mAT-125E使用说明
mAT-125E短波全自动天线调谐器磁保持版说明书
第一部分 天调的链接
首先感谢您选择mAT的产品，我们会不断的努力，为您提供更好的Ham用设备，感谢您的支持！
重要安全警告：不仅仅是mAT-125E，包括任何天调在调谐工作时，请一定要设置您的发射机发射功率到
不高于10瓦的小功率，否则可能致使您的发射机损坏。QRP等小功率机器则需要设置到发射功率的1/10。
连接说明：
1、不使用额外驻波表时的连接示意图，请按照如图连接，连接不正确可能导致调谐失败。
2、 使用额外驻波表时的连接示意图，请按照如图连接，连接不正确可能导致调谐失败。
3、 该调谐器不需要控制线，可以配合任意型号的短波电台工作。
4、 使用50欧的连接跳线把调谐器的RF IN座和发射机的ANT座连接，再把天线连接到调谐器的ANT座即可。
5、 如果您使用额外的驻波表，驻波表要连接在调谐器和电台之间。
6、 不建议使用巴伦，因为这样可能导致调谐失败。
7、 尽量连接接地良好的地线。如果使用长线天线，良好的地线非常重要。没有条件接地的情况下，可以连接至少一条
和天线长度相当的导线做地网垂在窗户下或者扔在地上，代替接地
第二部分 天调的使用
1、 mAT-125E天调最大的特点就是采用磁保持继电器，具有省电的有点，同时调谐结束后可以关掉电源，以节省电量。
天调内置两节大容量18650锂电池，无需外接电源即可长时间持续工作。当电池由于年久失效后，更换两节通用锂电池即可继
续使用，维护成本极低。天调所需18650锂电池不带保护板，天调电路自带保护功能，如果更换成带保护板的锂电池，可能会
无法工作。当在1分钟内没有任何操作，并且没有射频信号输入时，天调会自动关掉电源，以延长电池续航时间， 天调关闭后，
不会影响已经调谐好的配置。
2、 mAT-125E适用于3-50MHz，5-120W（PEP）功率的短波发射机。SSB模式时最大功率为120瓦；CW、FM、
RTTY、JT65等模式时为80瓦，短时可到120瓦。
3、 使用时，首先按POWER键，打开天线调谐器电源，待前面板指示灯自检稳定后，Tune灯点亮。
4、把发射机设置为CW、RTTY或者FM模式，功率设置为5瓦，如果您使用小功率（QRP）的发射机，也可以使用更小
的功率（0.5W）调谐 。如果功率过大，调谐器会进入保护状态，不做调谐，同时3.0不断闪亮，提示输入功率过大。
5、按住并保持发射机的PTT键，使发射机向天线调谐器提供一个稳定的射频信号。此时如果天线调谐器处于全自动模式，
则会自动开始调谐；如果天线调谐器处于半自动模式，短按TUNE键即开始调谐。待调谐结束后，面板显示调谐后的驻波比。
6、如果调谐后驻波比小于1.5，2.0灯闪亮一次，提示天线调谐器已经把当前配置存入自身的内存中，断电后也不会丢失。
一次自动调谐后，通过手动按LUp、LDn、CUp、CDn四个键可以把驻波调整的更低。手动调节后，先按住TUNE键并保持，
再按CUp，2.0灯闪亮一次，即把当前配置手动存入天线调谐器内存中，下次调谐会自动调用驻波最小的配置数据。
7、如果要调谐器离线不做调谐，按Tune+CDn键即进入离线状态，再次按Tune+CDn退出离线状态参与调谐。
第三部分 注意事项
1、 请使用天调自带的充电器进行充电。使用其他充电器有可能会损坏天调，甚至引起火灾！天调切记不要直接输入13.8V
直流电源。为了防止误操作，天调的充电插口设计成非常用的直流电源插口。
2、 一般情况下，使用天线调谐器后，如果不能良好调谐，可以添加或者去掉巴伦后，再调谐。
3、天线调谐器正常工作时，最大允许输入120瓦功率（PEP，CW为60W）,输入过大的功率信号有可能造成损坏，这种
损坏不在保修范围内。调谐功率最大为10瓦，为了防止过大的调谐功率对调谐器的损害，当调谐功率超过10瓦时，调谐器进
入保护状态，不做调谐，同时3.0灯不停闪亮，提醒使用者输入调谐功率过大。
4、该调谐器有两种工作模式：半自动（默认模式，开机后1.5灯闪亮一次）、全自动（开机后1.5灯闪亮两次）。开机状态
下，先按住TUNE键并保持，再按LDn键，可以在两种模式之前切换，推荐使用半自动模式，1.5灯闪亮一次表示切换为半自
动模式；1.5灯闪亮两次表示切换为全自动模式。
5、推荐使用5瓦功率的CW、FW或RTTY信号进行调谐。当没有取得理想的驻波比时，可以适当加大调谐功率再次进行
