pcb基础英语
pcb线路板专业英语(中英)
不定形的改變
amount
總量
amyl nitrite
硝基戊烷
analyzer
分析儀
anneal
回火
annular ring
環狀墊圈;孔環
anode slime (sludge)
陽極泥
anodizing
陽極處理
AOI ( automatic optical inspection )
自動光學檢測
applicable documents
補償
competitive performance
競爭力績效
complex salt
錯化物
complexor
錯化物
component hole
零件孔
component sid
conformance
密貼性
consumer products
消費性產品
contact resistance
1
* Process Module 說明 :
A. 下料 ( Cut Lamination) a-1 裁板 ( Sheets Cutting) a-2 原物料發料 (Panel)(Shear material to Size)
B. 鑽孔 (Drilling) b-1 內鑽 (Inner Layer Drilling ) b-2 一次孔(Outer Layer Drilling ) b-3 二次孔 (2nd Drilling) b-4 雷射鑽孔 (Laser Drilling )(Laser Ablation ) b-5 盲(埋)孔鑽孔 (Blind & Buried Hole Drilling)
K. 成型 (Profile)(Form)
PCB专业英语名词介绍
介面合金共化物
IMC (Inter Metallic Compound)
廣義上是指某些金屬相互接觸的介面間會產生一種原子遷移互動的行為,組成一種類似合金的化合物。在焊接領域上狹義上是指銅錫、金錫、鎳錫及銀錫之間的共合物(如:Cu6Sn5)
6
助焊作用
Fluxing
是利用一些具活性的化學品,如氯與溴的化合物混入鬆香中在高溫下把待焊的銅面或錫面予以清除干凈,以便外加工的熔融焊錫能焊牢在板子銅面上。此種化學品稱為“助焊劑”(FLUX)
40
熱應力試驗
thermal stress test
係取2in*2in各種厚度板材,有銅箔無銅箔分別試驗在288˚c的錫池表面漂浮10秒鐘洗凈后在正常視力下(左右眼各為2.0/2.0)檢查板面之外觀.
41
織紋隱現
weave texture
為基材中的玻璃纖維上的樹酯於壓合后或制程中受藥水的攻擊而造成減薄情形而從外觀可隱約見到玻纖的織點且呈現則性的點狀分佈稱之.
美國印刷電路板協會主要對各种工程技術及規範進行研究
26
ISO
International Organization for Standardization
國際標准化組織
27
粉紅圈
Pink-ring
多層板内層上的銅箔孔環與鍍通孔的孔壁互連處其孔環表面的黑化或棕化層受鑽孔機電鍍之影響以至後來被藥水浸蝕而擴散還原成爲不規則圈狀紅銅色的裸銅面稱之。
28
防焊堤
solder dam
指焊點週圍由綠漆厚度形成的堤岸,可心止高溫中溶錫流動縮所形成這短路
29
摺鍍
plating fold
電鍍過程中因鑽孔不良或鍍污染而造成孔內有長條狀異物附著,隨鍍液沉積形成包銅現象稱之。
PCB&FPC专业英语
PCB专用词语A aA.O.I(Automatic Optical Inspection) 自动光学检查Acceptable quality level (AQL) 可接受质量水平Accuracy 精确度Activating 活化Active carbon treatment 活性碳处理After Pressed Thickness 压板后之厚度Alignment 校直，结盟Annular ring 锡圈Anti-Static Bag 静电胶袋Apparatus 设备，仪器Area 面积Artwork 菲林Artwork Drawing 菲林图形Artwork Film 原装菲林Artwork Modification 菲林修改Artwork No. 菲林编号Assembly 组装，装配Axis 轴B bBackplane 背板Back-up 垫板Baking 烘板Ball Grid Array (BGA) 球栅阵列Bare board 裸板Base Copper 底铜Base material 基材Bevelling 斜边Black Oxide 黑氧化Blind via hole 盲孔Blistering 起泡/水泡Board Cutting 开料Board Thickness 板厚Bottom side 底层Breakaway tab 打断点Brushing 磨刷Build-up 积层Bullet pad 子弹盘Buried hole 埋孔C cC/M(Component Marking) 元件字符Carbon ink 碳油Carrier 带板Ceramic substrate 陶瓷Certificate of Compliance 合格证书Chamfer 倒角Chemical cleaning 化学清洗Chemical corrosion 化学腐蚀Chip Scale Package (CSP) 晶片比例包装Circuit 线路Clearance 间距/间隙Color 颜色Component Side(C/S) 元件面Composite layers 复合层Computer Aided Design (CAD) 电脑辅助设计Computer Aided Manufacturing (CAM) 电脑辅助制作Computer Numerial Control (CNC) 数控Conductor 导体Conductor width/space 导体线宽/线隙Contact 接点Copper area 铜面积Copper clad 铜箔Copper foil 铜箔Copper plating 电镀铜Corner 角线Corner mark 板角记号Corner REG.Hole 角位对位孔Cracking 裂缝Creasing 皱折Criteria 规格,标准Crossection area 切面Cu/Sn Plating 镀铜锡Current efficiency 电流效率Customer 客户Customer Drilling File 客户钻孔资料Customer P/N 客户产品编号D dD/F Registration Hole 干菲林对位孔D/F(Dry Film) 干膜Date Code 日期代号Datum hole 基准参考孔Daughter board 子板Deburring 去毛刺Defect 缺陷Definition 定义Delamination 分层Delay 耽搁Delivery 交货Densitomefer 透光度计Density 密度Department 部门Description 说明Design origin 设计原点Desmear 去钻污,除胶Dessicant 防潮珠Developer 显影液,显影机Diamond 钻石Diazo film 重氮片Dielectric breakdown 介电击穿Dielectric constant 介电常数Dielectric Thickness 介电层厚度Dielectric V oltage Test 绝缘测试Dimension 尺寸Dimensional stability 尺寸稳定性Direct/indirect 直接/间接Distribution 发放Document type 文件种类Documentation Control 文件控制Double sided board 双面板Drill bit 钻咀Drilling 钻孔Drilling Roughness 钻孔粗糙度Dry Film 干菲林Dry Film-Pattern 干膜线路Dynamic 动态E eECN(Engineering Change Notification) 工程更改通知Effective date 有效期Electrical Test Fixture 电测试针床Electro migration 漏电Electroconductive paste 导电胶Electroless 无电沉Electroless copper 无电沉铜Electroless Ni 无电沉镍Electroless Gold/Au 无电沉金Engineering drawing 工程图纸Entek 有机涂覆Epoxy glass substrate 环氧玻璃基板Epoxy resin 环氧基树脂Etch 蚀刻Etchback 凹蚀Etching 蚀刻E-Test Marking 电测试标记E-Test(Electrical Test) 电测试Exposure 曝光External layer 外层F fFiducial mark 基准点Filling 填充Film Fabrication 菲林制作Final QC 最终检查Finish Overall Board Thickness 成品总板厚度Fixture 夹具Flammability 可燃性Flash Gold 薄金Flexible 易曲的,能变形的Flux 助焊剂G gGeneral information 一般资料Ghost image 重影Glass transition temperature 玻璃化湿度Gold Finger(G/F) 金手指Golden board 金板Grid 网格Ground plane 地线层H hHAL(Hot Air Leveling) 热风整平Hand Rout 手锣Hardness 硬度Heat Sealed 热密封Heat Shrink-warp 热收缩Holding time 停留时间Hole 孔Hole breakout 破环Hole density 孔的密度Hole Diameter 孔径Hole location 孔位Hole Location Chart 孔位座标表Hole Position Tolerance 孔位误差Hole size 孔尺寸Hot Air Leveling(HAL) 热风整平Humidity 湿度IIdentification 标识,指标Image 影像Imaging transfer 图形转移Impedance 阻抗Impedance Test 阻抗测试Inner copper foil 内层铜箔Inspection 检验Insulation resistance Test 绝缘测试Inter Plane Separation 内层分离Interleave Paper 隔纸Internal layer 内层Internal stress 内应力Ionic cleanliness 离子清洁度Isolation 孤立Isolation Resistance 绝缘电阻Item 项目K kKEY board 按键盘Key slot 槽孔Kraft paper 牛皮纸L lLaminate 板材Laminate Thickness 材料厚度Lamination void 层间空洞Landless hole 破孔Laser plotter 激光绘图机Laser plotting 激光绘图Laser via hole 激光穿孔Layup 层压配本Lay-up Instruction 压板指示Legend 字符Legend Width 字符宽度Length 长度Lifted Lands 残铜Line Width 线宽Liquid 液体Logic diagram 逻辑图形Logo 唛头,标记Lot size 批卡Mesh 目数M mMark 标记Master drawing 菲林图形Material Thickness 材料厚度Material Type 材料类型Max. X-out 坏板上限Max.Board Thickness After Plating 电镀后总板厚度之上限Measling 白斑Mech Drawing No. 图纸编号Mechanical cleaning 机械清洗Metal 金属Method 方法MI(Manufacturing Instruction) 生产制作指示Microstrip 微条线Min Conductor Copper Thickness 最小线路铜厚Min Hole Wall Copper Thickness 最小孔壁铜厚Min. Gold Plating Thickness 最小金厚Min. Nickel Thickness 最小镍厚Min. Tin-Lead Thickness (After HAL) （喷锡后）最小锡厚Min.Annular Ring 最小环宽Min.Spacing between Line to Line 线与线之间的最小距离Min.Spacing between Line to Pad 线与焊盘之间的最小距离Min.Spacing between Pad to Pad 焊盘与焊盘之间的最小距离Minimum 最小Mirroring 镜像Missing 缺少Model No. 产品名称Molded 模塑Mother board 主板Moulding 模房Mounting hole 安装孔Multilayer 多层板Multi-layer Laminate 多层板材料N nNegative 反面的Net list 网络表Nick 缺口No. of holes 孔数No.of Array/Panel 每个拼板套板数No.of Panel per Stack 每叠板数No.of Panel/Sheet 每张大料拼板数No.of Pcs Per Bag 每包数量No.of Unit/Array 每套单元数Normal value标准值O oOblong 椭圆形的Offset 偏移Open/short 开路/短路Optimization(design) 最佳化(设计)Organic Solerability Peservatives(OSP) 有机保护剂Originator 原作者Outer copper foil 外层铜箔Outline 外形P pPacking 包装Packing 包装Pad 焊盘Panel Area 拼板面积Panel Plated Crack 板镀缺口Panel plating 整板电镀Panel Size 拼板尺寸Panel Size After Outerlayer Cutting 外层切板后拼板尺寸Panel Utilization 拼板利用率Pass rate 通过率Passivation 钝化Pattern 线路Pattern Inspection 线路检查Pattern plating 图形电镀PCB(Printed Circuit Board) 印制线路板Peck drilling 啄钻Peel strength 剥离强度Peelable 可剥性Peelable 剥离强度Peelable Mask 可脱油Peeling 剥离Permanent 永久性PH value PH值Photo plotting 图形输出Photo via hole 菲林过孔Photographers 照片靶标Photoplotler 光绘机Physical 物理的Pin hole 销定孔Pink ring 粉红环Pinning hole 钻孔管位Pitch 间距Placement 放置Plated Though Hole(PTH) 沉铜Plating 电镀Plating Crack 电镀裂缝Plating line 电镀线Plating rack 电镀架Plating V oid 电镀针孔Plug Hole 塞孔Polymer 聚合体Porosity 孔隙率Positive 绝对的Power plane 电源层Prepreg 半固化片Primary side 首面Print 印刷Probe point 针床测点Process 工序Process flow 工序流程Product Planning Dept. 生产计划部Production 生产板Profile 外形Profiling 外形加工Profiling Process 外形加工Project No. 产品编号PTH Thermal Seress Test PTH热冲击测试PTH(Plating Through Hole) 沉铜Pull away 拉离Punch 啤模Punching 冲切Punching Mould Drawing 啤模图形Q qQA Audit 品质审计QA(Quanlity Assurance) 品质部Quad Palt Pack (QFP) 四边扁平林整器件Quantity 数量R rRaw Material Utilization 原材料利用率Recall 回收Rectifier 整流器Register mark 对位点Registration 重合点Remark 备注Resin 树脂Resin Recession 流胶Resist 抗蚀剂Resolution 分辨率Rigid 精密的Roller coating 涂覆Roughening 粗化Round pad 圆盘Routing 外形加工,铣板S sS/M Material 绿油物料S/M(Solder Mask) 阻焊Sales 销售Sample 样板Sampling inspection 抽样检验Scaling factor 缩放比例因素Scope 范围Scoring 刻槽Scratch 划痕Secondary side 第二面Section Code 组别代号Section Code Change 组别代号更改Segment 部分,片段Separated 分离Sequence 顺序Sets 套Sheet Size 大料尺寸Shematic diagram 原理图Shiny 有光泽的,发光的Silk screen 丝印Silver film 银盐片Single/double 单层/双面Slot 槽,坑Solder Mask 阻焊Solder mask on bare copper (smobc) 裸铜覆盖阻焊膜Solder side 焊接面Solder Side C/M 阻焊面字符Solder Side Cir. 焊接面线路Solder Side Circuit 焊接面Solder Side S/M 焊接面阻焊Solderability 可焊性Solvent Test 可溶性测试Spacing 线距Special requirement 特殊要求Specification 详细说明，规范Spindle 主轴Split 裂片Square pad 方块Standard 标准值Static 静态Stencial 网版Step drilling 分布钻Step scale 光梯尺Store 货仓Supplier 供应商Supported hole 支撑点Surface 表面Surface mount technology 表面组装技术Swimming 滑移T tTack 堆起Tape Programming 铬带制作Tape Test 胶带测试Target Hole 目标孔Teardrop 泪珠Template 天平Tenting 封孔Test 测试Test coupon 图样Test Parameter 测试参数Test Pattern 测试孔Testing V oltage 电压Thermal shock 热冲击Thermal stress 热应力Thickness 厚度Tin Content 锡含量Tin/Lead Stripping 退铅锡Tin-lead plating 电镀铅锡Tolerance 公差Top side 板面Touch up 修理(执漏)Training 训练Transmission 传输线Transmittance 传送Trim line 修剪U uUltrasonic cleaning 超声波清洗Undercut 侧蚀Unit Arrangement 单元排版Unit Layout Per Panel 单元拼板图Uv-blocking 阻挡紫外线V vVacunm Pack 真空包装Vacuum lamination 真空压制V-Cut V- 坑View From…观察方向由…Visual & Warpage 可视性和翘曲度Visual inspection 目检V oltage 电压W wW/F(Wet Film) 湿膜Warp & Twist 翘曲和弯曲Wet Film 湿模Width 宽度Wiring 线路。
中英文对照的PCB专业用语
中英文对照的PCB专业用语一、综合词汇1、印制电路：printed circuit2、印制线路：printed wiring3、印制板：printed board4、印制板电路：printed circuit board (pcb)5、印制线路板：printed wiring board(pwb)6、印制元件：printed component7、印制接点：printed contact8、印制板装配：printed board assembly9、板：board10、单面印制板：single-sided printed board(ssb)11、双面印制板：double-sided printed board(dsb)12、多层印制板：mulitlayer printed board(mlb)13、多层印制电路板：mulitlayer printed circuit board14、多层印制线路板：mulitlayer prited wiring board15、刚性印制板：rigid printed board16、刚性单面印制板：rigid single-sided printed borad17、刚性双面印制板：rigid double-sided printed borad18、刚性多层印制板：rigid multilayer printed board19、挠性多层印制板：flexible multilayer printed board20、挠性印制板：flexible printed board21、挠性单面印制板：flexible single-sided printed board22、挠性双面印制板：flexible double-sided printed board23、挠性印制电路：flexible printed circuit (fpc)24、挠性印制线路：flexible printed wiring25、刚性印制板：flex-rigid printed board, rigid-flex printed board26、刚性双面印制板：flex-rigid double-sided printed board, rigid-flex double-sided printed27、刚性多层印制板：flex-rigid multilayer printed board, rigid-flex multilayer printed board28、齐平印制板：flush printed board29、金属芯印制板：metal core printed board30、金属基印制板：metal base printed board31、多重布线印制板：mulit-wiring printed board32、陶瓷印制板：ceramic substrate printed board33、导电胶印制板：electroconductive paste printed board34、模塑电路板：molded circuit board35、模压印制板：stamped printed wiring board36、顺序层压多层印制板：sequentially-laminated mulitlayer37、散线印制板：discrete wiring board38、微线印制板：micro wire board39、积层印制板：buile-up printed board40、积层多层印制板：build-up mulitlayer printed board (bum)41、积层挠印制板：build-up flexible printed board42、表面层合电路板：surface laminar circuit (slc)43、埋入凸块连印制板：b2it printed board44、多层膜基板：multi-layered film substrate(mfs)45、层间全内导通多层印制板：alivh multilayer printed board46、载芯片板：chip on board (cob)47、埋电阻板：buried resistance board48、母板：mother