Celtron

Double Ended Shear Beam FEATURES • Capacities 20K-125Klb • Free of horizontal movement • Insensitive to side load • Electroless nickel plated alloy tool steel • NTEP Class lllL 10000 approval from 20Klb to 125Klb

OPTIONAL FEATURE • FM approval available

APPLICATIONS • Truck/rail scales DESCRIPTION • Silo/hopper/tank weighing

• Fork-lift scales The double-ended mounting provides good restraint for

possible movement of the tanks and, in many cases, eliminates the need for check rods. The Shear Beam design gives excellent performance for high capacity loading.

CLB is constructed of alloy steel and is fully potted with special chemical compounds to IP67 providing excellent protection against moisture and humidity.

OUTLINE DIMENSIONS L2

R Rad R1 Rad D Dia

T

H2 H1 H Wiring diagram

+ Excitation - Excitation + Signal Red Black Green White L1

L W

- Signal

All Capacity Cable Length: 25'/7.6m

CAPACITY 20K/25Klb L L1 L2 W H H1 H2 D R R1 T mm (inch) mm 196.9 7.75 126.7 4.99 165.1 6.50 42.9 1.69 49.3 1.94 62.0 2.44 73.7 2.90 49.3 1.94 62.0 2.44 74.7 2.94 98.0 3.86 43.2 1.70 53.3 2.10 67.3 2.65 87.1 2.43 41.4 1.63 50.8 2.00 64.5 2.54 83.8 3.30 17.3 0.68 20.6 0.81 26.9 1.06 41.2 1.62 22.9 0.90 28.5 1.12 34.8 1.37 45.7 1.80 19.1 0.75 25.4 1.00 25.4 1.00 38.1 1.50 1/4-18NPT 1/4-18NPT 1/2-14NPT 1/2-14NPT 260.4 10.25 260.4 10.25 387.4 15.25 162.3 6.39 215.9 8.50 40Klb (inch)

mm 162.3 6.39 215.9

8.50 50K/60K/75Klb

100K/125Klb (inch)

mm 228.4 8.99 323.9

12.75 (inch) Model CLB Double Ended Shear Beam Celtron

SPECIFICATIONS PARAMETER VALUE UNIT NTEP/OIML Accuracy class Maximum no. of intervals (n) Y = Emax/Vmin NTEP IIIL 10000 multiple 14000 Non-Approved 1000 5000 Maximum available

lbs Standard capacities (Emax Rated output-R.O. Rated output tolerance Zero balance ) 20K, 25K, 40K, 50K, 60K, 75K, 100K, 125K

3.0 0.25 1 mV/V ±% of rated output ±% of rated output ±% of rated output ±% of rated output ±% of rated output ±% of rated output ±% of rated output ±% of rated output/°C ±% of applied load/°C °C Non linearity 0.025 0.025 0.02 0.030 0.030 Hysteresis Non-repeatability Creep error (20 minutes) Zero return (20 minutes) Temperature effect on min. dead load output Temperature effect on sensitivity Compensated temperature range Operating temperature range Safe overload 0.0010 0.0010 0.0026 0.0015 -10 to +40 -20 to +60 °C 150 % of R.C. Ultimate overload 300 % of R.C. Excitation, recommended Excitation, maximum 10 Vdc or Vac rms Vdc or Vac rms Ohms 15 770±10 Input impedance

Output impedance 700±5 Ohms Insulation resistance >5000 Mega-Ohms Construction Nickel plated alloy steel IP67 Environmental protection

All specifications subject to change without notice. FM Approval Intrinsically Safe: Class I, II, III; Div. 1 Groups A-G Non-Incendive: Class I; Div. 2 Groups A-D Legal Disclaimer Notice Vishay Precision Group
