- ASCII character string's start point coordinate* ForeColor -- appointed color value* pucChar -- ASCII character string* ret: none* modify:* comment:******************************************************************************* **************/void Lcd_DspAscII6x8(INT16U usX0, INT16U usY0,INT8U ForeColor, INT8U* pucChar) {INT32U i,j;INT8U ucTemp;while( *pucChar != 0 ){for( i=0; i < 8; i++ ){ucTemp = g_auc_Ascii6x8[(*pucChar) * 8 + i];for( j = 0; j < 8; j++ ){if( (ucTemp & (0x80 >> j)) != 0 ){LCD_PutPixel(usX0 + i, usY0 + 8 - j, (INT8U)ForeColor);}}}usX0 += XWIDTH;pucChar++;}}#ifndef Eng_v/****************************************************************************** **************** name: Lcd_DspHz16()* func: display chinese character string in 16x16 dot array* para: usX0,usY0 -- ASCII character string's start point coordinate* ForeColor -- appointed color value* pucChar -- ASCII character string* ret: none* modify:* comment:******************************************************************************* **************/extern const INT8U g_auc_HZK16[];void Lcd_DspHz16(INT16U x0, INT16U y0, INT8U ForeColor, INT8U *s){INT16 i,j,k,x,y,xx;INT8U qm,wm;INT32U ulOffset;INT8 hzbuf[32],temp[2];for( i = 0; i < strlen((const char*)s); i++ ){if( ((INT8U)(*(s+i))) < 161 ){temp[0] = *(s+i);temp[1] = '\0';break;}else{qm = *(s+i) - 161;wm = *(s + i + 1) - 161;ulOffset = (INT32U)(qm * 94 + wm) * 32;for( j = 0; j < 32; j ++ ){hzbuf[j] = g_auc_HZK16[ulOffset + j];}for( y = 0; y < 16; y++ ){for( x = 0; x < 16; x++ ){k = x % 8;if( hzbuf[y * 2 + x / 8] & (0x80 >> k) ){xx = x0 + x + i * 8;LCD_PutPixel( xx, y + y0, (INT8U)ForeColor);}}}i++;}}}#endif/****************************************************************************** **************** name: Lcd_Test()* func: LCD test function* para: none* ret: none* modify:* comment:******************************************************************************* **************/void Lcd_Test(void){int i, j;Uart_Printf("\n LCD display Test Example(please look at LCD screen)\n");/* initial LCD controller */Lcd_Init();/* clear screen */Lcd_Clr();/* draw rectangle pattern */#ifdef Eng_v // english versionLcd_DspAscII8x16(10,0,BLUE,"Embest S3CEV40");#elseLcd_DspAscII8x16(100, 50, RED, "2009073 20091989 ");Lcd_DspHz16(155, 70, RED, "马一鸣");Lcd_DspAscII8x16(100, 90, BLACK, "2009073 20091993 ");Lcd_DspHz16(155, 110, BLACK, "邓家坤");Lcd_DspAscII8x16(100, 130, BLUE, "2009073 20092022 ");Lcd_DspHz16(155, 150, BLUE, "蒋赵睿");DelayMs(500);Lcd_DspHz16( 100, 100, BLUE, "欢迎使用电子词典");Lcd_DspAscII8x16(100, 50, WHITE, "2009073 20091989 ");Lcd_DspHz16(155,70, WHITE, "马一鸣");Lcd_DspAscII8x16(100, 90, WHITE, "2009073 20091993 ");Lcd_DspHz16(155, 110, WHITE, "邓家坤");Lcd_DspAscII8x16(100, 130, WHITE, "2009073 20092022 ");Lcd_DspHz16(155, 