调谐，但不要超过10W，。
6、如果您额外使用驻波表，请把驻波表连接在天线调谐器和发射机之间，不要连接到天线和天线调谐器之间。
7、当您首次使用或者更换了新的天线后，可以在每一个常用频率段均作一次调谐，以便调谐器记住这些配置，必要时可
以进行手动微调和手动存储。每一个新的频率段首次调谐需要几秒钟的时间，待调谐器记住这些配置后，下次调谐可在极短的
时间内完成。
8、当您从当前工作频率切换到另一个频率时，需要视驻波情况决定是否做重新调谐。
9、在关机状态下，先按住TUNE键并保持，再按FUNC（或者POWER）键开机，待2.0灯闪烁亮此后松开，即可清除
内存中已保存配置。
10、该天线调谐器为室内使用，不具有防水性能，不推荐室外使用。如果使用长线天线时，必须良好接地或连接足够长的
长线做地网。
11、任何天调（不仅仅是mAT-125）的调整能力都是有限的。根据使用的天线、环境的不同，不能保证所有频率都能良
好调谐。当在您希望的频率上不能良好调谐时，可以试着通过改变一下天线尺寸或者增减巴伦来改变一下天线系统阻抗后再尝
试调谐。
第四部分 常见天线的连接
长线天线和倒V电线的连接方法：
安全警告
天线调谐器、馈线和天线都是天线系统的一部分，所有类型的天线调谐器在工作时，这几部分都会向外辐射电磁波，有可
能对周围电子设备产生干扰，请做好相关抗干扰措施。
作为天线系统的一部分，如果没有良好的接地，天线调谐器工作期间其外壳和内部可能会带有较高的电压，为了安全起见，
请勿触碰，请勿打开外壳使用，并做良好的接地。
第五部分 关于天调的基础知识
以下知识适用于任何专用型和通用型自动天调，不仅限于mAT系列天调。如果您是第一次使用自动天调，请认真阅读。
1、 如果您要使用驻波表，请连接在短波机和天调之间，不要连接在天调和天线之间。
2、 天调使用时有两个功率要求：调谐功率和工作功率。调谐功率是指的天调开始调谐时，短波机为其提供的稳定的射
接天调ANT
ANT
RF
长线
良好接线或地网
天线调谐器
馈线 屏蔽网 芯线
频信号的功率，对于最大功率为100瓦的短波机，调谐功率一般不超过10瓦，以5瓦为宜； 工作功率是指当天调调谐完成，
并且驻波小于2时，其允许通过的最大功率，也就是正常工作的最大功率，如果超过了这个最大功率将有可能损坏天调。mAT-125
和mAT-125E天调的调谐功率为0.5-10瓦，工作功率最大为120瓦（PEP功率）。
3、 自动天调在调谐的时候，需要短波机向其提供一个适当大小，并且稳定的射频调谐信号才能完成正常调谐。在调谐
完成后，短波机就可以正常工作。短波机中能输出稳定射频信号的工作模式有CW、FM、AM、FSK、RTTY等。其中CW模式，
不同的机器有着不同的操作方式，有的机器直接按住PTT键就可以；有的机器需要连接并按下电键才行，请注意检查您的短波
机是哪有一种操作方式。另外，部分DIY的短波机没有CW工作模式，而是采用SSB+音频信号的方式模拟CW模式工作，对
于这种机器在使用天调的时候可能会有问题。 还有部分较高级的短波机（比如FT-897、FT-857）带有自动键功能，这时需要
关闭自动键，设置成手动键模式。
4、 如果您使用的是专用型天调，比如Yeasu、ICOM品牌的天调，配合相同品牌的短波机使用，当调谐开始时，短波
机会在其自身的CPU控制下，自动把工作模式临时改成FM模式，并把功率降低到5-10瓦，然后通过控制线向天调发送调谐
指令进行调谐，待调谐结束后，短波机的CPU又会自动把工作模式改回到调谐前的状态。
5、 如果您使用的是通用型天调，比如mAT-125，mAT-125E，LDG系列等，在调谐开始前，需要手动把短波机的功
率降低到5瓦，并把工作模式调整到上面第3条中说明的工作模式，然后开始调谐。待调谐结束后，再把短波机调整到您需要
的工作状态即可。
6、 任何天调的调整能力都是有限的，根据使用的天线、环境的不同，不能保证所有频率都能良好调谐。
7、 如果要使用单段倒V天线配合天调工作在短波全段，天线振子应选择12米（首选）或者7米。
8、 如果您的短波机有内置天调，使用外置天调时，记得一定要把内置天调关掉。
感谢您选择mAT的产品，欢迎您提出宝贵的意见和建议，以便于我们不断的完善我们的产品，为您提供更好的设备。
Bg3mzu 2014年6月