board49、子板：daughter board50、背板：backplane51、裸板：bare board52、键盘板夹心板：copper-invar-copper board53、动态挠性板：dynamic flex board54、静态挠性板：static flex board55、可断拼板：break-away planel56、电缆：cable57、挠性扁平电缆：flexible flat cable (ffc)58、薄膜开关：membrane switch59、混合电路：hybrid circuit60、厚膜：thick film61、厚膜电路：thick film circuit62、薄膜：thin film63、薄膜混合电路：thin film hybrid circuit64、互连：interconnection65、导线：conductor trace line66、齐平导线：flush conductor67、传输线：transmission line68、跨交：crossover69、板边插头：edge-board contact70、增强板：stiffener71、基底：substrate72、基板面：real estate73、导线面：conductor side74、元件面：component side75、焊接面：solder side76、印制：printing77、网格：grid78、图形：pattern79、导电图形：conductive pattern80、非导电图形：non-conductive pattern81、字符：legend82、标志：mark二、基材：1、基材：base material2、层压板：laminate3、覆金属箔基材：metal-clad bade material4、覆铜箔层压板：copper-clad laminate (ccl)5、单面覆铜箔层压板：single-sided copper-clad laminate6、双面覆铜箔层压板：double-sided copper-clad laminate7、复合层压板：composite laminate8、薄层压板：thin laminate9、金属芯覆铜箔层压板：metal core copper-clad laminate10、金属基覆铜层压板：metal base copper-clad laminate11、挠性覆铜箔绝缘薄膜：flexible copper-clad dielectric film12、基体材料：basis material13、预浸材料：prepreg14、粘结片：bonding sheet15、预浸粘结片：preimpregnated bonding sheer16、环氧玻璃基板：epoxy glass substrate17、加成法用层压板：laminate for additive process18、预制内层覆箔板：mass lamination panel19、内层芯板：core material20、催化板材：catalyzed board ,coated catalyzed laminate21、涂胶催化层压板：adhesive-coated catalyzed laminate22、涂胶无催层压板：adhesive-coated uncatalyzed laminate23、粘结层：bonding layer24、粘结膜：film adhesive25、涂胶粘剂绝缘薄膜：adhesive coated dielectric film26、无支撑胶粘剂膜：unsupported adhesive film27、覆盖层：cover layer (cover lay)28、增强板材：stiffener material29、铜箔面：copper-clad surface30、去铜箔面：foil removal surface31、层压板面：unclad laminate surface32、基膜面：base film surface33、胶粘剂面：adhesive faec34、原始光洁面：plate finish35、粗面：matt finish36、纵向：length wise direction37、模向：cross wise direction38、剪切板：cut to size panel39、酚醛纸质覆铜箔板：phenolic cellulose paper copper-clad laminates(phenolic/paper ccl)40、环氧纸质覆铜箔板：epoxide cellulose paper copper-clad laminates (epoxy/paper ccl)41、环氧玻璃布基覆铜箔板：epoxide woven glass fabric copper-clad laminates42、环氧玻璃布纸复合覆铜箔板：epoxide cellulose paper core, glass cloth surfaces copper-clad laminates43、环氧玻璃布玻璃纤维复合覆铜箔板：epoxide non woven/woven glass reinforced copper-clad laminates44、聚酯玻璃布覆铜箔板：ployester woven glass fabric copper-clad laminates45、聚酰亚胺玻璃布覆铜箔板：polyimide woven glass fabric copper-clad laminates46、双马来酰亚胺三嗪环氧玻璃布覆铜箔板：bismaleimide/triazine/epoxide woven glass fabric copper-clad lamimates47、环氧合成纤维布覆铜箔板：epoxide synthetic fiber fabric copper-clad laminates48、聚四乙烯玻璃纤维覆铜箔板：teflon/fiber glass copper-clad laminates49、超薄型层压板：ultra thin laminate50、陶瓷基覆铜箔板：ceramics base copper-clad laminates51、紫外线阻挡型覆铜箔板：uv blocking copper-clad laminates三、基材的材料1、a阶树脂：a-stage resin2、b阶树脂：b-stage resin3、c阶树脂：c-stage resin4、环氧树脂：epoxy resin5、酚醛树脂：phenolic resin6、聚酯树脂：polyester resin7、聚酰亚胺树脂：polyimide resin8、双马来酰亚胺三嗪树脂：bismaleimide-triazine resin9、丙烯酸树脂：acrylic resin10、三聚氰胺甲醛树脂：melamine formaldehyde resin11、多官能环氧树脂：polyfunctional epoxy resin12、溴 费跏髦 篵rominated epoxy resin13、环氧酚醛：epoxy novolac14、氟树脂：fluroresin15、硅树脂：silicone resin16、硅烷：silane17、聚合物：polymer18、无定形聚合物：amorphous polymer19、结晶现象：crystalline polamer20、双晶现象：dimorphism21、共聚物：copolymer22、合成树脂：synthetic23、热固性树脂：thermosetting resin24、热塑性树脂：thermoplastic resin25、感光性树脂：photosensitive resin26、环氧当量：weight per epoxy equivalent (wpe)27、环氧值：epoxy value28、双氰胺：dicyandiamide29、粘结剂：binder30、胶粘剂：adesive31、固化剂：curing agent32、阻燃剂：flame retardant33、遮光剂：opaquer34、增塑剂：plasticizers35、不饱和聚酯：unsatuiated polyester36、聚酯薄膜：polyester37、聚酰亚胺薄膜：polyimide film (pi)38、聚四氟乙烯：polytetrafluoetylene (ptfe)39、聚全氟乙烯丙烯薄膜：perfluorinated ethylene-propylene copolymer film (fep)40、增强材料：reinforcing material41、玻璃纤维：glass fiber42、e玻璃纤维：e-glass fibre43、d玻璃纤维：d-glass fibre44、s玻璃纤维：s-glass fibre45、玻璃布：glass fabric46、非织布：non-woven fabric47、玻璃纤维垫：glass mats48、纱线：yarn49、单丝：filament50、绞股：strand51、纬纱：weft yarn52、经纱：warp yarn53、但尼尔：denier54、经向：warp-wise55、纬向：weft-wise, filling-wise56、织物经纬密度：thread count57、织物组织：weave structure58、平纹组织：plain structure59、坏布：grey fabric60、稀松织物：woven scrim61、弓纬：bow of weave62、断经：end missing63、缺纬：mis-picks64、纬斜：bias65、折痕：crease66、云织：waviness67、鱼眼：fish eye68、毛圈长：feather length69、厚薄段：mark70、裂缝：split71、捻度：twist of yarn72、浸润剂含量：size content73、浸润剂残留量：size residue74、处理剂含量：finish level75、浸润剂：size76、偶联剂：couplint agent77、处理织物：finished fabric78、聚酰胺纤维：polyarmide fiber79、聚酯纤维非织布：non-woven polyester fabric80、浸渍绝缘纵纸：impregnating insulation paper81、聚芳酰胺纤维纸：aromatic polyamide paper82、断裂长：breaking length83、吸水高度：height of capillary rise84、湿强度保留率：wet strength retention85、白度：whitenness86、陶瓷：ceramics87、导电箔：conductive foil88、铜箔：copper foil89、电解铜箔：electrodeposited copper foil (ed copper foil)90、压延铜箔：rolled copper foil91、退火铜箔：annealed copper foil92、压延退火铜箔：rolled annealed copper foil (ra copper foil)93、薄铜箔：thin copper foil94、涂胶铜箔：adhesive coated foil95、涂胶脂铜箔：resin coated copper foil (rcc)96、复合金属箔：composite metallic material97、载体箔：carrier foil98、殷瓦：invar99、箔（剖面）轮廓：foil profile100、光面：shiny side101、粗糙面：matte side102、处理面：treated side103、防锈处理：stain proofing104、双面处理铜箔：double treated foil四、设计1、原理图：shematic diagram2、逻辑图：logic diagram3、印制线路布设：printed wire layout4、布设总图：master drawing5、可制造性设计：design-for-manufacturability6、计算机辅助设计：computer-aided design.(cad)7、计算机辅助制造：computer-aided manufacturing.(cam)8、计算机集成制造：computer integrat manufacturing.(cim)9、计算机辅助工程：computer-aided engineering.(cae)10、计算机辅助测试：computer-aided test.(cat)11、电子设计自动化：electric design automation .(eda)12、工程设计自动化：engineering design automaton .(eda2)13、组装设计自动化：assembly aided architectural design. (aaad)14、计算机辅助制图：computer aided drawing15、计算机控制显示：computer controlled display .(ccd)16、布局：placement17、布线：routing18、布图设计：layout19、重布：rerouting20、模拟：simulation21、逻辑模拟：logic simulation22、电路模拟：circit simulation23、时序模拟：timing simulation24、模块化：modularization25、布线完成率：layout effeciency26、机器描述格式：machine descriptionm format .(mdf)27、机器描述格式数据库：mdf databse28、设计数据库：design database29、设计原点：design origin30、优化（设计）：optimization (design)31、供设计优化坐标轴：predominant axis32、表格原点：table origin33、镜像：mirroring34、驱动文件：drive file35、中间文件：intermediate file36、制造文件：manufacturing documentation37、队列支撑数据库：queue support database38、元件安置：component positioning39、图形显示：graphics dispaly40、比例因子：scaling factor41、扫描填充：scan filling42、矩形填充：rectangle filling43、填充域：region filling44、实体设计：physical design45、逻辑设计：logic design46、逻辑电路：logic circuit47、层次设计：hierarchical design48、自顶向下设计：top-down design49、自底向上设计：bottom-up design50、线网：net51、数字化：digitzing52、设计规则检查：design rule checking53、走（布）线器：router (cad)54、网络表：net list55、计算机辅助电路分析：computer-aided circuit analysis56、子线网：subnet57、目标函数：objective function58、设计后处理：post design processing (pdp)59、交互式制图设计：interactive drawing design60、费用矩阵：cost metrix61、工程图：engineering drawing62、方块框图：block diagram63、迷宫：moze64、元件密度：component density65、巡回售货员问题：traveling salesman problem66、自由度：degrees freedom67、入度：out going degree68、出度：incoming degree69、曼哈顿距离：manhatton distance70、欧几里德距离：euclidean distance71、网络：network72、阵列：array73、段：segment74、逻辑：logic75、逻辑设计自动化：logic design automation76、分线：separated time77、分层：separated layer78、定顺序：definite sequence五、形状与尺寸：1、导线（通道）：conduction (track)2、导线（体）宽度：conductor width3、导线距离：conductor spacing4、导线层：conductor layer5、导线宽度/间距：conductor line/space6、第一导线层：conductor layer no.17、圆形盘：round pad8、方形盘：square pad9、菱形盘：diamond pad10、长方形焊盘：oblong pad11、子弹形盘：bullet pad12、泪滴盘：teardrop pad13、雪人盘：snowman pad14、v形盘：v-shaped pad15、环形盘：annular pad16、非圆形盘：non-circular pad17、隔离盘：isolation pad18、非功能连接盘：monfunctional pad19、偏置连接盘：offset land20、腹（背）裸盘：back-bard land21、盘址：anchoring spaur22、连接盘图形：land pattern23、连接盘网格阵列：land grid array24、孔环：annular ring25、元件孔：component hole26、安装孔：mounting hole27、支撑孔：supported hole28、非支撑孔：unsupported hole29、导通孔：via30、镀通孔：plated through hole (pth)31、余隙孔：access hole32、盲孔：blind via (hole)33、埋孔：buried via hole34、埋/盲孔：buried /blind via35、任意层内部导通孔：any layer inner via hole (alivh)36、全部钻孔：all drilled hole37、定位孔：toaling hole38、无连接盘孔：landless hole39、中间孔：interstitial hole40、无连接盘导通孔：landless via hole41、引导孔：pilot hole42、端接全隙孔：terminal clearomee hole43、准表面间镀覆孔：quasi-interfacing plated-through hole44、准尺寸孔：dimensioned hole45、在连接盘中导通孔：via-in-pad46、孔位：hole location47、孔密度：hole density48、孔图：hole pattern49、钻孔图：drill drawing50、装配图：assembly drawing51、印制板组装图：printed board assembly drawing52、参考基准：datum referance。
PCB英文术语整理
b/電路板朮語總整理*****A*****Abietic Acid松脂酸.Abrasion Resistance耐磨性.Abrasives磨料,刷材.ABS樹脂.Absorption吸收(入).Ac Impedance交流阻抗. Accelerated Test(Aging)加速老化(試驗). Acceleration速化反應. Accelerator 加速劑,速化劑. Acceptability,Acceptance 允收性,允收.Access Hole露出孔,穿露孔. Accuracy准確度.Acid Number (Acid Value)酸值.Acoustic Microscope (AM)感音成像顯微鏡. Acrylic壓克力(聚丙烯酸樹脂). Actinic Light (or Intensity, or Ra有效光.Activation活化.Activator活化劑.Active Carbon活性炭.Active Parts(Devices)主動零件.Acutance解像銳利度.Addition Agent添加劑.Additive Process加成法.Adhesion附著力.Adhesion Promotor附著力促進劑. Adhesive膠類或接著劑.Admittance導納(阻抗的倒數). Aerosol噴霧劑,氣熔膠,氣懸體. Aging老化.Air Inclusion氣泡夾雜.Air Knife風刀.Algorithm演算法.Aliphatic Solvent脂肪族溶劑. Aluminium Nitride(AlN)氮化鋁.Ambient Tamp環境溫度. Amorphous無定形,非晶形.Amp-Hour安培小時.Analog Circuit/Analog Signal類比電路/類比訊號. Anchoring Spurs著力爪.Angle of Contack接觸角.Angle of Attack攻角.Anion陰離子.Anisotropic異向性,單向的. Anneal 韌化(退火).Annular Ring孔環.Anode陽極.Anode Sludge陽極泥.Anodizing陽極化.ANSI美國標準協會.Anti-Foaming Agent消泡劑.Anti-pit Agent抗凹劑.AOI自動光學檢驗. Apertures開口,鋼版開口.AQL品質允收水準.AQL(Acceptable Quality Level)允收品質水準. Aramid Fiber聚醯胺纖維.Arc Resistance耐電弧性.Array排列.Artwork底片.ASIC特定用途勣體電路器. Aspect Ratio縱橫比.Assembly組裝裝配.A-stage A階段.ATE自動電測設備. Attenuation訊號衰減.Autoclave壓力鍋.Axial-lead軸心引腳. Azeotrope共沸混合液.*****B*****Back Light (Back Lighting)背光法.Back Taper反錐斜角. Backpanels, Backplanes支撐板.Back-up 墊板.Balanced Transmission Lines平衡式傳輸線.Ball Grid Array球腳陣列(封裝). Bandability彎曲性.Banking Agent護岸劑.Bare Chip Assembly裸體晶片組裝. Barrel孔壁,滾鍍.Base Material基材.Basic Grid基本方格.Batch批.Baume波美度(凡液體比重比水重則 Be=145-(1凡液體比重比水輕則 Be=140÷(Sp.Gr-13*Sp.Gr 為比重即同體勣物質對"純水"1g/ Beam lead光芒式的平行密集引腳.Bed-of-Nail Testing針床測試.Bellows Conact彈片式接觸.Beta Ray Backscatter貝他射線反彈散射.Bevelling切斜邊.Bias斜張綱布,斜纖法.Bi-Level Stencil]雙階式鋼板.Binder粘結劑.Bits頭(Drill Bits).Black Oxide黑氧化層.Blanking沖空斷開.Bleack 漂洗.Bleeding溢流.Blind Via Hole肓通孔.Blister局部性分層或起泡.Block Diagram電路系統塊圖 .Blockout封綱.Blotting干印.Blotting Paper吸水紙.Blow Hole吹孔.Blue Plaque藍紋(錫面鈍化層).Blur Edge (Circle)模糊邊帶(圈).Bomb Sight彈標.Bond Strength結合強度.Bondability結合性.Bonding Layer結合層接著層.Bonding Sheet(Layer)接合片.Bonding Wire結合線.Bow, Bowing板彎.Braid編線.Brazing硬焊(用含銀的銅鋅合金焊條).