浅谈车载网络为了在提高性能与控制线束数量之间寻求一种有效的解决途径,在20世纪80年代初，出现了一种基于数据网络的车内信息交互方式——车载网络。
车载网络采取基于串行数据总线体系的结构，最早的车载网络是在UART(Universal Asynchronous Receiver/Transmitter)的基础上建立，如通用汽车的E&C、克莱斯勒的CCD等车载网络都是UART在汽车上的应用实例。
由于汽车具有强大的产业背景，随后车载网络由借助通用微处理器/微控制器集成的通用串行数据总线，逐渐过渡到根据汽车具体情况，在微处理器/微控制器中定制专用串行数据总线。
20世纪90年代中期，为了规范车载网络的研究设计与生产应用，美国汽车工程师协会(SAE)下属的汽车网络委员会按照数据传输速率划分把车载网络分为Class A、Class B、Class C三个级别：Class A的数据速率通常低于20Kbps，如LIN，主要用于车门控制、空调、仪表板；Class B的数据速率为10Kbps～125Kbps，如低速CAN(ISO 11898)，主要是事件驱动和周期性的传输；Class C的数据速率为125Kbps～1Mbps，如高速CAN(ISO898)，主要用于引擎定时、燃料输送、ABS等需要实时传输的周期性参数。
拥有更高传输速率的MOST和FlexRay主要适用于音视频数据流的传输。
目前与汽车动力、底盘和车身密切相关的车载网络主要有CAN、LIN和FlexRay。
从全球车载网络的应用现状来看，通过20多年的发展，CAN已成为目前全球产业化汽车应用车载网络的主流。
CAN，全称为“Controller Area Network”，即控制器局域网，CAN 数据总线又称为CAN—BUS总线，20世纪80年代初由德国Bosch 公司开发，作为一种由ISO定义的串行通讯总线，其通信介质可以是双绞线、同轴电缆或光导纤维。
