HLC系列通用控制器安装使用说明
HLC系列通用控制器安装使用说明书北京海林自控设备有限公司目录一、HLC系列产品概述二、安全使用说明三、技术参数四、外形图及端子定义五、操作说明六、典型应用接线说明HLC系列通用控制器安装使用说明书一、产品概述我公司生产的HLC系列控制器是一种智能型，可编程的中小型通用型直接数字控制器，简称DDC。
其通用性很强，内部集成了多个不同类型的IO口以及10M/100M 以太网和RS-232/RS-485的通讯接口。
用户使用HBS楼宇自控系统的监控软件编辑好现场运行程序后，通过以太网下载到DDC后，DDC即可根据要求独立工作，又可与监控计算机或其他控制器联网使用。
DDC内置周计划时间控制程序、节假日控制程序、循环控制程序等，可以满足实际控制的各种要求。
应用范围：非常适合应用于暖通空调系统中新风机组或空调机组的全面控制，可以同时监控两个典型的空调机组，也可以用于冷热源系统的群控。
同时可应用于各种离散点的监控，适用暖通空调系统、变配电系统、给排水系统或照明系统的混合监控。
通过RS-232/RS-485接口，可以将其它厂家的一些智能产品接入控制系统。
特点：✧外壳采用金属材料，坚固、抗震。
上盖的面板指示灯与内部电路板采取柔性连接，上盖与底壳采用铰链连接，当需要开启上盖调整内部电路设置时非常方便。
✧可以采集电压、电流、电阻、电压脉冲等类型信号，并可以选择中值平均、一阶滞后等多种滤波算法。
✧可以采集无源、有源等开关类型信号，并可以记录开关次数、活动时间、最近改变时间等统计信息。
✧可以输出电压、电流、电压脉冲等类型的模拟控制信号。
并提供控制级别机制。
✧可以输出无源、有源0－5V、有源0－10V等开关类型控制信号。
提供开关次数、活动时间、最近改变时间等统计信息；提供控制级别机制；提供最小开关时间机制；设置输出极性等。
✧可以进行PID控制，并提供限位PID、积分分离、带死区的PID控制等多种控制算法。
✧可以提供优化起停控制策略。