在425℃~870℃下進行熔接的方式). Break Point顯像點.Break-away Panel可斷開板.Breakdown Voltage崩潰電壓.Break-out破出.Bridging搭橋.Bright Dip光澤浸漬處理.Brightener光澤劑.Brown Oxide棕氧化.Brush Plating刷鍍.B-stage B階段.Build Up Process增層法制程.Build-up堆積.Bulge鼓起.Bump 突塊.Bumping Process击塊制程.Buoyancy浮力.Buried Via Hole埋導孔.Burn-in高溫加速老化試驗.Burning燒焦.Burr毛頭.Bus Bar勤電杆.Butter Coat 外表樹脂層.*****C*****C4 Chip Joint C4晶片焊接. Cable電纜.CAD電腦輔助設計. Calendered Fabric軋平式綱布.Cap Lamination帽式壓合法. Capacitance電容.Capacitive Coupling電容耦合. Capillary Action毛細作用. Carbide碳化物.Carbon Arc Lamp碳弧燈.Carbon Treatment, Active活化炭處理. Card卡板.Card Cages/Card Racks電路板搆裝箱. Carlson Pin卡氏定位稍. Carrier載體.Cartridge濾心. Castallation堡型勣體電路器. Catalyzed Board, Catalyzed Subs催化板材. Catalyzing催化.Cathode陰極.Cation陰向離子, 陽离子. Caul Plate隔板.Cavitation空泡化 半真空. Center-to-Center Spacing中心間距. Ceramics陶瓷.Cermet陶金粉.Certificate証明書.CFC氟氫碳化物. Chamfer倒角. Characteristic Impedance特性阻抗.Chase綱框.Check List檢查清單.Chelate螯合.Chemical Milling化學研磨. Chemical Resistance抗化性. Chemisorption化學吸附.Chip晶片(粒).Chip Interconnection晶片互連.Chip on Board晶片粘著板.Chip On Glass晶玻接裝(COG). Chisel鑽針的尖部. Chlorinated Solvent含氯溶劑,氯化溶劑. Circumferential Separation環狀斷孔.Clad/Cladding披覆.Clean Room無塵室. Cleanliness清潔度.Clearance余地,余環. Clinched Lead Terminal緊箝式引腳. Clinched-wire Through Connecti通孔彎線連接法 . Clip Terminal繞線端接.Coat, Coating皮膜表層.Coaxial Cable同軸纜線. Coefficient of Thermal Expansion熱膨脹系數.Co-Firing共繞.Cold Flow冷流.Cold Solder Joint冷焊點.Collimated Light平行光.Colloid膠體.Columnar Structure柱狀組織.Comb Pattern梳型電路.Complex Ion錯離子.Component Hole零件孔.Component Orientation零件方向.Component Side組件面.Composites,(CEM-1,CEM-3)復合板材. Condensation Soldering凝熱焊接,液化放熱焊接. Conditioning整孔.Conductance導電.Conductive Salt導電鹽.Conductivity導電度.Conductor Spacing導體間距.Conformal Coating貼護層.Conformity吻合性, 服貼性. Connector連接器.Contact Angle接觸角.Contact Area接觸區.Contact Resistance接觸電阻.Continuity連通性.Contract Service協力廠,分包廠. Controlled Depth Drilling定深鑽孔.Conversion Coating 轉化皮膜.Coplanarity共面性.Copolymer共聚物. Copper Foil銅皮.Copper Mirror Test銅鏡試驗. Copper Paste銅膏.Copper-Invar-Copper (CIC)綜合夾心板. Core Material內層板材,核材. Corner Crack 通孔斷角. Corner Mark板角標記. Counterboring方型擴孔. Countersinking錐型擴孔. Coupling Agent 偶合劑. Coupon, Test Coupon板邊試樣. Coverlay/Covercoat表護層.Crack裂痕.Crazing白斑.Crease皺折.Creep潛變. Crossection Area截面積. Crosshatch Testing十字割痕試驗. Crosshatching十字交叉區. Crosslinking, Crosslinkage交聯,架橋. Crossover越交,搭交. Crosstalk雜訊, 串訊. Crystalline Melting Point晶體熔點.C-Stage C階段.Cure硬化,熟化. Current Density電流密度. Current-Carrying Capability載流能力.Curtain Coating濂塗法.*****D*****Daisy Chained Design菊瓣設計.Datum Reference基准參考.Daughter Board子板.Debris碎屑,殘材.Deburring去毛頭.Declination Angle斜射角.Definition邊緣逼真度.Degradation 劣化.Degrasing脫脂.Deionized Water去離子水.Delamination分離.Dendritic Growth 枝狀生長.Denier丹尼爾(是編織紡織所用各種紗類直徑單定義9000米紗束所具有的重量(以克米計Densitomer透光度計.Dent凹陷.Deposition 皮膜處理.Desiccator干燥器.Desmearing去膠渣.Desoldering解焊.Developer顯像液,顯像機.Developing顯像 .Deviation偏差.Device電子元件.Dewetting縮錫.D-glass D玻璃.Diaze Film偶氮棕片. Dichromate重鉻 酸鹽.Dicing晶片分割. Dicyandiamide(Dicy)雙氰胺.Die 沖模.Die Attach晶粒安裝.Die Bonding晶粒接著.Die Stamping沖壓.Dielectric 介質.Dielectric Breakdown Voltage介質崩潰電壓. Dielectric Constant介質常數.Dielectric Strength介質強度.微差掃瞄熱卡分析法. Differential Scanning CalorimetryDiffusion Layer擴散層.Digitizing數位化.Dihedral Angle雙反斜角. Dimensional Stability尺度安定性.Diode二極體.Dip Coating浸塗法.Dip Soldering浸焊法.DIP(Dual Inline Package)雙排腳封裝體. Dipole偶極,雙極.Direct / Indirect Stencil直接/間接版膜. Direct Emulsion直接乳膠.Direct Plating直接電鍍.Discrete Compenent散裝零件.Discrete Wiring Board散線電路板,復線板. Dish Down碟型下陷.Dispersant分散劑. Dissipation Factor散失因素. Disspation Factor散逸因子. Disturbed Joint受擾焊點. Doctor Blade修平刀,刮平刀. Dog Ear狗耳.Doping摻雜.Double Layer雙電層.Double Treated Foil雙面處理銅箔. Drag In / Drag Out帶[進/帶出. Drag Soldering拖焊. Drawbridging吊橋效應.Drift漂移.Drill Facet鑽尖切削面. Drill Pointer鑽針重磨機. Drilled Blank已鑽孔的裸板. Dross浮渣.Drum Side銅箔光面.Dry Film干膜.Dual Wave Soldering 雙波焊接. Ductility展性.Dummy Land假焊墊. Dummy, Dummying假鍍(片). Durometer橡膠硬度計. DYCOstrate電漿蝕孔增層法. Dynamic Flex(FPC)動態軟板.*****E*****E-Beam (Electron Beam)電子束.Eddy Current渦電流.Edge Spacing板邊空地.Edge-Board Connector板邊(金手指)承接器. Edge-Board Contact板邊金手指.Edge-Dip Solderability Test板邊焊錫性測試. EDTA乙二胺四乙酸. Effluent排放物.E-glass電子級玻璃. Elastomer彈性體.Electric Strength(耐)電性強度. Electrodeposition電鍍.Electro-deposition Photoresist電著光阻, 電泳光阻. Electroforming電鑄.Electroless-Deposition無電鍍.Electrolytic Tough Pitch電解銅.. Electrolytic-Cleaning電解清洗.Electro-migration電遷移.Electro-phoresis電泳動, 電滲. Electro-tinning鍍錫.Electro-Winning電解冶煉. Elongation 延伸性, 延伸率. Embossing击出性壓花.EMF(Electromotive Force)電動勢.EMI(Electromagnetic Interferenc電磁干擾. Emulsion乳化.Emulsion Side藥膜面. Encapsulating膠囊. Encroachment沾污,侵犯.End Tap封頭.Entek有機護銅處理. Entrapment夾雜物.Entry Material蓋板.Epoxy Resin環氧樹脂.Etch Factor蝕刻因子.Etchant蝕刻劑(液). Etchback回蝕.Etching Indicator蝕刻指標.Etching Resist蝕刻阻劑.Eutetic Composition共融組成. Exotherm放熱(曲線). Exposure曝光.Eyelet鉚眼.*****F*****Fabric綱布.Face Bonding反面朝下結合. Failure故障.Fan Out Wiring/Fan In Wiring扇出布線/扇入布線. Farad 法拉.Farady法拉第.Fatigue Strength抗疲勞強度.Fault缺陷.Fault Plane斷層面.Feed Through Hole導通孔.Feeder 進料器.Fiber Exposure玻纖顯露.Fiducial Mark基准記號.Filament纖絲.Fill緯向.Filler填充料.Fillet內圓填角.Film底片.Film Adhesive接著膜,粘合膜.Filter過濾器.Fine Line細線.Fine Pitch密腳距,密線距,密墊距. Fineness粒度, 純度.Finger手指.Finishing終修(飾).Finite Element Method有限要素分析法.First Article首產品.First Pass-Yield初檢良品率.Fixture夾具.Flair刃角變形.Flame Point自燃點.Flame Resistant耐燃性.Flammability Rate燃性等級.Flare扇形崩口.Flash Plating閃鍍.Flashover閃絡.Flat Cable扁平排線.Flat Pack扁平封裝(之零件). Flatness平坦度.Flexible Printed Circuit (FPC)軟板.Flexural Failure撓曲損壞.Flexural Module彎曲模數, 抗撓性模數 . Flexural Strength抗撓強度.Flip Chip覆晶,扣晶.Flocculation絮凝.Flood Stroke Print覆墨沖程印刷.Flow Soldering (Wave Soldering流焊.Fluorescence熒光.Flurocarbon Resin碳氟樹脂.Flush Conductor嵌入式線路 , 貼平式 導體. Flush Point閃火點.Flute退屑槽.Flux助焊劑.Foil Burr銅箔毛邊.Foil Lamination銅箔壓板法.Foot殘足(干膜殘余物).Foot Print (Land Pattern)腳墊.Foreign Material 外來物,異物.Form-to-List布線說明清單.Four Point Twisting四點扭曲法.Free Radical自由基.Freeboard干舷.Frequency頻率.Frit 玻璃熔料.Fully-Additive Process全加成法.Fungus Resistance抗霉性.Fused Coating熔錫層.Fusing熔合.Fusing Fluid助熔液.*****G*****G-10由連續玻纖所織成的玻纖布與環氧樹脂粘結劑所復合成的材料. Gage, Gauge量規.Gallium Arsenide (GaAs)砷化鎵.Galvanic Corrosion賈凡尼式腐蝕(電解式腐蝕).Galvanic Series賈凡尼次序(電動次序).Galvanizing鍍鋅.GAP第一面分離,長刃斷開.Gate Array閘列,閘極陣列.Gel Time膠化時間.Gelation Particle膠凝點.Gerber Data ,Gerber File格博檔案(是美商Gerber公司專為PCB面線圖形與孔位,所發展一系列完整的軟體檔Ghost Image陰影.Gilding鍍金 (現為:Glod Plating).Glass Fiber玻纖.Glass Fiber Protrusion/Gouging, 玻纖突出/挖破.Glass Transition Temperature, Tg玻璃態轉化溫度.Glaze釉面,釉料.Glob Top圓頂封裝體.Glouble Test球狀測試法.Glycol (Ethylene Glycol)乙二醇.Golden Board測試用標準板.Grain Size結晶粒度.Grass Leak 大漏.Grid標准格.Ground Plane /Earth Plane接地層.Ground Plane Clearance接地空環.Guide Pin導針.Gull /Wing Lead鷗翼引腳.*****H*****Halation環暈.Half Angle半角.Halide鹵化物.Haloing白圈,白邊.Halon海龍,是CFC"氟碳化物"的一種商品名. Hard Anodizing硬陽極化.Hard Chrome Plating鍍硬鉻.Hard Soldering硬焊.Hardener (Curing Agent)硬化劑(或Curing Agent).Hardness硬度.Haring-Blum Cell海固槽.Harness電纜組合.Hay Wire跳線.Heat Cleaning燒潔.Heat Dissipation散熱.Heat Distortion Point (Temp)熱變形點(溫度).Heat Sealing熱封.Heat Sink Plane散熱層.Heat Transfer Paste導熱膏.Heatsink Tool散熱工具.Hertz(Hz)赫.High Efficiency Particulate Air F高效空氣塵粒過瀘機.Hipot Test 高壓電測.Hi-Rel高度靠度.Hit 擊(鑽孔時鑽針每一次"刺下"的動作). Holding Time停置時間.Hole Breakout孔位破出.Hole Counter數孔機.Hole Density孔數密度.Hole Preparation通孔准備.Hole Pull Strength孔壁強度.Hole Void破洞.Hook 切削刀緣外击.Hot Air Levelling噴錫.Hot Bar Soldering熱把焊接.Hot Gas Soldering熱風手焊.HTE(High Temperature Elongati高溫延伸性.Hull Cell哈氏槽.Hybrid Integrated Circuit混成電路.Hydraulic Bulge Test液壓鼓起試驗.H ydrogen Embrittlement氫脆.Hydrogen Overvoltage氫過(超)電壓.Hydrolysis水解.Hydrophilic親水性.Hygroscopic吸溼性.Hypersorption超吸咐.*****I*****I.C. Socket勣體電路器插座.Icicle錫尖.Illuminance照度.Image Transfer影像轉移.Immersion Plating浸鍍.Impedance阻抗.Impedance Match阻抗匹配.Impregnate含浸.In-Circuit Testing組裝板電測.Inclusion異物,夾雜物.Indexing Hole基准孔.Inductance(L)電感.Infrared(IR)紅外線.Input/Output輸入/輸出.Insert, Insertion插接.Inspection Overlay套檢底片.Insulation Resistance絕緣電阻.Integrated Circuit(IC)勣體電路器.InterFace介面.Interconnection互連.Intermetallic Compound (IMC)介面共化物.Internal Stress內應力.Interposer互邊導電物.Interstitial Via-Hole(IVH)局部層間導通孔.Invar殷鋼(63.8%Fe,36%Ni,0.2%C).Ion Cleanliness離子清潔度.Ion Exchange Resins離子交換樹脂.Ion Migration離子遷移.Ionizable (Ionic) Contaimination離子性污染.Ionization游離,電離.Ionization Voltage (Corona Leve電離化電壓(電纜內部狹縫空氣中,引起電離所施加之最小電壓).IPC美國印刷電路板協會.Isolation隔離性,隔絕性.*****J*****JEDEC(Joint Electronic Device 聯合電子元件工程委員會. Engineering Council)J-Lead J型接腳.Job Shop專業工廠.Joule焦耳.Jumper Wire跳線.Junction接(合)面,接頭.Just-In-Time(JIT)適時供應,及時出現.*****K*****Kapton聚亞醯胺軟板.Karat克拉 (1克拉(鑽石)=0.2g 純金則24k金100%的鈍金.Kauri-Butanol Value考立丁醇值(簡稱K.B.值).Kerf.切形,裁剪.Kevlar聚醯胺纖維.Key電鍵Key Board鍵盤.Kiss Pressure吻壓, 低壓.Knoop Hardness努普硬度.Known Good Die(KGD)已知之良好晶片.Kovar科伐合金(Fe53%,Ni29%,Co17%).Kraft Paper牛皮紙.*****L*****Lamda Wave延伸平波.Laminar Flow平流.Laminar Structure片狀結搆.Laminate Void板材空洞. Laminate(s)基板.Lamination Void壓合空洞. Laminator壓膜機.Land孔環焊墊,表面焊墊. Landless Hole無環通孔.Laser Direct Imaging (LDI)雷射直接成像. Laser Maching雷射加工法.雷射曝光機.Laser Photogenerator(LPG), LaseLaser Soldering雷射焊接法.Lay Back 刃角磨損.Lay Out布線,布局.Lay Up 疊合.Layer to Layer Spacing層間距離Leaching焊散漂出,熔出. Lead 引腳.Lead Frame腳架.Lead Pitch腳距.Leakage Current漏電電流.Legend文字標記.Leveling整平.Lifted Land孔環(焊墊)浮起. Ligand錯離子附屬體. Light Emitting Diodes (LED)發光二極體.Light Integrator光能累積器.Light Intensity光強度.Limiting Current Density極限電流密度. Liquid Crystal Display (LCD)液晶顯示器.Liquid Dielectrics液態介質.液態感光防焊綠漆.Liquid Photoimagible Solder MasLocal Area Network區域性網路.Logic 邏輯.Logic Circuit 邏輯電路.Loss Factor損失因素.Loss Tangent (TanδDK)損失正切.Lot Size批量.Luminance發光強度.Lyophilic親水性膠體.*****M*****Macro-Throwing Power巨觀分布力.Major Defect主要(嚴重)缺點.Major Weave Direction主要織向.Margin刃帶(鑽頭尖部).Marking標記.Mask阻劑.Mass Finishing大量整面(拋光).Mass Lamination大型壓板.Mass Transport質量輸送.Master Drawing主圖.Mat蓆(用于CEM-3(Composite Epoxy Material)復合材料.)Matte Side毛面(電鍍銅皮(ED Foil)之粗糙面). Mealing泡點.Mean Time To Failure (MTTF)故障前可用之平均時數.Measling白點.Mechanical Stretcher機械式張網機.Mechanical Warp機械式纏繞. Mechanism機理.Membrane Switch薄膜開關. Meniscograph Test弧面狀沾錫試驗. Meniscus彎月面.Mercury Vaper Lamp汞氣燈.Mesh Count綱目數.Metal Halide Lamp 金屬鹵素燈. Metallization金屬 化.Metallized Fabric金屬化綱布.Micelle微胞.Micro Wire Board微封線板.Micro-electronios微電子. Microetching微蝕. Microsectioning微切片法.Microstrip 微條.Microstrip Line微條線,微帶線. Microthrowing Power微分布力. Microwave微波.Migration遷移.Migration Rate遷移率.Mil英絲.Minimum Annular Ring孔環下限.Minimum Electrical Spacing電性間距下限.Minor Weave Direction次要織向. Misregistration 對不准度.Mixed Componmt Mounting Tec混合零件之組裝技術. Modem調變及解調器.Modification修改.Module模組.Modulus of Elasticity彈性系數.溼氣與絕緣電阻試驗.Moisture and Insulation ResistancMold Release 脫模劑,離型劑.Mole摩爾.Monofilament單絲.Mother Board主機板,母板.Moulded Circuit模造立體電路機.Mounting Hole安裝孔.Mounting Hole組裝孔,機裝孔.Mouse Bite鼠齒(蝕刻后線路邊緣出現不規則缺口). Multi-Chip-Module(MCM)多晶片芯片模組.復線板.Multiwiring Board (or Discrete W*****N*****N.C.