┊┊┊┊┊┊┊┊┊┊┊┊┊装┊┊┊┊┊订┊┊┊┊┊线┊┊┊┊┊┊┊┊┊┊┊┊┊2011年第三届国际测量技术和机电自动化会议嵌入式智能控制汽车倒车雷达报警系统台湾彰化路500号，建国科技大学，自动化工程系台湾台中市408号，岭东科技大学，技术产品设计系台湾彰化路500号，建国科技大学，机械工程系schwang@.twtfc@.twtfmau@.tw摘要: 大多数驾驶者在汽车挂入倒档时都会用到倒车雷达或者倒车影像去观察汽车后面的路况。
事实上，所有行人只能通过明显的倒车示位灯知道汽车是否在倒车。
而且当汽车倒车示位灯改变不够明显时，最终就导致它们对于行人的报警系统看起来依然不够充足。
因此上此项研究尝试设计一种嵌入式智能倒车报警系统，此系统并且能够提高行人和道路上其他驾驶者的安全性。
这种嵌入式系统用到了微软公司Win CE 运行系统并且适合于正在发展的迷你2440公司。
它的智能触屏工作模式的开发用了2005版的可视化开发环境。
迷你2440公司上的该系统的通用异步收发器界面接口通过单片机PIC16F877控制着变频器，阻容服务器和LED显示器之间传感器信号的转换。
然后连接各引脚，光度和距离的传感器通过用27模糊逻辑法则进行的模糊逻辑过滤可以读取传感器电压值并把其转换成实值。
LED倒车灯架角度可通过这种逻辑过滤的结果自动调节。
此项研究试图对相当于一辆真车的同一高度的运动的架子做模拟测试。
让测试运动框架位于离障碍物240cm远的位置，然后开启驱动马达并把频率调到60Hz.(也就是说马达速度接近于2.52Km/h)让运动的测试框架停在障碍物之前40cm 的位置。
我们发现报警灯灯架安装角度会随着测试框架和障碍物之间距离的改变而不断改变，并且自动的从90度下降到0度。
从测试结果可明显证明此系统可以真实的达到自动控制的汽车后备报警功能，关键词：嵌入式控制，汽车倒车，报警系统一.说明目前市场上用于汽车的后备报警系统有好几种，有倒车雷达，倒车影像，还有倒车语音报警系统等。