150, WHITE, "蒋赵睿");DelayMs(500);Lcd_Clr();Lcd_DspHz16(15,15,BLUE,"电子词典");#endif//Lcd_DspAscII8x16(10,24,GREEN-55,"ShenZhen Embest Info&Tech Co.,LTD");Lcd_Draw_Box(5,30,115,180,GREEN);/*显示窗口*/Lcd_Draw_Box(5,190,75,230,GREEN);/*输入窗口*/Lcd_Draw_Box(75,190,115,230,GREEN);/*搜索键*/Lcd_Draw_Box(120,30,165,75,GREEN);/*abc*/Lcd_Draw_Box(170,30,215,75,GREEN);/*def*/Lcd_Draw_Box(220,30,265,75,GREEN);/*ghi*/Lcd_Draw_Box(270,30,315,75,GREEN);/*jkl*/Lcd_Draw_Box(120,80,165,125,GREEN);/*mno*/Lcd_Draw_Box(170,80,215,125,GREEN);/*pqr*/Lcd_Draw_Box(220,80,265,125,GREEN);/*stu*/Lcd_Draw_Box(270,80,315,125,GREEN);/*vwx*/Lcd_Draw_Box(120,130,165,175,GREEN);/*yz*/Lcd_Draw_Box(170,130,215,175,GREEN);/*选择1*/Lcd_Draw_Box(220,130,265,175,GREEN);/*选择2*/Lcd_Draw_Box(270,130,315,175,GREEN);/*选择3*/Lcd_Draw_Box(120,180,165,225,GREEN);/*back*/Lcd_Draw_Box(170,180,215,225,GREEN);/*ent*/Lcd_Draw_Box(220,180,265,225,GREEN);/*save*/Lcd_Draw_Box(270,180,315,225,GREEN);/* output ASCII symbol */Lcd_DspAscII6x8(90,210,BLACK,"scan");Lcd_DspAscII6x8(140,50,BLACK,"abc");Lcd_DspAscII6x8(190,50,BLACK,"def");Lcd_DspAscII6x8(240,50,BLACK,"ghi");Lcd_DspAscII6x8(290,50,BLACK,"jkl");Lcd_DspAscII6x8(140,100,BLACK,"mno");Lcd_DspAscII6x8(190,100,BLACK,"pqr");Lcd_DspAscII6x8(240,100,BLACK,"stu");Lcd_DspAscII6x8(290,100,BLACK,"vwx");Lcd_DspAscII6x8(140,150,BLACK,"yz");Lcd_DspAscII6x8(190,150,BLACK,"ch1");Lcd_DspAscII6x8(240,150,BLACK,"ch2");Lcd_DspAscII6x8(290,150,BLACK,"ch3");Lcd_DspAscII6x8(140,200,BLACK,"back");Lcd_DspAscII6x8(190,200,BLACK,"ent");Lcd_DspAscII6x8(240,200,BLACK,"save");Lcd_DspAscII6x8(290,200,BLACK," ");/*for (j = 0; j < 1000000 * 5; j++);while (1){for (i = 0; i < 5; i++){BitmapView320x240x256((INT8U*)(aucTempBitmap[i]));for (j = 0; j < 1000000 * 5; j++);}}*/}/****************************************************************************** **************** name: Lcd_Test_board()* func: LCD test function for board all test* para: none* ret: none* modify:* comment:******************************************************************************* **************/void Lcd_Test_board(void){int i, j;/* initial LCD controller */Lcd_Init();/* clear screen */Lcd_Clr();/* draw rectangle pattern */#ifdef Eng_v // english versionLcd_DspAscII8x16(10,0,BLUE,"Embest S3CEV40 ");#elseLcd_DspHz16(10,10,BLUE,"英蓓特三星实验平台");#endifLcd_DspAscII8x16(10,24,GREEN-55,"ShenZhen Embest Info&Tech Co.,LTD");// Lcd_Draw_Box(10,40,310,230,GREEN);// Lcd_Draw_Box(20,45,300,225,GREEN);// Lcd_Draw_Box(30,50,290,220,GREEN);// Lcd_Draw_Box(40,55,280,215,GREEN);/*for (j = 0; j < 1000000 * 5; j++);for (i = 0; i < 5; i++){BitmapView320x240x256((INT8U*)(aucTempBitmap[i]));for (j = 0; j < 1000000 * 5; j++);}*/}五、问题反馈1、在做键盘中断时会有一些键常常出现错误2、在输入键值是会有一些值输入后无法清零的现象出现3、一些键要求与设计不服的现象也会出现六、实验总结通过本次试验让我学会了嵌入式实验的基本操作方法和相关应用技巧，学会了相关编程的基本思路和方式，，试验中遇到了很多的困难和问题，操作起来确实不易，但最终我们克服了这些困难成功实现了预期目标。