數值控制.Nail Head釘頭.Near IR近紅外線.Negative負片,鑽尖的第一面外緣變窄. Negative Etch-back反回蝕.Negative Stencil負性感光膜.Negative-Acting Resist負性作用之阻劑.Network綱狀元件.Newton牛頓.Newton Ring 牛頓環.Newtonian Liquid牛頓流體.Nick缺口.N-Methyl Pyrrolidine (NMP)N-甲基四氫嗶咯.Noble Metal Paste貴金屬印膏.Node節點.Nodule節瘤. Nomencleature標示文字符號. Nominal Cured Thickness標示厚度.Non-Circular Land非圓形孔環焊墊. Non-flammable非燃性.Non-wetting不沾錫.標準濃度,當量濃度. Normal Concentration (Strength)Normal Distribution常態分布.Novolac酯醛樹脂. Nucleation , Nucleating核化.Numerical Control數值控制.Nylon尼龍.*****O*****Occlusion吸藏.Off-Contact架空.Offset第一面大小不均. OFHC(Oxyen Free High Conduc無氧高導電銅. Ohm歐姆.Oilcanning蓋板彈動.OLB(Outer Lead Bond)外引腳結合. Oligomer寡聚物.Omega Meter離子污染檢測儀. Omega Wave振盪波.On-Contact Printing密貼式印刷. Opaquer不透明劑,遮光劑. Open Circuits斷線.Optical Comparater光學對比器(光學放大器.) Optical Density光密度.Optical Inspection光學檢驗.Optical Instrument光學儀器.Organic Solderability Preservativ有機保焊劑.Osmosis滲透.Outgassing出氣,吹氣.Outgrowth懸出,橫出,側出.Output產出,輸出.Overflow溢流.Overhang總懸空.Overlap 鑽尖點分離. Overpotantial(Over voltage)過電位,過電壓. Oxidation氧化.Oxygen Inhibitor氧化抑制劑.Ozone Depletion臭氧層耗損.*****P*****Packaging封裝,搆裝.Pad焊墊,圓墊.Pad Master圓墊底片.Pads Only Board唯墊板.Palladium鈀.Panel制程板.Panel Plating全板鍍銅.Panel Process全板電鍍法.Paper Phenolic紙質酚醛樹脂(板材). Parting Agent脫膜劑.Passivation鈍化 ,鈍化外理.Passive Device (Component)被動元件(零件)Paste膏,糊.Pattern板面圖形.Pattern Plating線路電鍍.Pattern Process線路電鍍法.Peak Voltage峰值電壓.Peel Strength抗撕強度.Periodic Reverse (PR) Current周期性反電流. Peripheral周邊附屬設備. Permeability透氣性,導磁率. Permittivity誘電率,透電率.pH Value酸堿值.Phase相.Phase Diagram相圖.Phenolic酚醛樹脂. Photofugitive感光褪色. Photographic film感光成像之底片. Photoinitiator感光啟始劑. Photomask光罩.Photoplotter, Plotter光學繪圖機. Photoresist光阻.光阻式化學(銑刻)加工. Photoresist Chemical MachinningPhototool底片.Pick and Place拾取與放置. Piezoelectric壓電性.Pin 插腳,插梢,插針.Pin Grid Array (PGA)矩陣式針腳對裝. Pinhole針孔.Pink Ring粉紅圈.Pitch跨距,腳距,墊距,線距.Pits凹點.Plain Weave平織.Plasma電漿.Plasticizers可塑劑,增塑劑.Plated Through Hole鍍通孔.Platen熱盤.Plating鍍.Plotting標繪.Plowing犁溝.Plug插腳,塞柱.Ply層,股.Pneumatic Stretcher氣動拉伸器.Pogo Pin伸縮探針.Point 鑽尖.Point Angle鑽尖面.Point Source Light點狀光源.Poise泊."粘滯度"單位=1dyne*sec/cm2. Polar Solvent極性溶劑.Polarity電極性.Polarization分極,極化.Polarizing Slot偏槽.Polyester Films聚酯類薄片.Polymer Thick Film (PTF)厚膜糊.Polymerization聚合.Polymide(PI)聚亞醯胺.Popcorn Effect爆米花效應.Porcelain瓷材,瓷面.Porosity Test疏孔度試驗.Positive Acting Resist正性光阻劑.Post Cure后續硬化,后烤.Post Separation后期分離,事后公離.Pot Life運用期,鍋中壽命.Potting鑄封,模封.Power Supply電源供應器.Preform 預制品.Preheat預熱.Prepreg膠片,樹脂片.Press Plate鋼板.Press-Fit Contact擠入式接觸.Pressure Foot 壓力腳.Pre-tinning預先沾錫.Primary Image線路成像.Print Through壓透,過度擠壓..Probe探針.Process Camera制程用照像機.Process Window操作范圍.Production Master生產底片.Profile輪廓,部面圖,升溫曲線圖稜線. Propagation傳播.Propagation Delay傳播延遲.Puddle Effect水坑效應.Pull Away拉離.Pulse Plating脈沖電鍍法.Pumice Powder 浮石粉.Punch沖切.Purge, Purging淨空,淨洗.Purple Plague紫疫(金與鋁的共化物層). Pyrolysis熱裂解,高溫分解.*****Q*****Quad Flat Pack (QFP)方扁形封裝體. Qualification Agency資格認証機搆. Qualification Inspection資格檢驗.Qualified Products List合格產品(供應者)名單. Qualitative Analysis定性分析.品質符合之試驗線路(樣板). Quality Conformance Test CircuiQuantitative Analysis定量分析.Quench 淬火,驟冷.Quick Disconnect快速接頭.Quill緯紗繞軸.*****R*****Rack 挂架.Radial Lead放射狀引腳.Radio Frequency Interference (RF射頻干擾.Rake Angle摳角,耙角.Rated Temperature, Voltage額定溫度,額定電壓. Reactance電抗.Real Estate底材面,基板面.Real Time System 即時系統.Reclaiming再生,再制.Rediometer輻射計,光度計.Reel to Reel卷輪(盤)式操作. Reference Dimension參考尺度.Reference Edge參考邊緣. Reflection反射.Reflow Soldering重熔焊接,熔焊. Refraction折射.Refractive Index折射率.Register Mark對准用標記. Registration對准度. Reinforcement補強物.Rejection剔退,拒收. Relamination(Re-Lam)多層板壓合. Relaxation松弛.緩和.Relay繼電器.Release Agent, Release Sheets脫模劑,離模劑. Reliability可靠度,可信度. Relief Angle浮角.Repair修理.Resin Coated Copper Foil背膠銅箔.Resin Content膠含量,樹脂含量. Resin Flow膠流量,樹脂流量. Resin Recession樹脂下陷.Resin Rich Area 多膠區,樹脂丰富區. Resin Smear膠(糊)渣.Resin Starve Area缺膠區,樹脂缺乏區. Resist阻膜,阻劑. Resistivity電阻系數,電阻率. Resistor電阻器,電阻. Resistor Drift電阻漂移.Resistor Paste電阻印膏.Resolution解像,解像度,解析度.Resolving Power解析(像)力,分辨力.Reverse Current Cleaning反電流(電解)清洗.Reverse Etchback反回蝕.Reverse Image負片影像(阻劑).Reverse Osmosis (RO)反(逆滲透).Reversion反轉,還原.Revision修正版.改訂版.Rework(ing)重工,再加工.Rhology流變學,流變性質.Ribbon Cable圓線纜帶.Rigid-Flex Printed Board硬軟合板.Ring 套環.Rinsing水洗,沖洗.Ripple紋波(指整流器所輸出電流中不穩定成分Rise Time上升時間.Roadmap 線路與零件之布局圖.Robber輔助陰極.Roller Coating輥輪塗布.Roller Coating滾動塗布法.Roller Cutter輥切機.Roller Tinning輥錫法,滾錫法.Rosin松香.Rotary Dip Test擺動沾錫試驗.Routing切外型.Runout偏轉,累勣距差.Rupture迸裂.*****S*****Sacrificial Protection犧牲性保護層. Salt Spray Test鹽霧試驗. Sand Blast噴砂. Saponification皂化作用. Saponifier皂化劑.Satin Finish緞面處理. Scaled Flow Test比例流量實驗. Schemetic Diagram電路概略圖. Scoring V型刻槽. Scratch刮痕.Screen Printing綱版印刷. Screenability綱印能力. Scrubber磨刷機,磨刷器. Scum透明殘膜. Sealing封孔. Secondary Side第二面 . Seeding下種. Selective Plating選擇性電鍍. Self-Extinguishing自熄性. Selvage布邊.Semi-Additive Process半加成制程. Semi-Conductor半導體. Sensitizing敏化. Separable Component Part可分離式零件. Separator Plate隔板, 鋼板. Sequential Lamination接續性壓合法. Sequestering Agent螯合劑. Shadowing陰影,回蝕死角.Shank鑽針柄部.Shear Strength 抗剪強度.Shelf Life儲齡.Shield遮蔽.Shore Hardness蕭氏硬度.Short短路.Shoulder Angle肩斜角.Shunt分路.Side Wall側壁.Siemens電阻值.Sigma (Standard Deviation)標准差.Signal訊號.Silane硅烷.Silica Gel硅膠砂.Silicon硅.Silicone硅銅.Silk Screen綱版印刷,絲綱印刷.Silver Migration銀遷移.Silver Paste 銀膏.Single-In-Line Package(SIP)單邊插腳封裝體.Sintering燒結.Sizing上膠,上漿.Sizing上漿處理.Skin Effect集膚效應 (高頻下,電流在傳遞時多集中表面,使得道線內部通過電流甚少, 造成浪費,并也使得表面導體部分電阻升高. Skip Printing, Skip Plating漏印,漏鍍.Skip Solder 缺錫, 漏焊.Slashing漿經.Sleeve Jint套接.Sliver邊絲,邊余.Slot, Slotting槽口.Sludge於泥.Slump塌散.Slurry稠漿,懸浮漿. Small Hole小孔.Smear膠渣.Smudging錫點沾污.Snap-off彈回高度.Socket插座.Soft Contact輕觸.Soft Glass 軟質玻璃(鉛玻璃). Solder焊錫.Solder Ball錫球.Solder Bridging錫橋.Solder Bump 焊錫击塊.Solder Column Package錫柱腳封裝法. Solder Connection焊接.Solder Cost焊錫著層.Solder Dam錫堤.Solder Fillet填錫.Solder Levelling噴錫,熱風整平. Solder Masking(S/M)防焊膜綠漆. Solder Paste錫膏.Solder Plug錫塞(柱).Solder Preforms預焊料.Solder Projection焊錫突點.Solder Sag 焊錫垂流物.Solder Side焊錫面.Solder Spatter濺錫.Solder Splash賤錫.Solder Spread Test散錫試驗.Solder Webbing錫綱.Solder Webbing錫綱.Solder Wicking滲錫,焊錫之燈芯效應. Solderability可焊性.Soldering軟焊,焊接.Soldering Fluid, Soldering Oil助焊液,護焊油.Solid Content固體含量,固形分. Solidus Line固相線.Spacing間距.Span跨距.Spark Over閃絡.Specific Heat 比熱.Specification (Spec)規范,規格. Specimen樣品,試樣. Spectrophotometry分光光度計檢測法. Spindle主軸,鑽軸.Spinning Coating自轉塗布.Splay斜鑽孔.Spray Coating噴著塗裝.Spur底片圖形邊緣突出. Sputtering濺射.Squeege刮刀.Stagger Grid蹣跚格點.Stalagometer滴管式表面張力計.Stand-off Terminals直立型端子.Starvation缺膠.Static Eliminator靜電消除器.Steel Rule Die(鋼)刀模.Stencil版膜.Step and Repeat逐次重覆曝光.Step Plating梯階式鍍層.Step Tablet階段式曝光表.Stiffener補強條(板).Stop Off防鍍膜, 阻劑.Strain變形,應變.Strand絞(指由許多股單絲集束并旋扭而成的絲Stray Current迷走電流, 散雜電流(在電鍍槽系統中,其由整流器所提供,應在陽極板與被鍍件之電杆與槽體液體中流通,但有時少部分電從槽體本身或加熱器上迷走,漏失). Stress Corrosion應力腐蝕.Stress Relief消除應力.Strike預鍍.Stringing拖尾.Stripline條線.Stripper剝除液(器).Substractive Process減成法.Substrate底材.Supper Solder超級焊錫.Supported Hole(金屬)支助通孔.Surface Energy表面能.Surface Insulation Resistance表面絕緣電阻. Surface Mount Device 表面粘裝元件. Surface Mounting Technology (S表面粘裝技術. Surface Resistivity表面電阻率. Surface Speed鑽針表面速度. Surface Tension表面張力. Surfactant表面潤溼劑.Surge突流,突壓. Swaged Lead壓扁式引腳. Swelling Agents, Sweller膨松劑. Swimming 線路滑離. Synthetic Resin合成樹脂.*****T*****Tab接點,金手指. Taber Abraser泰伯磨試器. Tackiness粘著性, 粘手性. Tape Automatic Bonding (TAB)卷帶自動結合. Tape Casting 帶狀鑄材.Tape Test撕膠帶試驗.Tape Up Master原始手貼片. Taped Components卷帶式連載元件. Taper Pin Gauge錐狀孔規.Tarnish污化.Tarnish 污化, 污著.Teflon鐵氟龍(聚4氟乙烯). Telegraphing浮印,隱印. Temperature Profile溫度曲線.Template模板.Tensile Strength抗拉強度. Tensiomenter張力計.Tenting蓋孔法. Terminal端子.Terminal Clearance端子空環.Tetra-Etch氟樹脂蝕粗劑. Tetrafunctional Resin四功能樹脂. Thermal Coefficient of Expansion熱膨脹系數. Thermal Conductivity導熱率. Thermal Cycling熱循環,熱震盪. Thermal Mismstch感熱失諧. Thermal Relief散熱式鏤空. Thermal Via導熱孔. Thermal Zone感熱區. Thermocompression Bonding熱壓結合. Thermocouple熱電偶. Thermode發熱體. Thermode Soldering熱模焊接法.熱重分析法. Thermogravimetric Analysis, (TG熱機分析法. Thermomechanical Analysis (TM Thermoplastic熱塑性. Thermosetting熱固性. Thermosonic Bonding熱超音波結合. Thermount聚醯胺短纖蓆材. Thermo-Via導熱孔.Thick Film Circuit厚膜電路.Thief輔助陽極.Thin Copper Foil薄銅箔.Thin Core薄基板.Thin Film Technology薄膜技術.Thin Small Outline Package(TSO薄小型勣體電路器.Thinner調薄劑.Thixotropy抗垂流性,搖變性.Three Point Bending三點壓彎試驗.Three-Layer Carrier三層式載體.Threshold Limit Value (TLV)極限值.Through Hole Mounting通孔插裝.Through Put物流量,物料通過量.Throwing Power分布力.Tie Bar分流條.Tin Drift錫量漂飄失.Tin Immersion浸鍍錫.Tin Pest錫疫(常見白色金屬錫為"β錫",當溫度低時則β錫將逐漸轉變成粉末狀灰色"α錫Tin Whishers錫須.Tinning熱沾焊錫.Tolerance公差.Tombstoning墓碑效應.Tooling Feature工具標示物.Topography表面地形.Torsion Strength抗扭強度.Touch Up觸修,簡修.Trace 線路,導線.Traceability追溯性,可溯性.Transducer轉能器.Transfer Bump移用式突塊. Transfer Laminatied Circuit轉壓式線路. Transfer Soldering移焊法. Transistor電晶體. Translucency半透性. Transmission Line傳輸線. Transmittance透光率. Treament, Treating含浸處理.Treeing枝狀鍍物,鍍須. Trim修整, 精修.Trim Line裁切線.Trimming修整,修邊.True Position真位.Tungsten鎢Tungsten Carbide碳化鎢.Turnkey System包辦式系統. Turret Solder Terminal塔立式焊接端子. Twill Weave斜織法.Twist板扭.Two Layer Carrier兩層式載体.*****U*****保儉業試驗所標志. UL Symbol(UL.為Under-Writers Laboratories,INC)Ultimate Tensile Strength (UTS)極限抗拉強度. Ultra High Frequency (UHF)超高頻率.Ultra Violet Curing (UV Curing)紫外線硬化. Ultrasonic Bonding超音波結合. Ultrasonic Cleaning超音波清洗.Ultrasonic Soldering超音波焊接.Unbalanced Transmission Line非平衡式傳輸線.Undercut, Undercutting側蝕.Underplate底鍍層.Universal Tester汛用型電測機.Unsupported Hole非鍍通孔.Urea尿素.Urethane胺基甲酸乙脂.*****V*****Vacuoles焊洞.Vacuum Evaporation(or Depositi真空蒸鍍法.Vacuum Lamination真空壓合.Van Der Waals Force凡得華力.Vapor Blasting蒸汽噴砂.Vapor Degreasing蒸汽除油法.Vapor Phase Soldering氣相焊接.Varnish凡力水,清漆(樹脂之液態單體). V-cut V型切槽.Very Large-Scale Integration(VL極大勣體電路器.Via Hole 導通孔.Vickers Hardness維氏硬度.Viscosity粘滯度,粘度.Vision Systems視覺系統.Visual Examination目視檢驗.Void 破洞,空洞.Volatile Content揮發份含量.Voltage電壓.Voltage Breakdown崩潰電壓.Voltage Drop 電壓降落.Voltage Efficiency電壓效率.Voltage Plane電壓層.Voltage Plane Clearance電壓層的空環. Volume Resistivity體勣電阻率. Volume Resistivity體勣電阻率. Volumetric Analysis容量分析法. Vulcanization交聯,硫化.*****W*****Wafer晶圓.Waive暫准過關,暫不檢查. Warp Size 漿經處理.Warp, Warpage板彎.Washer墊圈.Waste Treatment廢棄處理.Water Absorption吸水性.Water Break水膜破散,水破. Water Mark水印.Watt瓦特.Watts Bath瓦玆鍍鎳液.Wave Guide導波管.Wave Soldering波焊.Waviness 波紋,波度.Wear Resistance耐磨性,耐磨度. Weatherability耐候性.Weave Eposure織紋顯露.Weave Texture織紋隱現.Web蹼部.Wedge Bond 楔形結合點.Wedge Void楔形缺口(破口).Weft Yarn緯紗.Welding熔接.Wet Blasting溼噴砂.Wet Lamination溼壓膜法.Wet Process溼式制程.Wetting Agent潤溼劑.Wetting Balance沾錫天平.Wetting Balance沾錫,沾溼.Whirl Brush旋渦式磨刷法.Whirl Coating旋渦塗布法.Whisker晶須.White Residue白色殘渣.White Spot白點.Wicking燈蕊效應.Window操作范圍,傳動齒孔. Wiping Action 滑動接觸(導電).Wire Bonding打線結合.Wire Gauge線規.Wire Lead金屬線腳.Wire Pattern布線圖形.Wire Wrap繞線互連.Working Master工作母片.Working Time (Life)堪用時間. Workmanship 手藝,工藝水平,制作水準. Woven Cable扁平編線.Wrinkle皺折, 皺紋.Wrought Foil鍛碾金屬箔.*****X*****X Axis X軸.X-Ray X光.X-Ray Fluorescence X螢光.*****Y*****Yarn紗線.Y-Axis Y軸.Yield良品率,良率,產率. Yield Point屈服點.*****Z*****Z-Axis Z軸.Zero Centering中心不變(疊合法). Zig-Zag In-Line Package (ZIP)鍊齒狀雙排腳封裝件.145-(145÷Sp.Gr)÷(Sp.Gr-130)水"1g/cm的比值).。
PCB综合词汇中英文对照：
PCB综合词汇中英文对照：1、印制电路：printed circuit2、印制线路：printed wiring3、印制板：printed board4、印制板电路：printed circuit board (pcb)5、印制线路板：printed wiring board(pwb)6、印制元件：printed component7、印制接点：printed contact8、印制板装配：printed board assembly9、板：board10、单面印制板：single-sided printed board(ssb)11、双面印制板：double-sided printed board(dsb)12、多层印制板：mulitlayer printed board(mlb)13、多层印制电路板：mulitlayer printed circuit board14、多层印制线路板：mulitlayer prited wiring board15、刚性印制板：rigid printed board16、刚性单面印制板：rigid single-sided printed borad17、刚性双面印制板：rigid double-sided printed borad18、刚性多层印制板：rigid multilayer printed board19、挠性多层印制板：flexible multilayer printed board20、挠性印制板：flexible printed board21、挠性单面印制板：flexible single-sided printed board22、挠性双面印制板：flexible double-sided printed board23、挠性印制电路：flexible printed circuit (fpc)24、挠性印制线路：flexible printed wiring25、刚性印制板：flex-rigid printed board, rigid-flex printed board26、刚性双面印制板：flex-rigid double-sided printed board, rigid-fle x double-sided printed27、刚性多层印制板：flex-rigid multilayer printed board, rigid-flex multilayer printed board28、齐平印制板：flush printed board29、金属芯印制板：metal core printed board30、金属基印制板：metal base printed board31、多重布线印制板：mulit-wiring printed board32、陶瓷印制板：ceramic substrate printed board33、导电胶印制板：electroconductive paste printed board34、模塑电路板：molded circuit board35、模压印制板：stamped printed wiring board36、顺序层压多层印制板：sequentially-laminated mulitlayer37、散线印制板：discrete wiring board38、微线印制板：micro wire board39、积层印制板：buile-up printed board40、积层多层印制板：build-up mulitlayer printed board (bum)41、积层挠印制板：build-up flexible printed board42、表面层合电路板：surface laminar circuit (slc)43、埋入凸块连印制板：b2it printed board44、多层膜基板：multi-layered film substrate(mfs)45、层间全内导通多层印制板：alivh multilayer printed board46、载芯片板：chip on board (cob)47、埋电阻板：buried resistance board48、母板：mother board49、子板：daughter board50、背板：backplane51、裸板：bare board52、键盘板夹心板：copper-invar-copper board53、动态挠性板：dynamic flex board54、静态挠性板：static flex board55、可断拼板：break-away planel56、电缆：cable57、挠性扁平电缆：flexible flat cable (ffc)58、薄膜开关：membrane switch59、混合电路：hybrid circuit60、厚膜：thick film61、厚膜电路：thick film circuit62、薄膜：thin film63、薄膜混合电路：thin film hybrid circuit64、互连：interconnection65、导线：conductor trace line66、齐平导线：flush conductor67、传输线：transmission line68、跨交：crossover69、板边插头：edge-board contact70、增强板：stiffener71、基底：substrate72、基板面：real estate73、导线面：conductor side74、元件面：component side75、焊接面：solder side76、印制：printing77、网格：grid78、图形：pattern79、导电图形：conductive pattern80、非导电图形：non-conductive pattern81、字符：legend82、标志：markPCB基材类词汇中英文对照：1、基材：base material2、层压板：laminate3、覆金属箔基材：metal-clad bade material4、覆铜箔层压板：copper-clad laminate (ccl)5、单面覆铜箔层压板：single-sided copper-clad laminate6、双面覆铜箔层压板：double-sided copper-clad laminate7、复合层压板：composite laminate8、薄层压板：thin laminate9、金属芯覆铜箔层压板：metal core copper-clad laminate10、金属基覆铜层压板：metal base copper-clad laminate11、挠性覆铜箔绝缘薄膜：flexible copper-clad dielectric film12、基体材料：basis material13、预浸材料：prepreg14、粘结片：bonding sheet15、预浸粘结片：preimpregnated bonding sheer16、环氧玻璃基板：epoxy glass substrate17、加成法用层压板：laminate for additive process18、预制内层覆箔板：mass lamination panel19、内层芯板：core material20、催化板材：catalyzed board ,coated catalyzed laminate21、涂胶催化层压板：adhesive-coated catalyzed laminate22、涂胶无催层压板：adhesive-coated uncatalyzed laminate23、粘结层：bonding layer24、粘结膜：film adhesive25、涂胶粘剂绝缘薄膜：adhesive coated dielectric film26、无支撑胶粘剂膜：unsupported adhesive film27、覆盖层：cover layer (cover lay)28、增强板材：stiffener material29、铜箔面：copper-clad surface30、去铜箔面：foil removal surface31、层压板面：unclad laminate surface32、基膜面：base film surface33、胶粘剂面：adhesive faec34、原始光洁面：plate finish35、粗面：matt finish36、纵向：length wise direction37、模向：cross wise direction38、剪切板：cut to size panel39、酚醛纸质覆铜箔板：phenolic cellulose paper copper-clad laminates (phenolic/paper ccl)40、环氧纸质覆铜箔板：epoxide cellulose paper copper-clad laminates (epoxy/paper ccl)41、环氧玻璃布基覆铜箔板：epoxide woven glass fabric copper-clad lam inates42、环氧玻璃布纸复合覆铜箔板：epoxide cellulose paper core, glass cloth surfaces copper-clad l aminates43、环氧玻璃布玻璃纤维复合覆铜箔板：epoxide non woven/woven glass reinforced copper-clad laminates44、聚酯玻璃布覆铜箔板：ployester woven glass fabric copper-clad lam inates45、聚酰亚胺玻璃布覆铜箔板：polyimide woven glass fabric copper-clad laminates46、双马来酰亚胺三嗪环氧玻璃布覆铜箔板：bismaleimide/triazine/epoxide woven glass fabric copper-clad lam imates47、环氧合成纤维布覆铜箔板：epoxide synthetic fiber fabric copper-cl ad laminates48、聚四乙烯玻璃纤维覆铜箔板：teflon/fiber glass copper-clad laminat es49、超薄型层压板：ultra thin laminate50、陶瓷基覆铜箔板：ceramics base copper-clad laminates51、紫外线阻挡型覆铜箔板：uv blocking copper-clad laminates PCB原材料化学用语中英文对照：1、 a阶树脂：a-stage resin2、 b阶树脂：b-stage resin3、 c阶树脂：c-stage resin4、环氧树脂：epoxy resin5、酚醛树脂：phenolic resin6、聚酯树脂：polyester resin7、聚酰亚胺树脂：polyimide resin8、双马来酰亚胺三嗪树脂：bismaleimide-triazine resin9、丙烯酸树脂：acrylic resin10、三聚氰胺甲醛树脂：melamine formaldehyde resin11、多官能环氧树脂：polyfunctional epoxy resin12、溴化环氧树脂：brominated epoxy resin13、环氧酚醛：epoxy novolac14、氟树脂：fluroresin15、硅树脂：silicone resin16、硅烷：silane17、聚合物：polymer18、无定形聚合物：amorphous polymer19、结晶现象：crystalline polamer20、双晶现象：dimorphism21、共聚物：copolymer22、合成树脂：synthetic23、热固性树脂：thermosetting resin24、热塑性树脂：thermoplastic resin25、感光性树脂：photosensitive resin26、环氧当量：weight per epoxy equivalent (wpe)27、环氧值：epoxy value28、双氰胺：dicyandiamide29、粘结剂：binder30、胶粘剂：adesive31、固化剂：curing agent32、阻燃剂：flame retardant33、遮光剂：opaquer34、增塑剂：plasticizers35、不饱和聚酯：unsatuiated polyester36、聚酯薄膜：polyester37、聚酰亚胺薄膜：polyimide film (pi)38、聚四氟乙烯：polytetrafluoetylene (ptfe)39、聚全氟乙烯丙烯薄膜：perfluorinated ethylene-propylene copolymer film (fep)40、增强材料：reinforcing material41、玻璃纤维：glass fiber42、 e玻璃纤维：e-glass fibre43、 d玻璃纤维：d-glass fibre44、 s玻璃纤维：s-glass fibre45、玻璃布：glass fabric46、非织布：non-woven fabric47、玻璃纤维垫：glass mats48、纱线：yarn49、单丝：filament50、绞股：strand51、纬纱：weft yarn52、经纱：warp yarn53、但尼尔：denier54、经向：warp-wise55、纬向：weft-wise, filling-wise56、织物经纬密度：thread count57、织物组织：weave structure58、平纹组织：plain structure59、坏布：grey fabric60、稀松织物：woven scrim61、弓纬：bow of weave62、断经：end missing63、缺纬：mis-picks64、纬斜：bias65、折痕：crease66、云织：waviness67、鱼眼：fish eye68、毛圈长：feather length69、厚薄段：mark70、裂缝：split71、捻度：twist of yarn72、浸润剂含量：size content73、浸润剂残留量：size residue74、处理剂含量：finish level75、浸润剂：size76、偶联剂：couplint agent77、处理织物：finished fabric78、聚酰胺纤维：polyarmide fiber79、聚酯纤维非织布：non-woven polyester fabric80、浸渍绝缘纵纸：impregnating insulation paper81、聚芳酰胺纤维纸：aromatic polyamide paper82、断裂长：breaking length83、吸水高度：height of capillary rise84、湿强度保留率：wet strength retention85、白度：whitenness86、陶瓷：ceramics87、导电箔：conductive foil88、铜箔：copper foil89、电解铜箔：electrodeposited copper foil (ed copper foil)90、压延铜箔：rolled copper foil91、退火铜箔：annealed copper foil92、压延退火铜箔：rolled annealed copper foil (ra copper foil)93、薄铜箔：thin copper foil94、涂胶铜箔：adhesive coated foil95、涂胶脂铜箔：resin coated copper foil (rcc)96、复合金属箔：composite metallic material97、载体箔：carrier foil98、殷瓦：invar99、箔（剖面）轮廓：foil profile100、光面：shiny side101、粗糙面：matte side102、处理面：treated side103、防锈处理：stain proofing104、双面处理铜箔：double treated foilPCB线路设计词汇中英文对照：1、原理图：shematic diagram2、逻辑图：logic diagram3、印制线路布设：printed wire layout4、布设总图：master drawing5、可制造性设计：design-for-manufacturability6、计算机辅助设计：computer-aided design.(cad)7、计算机辅助制造：computer-aided manufacturing.(cam)8、计算机集成制造：computer integrat manufacturing.(cim)9、计算机辅助工程：computer-aided engineering.(cae)10、计算机辅助测试：computer-aided test.(cat)11、电子设计自动化：electric design automation .(eda)12、工程设计自动化：engineering design automaton .(eda2)13、组装设计自动化：assembly aided architectural design. (aaad)14、计算机辅助制图：computer aided drawing15、计算机控制显示：computer controlled display .(ccd)16、布局：placement17、布线：routing18、布图设计：layout19、重布：rerouting20、模拟：simulation21、逻辑模拟：logic simulation22、电路模拟：circit simulation23、时序模拟：timing simulation24、模块化：modularization25、布线完成率：layout effeciency26、机器描述格式：machine descriptionm format .(mdf)27、机器描述格式数据库：mdf databse28、设计数据库：design database29、设计原点：design origin30、优化（设计）：optimization (design)31、供设计优化坐标轴：predominant axis32、表格原点：table origin33、镜像：mirroring34、驱动文件：drive file35、中间文件：intermediate file36、制造文件：manufacturing documentation37、队列支撑数据库：queue support database38、元件安置：component positioning39、图形显示：graphics dispaly40、比例因子：scaling factor41、扫描填充：scan filling42、矩形填充：rectangle filling43、填充域：region filling44、实体设计：physical design45、逻辑设计：logic design46、逻辑电路：logic circuit47、层次设计：hierarchical design48、自顶向下设计：top-down design49、自底向上设计：bottom-up design50、线网：net51、数字化：digitzing52、设计规则检查：design rule checking53、走（布）线器：router (cad)54、网络表：net list55、计算机辅助电路分析：computer-aided circuit analysis56、子线网：subnet57、目标函数：objective function58、设计后处理：post design processing (pdp)59、交互式制图设计：interactive drawing design60、费用矩阵：cost metrix61、工程图：engineering drawing62、方块框图：block diagram63、迷宫：moze64、元件密度：component density65、巡回售货员问题：traveling salesman problem66、自由度：degrees freedom67、入度：out going degree68、出度：incoming degree69、曼哈顿距离：manhatton distance70、欧几里德距离：euclidean distance71、网络：network72、阵列：array73、段：segment74、逻辑：logic75、逻辑设计自动化：logic design automation76、分线：separated time77、分层：separated layer78、定顺序：definite sequencePCB线路形状与尺寸词汇中英文对照：1、导线（通道）：conduction (track)2、导线（体）宽度：conductor width3、导线距离：conductor spacing4、导线层：conductor layer5、导线宽度/间距：conductor line/space6、第一导线层：conductor layer no.17、圆形盘：round pad8、方形盘：square pad9、菱形盘：diamond pad10、长方形焊盘：oblong pad11、子弹形盘：bullet pad12、泪滴盘：teardrop pad13、雪人盘：snowman pad14、 v形盘：v-shaped pad15、环形盘：annular pad16、非圆形盘：non-circular pad17、隔离盘：isolation pad18、非功能连接盘：monfunctional pad19、偏置连接盘：offset land20、腹（背）裸盘：back-bard land21、盘址：anchoring spaur22、连接盘图形：land pattern23、连接盘网格阵列：land grid array24、孔环：annular ring25、元件孔：component hole26、安装孔：mounting hole27、支撑孔：supported hole28、非支撑孔：unsupported hole29、导通孔：via30、镀通孔：plated through hole (pth)31、余隙孔：access hole32、盲孔：blind via (hole)33、埋孔：buried via hole34、埋/盲孔：buried /blind via35、任意层内部导通孔：any layer inner via hole (alivh)36、全部钻孔：all drilled hole37、定位孔：toaling hole38、无连接盘孔：landless hole39、中间孔：interstitial hole40、无连接盘导通孔：landless via hole41、引导孔：pilot hole42、端接全隙孔：terminal clearomee hole43、准表面间镀覆孔：quasi-interfacing plated-through hole44、准尺寸孔：dimensioned hole45、在连接盘中导通孔：via-in-pad46、孔位：hole location47、孔密度：hole density48、孔图：hole pattern49、钻孔图：drill drawing50、装配图：assembly drawing51、印制板组装图：printed board assembly drawing52、参考基准：datum referance54、基准尺寸：reference dimension55、参考尺寸：reaerence dimension56、直接量定尺寸：direct dimensioning57、基准图：datum feature58、基准边：reference edge59、导线设计距离：design space of conductor60、导线设计宽度：design width of conductor61、中心距：center to center spacing62、线宽/间距：conductor width/space63、节距：pitch64、精细节距：fine pitch65、层：layer66、层间距：layer-to-layer spacing67、边距：edge spacing68、外形线：trim line69、截面积：crossection area70、真实值表测量：truth table test71、准确位置：true position tolerance72、精确位置：accuracy73、精确位置误差：cumulative tolerance74、精确度：accuracy75、累积误差：cumulative tolerance76、焊垫：footprint77、外层：external layer78、内层：internal layer79、接地层：ground plane80、接地层隔离：ground plane clearance81、电压层：voltage plane82、电源层隔离：voltage plane clearance83、电源层：power plane, bus plane84、导通网络：basic grid85、导通网格：track grid86、导通孔网格：via grid87、连通盘网格：pad (land) grid88、定位偏差：positional tolerance89、对准靶标：bornb sight90、梳状图形：comb pattern91、对准标记：register mark92、散热层：heat sink planePCB线路电气互连词汇中英文对照：1、表面间连接：interlayer connection2、层间连接：interlayer connection3、内层连接：innerlayer connection4、非功能表面连接：nonfunctional interfacial connection5、跨接线：jumper wire6、节（交）点：node7、附加线：haywire8、端接（点）：terminal9、连接线：terminated line10、端接：termination11、连接端：pad, land12、贯穿连接：through connection13、支线：stub14、印制插头：tab15、键槽：keying slot16、连接器：connector17、板边连接器：edge board connector18、连接器区：connector area19、直角板边连接器：right angle edge connector20、偏槽口：polarizing slot21、偏置端接区：offset terminal area22、接地：ground23、端接隔离（空环）：terminal clearance24、连通性：continuity25、连接器接触：connector contact26、接触面积：contact area27、接触间距：contact spacing28、接触电阻：contact resistance29、接触尺寸：contact size30、元件引腿（脚）：component lead31、元件插针：component pin32、最小电气间距：minimum electrical spacing33、导电性：conductivity34、边卡连接器：card-edge connector35、插卡连接器：card-insertion connector36、载流量：current-carrying capacity37、蹯径：path38、最短路径：shortest path39、关键路径：critical path40、倒角：miter41、串推：daisy chain42、斯坦纳树：steiner tree43、最小生成树：minimum spanning tree (MST)44、瓶颈宽度：necked width45、短叉长度：spur length46、短柱长度：stub length47、曼哈顿路径：manhattan path48、连接度（性）：connectivityPCB线路板其他相关中英文对照：1、主面：primary side2、辅面：secondary side3、支撑面：supporting plane4、信号：signal5、信号导线：signal conductor6、信号地线：signal ground7、信号速率：signal rate8、信号标准化：signal standardization9、信号层：signal layer10、寄生信号：spurious signal11、串扰：crosstalk12、电容：capacitance13、电容耦合：capacitive coupling14、电磁干扰：electromagnetic interference15、电磁屏蔽：electromangetic shielding16、噪音：noise17、电磁兼容性：electromagnetic compatbility18、特性阻抗：impedance19、阻抗匹配：impedance match20、电感：inductance21、延迟：delay22、微带线：microstrip23、带状线：stripline24、探测点：probe point25、开窗口：cross hatching26、跨距：span27、共面性（度）：coplanarity28、埋入电阻：buried resistance29、黄金板：golden board30、芯板：core board31、薄基芯：thin core32、非均衡传输线：unbalanced transmission line33、阀值：threshold34、极限值：threshold limit value(TLV)35、散热层：heat sink plane36、热隔离：heat sink plane37、导通孔堵塞：via filiing38、波动：surge39、卡板：card40、卡板盒/卡板柜：card cages/card racks41、薄型多层板：thin type multilayer board42、埋/盲孔多层板：43、模块：module44、单芯片模块：single chip module (SCM)45、多芯片模块：multichip module (MCM)46、多芯片模块层压基板：laminate substrate version of multichip modu le (MCM-L)47、多芯片模块陶瓷基数板：ceramic substrate version o fmultichip mod ule (MCM-C)48、多芯片模块薄膜基板：deposition thin film substrate version of mu ltilayer module (MCM-D)49、嵌入凸块互连技术：buried bump interconnection technology (B2 it)50、自动测试技术：automatic test equipment (ATE)51、芯板导通孔堵塞：core board viafilling52、对准标记：alignment mark53、基准标记：fiducial mark54、拐角标记：corner mark55、剪切标记：crop mark56、铣切标记：routing mark57、对位标记：registration mark58、缩减标记：reduvtion mark59、层间重合度：layer to layer registration60、狗骨结构：dog hone61、热设计：thermal design62、热阻：thermal resistance。
pcb行业英汉词典
一、综合词汇1、印制电路：printed circuit2、印制线路：printed wiring3、印制板：printed board4、印制板电路：printed circuit board (pcb)5、印制线路板：printed wiring board(pwb)6、印制元件：printed component7、印制接点：printed contact8、印制板装配：printed board assembly9、板：board10、单面印制板：single-sided printed board(ssb)11、双面印制板：double-sided printed board(dsb)12、多层印制板：mulitlayer printed board(mlb)13、多层印制电路板：mulitlayer printed circuit board14、多层印制线路板：mulitlayer prited wiring board15、刚性印制板：rigid printed board16、刚性单面印制板：rigid single-sided printed borad17、刚性双面印制板：rigid double-sided printed borad18、刚性多层印制板：rigid multilayer printed board19、挠性多层印制板：flexible multilayer printed board20、挠性印制板：flexible printed board21、挠性单面印制板：flexible single-sided printed board22、挠性双面印制板：flexible double-sided printed board23、挠性印制电路：flexible printed circuit (fpc)24、挠性印制线路：flexible printed wiring25、刚性印制板：flex-rigid printed board, rigid-flex printed board26、刚性双面印制板：flex-rigid double-sided printed board, rigid-flex double-sided printed27、刚性多层印制板：flex-rigid multilayer printed board, rigid-flex multilayer printed board28、齐平印制板：flush printed board29、金属芯印制板：metal core printed board30、金属基印制板：metal base printed board31、多重布线印制板：mulit-wiring printed board32、陶瓷印制板：ceramic substrate printed board33、导电胶印制板：electroconductive paste printed board34、模塑电路板：molded circuit board35、模压印制板：stamped printed wiring board36、顺序层压多层印制板：sequentially-laminated mulitlayer37、散线印制板：discrete wiring board38、微线印制板：micro wire board39、积层印制板：buile-up printed board40、积层多层印制板：build-up mulitlayer printed board (bum)41、积层挠印制板：build-up flexible printed board42、表面层合电路板：surface laminar circuit (slc)43、埋入凸块连印制板：b2it printed board44、多层膜基板：multi-layered film substrate(mfs)45、层间全内导通多层印制板：alivh multilayer printed board46、载芯片板：chip on board (cob)47、埋电阻板：buried resistance board48、母板：mother board49、子板：daughter board50、背板：backplane51、裸板：bare board52、键盘板夹心板：copper-invar-copper board53、动态挠性板：dynamic flex board54、静态挠性板：static flex board55、可断拼板：break-away planel56、电缆：cable57、挠性扁平电缆：flexible flat cable (ffc)58、薄膜开关：membrane switch59、混合电路：hybrid circuit60、厚膜：thick film61、厚膜电路：thick film circuit62、薄膜：thin film63、薄膜混合电路：thin film hybrid circuit64、互连：interconnection65、导线：conductor trace line66、齐平导线：flush conductor67、传输线：transmission line68、跨交：crossover69、板边插头：edge-board contact70、增强板：stiffener71、基底：substrate72、基板面：real estate73、导线面：conductor side74、元件面：component side75、焊接面：solder side76、印制：printing77、网格：grid78、图形：pattern79、导电图形：conductive pattern80、非导电图形：non-conductive pattern81、字符：legend82、标志：mark二、基材：1、基材：base material2、层压板：laminate3、覆金属箔基材：metal-clad bade material4、覆铜箔层压板：copper-clad laminate (ccl)5、单面覆铜箔层压板：single-sided copper-clad laminate6、双面覆铜箔层压板：double-sided copper-clad laminate7、复合层压板：composite laminate8、薄层压板：thin laminate9、金属芯覆铜箔层压板：metal core copper-clad laminate10、金属基覆铜层压板：metal base copper-clad laminate11、挠性覆铜箔绝缘薄膜：flexible copper-clad dielectric film12、基体材料：basis material13、预浸材料：prepreg14、粘结片：bonding sheet15、预浸粘结片：preimpregnated bonding sheer16、环氧玻璃基板：epoxy glass substrate17、加成法用层压板：laminate for additive process18、预制内层覆箔板：mass lamination panel19、内层芯板：core material20、催化板材：catalyzed board ,coated catalyzed laminate21、涂胶催化层压板：adhesive-coated catalyzed laminate22、涂胶无催层压板：adhesive-coated uncatalyzed laminate23、粘结层：bonding layer24、粘结膜：film adhesive25、涂胶粘剂绝缘薄膜：adhesive coated dielectric film26、无支撑胶粘剂膜：unsupported adhesive film27、覆盖层：cover layer (cover lay)28、增强板材：stiffener material29、铜箔面：copper-clad surface30、去铜箔面：foil removal surface31、层压板面：unclad laminate surface32、基膜面：base film surface33、胶粘剂面：adhesive faec34、原始光洁面：plate finish35、粗面：matt finish36、纵向：length wise direction37、模向：cross wise direction38、剪切板：cut to size panel39、酚醛纸质覆铜箔板：phenolic cellulose paper copper-clad laminates(phenolic/paper ccl)40、环氧纸质覆铜箔板：epoxide cellulose paper copper-clad laminates (epoxy/paper ccl)41、环氧玻璃布基覆铜箔板：epoxide woven glass fabric copper-clad laminates42、环氧玻璃布纸复合覆铜箔板：epoxide cellulose paper core, glass cloth surfaces copper-cladlaminates43、环氧玻璃布玻璃纤维复合覆铜箔板：epoxide non woven/woven glass reinforced copper-cladlaminates44、聚酯玻璃布覆铜箔板：ployester woven glass fabric copper-clad laminates45、聚酰亚胺玻璃布覆铜箔板：polyimide woven glass fabric copper-clad laminates46、双马来酰亚胺三嗪环氧玻璃布覆铜箔板：bismaleimide/triazine/epoxide woven glass fabriccopper-clad lamimates47、环氧合成纤维布覆铜箔板：epoxide synthetic fiber fabric copper-clad laminates48、聚四乙烯玻璃纤维覆铜箔板：teflon/fiber glass copper-clad laminates49、超薄型层压板：ultra thin laminate50、陶瓷基覆铜箔板：ceramics base copper-clad laminates51、紫外线阻挡型覆铜箔板：uv blocking copper-clad laminates三、基材的材料1、a阶树脂：a-stage resin2、b阶树脂：b-stage resin3、c阶树脂：c-stage resin4、环氧树脂：epoxy resin5、酚醛树脂：phenolic resin6、聚酯树脂：polyester resin7、聚酰亚胺树脂：polyimide resin8、双马来酰亚胺三嗪树脂：bismaleimide-triazine resin9、丙烯酸树脂：acrylic resin10、三聚氰胺甲醛树脂：melamine formaldehyde resin11、多官能环氧树脂：polyfunctional epoxy resin12、溴化环氧树脂：brominated epoxy resin13、环氧酚醛：epoxy novolac14、氟树脂：fluroresin15、硅树脂：silicone resin16、硅烷：silane17、聚合物：polymer18、无定形聚合物：amorphous polymer19、结晶现象：crystalline polamer20、双晶现象：dimorphism21、共聚物：copolymer22、合成树脂：synthetic23、热固性树脂：thermosetting resin24、热塑性树脂：thermoplastic resin25、感光性树脂：photosensitive resin26、环氧当量：weight per epoxy equivalent (wpe)27、环氧值：epoxy value28、双氰胺：dicyandiamide29、粘结剂：binder30、胶粘剂：adesive31、固化剂：curing agent32、阻燃剂：flame retardant33、遮光剂：opaquer34、增塑剂：plasticizers35、不饱和聚酯：unsatuiated polyester36、聚酯薄膜：polyester37、聚酰亚胺薄膜：polyimide film (pi)38、聚四氟乙烯：polytetrafluoetylene (ptfe)39、聚全氟乙烯丙烯薄膜：perfluorinated ethylene-propylene copolymer film (fep)40、增强材料：reinforcing material41、玻璃纤维：glass fiber42、e玻璃纤维：e-glass fibre43、d玻璃纤维：d-glass fibre44、s玻璃纤维：s-glass fibre45、玻璃布：glass fabric46、非织布：non-woven fabric47、玻璃纤维垫：glass mats48、纱线：yarn49、单丝：filament50、绞股：strand51、纬纱：weft yarn52、经纱：warp yarn53、但尼尔：denier54、经向：warp-wise55、纬向：weft-wise, filling-wise56、织物经纬密度：thread count57、织物组织：weave structure58、平纹组织：plain structure59、坏布：grey fabric60、稀松织物：woven scrim61、弓纬：bow of weave62、断经：end missing63、缺纬：mis-picks64、纬斜：bias65、折痕：crease66、云织：waviness67、鱼眼：fish eye68、毛圈长：feather length69、厚薄段：mark70、裂缝：split71、捻度：twist of yarn72、浸润剂含量：size content73、浸润剂残留量：size residue74、处理剂含量：finish level75、浸润剂：size76、偶联剂：couplint agent77、处理织物：finished fabric78、聚酰胺纤维：polyarmide fiber79、聚酯纤维非织布：non-woven polyester fabric80、浸渍绝缘纵纸：impregnating insulation paper81、聚芳酰胺纤维纸：aromatic polyamide paper82、断裂长：breaking length83、吸水高度：height of capillary rise84、湿强度保留率：wet strength retention85、白度：whitenness86、陶瓷：ceramics87、导电箔：conductive foil88、铜箔：copper foil89、电解铜箔：electrodeposited copper foil (ed copper foil)90、压延铜箔：rolled copper foil91、退火铜箔：annealed copper foil92、压延退火铜箔：rolled annealed copper foil (ra copper foil)93、薄铜箔：thin copper foil94、涂胶铜箔：adhesive coated foil95、涂胶脂铜箔：resin coated copper foil (rcc)96、复合金属箔：composite metallic material97、载体箔：carrier foil98、殷瓦：invar99、箔（剖面）轮廓：foil profile100、光面：shiny side101、粗糙面：matte side102、处理面：treated side103、防锈处理：stain proofing104、双面处理铜箔：double treated foil四、设计1、原理图：shematic diagram2、逻辑图：logic diagram3、印制线路布设：printed wire layout4、布设总图：master drawing5、可制造性设计：design-for-manufacturability6、计算机辅助设计：computer-aided design.(cad)7、计算机辅助制造：computer-aided manufacturing.(cam)8、计算机集成制造：computer integrat manufacturing.(cim)9、计算机辅助工程：computer-aided engineering.(cae)10、计算机辅助测试：computer-aided test.(cat)11、电子设计自动化：electric design automation .(eda)12、工程设计自动化：engineering design automaton .(eda2)13、组装设计自动化：assembly aided architectural design. (aaad)14、计算机辅助制图：computer aided drawing15、计算机控制显示：computer controlled display .(ccd)16、布局：placement17、布线：routing18、布图设计：layout19、重布：rerouting20、模拟：simulation21、逻辑模拟：logic simulation22、电路模拟：circit simulation23、时序模拟：timing simulation24、模块化：modularization25、布线完成率：layout effeciency26、机器描述格式：machine descriptionm format .(mdf)27、机器描述格式数据库：mdf databse28、设计数据库：design database29、设计原点：design origin30、优化（设计）：optimization (design)31、供设计优化坐标轴：predominant axis32、表格原点：table origin33、镜像：mirroring34、驱动文件：drive file35、中间文件：intermediate file36、制造文件：manufacturing documentation37、队列支撑数据库：queue support database38、元件安置：component positioning39、图形显示：graphics dispaly40、比例因子：scaling factor41、扫描填充：scan filling42、矩形填充：rectangle filling43、填充域：region filling44、实体设计：physical design45、逻辑设计：logic design46、逻辑电路：logic circuit47、层次设计：hierarchical design48、自顶向下设计：top-down design49、自底向上设计：bottom-up design50、线网：net51、数字化：digitzing52、设计规则检查：design rule checking53、走（布）线器：router (cad)54、网络表：net list55、计算机辅助电路分析：computer-aided circuit analysis56、子线网：subnet57、目标函数：objective function58、设计后处理：post design processing (pdp)59、交互式制图设计：interactive drawing design60、费用矩阵：cost metrix61、工程图：engineering drawing62、方块框图：block diagram63、迷宫：moze64、元件密度：component density65、巡回售货员问题：traveling salesman problem66、自由度：degrees freedom67、入度：out going degree68、出度：incoming degree69、曼哈顿距离：manhatton distance70、欧几里德距离：euclidean distance71、网络：network72、阵列：array73、段：segment74、逻辑：logic75、逻辑设计自动化：logic design automation76、分线：separated time77、分层：separated layer78、定顺序：definite sequence五、形状与尺寸：1、导线（通道）：conduction (track)2、导线（体）宽度：conductor width3、导线距离：conductor spacing4、导线层：conductor layer5、导线宽度/间距：conductor line/space6、第一导线层：conductor layer no.17、圆形盘：round pad8、方形盘：square pad9、菱形盘：diamond pad10、长方形焊盘：oblong pad11、子弹形盘：bullet pad12、泪滴盘：teardrop pad13、雪人盘：snowman pad14、v形盘：v-shaped pad15、环形盘：annular pad16、非圆形盘：non-circular pad17、隔离盘：isolation pad18、非功能连接盘：monfunctional pad19、偏置连接盘：offset land20、腹（背）裸盘：back-bard land21、盘址：anchoring spaur22、连接盘图形：land pattern23、连接盘网格阵列：land grid array24、孔环：annular ring25、元件孔：component hole26、安装孔：mounting hole27、支撑孔：supported hole28、非支撑孔：unsupported hole29、导通孔：via30、镀通孔：plated through hole (pth)31、余隙孔：access hole32、盲孔：blind via (hole)33、埋孔：buried via hole34、埋/盲孔：buried /blind via35、任意层内部导通孔：any layer inner via hole (alivh)36、全部钻孔：all drilled hole37、定位孔：toaling hole38、无连接盘孔：landless hole39、中间孔：interstitial hole40、无连接盘导通孔：landless via hole41、引导孔：pilot hole42、端接全隙孔：terminal clearomee hole43、准表面间镀覆孔：quasi-interfacing plated-through hole44、准尺寸孔：dimensioned hole45、在连接盘中导通孔：via-in-pad46、孔位：hole location47、孔密度：hole density48、孔图：hole pattern49、钻孔图：drill drawing50、装配图：assembly drawing51、印制板组装图：printed board assembly drawing52、参考基准：datum referance【印制线路板术语中英对照简表】排序英语简称注解A Accelerate Aging加速老化使用人工的方法，加速正常的老化过程。
PCB常用专用名词英-汉对照
PCB常用专用名词英－汉对照一、综合词汇1、印制电路：printed circuit2、印制线路：printed wiring3、印制板：printed board4、印制板电路：printed circuit board (PCB)5、印制线路板：printed wiring board(PWB)6、印制元件：printed component7、印制接点：printed contact8、印制板装配：printed board assembly9、板：board10、单面印制板：single-sided printed board(SSB)11、双面印制板：double-sided printed board(DSB)12、多层印制板：mulitlayer printed board(MLB)13、多层印制电路板：mulitlayer printed circuit board14、多层印制线路板：mulitlayer prited wiring board15、刚性印制板：rigid printed board16、刚性单面印制板：rigid single-sided printed borad17、刚性双面印制板：rigid double-sided printed borad18、刚性多层印制板：rigid multilayer printed board19、挠性多层印制板：flexible multilayer printed board20、挠性印制板：flexible printed board21、挠性单面印制板：flexible single-sided printed board22、挠性双面印制板：flexible double-sided printed board23、挠性印制电路：flexible printed circuit (FPC)24、挠性印制线路：flexible printed wiring25、刚性印制板：flex-rigid printed board, rigid-flex printed board26、刚性双面印制板：flex-rigid double-sided printed board, rigid-flex double-sided printed27、刚性多层印制板：flex-rigid multilayer printed board, rigid-flex multilayer printed board28、齐平印制板：flush printed board29、金属芯印制板：metal core printed board30、金属基印制板：metal base printed board31、多重布线印制板：mulit-wiring printed board32、陶瓷印制板：ceramic substrate printed board33、导电胶印制板：electroconductive paste printed board34、模塑电路板：molded circuit board35、模压印制板：stamped printed wiring board36、顺序层压多层印制板：sequentially-laminated mulitlayer37、散线印制板：discrete wiring board38、微线印制板：micro wire board39、积层印制板：buile-up printed board40、积层多层印制板：build-up mulitlayer printed board (BUM)41、积层挠印制板：build-up flexible printed board42、表面层合电路板：surface laminar circuit (SLC)43、埋入凸块连印制板：B2it printed board44、多层膜基板：multi-layered film substrate(MFS)45、层间全内导通多层印制板：ALIVH multilayer printed board46、载芯片板：chip on board (COB)47、埋电阻板：buried resistance board48、母板：mother board49、子板：daughter board50、背板：backplane51、裸板：bare board52、键盘板夹心板：copper-invar-copper board53、动态挠性板：dynamic flex board54、静态挠性板：static flex board55、可断拼板：break-away planel56、电缆：cable57、挠性扁平电缆：flexible flat cable (FFC)58、薄膜开关：membrane switch59、混合电路：hybrid circuit60、厚膜：thick film61、厚膜电路：thick film circuit62、薄膜：thin film63、薄膜混合电路：thin film hybrid circuit64、互连：interconnection65、导线：conductor trace line66、齐平导线：flush conductor67、传输线：transmission line68、跨交：crossover69、板边插头：edge-board contact70、增强板：stiffener71、基底：substrate72、基板面：real estate73、导线面：conductor side74、元件面：component side75、焊接面：solder side76、印制：printing77、网格：grid78、图形：pattern79、导电图形：conductive pattern80、非导电图形：non-conductive pattern81、字符：legend82、标志：mark二、基材：1、基材：base material2、层压板：laminate3、覆金属箔基材：metal-clad bade material4、覆铜箔层压板：copper-clad laminate (CCL)5、单面覆铜箔层压板：single-sided copper-clad laminate6、双面覆铜箔层压板：double-sided copper-clad laminate7、复合层压板：composite laminate8、薄层压板：thin laminate9、金属芯覆铜箔层压板：metal core copper-clad laminate10、金属基覆铜层压板：metal base copper-clad laminate11、挠性覆铜箔绝缘薄膜：flexible copper-clad dielectric film12、基体材料：basis material13、预浸材料：prepreg14、粘结片：bonding sheet15、预浸粘结片：preimpregnated bonding sheer16、环氧玻璃基板：epoxy glass substrate17、加成法用层压板：laminate for additive process18、预制内层覆箔板：mass lamination panel19、内层芯板：core material20、催化板材：catalyzed board ,coated catalyzed laminate21、涂胶催化层压板：adhesive-coated catalyzed laminate22、涂胶无催层压板：adhesive-coated uncatalyzed laminate23、粘结层：bonding layer24、粘结膜：film adhesive25、涂胶粘剂绝缘薄膜：adhesive coated dielectric film26、无支撑胶粘剂膜：unsupported adhesive film27、覆盖层：cover layer (cover lay)28、增强板材：stiffener material29、铜箔面：copper-clad surface30、去铜箔面：foil removal surface31、层压板面：unclad laminate surface32、基膜面：base film surface33、胶粘剂面：adhesive faec34、原始光洁面：plate finish35、粗面：matt finish36、纵向：length wise direction37、模向：cross wise direction38、剪切板：cut to size panel39、酚醛纸质覆铜箔板：phenolic cellulose paper copper-clad laminates(phenolic/paper CCL)40、环氧纸质覆铜箔板：epoxide cellulose paper copper-clad laminates (epoxy/paper CCL)41、环氧玻璃布基覆铜箔板：epoxide woven glass fabric copper-clad laminates42、环氧玻璃布纸复合覆铜箔板：epoxide cellulose paper core, glass cloth surfaces copper-clad laminates43、环氧玻璃布玻璃纤维复合覆铜箔板：epoxide non woven/woven glass reinforcedcopper-clad laminates44、聚酯玻璃布覆铜箔板：ployester woven glass fabric copper-clad laminates45、聚酰亚胺玻璃布覆铜箔板：polyimide woven glass fabric copper-clad laminates46、双马来酰亚胺三嗪环氧玻璃布覆铜箔板：bismaleimide/triazine/epoxide woven glassfabric copper-clad lamimates47、环氧合成纤维布覆铜箔板：epoxide synthetic fiber fabric copper-clad laminates48、聚四乙烯玻璃纤维覆铜箔板：teflon/fiber glass copper-clad laminates49、超薄型层压板：ultra thin laminate50、陶瓷基覆铜箔板：ceramics base copper-clad laminates51、紫外线阻挡型覆铜箔板：UV blocking copper-clad laminates三、基材的材料1、A阶树脂：A-stage resin2、B阶树脂：B-stage resin3、C阶树脂：C-stage resin4、环氧树脂：epoxy resin5、酚醛树脂：phenolic resin6、聚酯树脂：polyester resin7、聚酰亚胺树脂：polyimide resin8、双马来酰亚胺三嗪树脂：bismaleimide-triazine resin9、丙烯酸树脂：acrylic resin10、三聚氰胺甲醛树脂：melamine formaldehyde resin11、多官能环氧树脂：polyfunctional epoxy resin12、溴化环氧树脂：brominated epoxy resin13、环氧酚醛：epoxy novolac14、氟树脂：fluroresin15、硅树脂：silicone resin16、硅烷：silane17、聚合物：polymer18、无定形聚合物：amorphous polymer19、结晶现象：crystalline polamer20、双晶现象：dimorphism21、共聚物：copolymer22、合成树脂：synthetic23、热固性树脂：thermosetting resin24、热塑性树脂：thermoplastic resin25、感光性树脂：photosensitive resin26、环氧当量：weight per epoxy equivalent (WPE)27、环氧值：epoxy value28、双氰胺：dicyandiamide29、粘结剂：binder30、胶粘剂：adesive31、固化剂：curing agent32、阻燃剂：flame retardant33、遮光剂：opaquer34、增塑剂：plasticizers35、不饱和聚酯：unsatuiated polyester36、聚酯薄膜：polyester37、聚酰亚胺薄膜：polyimide film (PI)38、聚四氟乙烯：polytetrafluoetylene (PTFE)39、聚全氟乙烯丙烯薄膜：perfluorinated ethylene-propylene copolymer film (FEP)40、增强材料：reinforcing material41、玻璃纤维：glass fiber42、E玻璃纤维：E-glass fibre43、D玻璃纤维：D-glass fibre44、S玻璃纤维：S-glass fibre45、玻璃布：glass fabric46、非织布：non-woven fabric47、玻璃纤维垫：glass mats48、纱线：yarn49、单丝：filament50、绞股：strand51、纬纱：weft yarn52、经纱：warp yarn53、但尼尔：denier54、经向：warp-wise55、纬向：weft-wise, filling-wise56、织物经纬密度：thread count57、织物组织：weave structure58、平纹组织：plain structure59、坏布：grey fabric60、稀松织物：woven scrim61、弓纬：bow of weave62、断经：end missing63、缺纬：mis-picks64、纬斜：bias65、折痕：crease66、云织：waviness67、鱼眼：fish eye68、毛圈长：feather length69、厚薄段：mark70、裂缝：split71、捻度：twist of yarn72、浸润剂含量：size content73、浸润剂残留量：size residue74、处理剂含量：finish level75、浸润剂：size76、偶联剂：couplint agent77、处理织物：finished fabric78、聚酰胺纤维：polyarmide fiber79、聚酯纤维非织布：non-woven polyester fabric80、浸渍绝缘纵纸：impregnating insulation paper81、聚芳酰胺纤维纸：aromatic polyamide paper82、断裂长：breaking length83、吸水高度：height of capillary rise84、湿强度保留率：wet strength retention85、白度：whitenness86、陶瓷：ceramics87、导电箔：conductive foil88、铜箔：copper foil89、电解铜箔：electrodeposited copper foil (ED copper foil)90、压延铜箔：rolled copper foil91、退火铜箔：annealed copper foil92、压延退火铜箔：rolled annealed copper foil (RA copper foil)93、薄铜箔：thin copper foil94、涂胶铜箔：adhesive coated foil95、涂胶脂铜箔：resin coated copper foil (RCC)96、复合金属箔：composite metallic material97、载体箔：carrier foil98、殷瓦：invar99、箔（剖面）轮廓：foil profile100、光面：shiny side101、粗糙面：matte side102、处理面：treated side103、防锈处理：stain proofing104、双面处理铜箔：double treated foil四、设计1、原理图：shematic diagram2、逻辑图：logic diagram3、印制线路布设：printed wire layout4、布设总图：master drawing5、可制造性设计：design-for-manufacturability6、计算机辅助设计：computer-aided design.(CAD)7、计算机辅助制造：computer-aided manufacturing.(CAM)8、计算机集成制造：computer integrat manufacturing.(CIM)9、计算机辅助工程：computer-aided engineering.(CAE)10、计算机辅助测试：computer-aided test.(CAT)11、电子设计自动化：electric design automation .(EDA)12、工程设计自动化：engineering design automaton .(EDA2)13、组装设计自动化：assembly aided architectural design. (AAAD)14、计算机辅助制图：computer aided drawing15、计算机控制显示：computer controlled display .(CCD)16、布局：placement17、布线：routing18、布图设计：layout19、重布：rerouting20、模拟：simulation21、逻辑模拟：logic simulation22、电路模拟：circit simulation23、时序模拟：timing simulation24、模块化：modularization25、布线完成率：layout effeciency26、机器描述格式：machine descriptionm format .(MDF)27、机器描述格式数据库：MDF databse28、设计数据库：design database29、设计原点：design origin30、优化（设计）：optimization (design)31、供设计优化坐标轴：predominant axis32、表格原点：table origin33、镜像：mirroring34、驱动文件：drive file35、中间文件：intermediate file36、制造文件：manufacturing documentation37、队列支撑数据库：queue support database38、元件安置：component positioning39、图形显示：graphics dispaly40、比例因子：scaling factor41、扫描填充：scan filling42、矩形填充：rectangle filling43、填充域：region filling44、实体设计：physical design45、逻辑设计：logic design46、逻辑电路：logic circuit47、层次设计：hierarchical design48、自顶向下设计：top-down design49、自底向上设计：bottom-up design50、线网：net51、数字化：digitzing52、设计规则检查：design rule checking53、走（布）线器：router (CAD)54、网络表：net list55、计算机辅助电路分析：computer-aided circuit analysis56、子线网：subnet57、目标函数：objective function58、设计后处理：post design processing (PDP)59、交互式制图设计：interactive drawing design60、费用矩阵：cost metrix61、工程图：engineering drawing62、方块框图：block diagram63、迷宫：moze64、元件密度：component density65、巡回售货员问题：traveling salesman problem66、自由度：degrees freedom67、入度：out going degree68、出度：incoming degree69、曼哈顿距离：manhatton distance70、欧几里德距离：euclidean distance71、网络：network72、阵列：array73、段：segment74、逻辑：logic75、逻辑设计自动化：logic design automation76、分线：separated time77、分层：separated layer78、定顺序：definite sequence五、形状与尺寸：1、导线（通道）：conduction (track)2、导线（体）宽度：conductor width3、导线距离：conductor spacing4、导线层：conductor layer5、导线宽度/间距：conductor line/space6、第一导线层：conductor layer No.17、圆形盘：round pad8、方形盘：square pad9、菱形盘：diamond pad10、长方形焊盘：oblong pad11、子弹形盘：bullet pad12、泪滴盘：teardrop pad13、雪人盘：snowman pad14、V形盘：V-shaped pad15、环形盘：annular pad16、非圆形盘：non-circular pad17、隔离盘：isolation pad18、非功能连接盘：monfunctional pad19、偏置连接盘：offset land20、腹（背）裸盘：back-bard land21、盘址：anchoring spaur22、连接盘图形：land pattern23、连接盘网格阵列：land grid array24、孔环：annular ring25、元件孔：component hole26、安装孔：mounting hole27、支撑孔：supported hole28、非支撑孔：unsupported hole29、导通孔：via30、镀通孔：plated through hole (PTH)31、余隙孔：access hole32、盲孔：blind via (hole)33、埋孔：buried via hole34、埋/盲孔：buried /blind via35、任意层内部导通孔：any layer inner via hole (ALIVH)36、全部钻孔：all drilled hole37、定位孔：toaling hole38、无连接盘孔：landless hole39、中间孔：interstitial hole40、无连接盘导通孔：landless via hole41、引导孔：pilot hole42、端接全隙孔：terminal clearomee hole43、准表面间镀覆孔：quasi-interfacing plated-through hole44、准尺寸孔：dimensioned hole45、在连接盘中导通孔：via-in-pad46、孔位：hole location47、孔密度：hole density48、孔图：hole pattern49、钻孔图：drill drawing50、装配图：assembly drawing51、印制板组装图：printed board assembly drawing52、参考基准：datum referan。
PCB专业英文单词
printed circuit 印制電路printed wiring 印制線路printed board 印制板printed circuit board 印制板電路printed wiring board 印制線路板printed component 印制元件printed contact 印制接點printed board assembly 印制板裝配board 板rigid printed board 剛性印制板flexible printed circuit 撓性印制電路flexible printed wiring 撓性印制線路flush printed board 齊平印制板metal core printed board 金屬芯印制板metal base printed board 金屬基印制板mulit-wiring printed board 多重布線印制板molded circuit board 模塑電路板discrete wiring board 散線印制板micro wire board 微線印制板buile-up printed board 積層印制板surface laminar circuit 表面層合電路板B2it printed board 埋入凸塊連印制板chip on board 載芯片板buried resistance board 埋電阻板mother board 母板daughter board 子板backplane 背板bare board 裸板copper-invar-copper board 鍵盤板夾心板dynamic flex board 動態撓性板static flex board 靜態撓性板break-away planel 可斷拼板cable 電纜flexible flat cable (FFC) 撓性扁平電纜membrane switch 薄膜開關hybrid circuit 混合電路thick film 厚膜thick film circuit 厚膜電路thin film 薄膜thin film hybrid circuit 薄膜混合電路interconnection 互連conductor trace line 導線flush conductor 齊平導線transmission line 傳輸線crossover 跨交edge-board contact 板邊插頭stiffener 增強板substrate 基底real estate 基板面conductor side 導線面component side 元件面solder side 焊接面printing 印制grid 網格pattern 圖形conductive pattern 導電圖形non-conductive pattern 非導電圖形legend 字符mark 標志base material 基材laminate 層壓板metal-clad bade material 覆金屬箔基材copper-clad laminate (CCL) 覆銅箔層壓板composite laminate 復合層壓板thin laminate 薄層壓板basis material 基體材料prepreg 預浸材料bonding sheet 粘結片preimpregnated bonding sheer 預浸粘結片epoxy glass substrate 環氧玻璃基板mass lamination panel 預制內層覆箔板core material 內層芯板bonding layer 粘結層film adhesive 粘結膜unsupported adhesive film 無支撐膠粘劑膜cover layer (cover lay) 覆蓋層stiffener material 增強板材copper-clad surface 銅箔面foil removal surface 去銅箔面unclad laminate surface 層壓板面base film surface 基膜面adhesive faec 膠粘劑面plate finish 原始光潔面matt finish 粗面length wise direction 縱向cross wise direction 模向cut to size panel 剪切板ultra thin laminate 超薄型層壓板A-stage resin A階樹脂B-stage resin B階樹脂C-stage resin C階樹脂epoxy resin 環氧樹脂phenolic resin 酚醛樹脂polyester resin 聚酯樹脂polyimide resin 聚亞胺樹脂bismaleimide-triazine resin 雙馬來亞胺三樹脂acrylic resin 丙烯酸樹脂melamine formaldehyde resin 三聚氰胺甲醛樹脂polyfunctional epoxy resin 多官能環氧樹脂brominated epoxy resin 溴化環氧樹脂epoxy novolac 環氧酚醛fluroresin 氟樹脂silicone resin 硅樹脂silane 硅烷polymer 聚合物amorphous polymer 無定形聚合物crystalline polamer 結晶現象dimorphism 雙晶現象copolymer 共聚物synthetic 合成樹脂thermosetting resin 熱固性樹脂thermoplastic resin 熱塑性樹脂photosensitive resin 感光性樹脂epoxy value 環氧值dicyandiamide 雙氰胺binder 粘結劑adesive 膠粘劑curing agent 固化劑flame retardant 阻燃劑opaquer 遮光劑plasticizers 增塑劑unsatuiated polyester 不飽和聚酯polyester 聚酯薄膜polyimide film (PI) 聚亞胺薄膜polytetrafluoetylene (PTFE) 聚四氟乙烯reinforcing material 增強材料glass fiber 玻璃纖維E-glass fibre E玻璃纖維D-glass fibre D玻璃纖維S-glass fibre S玻璃纖維glass fabric 玻璃布non-woven fabric 非織布glass mats 玻璃纖維墊yarn 紗線filament 單絲strand 絞股weft yarn 緯紗warp yarn 經紗denier 但尼爾warp-wise 經向thread count 織物經緯密度weave structure 織物組織plain structure 平紋組織grey fabric 壞布woven scrim 稀松織物bow of weave 弓緯end missing 斷經mis-picks 缺緯bias 緯斜crease 折痕waviness 雲織fish eye 魚眼feather length 毛圈長mark 厚薄段split 裂縫twist of yarn 捻度size content 浸潤劑含量size residue 浸潤劑殘留量finish level 處理劑含量size 浸潤劑couplint agent 偶聯劑finished fabric 處理織物polyarmide fiber 聚胺纖維aromatic polyamide paper 聚芳胺纖維紙breaking length 斷裂長height of capillary rise 吸水高度wet strength retention 溼強度保留率whitenness 白度ceramics 陶瓷conductive foil 導電箔copper foil 銅箔rolled copper foil 壓延銅箔annealed copper foil 退火銅箔thin copper foil 薄銅箔adhesive coated foil 涂膠銅箔resin coated copper foil 涂膠脂銅箔composite metallic material 復合金屬箔carrier foil 載體箔invar 殷瓦foil profile 箔（剖面）輪廓shiny side 光面matte side 粗糙面treated side 處理面stain proofing 防銹處理double treated foil 雙面處理銅箔shematic diagram 原理圖logic diagram 邏輯圖printed wire layout 印制線路布設master drawing 布設總圖computer aided drawing 計算機輔助制圖computer controlled display 計算機控制顯示placement 布局routing 布線layout 布圖設計rerouting 重布simulation 模擬logic simulation 邏輯模擬circit simulation 電路模擬timing simulation 時序模擬modularization 模塊化layout effeciency 布線完成率MDF databse 機器描述格式數據庫design database 設計數據庫design origin 設計原點optimization (design) 優化（設計）predominant axis 供設計優化坐標軸table origin 表格原點mirroring 鏡像drive file 驅動文件intermediate file 中間文件manufacturing documentation 制造文件queue support database 隊列支撐數據庫component positioning 元件安置graphics dispaly 圖形顯示scaling factor 比例因子scan filling 掃描填充rectangle filling 矩形填充region filling 填充域physical design 實體設計logic design 邏輯設計logic circuit 邏輯電路hierarchical design 層次設計top-down design 自頂向下設計bottom-up design 自底向上設計net 線網digitzing 數字化design rule checking 設計規則檢查router (CAD) 走（布）線器net list 網絡表subnet 子線網objective function 目標函數post design processing (PDP) 設計後處理interactive drawing design 交互式制圖設計cost metrix 費用矩陣engineering drawing 工程圖block diagram 方塊框圖moze 迷宮component density 元件密度traveling salesman problem 回售貨員問題degrees freedom 自由度out going degree 入度incoming degree 出度manhatton distance 曼哈頓距離euclidean distance 歐幾裏德距離network 網絡array 陣列segment 段logic 邏輯logic design automation 邏輯設計自動化separated time 分線separated layer 分層definite sequence 定順序conduction (track) 導線（通道）conductor width 導線（體）寬度conductor spacing 導線距離conductor layer 導線層conductor line/space 導線寬度/間距conductor layer No.1 第一導線層round pad 圓形盤square pad 方形盤diamond pad 菱形盤oblong pad 長方形焊盤bullet pad 子彈形盤teardrop pad 淚滴盤snowman pad 雪人盤V-shaped pad V形盤annular pad 環形盤non-circular pad 非圓形盤isolation pad 隔離盤monfunctional pad 非功能連接盤offset land 偏置連接盤back-bard land 腹（背）裸盤anchoring spaur 盤址land pattern 連接盤圖形land grid array 連接盤網格陣列annular ring 孔環component hole 元件孔mounting hole 安裝孔supported hole 支撐孔unsupported hole 非支撐孔via 導通孔plated through hole (PTH) 鍍通孔access hole 餘隙孔blind via (hole) 盲孔buried via hole 埋孔buried blind via 埋,盲孔any layer inner via hole 任意層內部導通孔all drilled hole 全部鑽孔toaling hole 定位孔landless hole 無連接盤孔interstitial hole 中間孔landless via hole 無連接盤導通孔pilot hole 引導孔terminal clearomee hole 端接全隙孔dimensioned hole 準尺寸孔via-in-pad 在連接盤中導通孔hole location 孔位hole density 孔密度hole pattern 孔圖drill drawing 鑽孔圖assembly drawing 裝配圖datum referan 參考基準。
PCB英文术语及释义
一．MATERIAL TERM1.A-stage A 階段—指膠片(prepreg)製造過程中,其補強材料的玻織布或棉紙,在通過膠水槽進行含浸工程時,該樹脂之膠水(Varnish,也譯為清漆水),尚處於單體且被溶劑稀釋的狀態,稱為A-stage,相對的當玻織布或棉紙吸入膠水,又經熱風及紅外線乾燥後,將使樹脂分子量增大為複體或寡聚物(Oligomer),再集附於補強材上形成膠片.此時的樹脂狀態稱為B-Stage.當再繼續加熱軟化,並進一步聚合成為最後高分子樹脂時,則稱為C-Stage.2.B-Stage,B階段—指熱固型樹脂的聚合半硬化狀態,如經A-Stage的環氧樹脂含浸工程後,在膠片玻織布上所附著的樹脂,尚可再加溫而軟化者即屬此類.3.Basematerial基材—指板材的樹脂及補強材料部份,可當做為銅線路與導體的載體及絕緣材料.4.CEM-1,CEM-3(composited epoxy material)环氧树脂複合板材指基板底材是由玻織布及玻織席(零散短織)所共同組成的,所用的樹脂仍為環氧樹脂,此種板材的兩面外層,仍使用玻織布所含浸的膠片(Prepreg)與銅箔壓合,內部則用短織席材含浸樹脂而成WEB(網片),若其”席材”纖維仍為玻纖時,其板材稱為CEM-3(Composite Epoxy Material)L;若席材為紙纖時,則稱之為CEM-1.此為美國NEMA規範LI 1-1989中所記載.5.COPPER FOIL 銅箔,銅皮—是CCL銅箔基板外表所壓複的金屬銅層.PCB工業所需的銅箔可由電鍍方式(Electrodeposited),或以輾壓方式(Rolled)所取得,前者可用在一般硬質電路板,後者則可用於軟板上.6.Dry Film幹膜—是一種做為電路板影像轉移用的幹性感光薄膜阻劑,另有PE及PET兩層皮膜將之夾心保護,現聲施工時可將PE的隔離層撕掉,讓中間的感光阻劑膜壓貼在板子的銅面上.在經過底片感光後即可再撕掉PET的表護膜,進行沖洗顯像而形成線路圖形的局部阻劑.進而可再執行蝕刻(內層)或電鍍(外層)制程,最後在蝕銅及剝膜後,即得到有裸線路的板面.7.Epoxy Resin環氧樹脂—是一種用途極廣的熱固型(Thermosetting)高分子聚合物,一般可做為成型,封裝,塗裝,粘著等用途.在電路板業中,更是耗量最大的絕緣及粘結用途的樹脂,可與玻纖布,玻纖席,及白牛皮紙等複合成為板材.且可容納各種添加助劑,以達到難燃及高功能的目的,做為各級電路板材的基料.8.Film 底片—指已有線路圖形的膠捲而言,通常厚度有7MIL及4mil兩種,其感光的藥膜有黑,白的鹵化銀,及棕色或其他顏色的偶氮化合物.此詞亦稱為Artwork.9.Flame Resistant耐燃性—指電路板在其絕緣性板材的樹脂中,為了要达到某種燃性等級(在UL94中共分HB.VO,V1及V2等四級),必須在樹脂中刻意加入某些化學品,如溴,矽,氧化鋁等(如FR-4中即加入20%以上的溴),使板材之性能可達到一定的耐燃性.10.Flammability Rate燃性等級—指電路板板材之耐燃性或難燃性的程度.在按即定的試驗步驟(如UL-94或NEMA的LE1-1988中的7.11所明定者)執行樣板試驗之後,其板材所能達到的何種規定等級而言.11.Flexible Printed Circuit,FPC軟板—是一種特殊的電路板,在下游組裝時可做三度空間的外形變化,其底材為可撓性的聚亞醯胺(PI)或聚酯類(PE).這種軟板也像硬板一樣,可製作鍍通孔或表面焊墊.以進行通孔插裝或表面粘裝.板面還可貼附軟性具保護及防焊用途的保護層(COVER LAYER),或加印軟性的防焊綠漆.12.Flurocarbon Resin碳氟樹脂—是一系列有機含氟的熱塑型高分子聚合物,可用於電子工業的主要產品有FEP(Fluorinated Ethylene Propylend,氟化乙烯丙烯)及PTFE(Polytetrafluoroethylene,聚四氟乙烯)等兩種塑膠材料.13.Flux助焊劑—是一種在高溫下,具有活性的化學品,能將板子表面的氧化物或汙化物予以清除,使熔融的焊錫能與潔淨的底金屬結合而完成焊接.Flux原來的希腊文是Flow(流動)意思.早期是在礦石進行冶金當成”助焊劑”,促使熔點降低而達到容易流動的目的.14.Glass Transition Temperature, Tg玻璃態轉化溫度—聚合物會因溫度的升高而造成其物性的變化.當其在常溫時是一種結晶無定形態(Amorphous)脆硬的玻璃狀物質.到達高溫時將轉變成為一種如同橡皮狀的彈性體(Elastomer),這種由”玻璃態”明顯轉變成”橡皮態”的狹窄溫度區域稱為”玻璃态轉化溫度”,簡稱為Tg但應讀成”Ts OF g”,以示其轉變的溫度並非只在某一溫度點上.15.Photograhpic Film 感光成像之底片---是指電路板上線路圖案的原始載體,也就是俗稱的底片”(Art Work).常用的有Mylar 式膠捲及玻璃板之硬片。
